User's Manual
Color LCD Monitor

Advertisement

Table of Contents
loading

Related Manuals for Eizo FlexScan L465

Summary of Contents for Eizo FlexScan L465

  • Page 1 User’s Manual Color LCD Monitor...

  • Page 2: Safety Symbols

    Eizo Nanao Corporation. Eizo Nanao Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to Eizo Nanao Corporation's receipt of said information.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PRECAUTIONS ... 4 1. INTRODUCTION ... 9 1-1. Features... 9 1-2. Package Contents ... 9 1-3. Controls & Connectors ... 10 2. CABLE CONNECTION ... 12 2-1. Before connecting ... 12 2-2. Connecting the signal cable ... 13 2-3.

  • Page 4: Precautions

    English PRECAUTIONS IMPORTANT! • This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. •...
  • Page 5 WARNING Keep small objects or liquids away from the unit. Small objects accidentally falling through the ventilation slots into the cabinet or spillage into the cabinet may result in fire, electric shock, or equipment damage. If an object or liquid falls/spills into the cabinet, unplug the unit immediately. Have the unit checked by a qualified service engineer before using it again.
  • Page 6 English WARNING The equipment must be connected to a grounded main outlet. Not doing so may cause in fire or electric shock. Use the correct voltage. Do not overload your power circuit, as this may result in fire or electric shock.
  • Page 7 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury or equipment damage. When handling the unit, grip the bottom of the unit firmly with both hands ensuring the panel faces outward before lifting.

  • Page 8: Lcd Panel

    English LCD Panel The screen may have defective pixels. These pixels may appear as slightly light or dark area on the screen. This is due to the characteristics of the panel itself, and not the product. The backlight of the LCD panel has a fixed life span. When the screen becomes dark or begins to flicker, please contact your dealer.

  • Page 9: Introduction

    1. INTRODUCTION Thank you very much for choosing an EIZO Color Monitor. 1-1. Features • Dual inputs compliant • DVI (p.34) Digital input (TMDS (p.35)) compliant. • Horizontal scanning frequency: 24.8 - 80 kHz (Digital input: 31.5 - 64 kHz)

  • Page 10: Controls & Connectors

    English 1-3. Controls & Connectors Front Control Panel (1) ScreenManager (2) Speaker Volume Control Mute (3) Headphone jack (stereo mini-jack) (4) Input signal selection button (5) Auto Adjustment Button (6) Enter Button (7) Control Buttons (Up, Down, Left, Right) (8) Power Button (9) Power Indicator Blue Yellow...
  • Page 11 Rear POWER INPUT POWER INPUT Bottom (10) (10) Power Connector (11) External line in (stereo mini-jack) (12) DVI-D Input Connector (Signal 1) (13) D-Sub mini 15 pin Input Connector (Signal 2) (14) Security Lock Slot* (15) 4 Holes for Mounting an Arm-Stand (16) Stand (Detachable) Allows for connection of a security cable.

  • Page 12: Cable Connection

    English 2. CABLE CONNECTION 2-1. Before connecting Before connecting your monitor to the PC, change the display screen settings (resolution (p.34) and frequency) in accordance with the charts below. NOTE • The lower display modes like 640x 480, automatically enlarge to the maximum display mode (1280 x 1024), and some lines of the characters may become fuzzy.

  • Page 13: Connecting The Signal Cable

    Signal Cable (enclosed) Signal Cable (enclosed) + Adapter Digital Input Power Cord FD-C04 (Optional) NOTE • The L465 is not compatible with a Power Macintosh G4/G4 Cube ADC (Apple Display Connector). • Video Output Standard graphics card Connector D-Sub •...
  • Page 14 English Plug the power cord into the power connector on the rear of the monitor. Then, plug the other end of the cord into a power outlet. WARNING Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord.

  • Page 15: Sound Connections

    2-3. Sound Connections NOTE • Always switch the monitor and audio devices or computers off whenever connecting or disconnecting any audio devices (computer or CD player) to the monitor. • Use the enclosed stereo mini-jack cable for connecting audio devices or computers to the monitor.

