Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Contacte con SAMSUNG WORLDWIDE Si tiene alguna pregunta o comentario referente a nuestros productos, por favor contacte con nuestro Servicio de Atención al Cliente.
Page 2
Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. (See back cover for more informations.) Precautions When Displaying a Still Image A still image may cause permanent damage to the TV screen •...
Contents GENERAL INfORMAtION ChANNEL CONtROL ■ List of Features ................2 ■ Adding and Erasing Channels ............ 31 ■ Accessories .................. 2 ■ Activating the Child Lock ............32 ■ Viewing the Control Panel ............3 ■ Fine Tuning Analog Channels ............ 33 ■...
General Information List of features Adjustable picture settings that can be stored in the TV’s memory. Automatic timer to turn the TV on and off. A special sleep timer. hDMI/DVI connection of your PC to this tV. ...
Viewing the Control Panel Buttons on the Lower-Right Part of the Panel The buttons on the lower-right panel control your TV’s basic features, including the on-screen menu. To use the more advanced features, you must use the remote control. Side Panel buttons The product color and shape may vary depending on the model.
Viewing the Connection Panel Use the connection panel jacks to connect A/V components that will be connected continuously, such as DVD players or a VCR. For more information on connecting equipment, see pages 6~11. [tV Rear Panel] The product color and shape may vary depending on the model. 1 PC IN [PC] / [AUDIO] 5 SERVICE Connects to the video and audio output jacks on your...
Remote Control You can use the remote control up to a distance of about 23 feet from the TV. 1 POWER @ SOURCE Turns the TV on and off. Press to display and select the available video sources. 2 tV Selects the TV mode directly. # PRE-Ch Tunes to the previous channel.
Installing Batteries in the Remote Control 1. Lift the cover at the back of the remote control upward as shown in the figure. 2. Install two AAA size batteries. Make sure to match the "+" and "–" ends of the batteries with the diagram inside the compartment. 3. Replace the cover.
Connecting Cable tV To connect to a cable TV system, follow the instructions below. Cable without a Cable Box 1. Plug the incoming cable into the ANT IN terminal on the back of the TV. ANT IN Because this TV is cable-ready, you do not need a cable box to view unscrambled cable channels. Connecting to a Cable Box that Descrambles All Channels 1. Find the cable that is connected to the ANT OUT terminal on your cable box.
Connecting a DVD Player or Cable Box/Satellite receiver (Set-top Box) via hDMI This connection can only be made if there is an HDMI Output connector on the external device. 1. C onnect an HDMI Cable DVD Player or Cable Box/Satellite receiver between the HDMI IN (1 or 2) (Set-top Box) Rear Panel jack on the TV and the HDMI...
Connecting a DVD Player or Cable Box/Satellite receiver (Set-top Box) via Component cables The rear panel jacks on your TV make it easy to connect a DVD Player or Cable Box/Satellite receiver (Set-Top Box) to your TV. 1. C onnect a Component Cable tV Rear Panel between the COMPONENT IN (1 or 2) [Y, P...
Connecting a VCR Video Connection These instructions assume that you have already connected your TV to an antenna or a cable TV system (according to the instructions on pages 6~7). Skip step 1 if you have not yet connected to an antenna or a cable system. 1. U nplug the cable or antenna from the back of the TV.
Connecting an Amplifier/DVD Home Theater 1. C onnect Audio Cables tV Rear Panel between the AUDIO OUT [R-AUDIO-L] jacks on the TV and AUDIO IN [R-AUDIO-L] Amplifier/DVD Home Theater jacks on the Amplifier/DVD Home Theater. When an audio amplifier is connected to the "AUDIO OUT [R-AUDIO-L]"...
Operation turning the tV On and Off Press the POWER button on the remote control. You can also use the POWER button on the TV. Plug & Play feature Plug & Play When the TV is initially powered on, basic settings proceed automatically and subsequently : Start Plug &...
If you want to reset this feature... 1. Press the MENU button to display the menu. Setup Press the ▲ or ▼ button to select "Setup", then press the ENtER button. Plug & Play ► Language : English ► time ►...
Viewing the Display The display identifies the current channel and the status of certain audio-video settings. 1. Press the INfO button on the remote control. Mono The TV will display the channel, the type of sound, Picture : Standard and the status of certain picture and sound settings. Sound : Custom : Stereo...
