LEVOIT Vital 100 Series Manual

ABOUT THE FILTER

The air purifier uses a 3-stage filtration system to purify air.

1. Washable Pre-Filter
   • Captures large particles such as dust, lint, fibers, hair, and pet fur
   • Maximizes the filter's life by protecting it.
2. High-Efficiency Activated Carbon Filter
   • Physical y adsorbs smoke, odors, and fumes.
   • Filters compounds such as formaldehyde, benzene, ammonia, hydrogen sulfide, and volatile organic compounds (VOCs).
3. H13 True HEPA Filter
   • Traps at least 99.97% of airborne particles 0.3 micrometers in diameter.
   • Filters small particles such as fine dust, smoke particles, and allergens such as pollen and pet dander.

Note: air purifiers filter airborne particles 0.3 microns in Size. Arovast Corporation makes no claims that this air purifier helps reduce the COVID-19 virus.

Clean Air Delivery Rate
This air purifier has a Clean Air Delivery Rate of 130 cubic feet per minute (CFM), or 221 m3/h.
Clean Air Delivery Rate (CADR) measures the efficiency of an air purifier by indicating the volume of clean air that an air purifier produces per minute. This is based on removal of dust, pol en, and smoke, which are the 3 most common indoor air pollutants. The higher the CADR, the more particles the air purifier will remove and the larger the area it can clean. The rating is measured at the air purifier's highest speed.

Air Change Per Hour
The air change rate is how many times al of the air in a room can be purified (or "changed") by the air purifier in 1 hour. Air changes per hour are calculated on the recommended room size assuming 8 ft/ 2.4 m ceilings. For smaller rooms, the air change per hour will increase. This air purifier has an air change per hour of 3.3, which means it can change air 3.3 times at the max speed in a single, closed room up to 300 ft2 / 28 m2 in size. The air purifier is effective for larger rooms, but air purification will take longer, with fewer air changes per hour.
Note: To effectively clean air, keep windows and doors closed while the air purifier is on.

Humidity
Note: Water or moisture will allow mold to grow. To solve a mold prob em, get rid of the source of the moisture and clean up the mold.
Note: Water or moisture will a//ow mold to grow To solve a mold problem, get rid of the source of the moisture and clean up the mold.

Essential Oils
Do not add essential oils to the air purifier or air filter. The filter will become damaged by the oil and will eventually release an unpleasant smell. Do not use oil diffusers near the air purifier.

CARE & MAINTENANCE

Cleaning the Air Purifier

• Unplug before cleaning.
• Wipe the outside of the air purifier with a soft, dry cloth. If necessary, wipe the housing with a damp cloth, then immediately dry.
• Vacuum the inside of the air purifier.
• Do not clean with abrasive chemicals or flammable cleaning agents.

Check Filter Indicator
will light up as a reminder to check the filter. Depending on how often you use the air purifier, the indicator should turn on within 6—8 months. You may not need to replace your filter yet, but you should check it when turns on.

When Should I Replace the Filter?

The filter should be replaced every 6—8 months. You may need to replace your filter earlier or later depending on how often you use your air purifier. Using your air purifier in an environment with relatively high pollution may mean you will need to replace the filter more often, even if is off
You may need to replace your filter if you notice:

• Increased noise when the air purifier is on
• Decreased airflow
• Unusual odors
• A visibly clogged filter

Note:

• To maintain the performance of your air purifier, only use official Levoit filters. For more information, contact Customer Support.
• Remember to reset after changing the filter.

Resetting the Check Filter Indicator
Reset the Check Filter Indicator when:

1. Iights up.
   1. Replace the air filter.
   2. Turn on the air purifier
   3. Press and hold for 3 seconds.
   4. will turn off when successful y reset.
2. The filter was changed before lit up.
   1. Press and hold for 3 seconds. This will turn on
   2. Press and hold again for 3 seconds.
   3. will turn off when successfully reset.

Cleaning the Filter
The Pre-Filter should be cleaned once a month to increase efficiency and extend the life of your filter.

1. Remove the filter from the housing and clean the Pre-Filter with a soft brush or vacuum hose to remove hair, dust, and large particles.
2. Carefully peel the Pre-Filter away from the True HEPA and Activated Carbon Filters. [Figure 2.1]

3. Gently wash the Pre-Filter under running water. Dry completely before placing it back on the velcro tape.
4. Replace filter in housing.

Note: Do not clean the True HEPA and Activated Carbon Filters.

Replacing the Filter

1. Unplug the air purifier and remove the filter cover.
2. Remove the old air filter and properly dispose of it.
3. Clean out any remaining dust or hair inside the air purifier using a vacuum hose. Do not use water or liquids to clean the air purifier. [Figure 2.2]

4. Unwrap the new filter and place inside the air purifier with the pull tabs facing out.
5. Replace the filter cover. The air purifier will not power on unless he filter cover s replaced correctly.
6. Reset the Check Filter Indicator.