  • Page 16: Screenmanager

    English 3. ScreenManager 3-1. How to use the ScreenManager S I G . S I G . AUTO AUTO E N T . E N T . Entering the ScreenManager Push the Enter button once to display the main menu of the ScreenManager. [Main Menu ] Making Adjustments and Settings (1) Select the desired sub menu icon using the Control buttons and push the Enter...

  • Page 17: Adjustments And Settings

    NOTE • Double clicking the Enter button at any time also exits the ScreenManager menu. 3-2. Adjustments and Settings The following table shows all the ScreenManager’s adjustment and setting menus. “*” indicates adjustments of analog input only and “**” indicates digital input only. Main menu Screen ColorManagement...

  • Page 18: Useful Functions

    English 3-3. Useful Functions Adjustment Lock Use the “Adjustment Lock” function to prevent any accidental changes. Locked function Unlocked function • To lock Switch off the monitor’s power by the power switch. Press on the Auto adjustment button while switching on the monitor’s power. •...

  • Page 19: Automatically Selecting The Input Signal Function

    EIZO Logo disappearing function When switching on the power button on the front panel, the EIZO logo is displyed for a while. If you desire to display or undisplay this logo, use this function. (Default is logo appearing.) • To undisplay Switch off the monitor’s power by the power switch, then hold down the Enter...

  • Page 20: Adjustment

    We recommend setting the desktop pattern to that as shown in the diagram below. NOTE • More precise adjustment is available for using the “Screen Adjustment program” utility software. It can be downloaded from the EIZO homepage (http://www.eizo.com/). 4. ADJUSTMENT...
  • Page 21 Adjust by using <Screen> menu in the ScreenManager. (1) Vertical bars appear on the screen → Use the <Clock> (p.34) adjustment. Select the <Clock> and eliminate the vertical bars by using the right and left of the control buttons. Do not continuously press the control buttons, as the adjustment value will change quickly and make it difficult to locate the most suitable adjustment point.
  • Page 22 English To adjust the output signal range (Dynamic Range) of the signal. → Use the <Range Adjustment> (p.35)of <ColorManagerment> menu. This controls the level of output signal range to display the whole color gradation (256 colors). [Procedure 1] Push the Auto adjustment button on the front panel while displaying the <Range Adjustment>...
  • Page 23 To set the Contrast of the screen. → Use the <Contrast> adjustment. This controls the brightness for the each color (red, blue and green) at the same time. Select <Contrast/Brightness> and adjust by using the right and left buttons. NOTE •...

  • Page 24: Color Adjustment

    English 4-2. Color Adjustment The <ColorManagement> menu in the ScreenManager enables to change the color of the screen. By using the <Color Mode>, the adjustment mode can be selected from <Custom mode> (to adjust the color settings according to your preference) and <sRGB> mode.

  • Page 25: Power-Save Setup

    NOTE • The “Hue” adjustment may cause undisplayable color tone. To change each color (red, green and blue). → Use the <Gain> (p.34)adjustment. By adjusting the red, green and blue color tones for each mode, custom colors can be defined. The 100 % indicates unadjusted condition. Display a white or gray background image and adjust the <Gain>.

  • Page 26: Digital Input

    English Digital input This monitor complies with the DVI DMPM (p.34). [Procedure] (1) Set the PC’s power saving settings. (2) Select “DVI DMPM” from the “PowerManager” menu. [Power saving system] Operation Power saving Off mode Power saving through the PC’s off mode is only supported when “Manual”...

  • Page 27: Attaching An Arm Stand

    5. ATTACHING AN ARM STAND The LCD monitor can be used with an arm stand by removing the tilt stand and attaching the arm stand to the LCD monitor. NOTE • Use an arm stand that satisfies the followings. When using the LCD monitor with an arm stand, the arm stand must be VESA approved : * Use an arm stand with a 75 mm x 75 mm hole spacing on the arm mounting pad.

  • Page 28: Troubleshooting

    English 6. TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact an EIZO dealer. • No picture problems : See No.1 ~ No.2 • Imaging problems : See No.3 ~ No.11 • Other problems : See No.12 ~ No.14 Problems 1.
  • Page 29 Problems 3. Display position is incorrect. 4. Vertical bars of distortion appear. 5. Horizontal bars of distortion appear. ! Decrease the horizontal bars using the <Phase>. 6. Letters and lines appear blurred. 7. The screen is too bright or too dark. ! Adjust the <Contrast and brightness> (The 8.
  • Page 30 English Problems 10. Fingerprints remain on the screen. 11. The <Smoothing> cannot be selected. 12. The Enter button does not operate. ! The adjustment lock is probably on. To unlock: 13. The Auto adjustment button does not operate. 14. The signal selection button does not operate.

