  • Page 1 BullSequana EXD Installation Guide 86 A1 99FS 03 September 2024...
  • Page 2 30 bis rue du Nid de Pie 49000 Angers FRANCE The information in this document is subject to change without notice. Eviden will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material...

  • Page 3: Table Of Contents

    Table of Contents Preface Intended readers Important user information Chapter 1. Unpacking the delivery 1.1. General recommendations 1.2. Inspecting packaging 1.3. Checking the delivery 1.4. Checking labels 1.4.1. Identification label 1.4.2. MAC address label 1.4.3. Fan labels 1.4.4. Processor label Chapter 2.
  • Page 4 Installation Guide...

  • Page 5: Preface

    Preface This guide explains how to install the server for the first time. The Bull support web site for the most up­ t o­ d ate product information, documentation, firmware updates, software fixes and service offers: https://support.bull.com Intended readers This guide is intended for use by instructed or skilled personnel in charge of installing the server.
  • Page 6 Installation Guide...

  • Page 7: Chapter 1. Unpacking The Delivery

    Chapter 1. Unpacking the delivery Important ATTENTION: Please read carefully the safety instructions before you perform the procedures described in this manual. See the Multilingual Safety Notices Guide for translated versions of the safety notices. 1.1. General recommendations WARNING W020 The server drawer must not be unpacked before it has reached the room temperature (24 hours in the computer room).

  • Page 8: Inspecting Packaging

    1.2. Inspecting packaging Before unpacking, check the indicators on the shockwatch and tiltwatch labels, stuck on the packaging. If one of the labels is red, make a note on the delivery slip and check packaging contents. Label Description Shockwatch label Transport label Tiltwatch label Installation Guide...

  • Page 9: Checking The Delivery

    1.3. Checking the delivery According to the configuration, the following items are included. ■ Antennas ■ Screws and washers ■ Kit for installation ■ The BullSequana EXD server Chapter 1.   Unpacking the delivery...

  • Page 10: Checking Labels

    1.4. Checking labels Safety warning labels, including safety notices and graphic symbols, are present on the server. Check that the electrical installation complies with the label details. 1.4.1. Identification label Description Installation Guide...
  • Page 11 (1) this device may not cause harmful interference and (2) this device must accept any interference received including interference that may cause undesired operation. Model name Model name Commercial name Serial number BullSequana EXD 2U server with 1300W BSEXD1 XAN-ORD-xxxxx power supply Chapter 1.   Unpacking the delivery...

  • Page 12: Mac Address Label

    1.4.2. MAC address label Important It is recommended to write down the MAC address in case the label is lost. The label is on the motherboard, next to the memory modules. Installation Guide...

  • Page 13: Fan Labels

    1.4.3. Fan labels The labels are on the fans, inside the server. Chapter 1.   Unpacking the delivery...

  • Page 14: Processor Label

    1.4.4. Processor label The label is on top of the processor assembly. Mark Description Torque value Warning symbol Locking symbols Locking instructions Installation Guide...

  • Page 15: Chapter 2. Installing The Server

    Chapter 2. Installing the server CAUTION C050 The device must be installed in a location where the transmitting antenna is at least 20 cm from any people in order to comply with radio frequency exposure regulatory requirements. WARNING W079 Devices and antennas must not be operated with other antennas or transmitters.

  • Page 16: Installing The Antennas

    2.1. Installing the antennas Required tools ■ Cross-headed screwdriver ■ T10 Torx screwdriver ■ T8 Torx screwdriver 2.1.1. Preparing the installation Procedure 1. Locate the position of each antenna Rear view Configuration 1 Configuration 2 Configuration 3 Configuration 4 2 antennas 3 antennas 3 antennas 4 antennas...
  • Page 17 2. Remove the top cover 1. Loosen the captive screw to unlock the cover latch. Top view 2. Push the button (A) to release the latch. The upper part (B) rises up. Chapter 2.   Installing the server...
  • Page 18 3. Slide the cover back slightly and lift it up. Installation Guide...

