Final ZE8000 Manual

Package Contents

Part Name

Power/Charging

Charging the charging case

Connect the accessory USB charging cable (C) connector to the USB port on the charging case and connect the USB (A) connector to an electrical appliance or adapter with the same shape of connector and the internal battery within the charging case will begin to charge. While charging, the LED Indicator of the charging case will light up in different patterns depending on the battery power level of the charging case as shown in the table below.

Charging Case Battery Level	LED Indicator of the Charging Case
0 ~ 25%
26 ~ 50%
51 ~ 75%
76 ~ 99%
100%

ON
Blinking
OFF

Charging the unit

Returning the earphone units back to the adequately charged charging case, the power of the earphones will be turned OFF automatically and start charging with the LED Indicator of earphone units light up Red. By closing the charging case, the LED Indicator of the charging case will light up in different patterns for 3 seconds depending on the battery level of the charging case as shown in the table below.

Charging Case Battery Level	LED Indicator of the Charging Case
0 ~ 25%
26 ~ 50%
51 ~ 75%
76 ~ 100%

ON
OFF

Turning ON the Unit

After opening the charging case by sliding up the lid, the LED Indicator of the earphones will light up Blue for 1 second and the power of the earphone units will automatically turn ON. Meanwhile the LED Indicator of the charging case will light up in different patterns for 3 seconds depending on the battery level of the charging case as shown in the table below.

* If the LED Indicator of the charging case does not light up after opening the charging case, the battery of the charging case might have been completely depleted. In such case, the earphone units will not turn ON when the case is opened. In order to turn ON the earphone, please charge the charging case by plugging in the charging cable and take out the earphone units from the charging case.

Charging Case Battery Level	LED Indicator of the Charging Case
0~25%
26~50%
51~75%
76~100%

ON
OFF

* While the earphones are paired to a device with the dedicated "final CONNECT" application installed, the battery level of the earphones can be checked with the mobile app. Please refer to "What Is the final CONNECT Application" section for details regarding "final CONNECT".

Turning OFF the Unit

Returning the earphone units back to the adequately charged charging case, the power of the earphones will be turned OFF automatically and start charging with the LED Indicator of earphone units light up Red. By closing the charging case, the LED Indicator of the charging case will light up in different patterns for 3 seconds depending on the battery level of the charging case as shown in the table below.

* If the LED Indicator of the charging case does not light up after closing the charging case, the battery of the charging case might have been completely depleted. In such case, earphone units will not turn OFF automatically. In order to turn OFF the earphone, first remove the earphone units from the charging case, then please charge the charging case by plugging in the charging cable and return the earphone units to the charging case.

Charging Case Battery Level	LED Indicator of the Charging Case
0 ~ 25%
26 ~ 50%
51 ~ 75%
76 ~ 100%

ON
OFF

Performing Device Pairing

To connect the earphones to your smartphone or other devices initially, it is necessary to perform device pairing. For devices which have been performed with the device pairing, the Bluetooth connection will automatically be established the next time the power is switched ON if they are in close distance.

Performing initial device pairing:

1. When the case is opened by sliding up the lid, the power of the earphone units will automatically switch ON with the LED Indicator of the earphones lights up Blue for 1 second. Then, they will automatically switch to the pairing mode with the LED Indicator on one of the earphones flashes between Blue and Red.
2. Switch ON the Bluetooth connection of the smartphone or other devices and select [ZE8000] which is shown under the pairable device list. When [ZE8000 Connected*1] appears on the display, device pairing is completed.

Unpairing current device and performing new device pairing with another device:

1. Open the charging case by sliding up the lid. With the earphone units properly returned to the adequately charged charging case, press the Pairing Button of the charging case twice and the earphone will switch to the pairing mode with the LED Indicator on one of the earphones flashes between Blue and Red.
2. Switch ON the Bluetooth connection of the smartphone or other devices and select [ZE8000] which is shown under the pairable device list. When [ZE8000 Connected*1] appears on the display, the new device pairing is completed.

*1: The message display might differ depending on the connected device.

Operation of Touch Control Panel

*1: If you perform the touch control right after the start of a track, you will return to the previous track. If you perform the touch control in the middle of a track, you will return to the beginning of the current track. In order to return to the previous track while you are currently in the middle of a track, please perform the touch control twice in succession.
*2: Depending on the device to which connected, this function may not be available.

About Single Bud Use Mode

This earphone supports single bud use. Once the earphones are being paired to a device, Single Bud Use Mode is automatically activated when only 1 side of the earphones is on use with another side being kept inside the charging case. When used in Single Bud Use Mode, touch sensor operation differs from normal operation, as shown in the table below.

Performing Factory Reset

When there is trouble to achieve a successful pairing or unexpected error has occurred, please perform the factory reset by the following procedures stated below. Once the factory reset is completed, please attempt another pairing operation.

1. Return the left and right earphone units back to an adequately charged charging case then push and hold the Pairing Button of the charging case for 7 seconds until the LED Indicator of both earphone units light up in Purple.
2. After a certain amount of time, the earphones will automatically switch to the device pairing mode with the LED Indicator on one of the earphones flashes between Blue and Red. The factory reset has been completed.
3. The earphones are now in the factory default state with all previous pairing information with the smartphone or other devices deleted. Please remove the previous pairing record on the smartphone or other devices then perform device pairing again.

About Noise Canceling / Ambient Sound Mode

By interacting with the touch control panel (see "Operation of Touch Control Panel") or by using the "final CONNECT" application, users can easily switch between the 4 modes below for the best experiences.

• Noise Canceling Mode - Offers a virtual stress-free quiet environment for your best music listening experience by reducing ambient noise.
• Wind-Cut Mode - Reduces environmental wind noise picked up by the microphones of the earphones.
• Ambient Sound Mode - Allows users to hear both music and the ambient sounds seamlessly at the same time.
• Voice Through Mode - Allows users to focus on the ambient sounds or conversation by minimizing the volume of the music.

