Plejd TRM-01 Installation Manual

Mains electricity Circuit breaker
230 V AC~ / 50 Hz Max 16 A
Load Standby power
16 A, 2P, cos(φ) = 1 Po: N/A, Psm: 0.30 W,
Pnsm: 0.30 W, Pidle: N/A
IP rating
Calculated
IP20
battery life
Cable area
10 years reserve
< 10 A: 1.5 mm
2
(1xCR1616)
≥ 10 A: 2.5 mm
2
Radio
0.2 up to 2x2.5 mm
2
2.4 GHz mesh
Permissable ambient
Bluetooth
temperature
<10 dBm
-10 to +35 °C
Radio range
Thermostat mode
Approx. 10 m indoors.
5–40 °C
The Plejd mesh
technology extends
Regulator mode
the range by allowing
1–100 % PWM
the units to communicate
with each other.
· Do not place the thermostat where it can be exposed
to air drafts, direct sunlight or other heat sources.
· The NTC sensor should be placed ~1 m from the wall
and between loops of heating cable. The sensor cable
can be extended up to 100 m.
RISK OF INJURY TO PERSON OR PROPERTY
All work on the appliance must be carried out by
an authorized electrician. National laws and
Hereby, Plejd AB declares that the radio
equipment type TRM-01 is in compliance
The full text of the EU declaration of conformity
and third-party licenses are available at the following
®
internet address: plejd.com/compliance
Important information
Do not use the product if it has visible signs
of damage.
Disposal and recycling
This electrical product should not be disposed
of together with other household waste. Contact
your local recycling center for guidance on
electrical and electronic equipment disposal.
regulations must be followed.
Compliant to standards
with Directive 2014/53/EU.
Plejd AB, Krokslätts Fabriker 27A
431 37 Mölndal, Sweden
EN
T R M - 0 1
INSTALLATION MANUAL
Further information can be found
in the Plejd app or at plejd.com
