Eizo FLEXSCAN L997 Brochure

P
rofessionals working in CAD/CAM, DTP
and other graphics fields will welcome
the FlexScan L997's superb image qual-
ity, operational versatility and wide range
of image and color control capabilities.
An EIZO custom-developed integrated
circuit supports advanced functions like
industry-first automatic rotation. This
high performance monitor is an excel-
lent choice for large screen CRT users
wanting to switch to an LCD.
• 1600 × 1200 native resolution
• 250 cd/m brightness and
2
550:1 contrast ratio
• Digital and analog signal support
• 5-year warranty
F E A T U R E S
ActiveRotation II Portrait Mode Support
The FlexScan L997 introduces ActiveRotation II,
an EIZO-exclusive function that provides built-in
support for portrait mode. The monitor includes a
gravity sensor, so it "knows" when it is being ro-
tated and changes between portrait and landscape
modes accordingly. Because it is hardware-based,
ActiveRotation II does not absorb CPU power or
compromise graphics performance. It supports
Windows 2000/XP and Mac OS 9/X platforms.
Graphics board support for ActiveRotation II varies by manufac-
turer and model. With some graphics boards, it may be necessary
to change the resolution on the PC side or restart the computer
after rotating the screen. For details on graphics board support,
please see www.eizo.com/support/compatibility/lcd/
ActiveShot Picture-in-Picture Display
ActiveShot improves work efficiency by letting you
use two computers simultaneously from a single
monitor. Two picture-in-picture modes are avail-
able: Standard, which shows the entire screen from
the second source, and Clip, which allows selec-
tion of any screen segment for viewing. You can
2 1 . 3 " C o l o r L C D M o n i t o r
assign main and
sub-computers, select the size and position of the
sub-window, and make the sub-window appear and
disappear at the touch of a button.
Fine Contrast Mode Selection
Choose from among six different Fine Contrast
modes — Text, Picture, Movie, External, Custom
and sRGB — for the one that best suits the kind of
application you're using. Access is handy via a but-
ton on the front panel.
Image Mode Assignment
Part of the ScreenManager Pro for LCD util-
ity software, this function lets you assign a Fine
Contrast mode to a specific application. Whenever
you use the application, the screen automatically
changes to the assigned mode. It also provides
a WindowMovie mode, which darkens the sur-
rounding background so the video window appears
clearer and brighter.
