Summary of Contents for Memorex MX-MCD200
- Page 1 TOP LOADING BLUETOOTH CD PLAYER & FM RADIO MODEL MX-MCD200 OPERATION MANUAL PLEASE READ BEFORE OPERATING THIS EQUIPMENT...
-
Page 2: Special Notes
SPECIAL NOTES For users in U.S. FOR YOUR RECORDS CAUTION For your assistance in reporting this unit in RISK OF ELECTRIC case of loss or theft, please record below the SHOCK DO NOT OPEN model number and serial number which are CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE located at the bottom of the unit. -
Page 7: Location Of Controls
LOCATION OF CONTROLS... - Page 8 1. CD DOOR TREBLE Control Knob 2. CD Door OPEN (Close) Area AL SET (Alarm Set) Button MUTE Button POWER Button 4. FUNCTION Button DIMMER Button AL ON/OFF (Alarm On/Off) Button 5. REPEAT Button 6. PROG (Program) Button BASS Control Knob TIME (Set) Button (Previous/Skip Backward) Button...
- Page 9 Battery Door ■ 1. REPEAT Button (Stop) Button (Next/Skip Forward) Button (Play/Pause) Button 6. Battery Holder (Previous/Skip Backward) Button...
-
Page 10: Power Source
CONNECTION: Connect the small plug from the Speaker Boxes to the SPEAKER OUT L & R Jacks on the rear of main unit as the illustrated below: POWER SOURCE: Main Unit: Unwind the AC power cord and extend it to its full length. Insert the AC plug of the cord into any convenient AC 120V~;... - Page 11 Notes: This unit is equipped with a polarized AC plug which has one blade wider than the other. This is a safety feature to reduce the likelihood of electric shock. This polarized AC plug will only fit in a polarized AC outlet. If you find that you cannot insert this plug into your outlet, you may have an obsolete non-polarized outlet.
-
Page 12: Remote Control
REMOTE CONTROL: First time use: Open the battery door on the bottom of the remote control by press the tab and then lifting it as illustrated below. Insert two (2) AAA size batteries (not included) according to the polarity diagram in side the battery compartment. - Page 13 possible battery leakage. 5. Do not try to recharge the battery not intended to be recharged; it can overheat and rupture. (Follow battery manufacturer’s instructions.) Do not dispose of battery in fire. Battery may explodes or leak. 7. Clean the battery contacts and also those of the device prior to battery installation. ⚠...
-
Page 14: General Operation
OPERATION GENERAL OPERATION: Connect the unit to AC power as previously instructed. The unit will enter to standby mode automatically and the LCD Display will illuminate. Press the POWER Button on the main unit or remote control to turn on the unit from standby mode. -
Page 15: Alarm Set
ALARM SET: To set or reset the alarm time: In Standby mode, press and holding the AL SET (Alarm Set) Button on the main unit or remote control, alarm time will appear on the display and blinking. Then: Button on the main unit or remote control to set hour. Press the (Make sure the PM Indicator appearing on the display if the alarm time is PM). - Page 16 Snooze: When the alarm sounds, tap the SLEEP/SNOOZE BUTTON to temporarily turn off the alarm and activate the snooze function, the alarm will stop and sound again 9 minutes later. If you tap the SLEEP/SNOOZE BUTTON again, the alarm will temporarily turn off again and sound again in 9 minutes and so CD Playback: 1.
- Page 17 Remote Control repeatedly to skip tracks. Notes: When the external BT Device searched the unit, model number “MX-MCD200” will appear on the display of external BT Device. If while pairing you are asked for a code, please try "0000" or "1234".
- Page 18 AUX IN: Connect the external Audio Device with a 3.5mm AUX cable. (Cable not included). Insert one end of the AUX cable to the Phone; Line Out or AUX Out Jack on the external Audio player. Power on the unit from Standby mode by press the POWER Button on the unit to select AUX In mode.
-
Page 19: Troubleshooting
TROUBLESHOOTING Check the following before requesting service: SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION AC Power cord had not connected Plug the AC Cord to any wall No power outlet having AC 120V~; 60Hz Increase the volume level by Volume of the unit was set to minimum pressing the VOLUME + / position No sound or sound weak... - Page 20 SPECIFICATTIONS Power Source: AC 120V~; 60Hz; 18W Clock Back Up: 3V; 2 x “AAA” size batteries (Not included) BT Version: BT Operation Distance: <=32 Feet in open area Radio Frequency: AM: 520-1710kHz FM: 87.5-108MHz Disc Compatible: CD; CD-R; CD-RW Impedance of Speakers: 2 x 3W; 4ohm Audio power: 2 x 2W (Total 4W, RMS) ACCESSORIES...