Storage
If not using the air purifier for an extended period of time, wrap the filter in plastic packaging and store in a dry place to avoid moisture damage.

TROUBLESHOOTING

Problem	Possible Solution
Air purifier will not turn on or respond to button controls.	Plug in the air purifier.
	Check to see if the power cord is damaged. If so, stop using the air purifier and contact Customer Support.
	Plug the air purifier into a different outlet.
	Air purifier is malfunctioning. Contact Customer Support.
Airflow is significantly reduced	Make sure the filter is removed from its packaging and properly in place.
	Tap to increase the fan speed.
	Leave at least 15 inches / 38 cm of clearance to allow air to pass through the air inlets on the sides.
	The Pre-Filter may be clogged by large particles, such as hair or lint, blocking air flow. Clean the Pre-Filter.
	Replace the filter.
Air purifier makes an unusual noise while the fan is on.	Make sure the filter is properly in place with plastic packaging removed.
	Make sure the air purifier is operating on a hard, flat, even surface.
	Replace the filter.
	Air purifier may be damaged, or a foreign object may be inside. Stop using the air purifier and contact Customer Support. Do not try to repair the air purifier.
Strange smell coming from the air purifier	Clean the filter or rep ace if necessary.
	Contact Customer Support.
	Make sure not to use your air purifier in an area with high humidity or while diffusing essential oils.
Poor air purification quality	Tap to increase the fan speed.
	Make sure no objects are blocking the sides or top of the air purifier (the inlet or outlet).
	Make sure the filter is removed from its packaging and properly in place.
	Close doors and windows while using the air purifier.
	If the room is larger than 300 ft2 / 28 m2,air purification will take longer. The air purifier may not be as effective in significantly larger rooms.
	Replace the filter.
is still on after replacing the filter.	Reset the Check Filter Indicator.
has not turned on within 8 months.	is a reminder for you to check the filter and will light up based on how much the air purifier has been used. If you don't use your air purifier often, will take longer to turn on.
turned on before 6 months.	is a reminder for you to check the filter and will light up based on how much the air purifier has been used. If you run your air purifier frequently, will turn on sooner.

If your problem is not listed, please contact Customer Support.

CUSTOMER SUPPORT
If you have any questions or concerns about your new product, please contact our helpful Customer Support Team.

Arovast Corporation
1202 N. MI ler St., Suite A
Anaheim, CA 92806
Email: support@levoit.com
Toll-Free: (888) 726-8520

Support Hours
Mon Fri, 9:00 am 5:00 pm PST/PDT
*Please have your order invoice and order ID ready before contacting Customer Support.

levoit.com

SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS
To reduce the risk of fire, electric shock, or other injury, follow all instructions and safety guidelines.

General Safety

• Only use your air purifier as described in this manual.
• Do not use without removing the plastic wrap from the filter. The air purifier will not filter air and may overheat, causing a fire hazard.
• Do not use your air purifier outdoors.
• Keep your air purifier away from water, and wet or damp areas. Never place in water or liquid.
• Do not use in excessively humid areas.
• Keep your air purifier away from heat sources.
• Do not use where combustible gases, vapors, metallic dust, aerosol (spray) products, or fumes from industrial oil are present.
• Keep 5 ft/.5 m away from where oxygen is being administered.
• Supervise children when they are near the air purifier.
• Do not place anything into any opening on the air purifier.
• Do not sit or p ace heavy objects on the air purifier.
• Keep the inside of the air purifier dry To prevent moisture build up, avoid placing in rooms with major temperature changes or underneath air conditioners.
• Always unplug your air purifier before servicing (such as changing the filter).

• Do not use your air purifier if it is damaged or not working correctly, or if the cord or plug is damaged. Do not try to repair it yourself. Contact Customer Support.
•
  To reduce the risk of fire or electric shock, do not use this air purifier with any sold-state speed controls (such as a dimmer switch).
• Not for commercial use. Household use only.
• This appliance is not intended for used by persons (including children) with reduced physical, sensory or menta capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Cleaning and user maintenance shall not be made by children without supervision.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

Plug & Cord

• Keep the air purifier near the outlet it is plugged into.
• Never place the cord near any heat source.
• Do not cover the cord with a rug, carpet, or other covering. Do not place the cord under furniture or appliances.
• Keep the cord out of areas where people walk often. Place the cord where it will not be tripped over.
• This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one ways If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to defeat this safety feature.
• This air purifier uses standard US 120V, 60Hz outlets. If using in a different area, check for compatibility.
