Saxby Lighting 112540 Instruction Manual

Setting
Technical data
Supply Voltage: 220-240V~
Power Frequency: 50Hz
Ambient Light: 10LUX / 30LUX / 100LUX / DAY 24H (Adjustable)
Time Delay: 10sec / 1min / 5min / 15min
Rated Load: Max. 800W 400W
Detection Range: 360º Ceiling / 180º Wall
Conformity with all relevant UKCA
Directive requirements.
The power supply is Double Insulated and does not require connection to an Earth circuit.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is for indoor use only.
Care and Safety
We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before changing lightbulbs, or cleaning.
V1 02/08/2024
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
1 Daylight Sensor
1 2 range
OFF OFF <10Lux
I
II ON OFF
<30Lux
III OFF ON <100Lux
IV ON ON DAY
2 Hold Time
3
ON
I
II OFF
III ON
OFF
IV
3 Detection Area
5 6 Sensitivity Detect Breathe
ON ON 100%
I
II OFF ON 75%
III ON OFF 50%
OFF OFF
IV 25%
Detection Distance: Max 3m (radius) movement signal
such as hand moving, shake head.
2-3m (radius) breathe signal.
Working Temperature: -20~+40ºC
Working Humidity: <93%RH
Power Consumption: approx 0.9W
Installation Height: 2.2-4m
Conformity with all relevant CE
Directive requirements.
Instruction manual
Ambient Light
very dark
Presence Sensor 2-in-1
dark
slight light
whole day
112540
4 Delay Time
ON 15Min
ON 5Min
OFF 1Min
OFF
10sec
25m (5*5m room)
2
16m (4*4m room)
2
4m (2*2m room)
2
1m (1*1m room)
2