Memorizing the Channels Your TV can memorize and store all of the available channels for both "off-air" (Air) and "Cable" channels. After the available channels are memorized, use the Ch< or Ch> button to scan through the channels. This eliminates the need to change channels by entering the channel digits.
to Select the Source Use to select TV or other external input sources such as DVD players or Cable Box/ Input Satellite receivers (Set-Top Box) connected to the TV. Use to select the input source Source List : tV ► Edit Name ►...
Picture Control Changing the Picture Standard You can activate either Dynamic, Standard, Movie by making a selection from the menu. Picture 1. Press the MENU button to display the menu. Mode : Standard ► Backlight Contrast Press the ENtER button, to select “Picture”. Brightness Sharpness Color...
Adjusting the Detailed Settings Samsung's new TVs allow you to make even more precise picture settings than previous models. See below to adjust detailed picture settings. Activating Detailed Settings 1. Press the MENU button to display the menu. Picture Press the ENtER button to select “Picture”.
Page 21
Activating Gamma Detailed Settings You can adjust the Primary Color (Red, Green, Blue) Intensity. (-3 ~ +3) Black Adjust : Off ► Dynamic Contrast : Medium ► 8. Press the ▲ or ▼ button to select “Gamma”, then press the ENtER button.
Activating White Balance Detailed Settings Black Adjust : Off ► You can adjust the color temperature for more natural picture colors. Dynamic Contrast : Medium ► Gamma ► 17. Press the ▲ or ▼ button to select “White Balance”, then press the ENtER Color Space : Native ►...
Configuring Picture Options Activating Picture Options 1. Press the MENU button to display the menu. Picture Press the ENtER button, to select “Picture”. Mode : Standard ► Backlight Contrast 2. P ress the ▲ or ▼ button to select "Picture Options", then press the ENtER Brightness Sharpness button.
Page 24
When Double ( ) mode has been set in PIP, the Picture Size cannot ➣ Size be set. 6: Wide Zoom Temporary image retention may occur when viewing a static image on the set ➣ Zoom for more than two hours. Just Scan After selecting “Zoom”...
Page 25
Digital Noise Reduction If the broadcast signal received by your TV is weak, you can activate the Digital Noise Picture Options Reduction feature to help reduce any static and ghosting that may appear on the screen. Color Tone : Normal ►...
Setting the Blue Only Mode This function is for AV device measurement experts. This function displays the blue signal Picture Options only by removing the red and green signals from the video signal so as to provide a Blue Color Tone : Normal ►...
Viewing Picture-in-Picture You can use the PIP feature to simultaneously watch two video sources. (See page 30 to select the PIP picture sound.) This product has one built-in tuner, which does not allow PIP to function in the same mode. Please see ‘PIP Settings’ below for details.
Page 28
Changing the Position of the PIP Window 5. Press the ▲ or ▼ button to select “Position”, then press the ENtER button. Press the ▲ or ▼ button to select the required option, then press the ENtER : On Source : tV button.
Sound Control Changing the Sound Standard You can select the sound mode to best suit the programming you’re watching. 1. Press the MENU button to display the menu. Sound Press the ▲ or ▼ button to select "Sound", then press the ENtER button.
Setting the truSurround xt (SRS tS xt) TruSurround XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers. TruSurround delivers a compelling, virtual surround sound experience through any two-speaker playback system, including internal television speakers.
Choosing a Multi-Channel Sound (MtS) track Depending on the particular program being broadcast, you can listen to “Mono”, “Stereo” or “SAP”. 1. Press the MENU button to display the menu. Sound Press the ▲ or ▼ button to select "Sound", then press the ENtER button.
Setting the tV Speaker On/Off Sound output from the TV speakers is muted. Sound 1. Press the MENU button to display the menu. Mode : Custom ► Equalizer ► Press the ▲ or ▼ button to select "Sound", then press the ENtER button.
Channel Control Adding and Erasing Channels You can add or delete a channel so only channels you want are displayed. 1. Press the MENU button to display the menu. Channel Press the ▲ or ▼ button to select "Channel", then press the ENtER button.