  • Page 19: Installing The Bottom Antennas

    2.1.2. Installing the bottom antennas Procedure 1. Remove the air duct 1. Remove the screws to unlock the air duct. 2. Remove the air duct. Front view Chapter 2.   Installing the server...
  • Page 20 2. Remove the M.2 NVMe disk tray 1. Rotate the plungers of the tray downwards. 2. Lift the tray up. Installation Guide...
  • Page 21 3. Remove the dummy bracket from each position where an antenna is to be installed Remove the screws to detach the dummy bracket. Rear view 4. Install each antenna cable 1. Remove the connector from the antenna. Chapter 2.   Installing the server...
  • Page 22 2. Remove the nut and the washer from the connector. 3. Insert the connector into the cutout from inside the server. Installation Guide...
  • Page 23 4. Install the washer and the nut onto the connector. 5. Connect the other end of the cable to the adequate card. 5. Install the M.2 NVMe disk tray 1. Install the tray onto the support brackets. Chapter 2.   Installing the server...
  • Page 24 2. Rotate the plungers upwards to lock the tray. 6. Install the air duct 1. Install the air duct. 2. Tighten the screws to lock the air duct into place. Front view 2-10 Installation Guide...

  • Page 25: Installing The Top Antennas

    2.1.3. Installing the top antennas Procedure 1. Remove the dummy bracket from each position where an antenna is to be installed Remove the screws to detach the dummy bracket. Rear view 2. Install each antenna cable 1. Remove the connector from the antenna. Chapter 2.
  • Page 26 2. Remove the nut and the washer from the connector. 3. Insert the connector into the cutout from inside the server. 2-12 Installation Guide...
  • Page 27 4. Install the washer and the nut onto the connector. 5. Connect the other end of the cable to the adequate card. Chapter 2.   Installing the server 2-13...

  • Page 28: Completing The Installation

    2.1.4. Completing the installation Procedure 1. Install the top cover 1. Position the cover on the server and slide it forward until it is in place. 2. Lower the upper part of the cover latch. Top view 3. Tighten the captive screw to lock the cover latch. 2-14 Installation Guide...
  • Page 29 2. Turn each antenna to fix it into place Rear view Chapter 2.   Installing the server 2-15...

  • Page 30: Installing The Server On A Flat Surface

    2.2. Installing the server on a flat surface Stick on the adhesive bumps under the server and install it on the flat surface. 2-16 Installation Guide...

  • Page 31: Installing The Server On A Din Rail

    2.3. Installing the server on a DIN rail Required tools ■ T20 Torx screwdriver ■ Phillips screwdriver ■ Screws, washers and nuts Appendix A. Screws, washers and nuts Procedure 1. Assemble the DIN rail kit with screws S6, washers W2 and nuts N2. Chapter 2.
  • Page 32 2. Assemble the DIN rail and the server. Tighten the screws S8. 2-18 Installation Guide...
  • Page 33 3. Turn the BullSequana EXD server to the upright position. 4. Attach the server to the DIN rail by carefully tilting it. Chapter 2.   Installing the server 2-19...

  • Page 34: Installing The Server On A Vesa Holder

    2.4. Installing the server on a VESA holder WARNING W088 To secure the server safely to the wall the correct type of screw anchor must be used. The screw anchors should be designed for the wall construction material (wood, concrete, etc.) and capable of bearing a weight of up to 30 kg. Required tools ■...
  • Page 35 2. Install the wall plate on a wall Case of solid wall 1. Drill two holes in the wall. 2. Fix the wall plate using screw anchors and lag bolts. Case of wooden wall 1. Drill two holes in the wall. 2.
  • Page 36 3. Install the monitor plate on the server Tighten the screws S7 with washers W3. 4. Install the server on the wall 1. Slide the monitor plate downwards into the wall plate (A). 2. Tighten the screw (B) to secure the server in place. 2-22 Installation Guide...

