BullSequana EXR
Installation Guide
86 A1 76FS 02
April 2024
-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BullSequana EXR and is the answer not in the manual?

Questions and answers

Summary of Contents for EVIDEN BullSequana EXR

  • Page 1 BullSequana EXR Installation Guide 86 A1 76FS 02 April 2024...
  • Page 2 30 bis rue du Nid de Pie 49000 Angers FRANCE The information in this document is subject to change without notice. Eviden will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material...
  • Page 3: Table Of Contents

    Table of Contents Table of Contents Preface Intended Readers Chapter 1. Checking the delivery contents 1.1. Unpacking the server 1.2. Checking labels 1.2.1. Identification label 1.2.2. MAC address label 1.2.3. Fan hazard safety label 1.2.4. Processor label Chapter 2. Installing the server 2.1.
  • Page 4 Installation Guide...
  • Page 5: Preface

    Preface This guide explains how to install the server for the first time. The Bull support web site for the most up­ t o­ d ate product information, documentation, firmware updates, software fixes and service offers: https://support.bull.com Intended Readers This guide is intended for use by instructed or skilled personnel in charge of installing the server.
  • Page 6 Installation Guide...
  • Page 7: Chapter 1. Checking The Delivery Contents

    (24 hours in the computer room). According to the configuration, the following items are included. ■ Antennas ■ Screws and washers ■ Slide rails, front brackets and rear brackets ■ The BullSequana EXR server Chapter 1.   Checking the delivery contents...
  • Page 8: Checking Labels

    1.2. Checking labels Safety warning labels, including safety notices and graphic symbols, are present on the server. Check that the electrical installation complies with the label details. 1.2.1. Identification label Description Installation Guide...
  • Page 9 (2) this device must accept any interference received including interference that may cause undesired operation. Model names Model name Commercial name Serial number BullSequana EXR 1U server with 1200W BSEXR1 XAN-ORH-xxxxx power supply and M.2 internal storage BullSequana EXR 1U server with 1200W BSEXR2...
  • Page 10: Mac Address Label

    1.2.2. MAC address label Important It is recommended to write down the MAC address in case the label is lost. The label (A) is underneath the processor block. If necessary, remove the cover to check the label. Installation Guide...
  • Page 11: Fan Hazard Safety Label

    1.2.3. Fan hazard safety label The labels are on the fans, inside the server. Chapter 1.   Checking the delivery contents...
  • Page 12: Processor Label

    1.2.4. Processor label The label is on top of the processor assembly. Mark Description Torque value Warning symbol Locking symbols Locking instructions Installation Guide...
  • Page 13: Chapter 2. Installing The Server

    Chapter 2. Installing the server CAUTION C050 The device must be installed in a location where the transmitting antenna is at least 20 cm from any people in order to comply with radio frequency exposure regulatory requirements. WARNING W079 Devices and antennas must not be operated with other antennas or transmitters.
  • Page 14: Installing The Antennas

    2.1. Installing the antennas Required tools None Procedure 1. Locate the position for the antennas Rear view Configuration 1 Configuration 2 Configuration 3 2 antennas 3 antennas 3 antennas ■ Dual-band Dual-band 2.4-5.9 GHz WIFI LTE/5G 2.4-5.9 GHz WIFI ■ LoRa ■...
  • Page 15: Preparing The Rail Assemblies

    2.2. Preparing the rail assemblies Required tools ■ PH1 cross-headed screwdriver ■ PH2 cross-headed screwdriver ■ 3 mm slot screwdriver ■ Two slide rails ■ Two rear brackets ■ Two front brackets ■ Screws, washers and nuts Appendix: Screws, washers and nuts Procedure 1.
  • Page 16 2. Remove the inner rails For each slide rail: 1. Pull the inner rail (C) out until it clicks. 2. Push the release latch in. Mark Description Outer rail Middle rail Inner rail 3. Remove the inner rail (C) completely. Installation Guide...
  • Page 17 3. Attach the inner rails to the server Ensure that the inner rail protruding edge is at the front of the server. Chapter 2.   Installing the server...
  • Page 18 4. Attach a front bracket to each outer rail 1. Pull the middle rail (A) out until it clicks. 2. Check that the outer rail (B) mount holes underneath are exposed. Installation Guide...
  • Page 19 3. Attach the front bracket to the outer rail. Mark Description Middle rail Outer rail Rear edge 5. Note the depth of the rack cabinet This will be between 600 and 900 millimeters. Chapter 2.   Installing the server...
  • Page 20 6. Attach a rear bracket to each outer rail 1. Place a rear bracket on the outer rail. 2. Adjust the rear bracket position on the outer rail to match the rack cabinet depth. Note According to the rack cabinet depth the number of rear bracket mount holes (A) used varies from three to six.
  • Page 21 Attaching a rear bracket for a 600 millimeters deep rack cabinet Note For a rack cabinet that is 600 millimeters deep six screws and nuts are required. Rear view Front view Chapter 2.   Installing the server...
  • Page 22 Attaching a rear bracket for a 900 millimeters deep rack cabinet Note For a rack cabinet that is 900 millimeters deep three screws and nuts are required. Rear view Front view 2-10 Installation Guide...
  • Page 23 3. Partially tighten the screws to secure the rear brackets into place. 4. Check that the distance between edge of the rear bracket and the edge of the front bracket matches the rack depth. 7. Insert a guide pin into the front and rear brackets of the rail assembly Note The rail assembly consists of the middle rail and the outer rail with the front bracket and the rear bracket attached.
  • Page 24 8. Push the middle rail back to its original position 1. Lift the middle rail release latch (A) up. 2. Push the middle rail (B) in until it clicks back into place. 2-12 Installation Guide...
  • Page 25: Attaching The Rail Assemblies To The Rack Cabinet

    2.3. Attaching the rail assemblies to the rack cabinet Required tools T25 Torx screwdriver Appendix: Screws, washers and nuts 1. Attach the rail assemblies to the rack cabinet For both rail assemblies: 1. Move the rail assembly into place. 2. If necessary, adjust the length of the rail assembly by sliding the rear bracket. Chapter 2.
  • Page 26 3. Position the rail assembly using the guide pins at each end. 4. Secure the rail assembly into place. 5. Tighten the rear bracket nuts. 2-14 Installation Guide...
  • Page 27: Installing The Server In The Rack Cabinet

    2.4. Installing the server in the rack cabinet CAUTION C045 Two people are required to perform this operation. 1. Pull the middle rails out 2. Slide the server into the middle rails 1. Using the inner rails attached to the server, slide the server into the middle rails. Chapter 2.
  • Page 28 2. When the rail assemblies click, push the release latch (A) on each side to allow the server to be pushed completely into the rack. 3. Secure the server into place Tighten the captive screws to secure the server into place. 2-16 Installation Guide...
  • Page 29: Appendix A. Screws, Washers And Nuts

    Appendix A. Screws, washers and nuts This appendix lists all the screws, washers and nuts included in the delivery. Screws Mark Head Body Diameter Length Description 3 mm 4 mm M3x4 Flat-headed screw 3.5 mm 12 mm Flat-head philip #6-32 screw 3 mm 6.5 mm M3x6.5 standard screw...
  • Page 30 Installation Guide...
  • Page 32 eviden.com...
