Delfield 204 Specifications

204 Series
Water And Ice Station
Models
• 204 Water and ice station with glass filler
• 204P Water and ice station with pitcher filler
204

Specifications

Top is 18-gauge stainless steel, has 1.37"
(3.49cm) overhang all around. Glass filler is 9.5"
(24.1cm) high, over die-stamped drain opening
fitted with chrome-plated wire strainer. Pitcher
filler is 13.5" (34.3cm) high, over die-stamped
drain opening fitted with chrome-plated wire
strainer. Ice bin opening is die-stamped with
.19" (.48cm) raised edges, measures 15.12" x
10.5" (38.4cm x 26.7cm), has one-piece 20-
gauge stainless steel lift-off cover.
Liner of ice bin is high-impact ABS plastic,
has rounded corners and is pitched to 1"
(2.54cm) diameter drain. Bin is insulated all
around with high-density environmentally
friendly, Kyoto Protocol Compliant, Non ODP
(Ozone Depletion Potential), Non GWP (Global
Warming Potential) polyurethane. Ice bin holds
45 pounds of ice.
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
Standard Features
• Top is 18-gauge stainless steel with
raised die stamped opening
• Chrome plated wire strainer
• Glass filler is 9.5" high
• Pitcher filler is 13.5" high
• One-piece 20-gauge stainless steel
lift-off cover with handle
• Liner of ice bin is high-impact ABS
plastic with coved corners
• 1" diameter drain plumbed out the
bottom
• High
friendly, Kyoto Protocol Compliant,
Non
Potential),
Warming Potential) polyurethane
foam throughout unit
• Exterior tank is made of galvanized
steel
Exterior body is 24-gauge galvanized steel.
Cutout dimensions are 21" (53.3cm) x 17.17"
(45.1cm).
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
density environmentally
ODP (Ozone Depletion
Non GWP (Global
www.delfield.com