Activating the Child Lock This feature allows you to prevent unauthorized users, such as children, from watching unsuitable programmes by muting out video and audio. Child Lock cannot be released using the buttons on the side. Only the remote control can release the Child Lock setting, so keep the remote control away from children.
fine tuning Analog Channels Use fine tuning to manually adjust a particular channel for optimal reception. 1. Press the MENU button to display the menu. Channel Press the ▲ or ▼ button to select "Channel", then press the ENtER button. Air / Cable : Air ►...
Windows and your particular video card. However, even if your actual screens look dif- ferent, the same basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.)
Setting up the tV with your PC how to Auto Adjust Use the Auto Adjust function to have the TV set automatically adjust the video signals it receives. The function also automatically fine-tunes the settings and adjusts the frequency values and positions. This function does not work in DVI-Digital mode.
Page 38
Changing the Screen Position Adjust the PC’s screen positioning if it does not fit the TV screen. Preset: Press the SOURCE button to select PC mode. Screen Coarse 1. Press the MENU button to display the menu. fine Position ► Press the ▲...
time Setting Setting the Clock Setting the clock is necessary in order to use the various timer features of the TV. Also, you can check the time while watching the TV. (Just press the INfO button.) 1. Press the MENU button to display the menu. Press the ▲...
Setting the Sleep timer The sleep timer automatically shuts off the TV after a preset time (30, 60, 90, 120, 150 and 180 minutes). 1. Press the MENU button to display the menu. Setup Press the ▲ or ▼ button to select "Setup", then press the ENtER button.
Setting the On/Off timer 1. Press the MENU button to display the menu. time Press the ▲ or ▼ button to select "Setup", then press the ENtER button. Clock Set : : 00 am ► Press the ▲ or ▼ button to select "Time", then press the ENtER button.
Viewing Closed Captions (On-Screen text Messages) The Analog Caption function operates when watching regular analog channels or when you have an analog external component (such as a VCR) connected. 1. Press the MENU button to display the menu. Setup Press the ▲ or ▼ button to select "Setup", then press the ENtER button.
Adjusting the tV On/Off Melody Sound A melody sound can be set to come on when the TV is powered On or Off. Setup 1. Press the MENU button to display the menu. Plug & Play ► Language : English ►...
Using the Energy Saving feature This feature adjusts the brightness of the TV in order to reduce power consumption. When watching TV at night, set the "Energy Saving" mode option to "High" to reduce eye fatigue as well as power consumption. 1. Press the MENU button to display the menu.
Appendix troubleshooting If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, call your nearest Samsung service center. Problem Possible Solution Poor picture. Try another channel.
Page 46
Problem Possible Solution Horizontal bars appear to flicker, Adjust the Coarse tuning and then adjust the Fine tuning. jitter or shimmer on the image. Vertical bars appear to flicker, Adjust the Coarse tuning and then adjust the Fine tuning. jitter or shimmer on the image. Screen is black and power On your computer check: Power, Signal Cable.
Installing the Stand 1. Attach your LCD TV to the stand. Two or more people should carry the TV. ➣ Make sure to distinguish between the front and back of the stand when attaching it. ➣ To make sure the TV is installed on the stand at a proper level, do not apply excess downward pressure to the upper left ➣...
Do not use fasten the screws too strongly, this may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
Using the Anti-theft Kensington Lock (depending on the model) The Kensington Lock is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for proper use.
Page 53
Contenido Información General Control de los Canales Listado de características ..........2 Adición y supresión de canales ........31 ■ ■ Accesorios ...............2 Activación del bloqueo infantil ........32 ■ ■ Aspecto general del panel de control ......3 Sintonización fina de los canales analógicos ....33 ■...
Información General Listado de características Valores ajustables de la imagen que se pueden almacenar en la memoria del televisor. Temporizador automático para encender o apagar el televisor. Temporizador de desconexión especial. Conexión HDMI/DVI del PC con este televisor. ...
Aspecto general del panel de control Botones de la parte inferior derecha del panel Los botones del panel inferior derecho controlan las funciones básicas del televisor, incluido el menú en pantalla. Para usar las funciones más avanzadas, debe usar el mando a distancia. Botones del panel lateral El color y la forma del producto pueden variar según el modelo.
Aspecto general del panel de conexiones Se pueden usar para conectar componentes de A/V que estarán conectados permanentemente, como reproductores de vídeo o de DVD. Si precisa información sobre la conexión de equipos, consulte las páginas 6 a 11. [Panel posterior del TV] El color y la forma del producto pueden variar según el modelo.