What Is the final CONNECT Application

"final CONNECT" application is a dedicated mobile app designed for ZE8000.
Please download it onto the smartphone paired to the ZE8000 to unlock the following features.

Download

• Switch between Noise Canceling Mode / Wind-Cut Mode / Ambient Sound Mode / Voice Through Mode
• PRO Equalizer with its design inspired by professional recording equipment allows user to perform finer sound quality adjustment effectively like a pro
• Volume Step Optimizer upgrades the smartphone standard volume control, allowing for enjoyment of music at a pinpoint volume in accordance with the listening environment and user's preferences
• 8K SOUND+ upgrades the digital signal processing algorithm to a higher level and utilizes the computing power of the ZE8000 at its maximum limit allowing you to enjoy the highest sound quality of the "8K SOUND"
• Firmware updates
• Access to the latest news
• Checking the battery level
• Switching voice guidance language (Japanese / English)

About Ear Tips

If you find that the bass is lacking or the treble is grating, the ear tips may not be properly fitted. In order to make enough of earphone's potential, make sure the ear tips are positioned properly and keep the ear canals sealed. Please try the following instructions for proper fitting.

• Not only the standard M size, but also try different sizes.
• Trying larger size (M, L, LL) might be effective for small ears.
• The size of ear canals might be different from left to right, so try different size ear tips for left and right ear canals.

Please note the following notes when replacing ear tips.
* The size is marked on the inside of the ear tips, so be sure to check the size when replacing the ear tips.

* Check that the ear tip is correctly hanging on the edge of the earphone body.*1

* Check that the aperture of the ear tip is properly aligned with the aperture at the base of the nozzle in the main body of the earphone.*2

* If ear tips other than the dedicated ones are used, they may come off and remain in the ear canal during use. Please be sure to use the dedicated ear tips.

Maintenance

Please take safety precautions and gently remove any build-up from the dust filter by using a cotton swab.
If the build-up cannot be removed, kindly replace the filters on both sides with new dust filters. For details on how to replace the dust filters, please refer to the "How to Replace Dust Filter" extra sheet which can be found together with the supplied dust filter in the accessories.

Troubleshooting

When You Think, "Is It Broken?"

Safety Precautions

The following descriptions are provided to explain matters that must be observed in order to prevent harm to the user as well as other people, along with damages to property. Please be sure to observe this before using the product.

	Failure to observe the precautions indicated by this label will result in death or serious injury to the user.
	Failure to observe the precautions indicated by this label may result in death or serious injury to the user.
	Failure to observe the precautions indicated by this label may result in personal injury or property damage.

Fire, electric shock, overheat, ignition, leakage, rupture, or accidental ingestion may cause death, blindness, or serious injury.

Do not use, store, or leave the product in a humid or dusty place, or in a car where it will be exposed to high temperatures, or places exposed to direct sunlight. Doing so may cause overheat, leakage, or rupture of the product.

Do not use other than the supplied USB cable. Doing so may cause rupture, battery leakage, or overheat and consequently result in fire, burn mark, or injury.

Do not connect to a fast charging power adapter with a maximum power output exceeding 20W per port. Doing so may cause rupture, battery leakage, or overheat and consequently result in fire, burn mark, or injury.

Do not charge the battery when the charging case or USB cable is wet. Doing so may cause abnormal heating or malfunction due to short circuit.

Do not put it in a fire. Doing so may cause leakage or rupture and consequently result in injury or burn mark.

Do not disassemble the product. Doing so may cause product malfunctions.

If you find that liquid is leaking from the earphones or charging case, or if there is an unusual odor or overheat, do not touch the liquid and stop using the earphones immediately. Besides that, move all combustible materials nearby away from the earphones or charging case.

Fire, electric shock, overheat, ignition may cause burn or serious injury.

Do not use the product while driving a car, motorcycle, bicycle, etc. Doing so may cause a traffic accident.

Do not use the product in places where it would be dangerous if the surrounding sound is not audible such as railroad crossings, pedestrian crossings, station platforms, etc. Listening at high volume makes it difficult to hear surrounding sounds. The product is equipped with noise cancellation, it is difficult to hear warning tones and other sounds, which may cause accidents or injuries.

Do not allow water or foreign matter to get inside the charging case. The charging case is not waterproof. Water or foreign matter may cause fire or electric shock. If water or foreign matter should enter the charging case, stop using it immediately. Regularly check and ensure that no foreign matter adheres to the terminals of the charging case as it may cause overheat or fire.

Do not charge the charging case while it is covered by bedding or other covering. The heat buildup may cause abnormal overheat, which may result in a fire.

May cause injury or damage to surrounding property.

Keep out of reach of children or persons requiring supervision.
The product uses magnets and batteries. Swallowing small parts may cause serious symptoms such as choking hazard or internal organ damage.

Do not use in medical institutions or around people using medical equipment. It may cause malfunction to medical devices such as pacemakers.

When using the earphones on board an aircraft, follow the instructions of the flight crew. Radio wave effects may cause an accident.

Ear tips must be securely attached. If the ear tips are not securely attached, they may come off and remain in the ear canal during use.

Do not listen at high volume for long periods of time.
Prolonged use at excessive volume may result in permanent hearing loss. Do not exceed 40 hours/week at 80 dB (A) and 5 hours/week at 89 dB (A).

Contacting Us

Please contact us by visiting our official "CONTACT" page by scanning the QR code below.

https://final-inc.com/pages/lang-contact

Video guide:

https://final-inc.com/pages/lang-videoguide-ze8000

Manufacturer:
final Inc.
