Whirlpool WRT6340AUS Installation Manual

FEATURES & BENEFITS
TRIPLE ZONE
Extended zones can provide a larger cooking area and additional
heat to fit for different sizes of cooking pan
STOP & GO
Suspend the cooking process if you're interrupted then re-start
again at the same temperature in an instant with the Stop & Go
function.
BLACK CERAMIC GLASS
A completely smooth cooking surface makes the cooktop extreme-
ly easy to clean with just a wipe.
CHILD LOCK
Featuring a Child Lock function to prevent toddlers and children
from accidentally using the hob.
RESIDUAL HEAT INDICATOR
As an added safety precaution, all Whirlpool ceramic hobs have
residual heat indicators on each zone to alert you when a zone is
still hot.
WARRANTY
5
5 Year warranty on parts and labour.
TECHNICAL SPECIFICATIONS
DISTRIBUTED BY ARISIT PTY LTD
40-50 Mark Anthony Drive, Dandenong South VIC 3175
Ph: 1300 762 219 Fax: 03 9768 0838 Website: www.arisit.com
WRT6340AUS
60CM 4-ZONE CERAMIC HOB
WITH TRIPLE ZONE
TYPE 60cm Built-in Ceramic Hob
COOKING ZONES
4
COLOR / FINISH Black Ceramic Glass
CONTROL Touch Control
LOCATION OF CONTROL
Front
PANEL
PRODUCT NET WEIGHT 8.24kg
PRODUCT DIMENSION W 590mm x H 51mm x D 520mm
CUT-OUT DIMENSION
W 560mm x D 500mm
FUNCTIONS Triple Zone, Stop & Go Function
FEATURES
Child Lock, Timer, Residual Heat Indicator, Auto
Shutdown, Overheat Protection, Overflow
Protection
TOTAL POWER
6,500W
LEFT, FRONT ZONE
2,300W/1,500W/700W
LEFT, REAR ZONE
1,200W
RIGHT FRONT ZONE
1,200W
RIGHT REAR ZONE
1,800W
POWER SETTING
9 levels
ENERGY INPUT Electric
POWER VOLTAGE 220-240V~, or 380-415V 3N~, 50-60Hz
LENGTH OF POWER CORD
110cm (without plug)
PACKAGING DIMENSION
W 635mm x H 113mm x D 568mm
GROSS WEIGHT 9.15kg
COUNTRY OF ORIGIN Asia
WARRANTY
5 years
