Summary of Contents for astreea Igloo MAX

  • Page 1 Built for a lifetime. Installation Guide Igloo MAX - All sizes ITM. NO. ART. 6426495301868 Astreea® Igloo MAX model M 6426495302254 Astreea® Igloo MAX model L 6426495302131 Astreea® Igloo MAX model XL 6426495302094 Astreea® Igloo MAX model XXL...
  • Page 2 3. Retain this Guide for future reference 4. The cards presented within the Guide are of paramount importance and necessitate your thorough consideration. Astreea Igloos North America, LLC PO Box 773192 Eagle River Alaska 99577 www.astreea.com/igloo Please call our customer service Worldwide: +1 (907) 931-4469 (English and French) or contact email address at: info@astreea.com...
  • Page 3: Table Of Contents

    Summary Introduction, Safety Protocols, Assembly and Maintenance Guidelines, Cleaning Procedures, Storage Protocols, and Disposal Instructions. Frame components 1. Installing the frame Step 1: Install the base frame Step 2: Install the sliding rail Step 3: Install the first lower pole Step 4: Install the first lower panel Step 5: Install the remaining panels and poles Step 6: Install the first upper panel with the central plate and upper poles...
  • Page 4: Introduction, Safety Protocols, Assembly And Maintenance Guidelines, Cleaning Procedures, Storage

    *Flower Bed or Fabric Weights - see our website • Ensure that candles, oil lamps, or any other sources of open • Astreea® Igloo can bear up to 200 kg (450 lbs) of snow. It is rec- flame are not left unattended within the confines of the igloo.
  • Page 5 MAKE SURE THAT THE IGLOO IS SECURED TO THE GROUND USING THE FIXING CLAMPS, OR WEIGHED DOWN USING THE ASTREEA® WEIGHTS AVAILABLE AT ASTREEA.COM. FOR ASTREEA® IGLOO MAX MODEL, LEAVING THE IGLOO IN WINDY CONDITIONS WITH MISSING POLYCARBONATE PANELS OR THE SLIDING DOOR OPEN, MAY RESULT IN DAMAGE TO THE IGLOO. THE SAME APPLIES TO OTHER COVERS, IF THERE’S AN OPENING THAT ALLOWS THE WIND TO INFLATE THE...
  • Page 6: Frame Components

    Installation Guide - Astreea® Igloo MAX - All sizes Frame Components M / L / XL / XXL Connector assembly Base tube Lower pole Lower panel 8 / 10 / 12 / 16 8 / 10 / 12 / 16...
  • Page 7: Let's Begin

    Installation Guide - Astreea® Igloo MAX - All sizes Let’s begin Remember The Astreea® Igloo is engineered to accommodate all seasons. Enhance your current product with a range of accessories and covers, enabling year-round utilization. Scan for: astreea.com/igloo Missing or lost spares? Please call our customer service: (907) 931-4469 Proudly manufactured by ARSAT®...
  • Page 8: Installing The Frame

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the frame Step 1: Install the base frame Position the connector assembly upside down, alongside the base tube, junction plates, and slider junction plates. Junction Plate Connector Assembly Base Tube...
  • Page 9 Installation Guide - Astreea® Igloo MAX - All sizes CAUTION: Direct tightening of the screws with an Allen key or a power screwdriver SM6207991 is ill advised. First, hand-thread the screws to ensure they are correctly positioned. This guideline should be followed throughout the entire assembly process.
  • Page 10: Step 2: Install The Sliding Rail

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the frame Step 2: Install the sliding rail Attach the sliding rail to the slider junction plate and secure it using three M6x16 7380 screws. Sliding Rail M6x16 7380 Screw...
  • Page 11 Installation Guide - Astreea® Igloo MAX - All sizes Choose the door position and fix the base to the platform. Once the sliding rail is mounted, place the base in the desired location for the Igloo, taking into account that the position of the door is determined by the sliding rail.
  • Page 12: Step 3: Install The First Lower Pole