Mando a distancia Puede usar el mando a distancia desde una distancia máxima de alrededor de 7 metros desde el TV. 1 POWER @ SOURCE Enciende o apaga el TV. Pulse este botón para ver y seleccionar las fuentes de vídeo 2 TV disponibles.
Instalación de las pilas en el mando a distancia . Levante la tapa de la parte posterior del mando a distancia, como se muestra en la ilustración. . Coloque dos pilas de tamaño AAA. Compruebe que los extremos “+” y “-” de las pilas concuerdan con el diagrama del interior del compartimiento.
Conexión de TV por cable Para conectar a un sistema de TV por cable, siga estas instrucciones. TV por cable sin decodificador ANT IN . Conecte el cable de entrada en la terminal de la antena ANT IN de la parte posterior del Dado que el TV está...
Conexión de un reproductor de DVD o receptores de televisión por cable/ satélite (decodificadores) a través de HDMI Solo es aplicable si hay un conector de salida de HDMI en el dispositivo externo. . Conecte un cable de HDMI Reproductor de DVD/ entre el conector de HDMI receptor de cable/satélite (decodificador)
Conexión de un reproductor de DVD o receptores de televisión por cable/ satélite (decodificadores) a través de los cables de componente Las tomas del panel posterior del televisor facilitan la conexión de un reproductor de DVD o un receptor de televisión por cable/ satélite (decodificador) al TV.
Conexión de un reproductor de vídeo Conexión de vídeo Estas instrucciones presuponen que ya ha conectado el TV a una antena o sistema de TV por cable (siguiendo las instrucciones de las páginas 6~7). Si aún no ha conectado el TV a una antena o un sistema de cable, sáltese el paso 1. .
Conexión de un amplificador/DVD para cine en casa . Conecte un cable de audio Panel posterior del TV entre las tomas AUDIO OUT [R-AUDIO-L] del televisor y Amplificador/DVD para las tomas AUDIO IN Cine en casa [R-AUDIO-L] del amplificador/ DVD para cine en casa. Cuando un amplificador de audio se conecta a las terminales “AUDIO OUT...
Funcionamiento Encendido o apagado del TV Pulse el botón POWER del mando a distancia. También puede usar el botón POWER del panel delantero. Función Plug & Play Cuando se enciende el televisor por primera vez, se configuran seguidos y automáticamente dos ajustes básicos del usuario. Plug &...
Si quiere volver a ajustar esta característica... Configuración . Pulse el botón MENU para ver el menú. Plug & Play ► Idioma : Español ► Pulse los botones o para seleccionar “Configuración” y pulse el botón Tiempo ► Subtítulo ►...
Visualización de la pantalla La pantalla identifica el canal actual y el estado de algunos ajustes de audio-vídeo. Aire Mono . Pulse el botón INFO del mando a distancia. El TV visualizará el canal, el tipo de sonido y el estado de determinados ajustes de Imagen : Normal sonido e imagen.
Memorización de los canales El televisor puede memorizar y almacenar todos los canales disponibles, tanto de “aire” (antena) como de “cable”. Una vez memorizados los canales disponibles, use los botones CH< o CH> para explorarlos. De este modo, no es necesario introducir dígitos para cambiar los canales.
Para seleccionar la fuente Úselo para seleccionar TV u otras fuentes de entrada externas como reproductores de DVD o receptores de cable y satélite (decodificadores), conectados al televisor. Permite seleccionar la fuente de entrada que se prefiera. . Pulse el botón MENU para ver el menú en pantalla. Entrada Pulse los botones ...
Control de la Imagen Cambio del formato de la imagen Puede activar el ajuste Dinámico, Normal o Cine seleccionándolo en el menú. . Pulse el botón MENU para ver el menú en pantalla. Imagen Pulse el botón ENTER para seleccionar “Imagen”. Modo : Normal ►...
Ajuste de la configuración detallada Los nuevos televisores Samsung permiten una configuración más precisa de la imagen que los modelos anteriores. Consulte más adelante cómo realizar una configuración detallada. Activación de la configuración detallada . Pulse el botón MENU para ver el menú en pantalla.
