Lorentz PowerPack PP150 AC Manual For Installation And Operation

Power Pack PP150 AC and PP200 AC
Manual for Installation and Operation
WARNING – This installation overview does not substitute the detailed instructions given in this
manual. Read and follow the manual carefully to ensure reliable operation and long life of the
product and to avoid danger to health and life.
Package Contents
• 1 x PP150AC/200AC
• 1 x MC4 T-connector female
• 1 x MC4 T-connector male
• 4 x mounting brackets
• 4 x screw
• 4 x washer
• 4 x spring washer
Safety Instructions
Safe operation of this product depends on its correct trans-
portation, installation, operation and maintenance. Failure to
follow these instructions can be dangerous to life or health
and/or void the warranty.
READ AND FOLLOW
ALL INSTRUCTIONS!
Explanation of warning symbols
WARNING – Disregard can lead to injury,
death or damage the system.
CAUTION – Recommended to avoid dam-
age, premature ageing of the pump or sim-
ilar negative consequences.
CAUTION – Hot surface. Indicates that the
marked item may be hot and should not
be touched .
Refer to the operating instructions
When installing and using this electrical equipment, basic
safety precautions should always be followed, including the
following:
WARNING – To reduce the risk of injury, do
not permit children to use this product un-
less they are closely supervised at all
times.
WARNING – The appliance is not to be
used by persons (including children) with
reduced physical, sensory or mental capa-
bilities, or lack of experience and knowl-
edge, unless they are instructed and close-
ly supervised.
BERNT LORENTZ GmbH & Co. KG Siebenstuecken 24, 24558 Henstedt-Ulzburg, Germany, Tel. +49 (0) 4193 8806 - 700, Fax - 708, www.lorentz.de
All specifi cations and information are given with good intent, errors are possible and products may be subject to change without notice. Pictures may
differ from actual products depending on local market requirements and regulations.
WARNING – To reduce the risk of
electric shock, replace damaged cords
immediately.
WARNING – It must be assured that all
grounding connections are properly made
and that the resistances meet local codes
or requirements.
The manual contains basic instructions which must be ob-
served during installation, operation and maintenance. Be-
fore installation and start-up, the manual should be care-
fully read by the person in charge of the installation. The
manual should also be read by all other technical personnel/
operators and should be available at the installation site at
all times.
ƒ Personnel qualifications and training – All person-
nel for the operation, maintenance, inspection and in-
stallation must be fully qualified to perform that type of
job. Responsibility, competence and the supervision of
such personnel must be strictly regulated by the operator.
Should the available personnel be lacking the necessary
qualification, they must be trained and instructed accord-
ingly. If necessary, the operator may request the manu-
facturer/supplier to provide such training. Furthermore
the operator/user must make sure that the personnel ful-
ly understand the contents of the manual.
ƒ Dangers of ignoring the safety symbols – Ignor-
ing the safety directions and symbols may pose a dan-
ger to humans as well as to the environment and the
equipment itself. Non-observance may void the warranty.
Non-observance of safety directions and symbols may
for example entail the following: Failure of important
functions of the equipment/plant; failure of prescribed
methods for maintenance and repair; danger to persons
through electrical, mechanical and chemical effects; dan-
ger to the environment because of leakage of hazardous
material; danger of damage to equipment and buildings.
ƒ Safety-oriented operation – The safety directions
contained in the manual, existing national regulations for
the prevention of accidents as well as internal guidelines
and safety-regulations for the operator and user must be
observed at all times.
ƒ General safety directions for the operator/user –
If hot or cold equipment parts pose a danger then they
must be protected by the operator/user against contact
with people. Protective covers for moving parts (e.g. cou-
plings) must not be removed when the equipment is run-
ning. Leaks (e.g. at the shaft seal) of hazardous pumping
media (e.g. explosive, toxic, hot liquids) must be disposed
of in such a way that any danger to personnel and the
environment is removed. All government and local regu-
lations must be observed at all times. Any danger to per-
sons from electrical energy must be eliminated by using
good installation practices and working to local regula-
tions (e.g. VDE in Germany).
ƒ Safety directions for maintenance, inspection and
assembly work – It is the user's responsibility to make
sure that all maintenance, inspection and assembly work
is performed exclusively by authorized and qualified ex-
perts sufficiently informed through careful study of the
operating instructions. The accident prevention regula-
tions must be observed. All work on the equipment must
be done when it is not operational and ideally electrically
isolated. Ensure all power sources and accessories (e.g.
float switch) are disconnected when working on the sys-
tem. Follow all appropriate electrical codes. There are
no user-serviceable parts inside the motor or the con-
troller. The sequence for shutting the equipment down is
described in the manual and must be strictly observed.
Pumps or pump units handling hazardous liquids must
be decontaminated. Immediately upon completion of
the work, all safety and protective equipment must be
restored and activated. Before restarting the equipment,
all points contained in chapter "Initial start-up" must be
observed.
