astreea Igloo MAX Installation Manual

Hide thumbs Also See for Igloo MAX:

Advertisement

Quick Links

Download this manual
Built for a lifetime.
ENG
Installation
Guide
Igloo MAX - All sizes
ITM. / ART. xx

Advertisement

loading
Need help?

Need help?

Do you have a question about the Igloo MAX and is the answer not in the manual?

Questions and answers

Related Manuals for astreea Igloo MAX

Summary of Contents for astreea Igloo MAX

  • Page 1 Built for a lifetime. Installation Guide Igloo MAX - All sizes ITM. / ART. xx...
  • Page 2 3. Retain this Guide for future reference 4. These cards that you will find in the Guide are very important. Please give them your attention. Astreea Igloos North America, LLC PO Box 773192 Eagle River Alaska 99577 www.us.astreea.com Please call our customer service US &...
  • Page 3 Summary Introduction, Safety regulations, Information regarding assembly and maintenance, Cleaning, storage and disposal. Component list for Frame and Plus cover 1. Mounting the Frame 1.1 Base rails, stop plate and locking plate. 1.2 Vertical poles 1.3 Support plate on the vertical pole 1.4 First vertical pole on the base rail 1.5 Second vertical pole 1.6 All the vertical poles and the crown plate...
  • Page 4 • Do not leave candles, oil lamps or other sources of fire unattended in the igloo! • Astreea® Igloo can bear up to 200 kg (450 lbs) of snow. It is rec- ommended to broom off the snow regularly to prevent collapsing.
  • Page 5 Please, use a specialized recycling center. The Astreea® Igloo must be secured to the ground using the aluminum fixing clamps, included in the package, and screws that are suitable for your ground material.

  • Page 6: Frame Components

    Installation Guide - Astreea® Igloo MAX - All sizes Frame Components M / L / XL / XXL Connector assembly Base tube Lower pole Lower panel 8 / 10 / 12 / 16 8 / 10 / 12 / 16...

  • Page 7: Let's Begin

    Installation Guide - Astreea® Igloo MAX - All sizes Let’s begin Remember The Astreea® Igloo is designed for any season. Update your existing product with accessories and covers for year round use. Scan for: astreea.com/igloo Missing or you lost spares? Please call our customer service: (907) 931-4469 Proudly manufactured by ARSAT®...

