XBOX 360 Component HD AV Cable Instructions

X16-69674-02
1111 Part No. X16-69674-02
englisH
Xbox 360 Component HD AV Cable
Thanks for choosing the Xbox 360 Component HD AV Cable to connect your Xbox 360
®
console to component AV inputs on high definition TVs. It is for use exclusively with the
Xbox 360 video game and entertainment system.
!
WARning
Before using this product, read this manual and the Xbox 360 console instructions for
important safety and health information. Keep all manuals for future reference. For
replacement manuals, go to www.xbox.com/support.
ConneCt YouR Component HD AV CAble
Use your component HD AV cable to connect your console to your TV.
impoRtAnt
Stationary images in video games can "burn" into some TV screens, creating a permanent
shadow. Consult your TV owner's manual or manufacturer before playing games.
Connect to a High Definition tV
To connect your console to your high definition TV:
Turn off your console.
1
Connect the HD AV cable connector to the AV port on the console.
2
Connect the red, green and blue color-banded connectors on the HD AV cable to the
3
corresponding coulor inputs (Y, Cb/Pb, Cr/Pr) on your TV.
Connect the solid coloured left and right (white and red) audio connectors on the HD
4
AV cable to the audio inputs on your TV.
Select the appropriate video input for your TV. Common names for video input
5
include Input Select, Input, AUX, Line in, Line, In, Source, and EXT.
Turn on your console. From the system area, select the appropriate high definition
6
video setting for your TV.
tRoublesHooting
If you encounter problems, try the possible solutions provided below.
no picture
Turn on the TV. Select the TV video input that displays the game. Try resetting your
display settings. Remove any disc from the disc tray and turn off your console. Then press
and hold the Xbox Guide button on player one's controller to turn the console back on.
As it starts up, press and hold the Y button while pulling the right trigger. Your console
will return to its default display settings.
中文
Xbox 360
色差高解析
感謝您購買 Xbox 360 色差高解析 AV 端子線，用於連接您的 Xbox 360 主機與高畫質電
®
視的 AV 輸入。它僅可與 Xbox 360 視訊遊戲家庭娛樂系統搭配使用。
!
警告
在使用此產品前，請閱讀本手冊與 Xbox 360 手冊，以取得重要 的安全和健康資訊。
請妥善保存所有手冊，以供未來參考之用。如需更換手冊，請至 www.xbox.com/
support 網站。
AV
端子線
Component HD AV CAble
picture with no sound
If you are setting up HDTV for the first time, verify that your TV supports the HDTV
settings in the Xbox Dashboard. Make sure the video and audio connectors are connected
to the same input group on the back of your TV.
sound with no picture
Verify that the TV is turned on. Make sure the audio and video connectors are connected
to the same input group on the back of your TV. Make sure the TV has been set to display
video from the input group into which the HD AV cable video connectors are plugged.
no High Definition output
Make sure that the HDTV settings in the Xbox Dashboard are supported by your TV.
if You neeD moRe Help
For answers to common questions, troubleshooting steps, and Xbox Customer Support
contact information, visit www.xbox.com/support.
Do not take your Xbox 360 console or its accessories to your retailer for repair. Please visit
www.xbox.com/support for troubleshooting and service information.
Disposal of Waste batteries and electrical & electronic equipment
This symbol on the product or its batteries or its packaging means that this
product and any batteries it contains must not be disposed of with your
household waste. Instead, it is your responsibility to hand this over to an
applicable collection point for the recycling of batteries and electrical and
electronic equipment. This separate collection and recycling will help to conserve natural
resources and prevent potential negative consequences for human health and the
environment due to the possible presence of hazardous substances in batteries and
electrical and electronic equipment, which could be caused by inappropriate disposal. For
more information about where to drop off your batteries and electrical and electronic
waste, please contact your local city/municipality office, your household waste disposal
service, or the shop where you purchased this product.
This product is for use with NRTL-listed (UL, CSA, ETL, etc.) and/or IEC/EN 60950
compliant (CE marked) Information Technology equipment.
foR CustomeRs in tAiWAn
product information
Product name: Xbox 360 Component HD AV Cable
Model no.: Xbox 360 Component HD AV Cable
Country of origin: China
Manufacturer name: Microsoft Corporation
Importer name: Synnex Technology International
Importer's Address: 4th Fl. 75, Section 3, Min-Sheng E. Rd., Taipei 104
Importer's number: (02) 2506-3320