  • Page 31: Cleaning

    7. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE • Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel.

  • Page 32: Specifications

    English 8. SPECIFICATIONS LCD Panel Dot Pitch Horizontal Scan Frequency Vertical Scan Frequency Resolution Dot Clock (Max.) Display Colors Display Area Power Supply Power Consumption Input Connector Analog Input Signal (Sync) Analog Input Signal (Video) 0.7Vp-p/75Ω Positive Input Signal (Digital) Signal registration Plug &...

  • Page 33: Default Settings

    Default settings Contrast Brightness Smoothing Color Management PowerManager Input Signal Off Timer Language Dimensions 14.5 370( 319.2(12.57) 155(6.1) Pin Assignment D-Sub mini 15 pin connector DVI-D Connector 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 19 20 21 22 23 24 17 18...

  • Page 34: Glossary

    English 9. GLOSSARY Afterimage The Afterimage is particular to LCD monitors when the monitor screen is left on for a long period without use. The “Afterimage” can be removed gradually by changing the displayed image. Clock With the analog input signal display, the analog signal is converted to a digital signal by the LCD circuitry.
  • Page 35 The LCD panel consists of a fixed number of pixel elements which are illuminated to form the screen image. The EIZO L465 display panel consists of 1280 horizontal pixels and 1024 vertical pixels. At a resolution of 1280 x 1024, all pixels are displayed as a full screen.
  • Page 36 English MEMO MEMO...

  • Page 37: Appendix/Anhang/Annexe

    APPENDIX/ANHANG/ANNEXE Preset Timing Chart for Analog input Timing-Übersichten für Analog Eingang Synchronisation des Signaux pour Analog numerique Based on the signal diagram shown below 20 factory presets have been registered in the monitor's microprocessor. Der integrierte Mikroprozessor des Monitors unterstützt 20 werkseitige Standardeinstellungen (siehe hierzu die nachfolgenden Diagramme).
  • Page 38 Sync Polarity Mode Clock 25.2 Nega. Nega. 640 × 480 28.3 Nega. 720 × 400 Macintosh 30.2 Posi. 640 × 480 Macintosh 57.3 Posi. 832 × 624 Macintosh 100.0 Posi. 1152 × 870 Macintosh 126.2 Posi. 1280×960 VESA 31.5 Nega. Nega.
  • Page 39 C: Back Porch D: Blanking Period H µs/ Dot V ms/ Line H µs/ Dot 1.907/ 1.049/ 6.356/ 1.907/ 1.112/ 6.355/ 3.175/ 1.114/ 7.407/ 3.911/ 0.784/ 5.587/ 1.440/ 0.568/ 3.040/ 1.838/ 0.482/ 3.233/ 3.810/ 0.528/ 5.587/ 3.810/ 0.427/ 6.349/ 3.556/ 0.626/ 6.222/ 2.200/...
  • Page 40 MEMO MEMO...
  • Page 41 [Applicable to gray (standard color version only).] Why do we have environmentally labelled computers? In many countries, environmental labelling has become an established method for encouraging the adaptation of goods and services to the environment. The main problem, as far as computers and other electronics equipment are concerned, is that environmentally harmful substances are used both in the products and during their manufacture.
  • Page 42 Environmental Requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs.

  • Page 43: Fcc Declaration Of Conformity

    Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord...
  • Page 44 Augenbelastung bei zu geringem Zeichenkontrast.) Recycle Auskunft Die Rücknahme dieses Produktes nach Nutzungsende übernimmt EIZO in Deutschland zusammen mit dem Partner von Roll MBB Recycling GmbH.Dort werden die Geräte in ihre Bestandteile zerlegt, die dann der Wiederverwertung zugeführt werden. Um einen Abholtermin zu vereinbaren und die aktuellen Kosten zu erfahren, benutzen Sie bitte folgende Rufnummer: 02153-73 35 00.