  • Page 8: Mounting The Frame

    Installation Guide - Astreea® Igloo MAX - All sizes Mounting the Frame Step 1: Install the base frame. Place the connector assembly upside down together with the base tube, junction plates and slider junction plates. Junction Plate Connector Assembly Base Tube...
  • Page 9 Installation Guide - Astreea® Igloo MAX - All sizes SM6207991 Base Tube Base Tube Connector Assembly The connector assembly will be inserted into the base tube, following which another base tube will be inserted into the opposite side. All of these will be secured using the junction plate and M6x20 7991 screws.
  • Page 10 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the Frame Step 2: Install the sliding rail. The sliding rail will be mounted on the slider junction plate and secured using 3pcs. of M6x16 7380 screws. Sliding Rail M6x16 7380...
  • Page 11 Installation Guide - Astreea® Igloo MAX - All sizes Choose the door position and fix the base to the platform. After mounting the sliding rail, position the base in the desired location for the Igloo, considering that the door’s position is determined by the sliding rail.
  • Page 12 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the Frame Step 3: Install the first lower pole. The first lower pole will be assembled directly above the central slider junction plate. It will be secured to the connector assembly using 2pcs. of M6x12 7380 screw.
  • Page 13 Installation Guide - Astreea® Igloo MAX - All sizes Step 4: Install the first lower panel. Slide the first lower panel into the left channel of the lower pole if you want the door open from right to left. If you want the door open from left to right slide the first lower panel into the right channel of the lower pole.
  • Page 14 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the Frame Step 5: Install the remaining panels and pipes. Proceed in the same way for the entire base frame. Door Position Sliding from right to left Page 14 Proudly manufactured by ARSAT® in the European Union...
  • Page 15 Installation Guide - Astreea® Igloo MAX - All sizes Step 6: Install the first upper panel with the central plate and upper poles. Central Plate Upper Panel M6x20 7991 Screw SM6207991 Upper pole Inside view Proudly manufactured by ARSAT® in the European Union...
  • Page 16 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the Frame Step 7: Install the first upper panel on the lower paneland poles. Begin the assembly of the upper panels from the side of the door. M6x12 7380 screw Page 16 Proudly manufactured by ARSAT®...
  • Page 17 Installation Guide - Astreea® Igloo MAX - All sizes Step 7: Install the first upper panel on the lower paneland poles. Slide the second upper panel into the channel of the secont upper pole then place the pole into the position and secure it to the lower pole by fixing it...
  • Page 18 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the Frame Step 9: Fix the second upper pole. Slide the second upper panel into the channel of the secont upper pole then place the pole into the position and secure it to the lower pole by fixing it...
  • Page 19 Installation Guide - Astreea® Igloo MAX - All sizes Step 10: Mount the 3th upper pole. Slide the 3th upper pole downwards onto the upper pannel so that its side fits into the lateral channel of the pole. M6x20 7991...
  • Page 20 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the Frame Step 11: Install the remaining panels and poles. Install the remaining panels and upper arches in the same manner as the preceding ones were fitted except for the last upper pole, which will be installed after mounting the shorter panel.
  • Page 21 Installation Guide - Astreea® Igloo MAX - All sizes Step 12 Install the short upper panel The short upper panel will be installed by loosening the M6x12 screw that secures the first upper pole to the first lower pole. This will allow the short panel to be fitted into the right channel of the upper pole.
  • Page 22 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the Frame Step 12: Install the short upper panel. Install the last upper pole between the two upper panels, ensuring that their lateral parts fit correctly into the side channels of the pole.
  • Page 23 Installation Guide - Astreea® Igloo MAX - All sizes Step 14: Secure the last upper panel The last upper pole will be fixed at both ends as follows: at the bottom, an M6x12 7380 screw will be used, and at the top, it will be fixed inside with 2 M6x20 7991 screws.
  • Page 24 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the Frame Step 15: Install the upper sealing and upper plate. Stick the D sealing to the upper plate on the exterior edge then mount the parts as shown. D sealing...
  • Page 25 Installation Guide - Astreea® Igloo MAX - All sizes Step 16: Fix the polycarbonate panels. Fix the polycarbonate panels, upper ones with the lower ones. Screw M6x8 73802 SM6873802 Nut M6 fixed from inside of the igloo Proudly manufactured by ARSAT® in the European Union...
  • Page 26 Installation Guide - Astreea® Igloo MAX - All sizes Frame Components M / L / XL / XXL Door base Door lower pole Handle pole Door upper pole 1 / 1 / 1 / 1 2 / 2 / 2 / 2...
  • Page 27 SLIDING DOOR 2024 MAXIMUM EFFICIENCY. The Astreea® Igloo is designed for any season. Update your existing product with accessories and covers for year round use. Super clear protected panels. 200 times more resistant than glass. Door Draw 2x Aluminum Anodized Handlebar...