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the frame Step 3: Install the first lower pole The initial lower pole will be assembled directly above the central slider junction plate. It will be fastened to the connector assembly using two M6x12 7380 screws.
  • Page 13: Step 4: Install The First Lower Panel

    Installation Guide - Astreea® Igloo MAX - All sizes Step 4: Install the first lower panel Slide the first lower panel into the left channel of the lower pole for a right-to-left door opening direction. Alternatively, for a left- to-right door opening, insert the first lower panel into the right channel of the lower pole.
  • Page 14: Step 5: Install The Remaining Panels And Poles

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the frame Step 5: Install the remaining panels and poles Proceed in the same way for the entire base frame. Door Position Sliding from right to left Page 14 Proudly manufactured by ARSAT® in the European Union...
  • Page 15: Step 6: Install The First Upper Panel With The Central Plate And Upper Poles

    Installation Guide - Astreea® Igloo MAX - All sizes Step 6: Install the first upper panel with the central plate and upper poles Central Plate Upper Panel M6x20 7991 Screw SM6207991 Upper pole Inside view Proudly manufactured by ARSAT® in the European Union...
  • Page 16: Step 7: Install The First Upper Panel On The Lower Paneland Poles

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the frame Step 7: Install the first upper panel on the lower panel and poles Begin the assembly of the upper panels from the side of the door. M6x12 7380...
  • Page 17 Installation Guide - Astreea® Igloo MAX - All sizes Step 7: Install the first upper panel on the lower paneland poles Insert the second upper panel into the channel of the second upper pole, then position the pole accordingly and secure it to the lower pole by fixing it in place.
  • Page 18: Step 8: Fix The Second Upper Pole

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the frame Step 8: Fix the second upper pole Slide the second upper panel into the channel of the second upper pole, then position the pole in place and secure it to the lower pole by fixing it.
  • Page 19: Step 9: Mount The 3Th Upper Pole

    Installation Guide - Astreea® Igloo MAX - All sizes Step 9: Mount the 3th upper pole Mount the third upper pole onto the upper panel by inserting the right channel over the panel strip, ensuring its side aligns with the lateral channel of the pole.
  • Page 20: Step 10: Install The Remaining Panels And Poles

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the frame Step 10: Install the remaining panels and poles Install the remaining panels and upper poles following the same procedure as the preceding ones, except for the final upper pole. The last upper pole will be installed after mounting the shorter panel.
  • Page 21: Step 11: Install The Short Upper Panel

    Installation Guide - Astreea® Igloo MAX - All sizes Step 11: Install the short upper panel To install the short upper panel, loosen the M6x12 screw securing the first upper pole to the first lower pole. This will enable the short panel to be inserted into the right channel of the upper pole.
  • Page 22: Step 12: Install The Last Upper Pole

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the frame Step 12: Install the last upper pole Mount the final upper pole between the two upper panels, ensuring that their lateral portions correctly align with the side channels of the pole.
  • Page 23: Step 13: Secure The Last Upper Pole

    Installation Guide - Astreea® Igloo MAX - All sizes Step 13: Secure the last upper pole Secure the last upper pole at both ends as follows: at the bottom, utilize an M6x12 7380 screw, and at the top, fix it in place with 2 M6x20 7991 screws.
  • Page 24: Step 14: Install The Upper Sealing And Upper Plate

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the frame Step 14: Install the upper sealing and upper plate Affix the D sealing to the upper plate on the exterior edge, then assemble the parts as illustrated. D sealing...
  • Page 25: Step 15: Fix The Polycarbonate Panels

    Installation Guide - Astreea® Igloo MAX - All sizes Step 15: Fix the polycarbonate panels Fix the polycarbonate panels, upper ones with the lower ones. Optional Screw M6x8 73802 SM6873802 Nut M6 fixed from inside of the igloo Proudly manufactured by ARSAT® in the European Union...
  • Page 26: Door Components

