COMPACT DISC STEREO SYSTEM
SISTEMA ESTEREO CON REPRODUCTOR DE DISCOS COMPACTOS
CHAINE STEREO AVEC LECTEUR DE DISQUES COMPACTS
Z-A60
8C-MA5-901-01
0200420AMO-U-S
FOR ASSISTANCE AND INFORMATION
POUR L'ASSISTANCE ET LES INFORMATIONS
Visit us on the Internet at
Consultez notre site Internet
www.aiwa.com
Call Toll Free
Appel gratuit
1-800-BUY-AIWA
U
OPERATING INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MODE D'EMPLOI
En
En
(English)
E
(Español)
F
(Français)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DINA Z-A60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa DINA Z-A60

Summary of Contents for Aiwa DINA Z-A60

  • Page 1 COMPACT DISC STEREO SYSTEM SISTEMA ESTEREO CON REPRODUCTOR DE DISCOS COMPACTOS CHAINE STEREO AVEC LECTEUR DE DISQUES COMPACTS Z-A60 FOR ASSISTANCE AND INFORMATION POUR L'ASSISTANCE ET LES INFORMATIONS www.aiwa.com 8C-MA5-901-01 0200420AMO-U-S OPERATING INSTRUCTIONS MANUAL DE INSTRUCCIONES Visit us on the Internet at...

  • Page 2: Important Safety Instructions

    For your convenience, record the model number and serial number (you will find them on the rear of your unit) in the space provided below. Please refer to them when you contact your Aiwa dealer in case of difficulty. Model No.

  • Page 3: Table Of Contents

    Outdoor Antenna Power lines - An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

  • Page 4: Preparations

    PREPARATIONS CONNECTIONS IMPORTANT Connect the speakers, antennas and all optional equipment first. Then connect the AC cord. There are no difference between the front speakers. Both speakers can be connected as L (left) or R (right). FM antenna AM antenna Right speaker Speaker...

  • Page 5: Remote Control

    REMOTE CONTROL Inserting batteries Detach the battery cover on the rear of the remote control and insert two R6 (size AA) batteries. When to replace the batteries The maximum operational distance between the remote control and the sensor on the main unit should be approximately 5 meters (16 feet).

  • Page 6: Setting Power Economizing Mode

    SETTING POWER ECONOMIZING MODE CLOCK When you set power economizing mode to “ECO ON” or “ECO AUTO”, the unit reduces power consumption by conducting four ECO operations as follows. • The unit (all the illumination of the display and the buttons) blacks out when the power is turned off.

  • Page 7: Sound

    SOUND AUDIO ADJUSTMENTS T-BASS VOLUME VOLUME CONTROL Turn VOLUME on the main unit, or press VOL N or M M on the remote control. The volume level is displayed as a number from 0 to MAX (31). The volume level is automatically set to 16 when the power is turned off with the volume level set to 17 or more.

  • Page 8: Radio Reception

    RADIO RECEPTION MANUAL TUNING POWER 1 Press TUNER/BAND to select the FM or AM band. When TUNER/BAND is pressed while the power is off, the power is turned on directly (Direct Play Function). To select a band with the remote control Press BAND while pressing SHIFT.

  • Page 9: Presetting Stations

    PRESETTING STATIONS TUNER BAND c PRESET s CLEAR a SET MULTI TUNER PRESET The unit can store a total of 32 preset stations for all bands. When a station is stored, a preset number is assigned to the station. Use the preset number to tune in to a preset station directly.

  • Page 10: Cd Playing

    CD PLAYING BASIC OPERATIONS DISC DIRECT PLAY 1-3 z OPEN/ CLOSE DISC CHANGE MULTI LOADING DISCS Press CD, then press zOPEN/CLOSE to open the disc compartment. Load disc(s) with the label side To load one or two discs, place the disc(s) on tray 1 and 2. To load three discs, press DISC CHANGE to rotate the trays after placing two discs.

  • Page 11: Programmed Play

    PROGRAMMED PLAY Up to 30 tracks can be programmed from any of the inserted discs. Use the remote control. 1 Press PRGM while pressing SHIFT in stop mode. “– –” and “PRGM” appear on the display. 2 Press one of DISC DIRECT PLAY 1-3 to select a disc.

  • Page 12: Dubbing

    INSERTING BLANK SPACES 4-second blank spaces can be inserted at the desired point during recording. (Applicable when the source is TUNER or VIDEO/ AUX/PHONO.) 1 Press wREC/REC MUTE during recording or while in recording pause mode. 4 on the display flashes for 4 seconds and a 4-second blank space is made.

  • Page 13: Ai Edit Recording

    AI EDIT RECORDING MULTI The AI edit recording function enables CD recording without worrying about tape length and track length. When a CD is inserted, the unit automatically calculates the total track lengths. If necessary, the order of tracks is rearranged so that no track is cut short.

  • Page 14: Programmed Edit Recording

    PROGRAMMED EDIT RECORDING MULTI 8,10 1,10 In the programmed edit recording function, the tracks can be programmed while checking the remaining time on each side of the tape as the tracks are programmed. NOTE The programmed edit recording will not start from a point halfway in the tape.

  • Page 15: Clock And Timer

    CLOCK AND TIMER SETTING THE CLOCK When the clock is set, the “:” between the hours and minutes flashes. When the power cord is plugged into an AC outlet for the first time after purchase or when the clock setting is canceled due to a power failure, the entire clock display flashes.

  • Page 16: Setting The Timer

    SETTING THE TIMER ENTER POWER 6STANDBY/ON The unit can be turned on at a specified time every day with the built-in timer. Preparation Make sure the clock is set correctly. 1 Press one of the function buttons to select a source.

  • Page 17: Other Connections

    (LD player, MD player, VCR, TV, etc.). Connect the red plug to VIDEO/AUX/PHONO IN R jack, and the white plug to VIDEO/AUX/PHONO IN L jack. When connecting a turntable Use an AIWA turntable equipped with a built-in equalizer amplifier. LISTENING TO EXTERNAL SOURCES POWER...

  • Page 18: To Reset

    GENERAL CARE AND MAINTENANCE Occasional care and maintenance of the unit and the software are needed to optimize the performance of your unit. To clean the cabinet Use a soft dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with mild detergent solution.

  • Page 19: Specifications

    SPECIFICATIONS Main unit CX-ZA60 FM tuner section Tuning range 87.5 MHz to 108 MHz Usable sensitivity (IHF) 13.2 dBf Antenna terminals 75 ohms (unbalanced) AM tuner section Tuning range 530 kHz to 1710 kHz (10 kHz step) 531 kHz to 1602 kHz (9 kHz step) Usable sensitivity 350 µV/m...

  • Page 20: Parts Index

    N ) ... 7 # # POWER ... 5, 6, 8 $ $ FUNCTION ... 5 FOR ASSISTANCE AND INFORMATION POUR L'ASSISTANCE ET LES INFORMATIONS www.aiwa.com NOMENCLATURE Page/Página/Page Visit us on the Internet at Consultez notre site Internet Call Toll Free...