  • Page 28: Mounting The Door

    Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Step1: Mount the wheels and the securing screws on the door base. Whaser d5 Wd5D107089 Wheel IGM12 Door base IGML61 M5x16 7380 Screw Retainer Screw SM5167380 IGM24 Page 28...
  • Page 29 Installation Guide - Astreea® Igloo MAX - All sizes Step2. Install the the handle pole Starting from this stage, the door installation is easier to perform if done on one side. For this, the handle pole will be placed horizontally, followed by mounting the door base afterwards.
  • Page 30 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Step 3: Install the handle polycarbonate panel. Slide the polycarbonate handle panel into the handle pole channel. The panel must be positioned with the hole facing the handle pole.
  • Page 31 Installation Guide - Astreea® Igloo MAX - All sizes Step4: Install the door lower pole. Slide the door lower pole over the polycarbonate panel and fix it at the bottom in the same way as the handle pole was. M6x12 7380...
  • Page 32 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Step 6: Install the second lower pole. Install the door lower pole in the same way the previous pole was installed. M6x12 7380 Screw SM6127380 M6x12 7380 Screw...
  • Page 33 Installation Guide - Astreea® Igloo MAX - All sizes Step 8: Install the first door upper panel Door upper Panel IGML68 Step 9: Install the second door upper pole. M6x12 7380 Screw SM6127380 Door upper Pole IGML68 Proudly manufactured by ARSAT® in the European Union...
  • Page 34 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Step 10: Install the last door upper panel. Door upper Panel IGML68 Step 11: Install the last door upper pole. M6x12 7380 Screw SM6127380 Door upper Pole IGML64 Page 34 Proudly manufactured by ARSAT®...
  • Page 35 Installation Guide - Astreea® Igloo MAX - All sizes Step 12: Install the PVC protection Insert the PVC protection, with the straight end into the side channel of the upper pole and pull it until it reaches the bolt at the door base.
  • Page 36 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Step 13: Install the pivoting assembly 6x M6x10 7380 Screw SM6107380 Page 36 Proudly manufactured by ARSAT® in the European Union...
  • Page 37 Installation Guide - Astreea® Igloo MAX - All sizes Mount the door on the Igloo Position the door onto the igloo and insert the pivoting bolt into the upper plate then secure the door at the top from inside the igloo.
  • Page 38 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Insert the retainer screw into the rail channel Position the door along the side of the sliding track, then rotate it so that the retainer screw enter the channel of the track.
  • Page 39 Installation Guide - Astreea® Igloo MAX - All sizes Install the slider end caps Install the slider end caps on the rails, at both ends. M4x10 7991 Screw SM4107991 M4x10 7991 Screw SM4107991 End caps IGM23 End caps IGM23 Proudly manufactured by ARSAT® in the European Union...
  • Page 40 Installation Guide - Astreea® Igloo MAX - All sizes Mounting the door Install the interior and exterior handles. For the installation of the interior handle, you will need to disassemble it and position the cap on the exterior of the igloo, then tighten the handle from the inside using the M5 screw.
  • Page 41 Installation Guide - Astreea® Igloo MAX - All sizes Install the hangers Screw M4x10 7991 SM4107991 Proudly manufactured by ARSAT® in the European Union Page 41...
  • Page 42 Installation Guide - Astreea® Igloo MAX - All sizes Accessories Use the M4 and M6 insert nuts to fix your accessories. M6 thread insert nut *max 3Kg M4 thread insert nut *max 2Kg Page 42 Proudly manufactured by ARSAT® in the European Union...
  • Page 43 Installation Guide - Astreea® Igloo MAX - All sizes Notes Proudly manufactured by ARSAT® in the European Union Page 43...
  • Page 44 Installation Guide - Astreea® Igloo MAX - All sizes Notes Page 44 Proudly manufactured by ARSAT® in the European Union...
  • Page 45 COSTCO ® Companies Distribution Locations Costco Wholesale Costco Wholesale Spain Iceland S.L.U. Polígono Distributed by: Costco Wholesale ehf. Kauptún Empresarial Los Costco Wholesale New Zealand 3-7, 210 Gardabaer Gavilanes C/ Agustín Corporation 2 Gunton Drive Iceland de Betancourt, 17 P.O. Box 34535 Limited Westgate 28906 Getafe Seattle, WA...
  • Page 46 Igloo MAX - All sizes ITM. / ART. xx / COSTCO DISTRIBUTION Scan for: astreea.com/igloo...