  • Page 37: Installing The Server In A Rack Cabinet

    2.5. Installing the server in a rack cabinet 2.5.1. Preparing the rail assemblies Required tools ■ PH1 cross-headed screwdriver ■ PH2 cross-headed screwdriver ■ 3 mm flat screwdriver ■ T10 Torx screwdriver ■ Two slide rails ■ Two rear brackets ■...
  • Page 38 2. Stick the Mylar sheets on each side of the server. 2. Unpack the slide rails 2-24 Installation Guide...
  • Page 39 3. Remove the inner rails For each slide rail, perform the following operations: 1. Pull the inner rail (C) out until it clicks. 2. Push the release latch in. Mark Description Outer rail Middle rail Inner rail 3. Remove the inner rail completely. Chapter 2.
  • Page 40 4. Intall the inner rails onto the server 1. Ensure that the inner rail protruding edge is at the front of the server. Top view 2. Tighten the screws. 2-26 Installation Guide...
  • Page 41 5. Install a front bracket onto each outer rail 1. Pull the middle rail (A) out until it clicks. 2. Check that the outer rail (B) mount holes underneath are exposed. Chapter 2.   Installing the server 2-27...
  • Page 42 3. Attach the front bracket to the outer rail. Mark Description Middle rail Outer rail Rear edge 2-28 Installation Guide...
  • Page 43 6. Install a rear bracket onto each outer rail 1. Place a rear bracket onto the outer rail. 2. Adjust the rear bracket position on the outer rail to match the rack cabinet depth. According to the rack cabinet depth the number of rear bracket mount holes (A) used varies from three to six.
  • Page 44 Front view 900 mm deep rack cabinet Rear view 2-30 Installation Guide...
  • Page 45 Front view 3. Partially tighten the screws to secure the rear brackets into place. 4. Check that the distance between edge of the rear bracket and the edge of the front bracket matches the rack depth. Chapter 2.   Installing the server 2-31...
  • Page 46 7. Insert a guide pin into the front and rear brackets of the rail assembly The rail assembly consists of the middle rail and the outer rail with the front bracket and the rear bracket attached. Mark Description Middle rail Front bracket Outer rail Rear bracket...
  • Page 47 8. Push the middle rail back to its original position 1. Lift the middle rail release latch (A) up. 2. Push the middle rail (B) in until it clicks back into place. Chapter 2.   Installing the server 2-33...

  • Page 48: Installing The Server Into The Rack Cabinet

    2.5.2. Installing the server into the rack cabinet CAUTION C045 Two people are required to perform this operation. Required tools T25 Torx screwdriver Appendix A. Screws, washers and nuts Procedure 1. Install the rail assemblies into the rack cabinet For each rail assemblies, perform the following operations: 1.
  • Page 49 3. Position the rail assembly using the guide pins at each end. 4. Secure the rail assembly into place. 5. Tighten the rear bracket nuts. Chapter 2.   Installing the server 2-35...
  • Page 50 6. Pull the middle rails out. 2. Install the server into the rack cabinet 1. Using the inner rails attached to the server, slide the server into the middle rails. 2-36 Installation Guide...
  • Page 51 2. When the rail assemblies click, push the release latch (A) on each side to allow the server to be pushed completely into the rack. 3. Tighten the captive screws to secure the server into place. Chapter 2.   Installing the server 2-37...
  • Page 52 2-38 Installation Guide...

  • Page 53: Appendix A. Screws, Washers And Nuts

    Appendix A. Screws, washers and nuts This appendix lists all the screws, washers and nuts included in the delivery. Screws Mark Head Body Diameter Length Description 3 mm 4 mm M3x4 Flat-headed screw 3.5 mm 12 mm Flat-head philip #6-32 screw 3 mm 6.5 mm M3x6.5 standard screw...
  • Page 54 Washers Mark Head Body Diameter Description 5 mm M5 Spring Lock Washer OD11 6 mm M6 Toothed Lock Washer 4 mm M4 conical spring lock washer Nuts Mark Head Body Diameter Description 3.5 mm Hex serrated flange locknut #6-32 6 mm Hex nut #6 Installation Guide...
