- Page 1 BullSequana EXD Installation Guide 86 A1 99FS 02 April 2024...
- Page 2 30 bis rue du Nid de Pie 49000 Angers FRANCE The information in this document is subject to change without notice. Eviden will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material...
-
Page 3: Table Of Contents
Table of Contents Table of Contents Preface Intended Readers Chapter 1. Checking the delivery contents 1.1. Unpacking the server 1.2. Checking labels 1.2.1. Identification label 1.2.2. MAC address label 1.2.3. Fan labels 1.2.4. Processor label Chapter 2. Installing the server 2.1. - Page 4 Installation Guide...
-
Page 5: Preface
Preface This guide explains how to install the server for the first time. The Bull support web site for the most up t o d ate product information, documentation, firmware updates, software fixes and service offers: https://support.bull.com Intended Readers This guide is intended for use by instructed or skilled personnel in charge of installing the server. - Page 6 Installation Guide...
-
Page 7: Chapter 1. Checking The Delivery Contents
The server drawer must not be unpacked before it has reached the room temperature (24 hours in the computer room). According to the configuration, the following items are included. ■ Antennas ■ Screws and washers ■ Kit for installation ■ The BullSequana EXD server Chapter 1. Checking the delivery contents... -
Page 8: Checking Labels
1.2. Checking labels Safety warning labels, including safety notices and graphic symbols, are present on the server. Check that the electrical installation complies with the label details. 1.2.1. Identification label Description Installation Guide... - Page 9 (1) this device may not cause harmful interference and (2) this device must accept any interference received including interference that may cause undesired operation. Model name Model name Commercial name Serial number BullSequana EXD 2U server with 1300W BSEXD1 XAN-ORD-xxxxx power supply Chapter 1. Checking the delivery contents...
-
Page 10: Mac Address Label
1.2.2. MAC address label Important It is recommended to write down the MAC address in case the label is lost. The label (A) is next to the processor assembly. Remove the cover and the air duct to check the label. Installation Guide... -
Page 11: Fan Labels
1.2.3. Fan labels The labels are on the fans, inside the server. Chapter 1. Checking the delivery contents... -
Page 12: Processor Label
1.2.4. Processor label The label is on top of the processor assembly. Mark Description Torque value Warning symbol Locking symbols Locking instructions Installation Guide... -
Page 13: Chapter 2. Installing The Server
Chapter 2. Installing the server CAUTION C050 The device must be installed in a location where the transmitting antenna is at least 20 cm from any people in order to comply with radio frequency exposure regulatory requirements. WARNING W079 Devices and antennas must not be operated with other antennas or transmitters. -
Page 14: Installing The Antennas
2.1. Installing the antennas 1. Locate the position for the antennas Rear view Configuration 1 Configuration 2 Configuration 3 Configuration 4 2 antennas 3 antennas 3 antennas 4 antennas ■ Dual-band Dual-band Dual-band 2.4-5.9 GHz WIFI LTE/5G 2.4-5.9 GHz WIFI 2.4-5.9 GHz WIFI ■... -
Page 15: Installing The Server On A Flat Surface
2.2. Installing the server on a flat surface Stick on the adhesive bumps under the server and install it on the flat surface. Chapter 2. Installing the server... -
Page 16: Installing The Server On A Din Rail
2.3. Installing the server on a DIN rail Required tools T20 Torx screwdriver Phillips screwdriver Procedure 1. Assemble the DIN rail kit with screws S1, washers W1 and nuts N1. Installation Guide... - Page 17 2. Assemble the DIN rail and the server. Tighten the screws S3. Chapter 2. Installing the server...
- Page 18 3. Turn the BullSequana EXD server to the upright position. 4. Attach the server to the DIN rail by carefully tilting it. Installation Guide...
-
Page 19: Installing The Server On A Vesa Holder
2.4. Installing the server on a VESA holder WARNING W088 To secure the server safely to the wall the correct type of screw anchor must be used. The screw anchors should be designed for the wall construction material (wood, concrete, etc.) and capable of bearing a weight of up to 30 kg. Required tools ■... - Page 20 2. Install the wall plate on a wall Case of solid wall 1. Drill two holes in the wall. 2. Fix the wall plate using screw anchors and lag bolts. Installation Guide...
- Page 21 Case of wooden wall 1. Drill two holes in the wall. 2. Fix the wall plate using two lag bolts. 3. Install the monitor plate on the server Tighten the screws S2. Chapter 2. Installing the server...
- Page 22 4. Install the server on the wall 1. Slide the monitor plate downwards into the wall plate (A). 2. Tighten the screw (B) to secure the server in place. 2-10 Installation Guide...
-
Page 23: Appendix A. Screws, Washers And Nuts
Appendix A. Screws, washers and nuts This appendix lists the screws, nuts and washers included in the delivery. Screws Mark Head Body Diameter Length Description 6 mm 10 mm Pan head screw 4 mm 8 mm CBLZ head screw M4x8 Black 4 mm 6. - Page 24 Installation Guide...
- Page 26 eviden.com...