    Installation Guide - Astreea® Igloo MAX - All sizes Door Components M / L / XL / XXL Door base Door lower pole Handle pole Door upper pole 1 / 1 / 1 / 1 2 / 2 / 2 / 2...
  • Page 27 SLIDING DOOR 2024 MAXIMUM EFFICIENCY. The Astreea® Igloo is crafted to withstand any season. Enhance your current set- up by incorporating a selection of accessories and covers, ensuring year-round usability of your product. Scan for: astreea.com/igloo THIS THE DOOR SLIDES...
  • Page 28: Installing The Door

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the door Step 1: Attach the wheels and fasten the retainer screws onto the door base Whaser d5 Wd5D107089 Wheel IGM12 Door base IGML61 M5x16 7380 Screw Retainer Screw SM5167380...
  • Page 29: Step 2: Install The The Handle Pole

    Installation Guide - Astreea® Igloo MAX - All sizes Step 2: Install the the handle pole From this point onward, door installation is simplified if conducted on one side. Begin by positioning the handle pole horizontally, then proceed to mount the door base.
  • Page 30: Step 4: Install The Door Lower Pole

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the door Step 4: Install the door lower pole Slide the door lower pole over the polycarbonate panel and secure it at the bottom using the same method as the handle pole.
  • Page 31: Step 6: Install The Second Lower Pole

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the door Step 6: Install the second lower pole Install the door lower pole using the same method as the previous pole. Door lower pole IGML62 M6x12 7380 Screw SM6127380...
  • Page 32: Step 8: Install The First Door Upper Panel

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the door Step 8: Install the first door upper panel Door upper Panel IGML68 Step 9: Install the second door upper pole M6x12 7380 Screw SM6127380 Door upper Pole IGML64 Page 32 Proudly manufactured by ARSAT®...
  • Page 33: Step 10: Install The Last Door Upper Panel

    Installation Guide - Astreea® Igloo MAX - All sizes Step 10: Install the last door upper panel Door upper Panel IGML68 Step 11: Install the last door upper pole M6x12 7380 Screw SM6127380 Door upper Pole IGML64 Proudly manufactured by ARSAT® in the European Union...
  • Page 34: Step 12: Install The Pvc Protection

    Installation Guide - Astreea® Igloo MAX - All sizes Installing the door Step 12: Install the PVC protection Place the PVC protection with the straight end into the side channel of the upper pole, pulling it until it reaches the bolt at the door base.
  • Page 35: Mounting The Door

    Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Step 1: Mount the door on the Igloo Place the door onto the igloo and insert the pivoting bolt into the upper plate. Finally, secure the top of the door from inside the igloo.
  • Page 36: Step 2: Insert The Retainer Screw Into The Rail Channel

    Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Step 2: Insert the retainer screw into the rail channel Align the door next to the sliding track, then rotate it to insert the retainer screw into the channel of the track.
  • Page 37: Step 3: Install The Slider End Caps

    Installation Guide - Astreea® Igloo MAX - All sizes Step 3: Install the slider end caps Attach the slider end caps to the rails at both ends. M4x10 7991 Screw SM4107991 M4x10 7991 Screw SM4107991 End caps IGM23 End caps...
  • Page 38: Step 4: Install The Interior And Exterior Handles

    Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Step 4: Install the interior and exterior handles To install the interior handle, begin by disassembling it. Position the cap on the exterior of the igloo, then tighten the handle from the inside using the M5 screw.
  • Page 39: Mount The Accessories

    Installation Guide - Astreea® Igloo MAX - All sizes Accessories Utilize the M4 and M6 insert nuts to securely fasten your accessories. M4 thread insert nut *max 2Kg/insert nut M6 thread insert nut *max 3kg/insert nut Install the hangers Screw M4x10 7991...
  • Page 40 MADE IN ROMANIA FABRIQUÉ EN ROUMANIE HECHO EN RUMANIA Igloo MAX - All sizes ITM. NO. ART. 6426495301868 Astreea® Igloo MAX model M 6426495302254 Astreea® Igloo MAX model L 6426495302131 Astreea® Igloo MAX model XL 6426495302094 Astreea® Igloo MAX model XXL Scan for: astreea.com/igloo...
