- Page 1 COMMODE CHAIR Instruction manual 713-011 Please read the instruction carefully before assembly. The product structure schematic diagram is as follows：...
- Page 2 1 Backrest 2 Armrest 3 Seat plate 4 Commode potty 5 Detachable legs 6 Frame 7 Footrest 8 caster 1. Preparation before assembly: When you open the package box, please pay attention to protect the box all spare parts; distinguish accessories, prepare the corresponding installation tools.
- Page 3 c. The demolition activities foot support plate alignment and then rotating frame lock pin. (as shown in Figure 3 below). d. The backrest assembly alignment frame of bolt holes, pressed down, and then the C type buckle into the hole in the hole behind the right hand side to limit, as shown in Figure 5, A is “C type buckle”).
- Page 4 b. verify that all parts are assembled, check whether there is any spare parts. c. check whether there is loosening screws, if yes,please lock it d. check the appearance of all components have no skew phenomenon, then make appropriate adjustment. 4.
