SureCall MIMO SC-650CBM Quick Start Manual

C-Band MIMO Outdoor Panel Antenna (SC-650CBM)
Directional Panel Antenna
Overview
The SureCall C-band panel antenna is a directional outdoor antenna designed to capture outdoor
signal when aimed in the direction of best signal.
This MIMO antenna transmits and receives 3500-4000 MHz frequencies.
4.3-10 Female connector (50 Ω)
»
» 19 dBi Max gain
» C-band: 3500 - 4000 MHz
» Includes mounting hardware
» Directional antenna needs to be pointed towards
nearest tower
Specifications
Frequency
Max gain
Polarization type
Horizontal beamwidth
Vertical beamwidth
Front-to-back ratio@180±30°
Cross-polarization ratio over HPBW
Isolation
Input impedance
VSWR
Max power
Connector type
Mount type
Dimensions
Weight
Radome material
Ingress protection
Mechanical tilt
Rated wind velocity
Operating temp.
© 2024 SureCall, Inc. v1.4
3500-4000 MHz
19 dBi
Vertical and Horizontal
15°
15°
≥25dB
≥15
≥20 dB
50 Ω
≤ 2
50W
4.3-10 Female
Pole or Mast with 1.2-2 in diameter
15 x 15 x 1.3 in
4.1 lbs (Antenna) / 1.33 lbs (Bracket)
UV+ABS
IP66
-15° /+15°
55 m/s
-40°F to +140°F