Page 71
Activación de Gamma Se puede ajustar la intensidad de los colores primarios (rojo, verde y azul). (-3 ~ +3) Configuración detallada Ajuste del negro : Apagado ► Contraste Dinám. : Medio ► . Pulse los botones ▲ o ▼ para seleccionar “Gamma” y pulse el botón ENTER Gamma ►...
Page 72
Activación de Balance de blanco Se puede ajustar la temperatura del color para conseguir colores más naturales. Configuración detallada . Pulse los botones ▲ o ▼ para seleccionar “Bal. blanco” y, a continuación, pulse el Ajuste del negro : Apagado ►...
Activación de las opciones de la imagen Activación de las opciones de la imagen Imagen . Pulse el botón MENU para ver el menú en pantalla. Modo : Normal ► Pulse el botón ENTER para seleccionar “Imagen”. Luz de fondo Contraste .
Page 74
Si se ha seleccionado el modo doble ( ) en el menú PIP, el tamaño de Tamaño la imagen no se puede definir. 6: Zoom ancho Puede producirse una retención temporal de imagen cuando se ve una imagen Zoom estática durante más de dos horas. Sólo buscar Después de seleccionar “Zoom”: Seleccione pulsando los botones...
Page 75
Reducción digital de ruido Si la señal de emisión que recibe el televisor es débil, puede activarse la función Opciones de imagen de reducción digital de ruido (Digital Noise Reduction) para reducir la estática y las Tono Color : Normal ►...
Configuración del modo sólo azul Esta función es para expertos en la medición de dispositivos AV. Esta función muestra Opciones de imagen sólo una señal azul ya que se eliminan las señales rojas y verdes de la señal de vídeo a Tono Color : Normal ►...
Visualización Imagen en imagen Para mirar dos fuentes simultáneamente, puede utilizar la función PIP. (Consulte la página 30 para seleccionar el sonido de la imagen PIP.) Este producto lleva un sintonizador incorporado que no permite la función PIP en el mismo modo. En el apartado ‘Configuración de PIP’...
Page 78
Cambio de la posición de la ventana PIP . Pulse los botones o para seleccionar “Posición” y, después, pulse el botón ENTER . Pulse los botones ▲ o ▼ para seleccionar la opción necesaria y, a : Encendido Origen : TV continuación, pulse ENTER...
Control de Sonido Cambio del estándar de sonido Puede seleccionar el modo de sonido que mejor se ajuste al programa que está viendo. . Pulse el botón MENU para ver el menú en pantalla. Pulse los botones o Sonido para seleccionar “Sonido”...
Configuración del TruSurround XT (SRS TS XT) TruSurround XT es una tecnología SRS patentada que solventa el problema de reproducir audio multicanal 5,1 en dos altavoces. Trusurround proporciona una experiencia de sonido virtual convincente a través de cualquier sistema de reproducción con dos altavoces.
Selección de una pista de sonido multicanal (MTS) Según el programa concreto emitido, puede escuchar en “Mono”, “Estéreo” o “SAP”. . Pulse el botón MENU para ver el menú en pantalla. Sonido Pulse los botones ▲ o ▼ para seleccionar “Sonido” y, después, pulse el botón Modo : Favorito ►...
Encendido/apagado del altavoz del televisor Se silencia la salida de sonido desde los altavoces del televisor. Sonido . Pulse el botón MENU para ver el menú en pantalla. Modo : Favorito ► Ecualizador ► SRS TS XT : Apagado ► Pulse los botones ...
Control de los Canales Adición y supresión de canales Puede agregar o suprimir un canal de manera que sólo se visualicen los canales que desee. . Pulse el botón MENU para ver el menú en pantalla. Canal Pulse los botones o para seleccionar "Canal” y, a continuación, pulse el Aire/Cable : Aire ►...
Activación del bloqueo infantil Esta función permite bloquear el vídeo y el audio para evitar que los usuarios no autorizados (por ejemplo, los niños) puedan ver programas poco recomendables. El bloqueo infantil no se puede desactivar mediante los botones del panel lateral. Mantenga el mando a distancia alejado de los niños, puesto que sólo mediante éste se puede desactivar el bloqueo infantil.
Sintonización fina de los canales analógicos Utilice el ajuste preciso para sintonizar manualmente un canal concreto para que la recepción sea óptima. . Pulse el botón MENU para visualizar el menú. Canal Pulse los botones o para seleccionar “Canal” y, después, pulse el botón Aire/Cable : Aire ►...
(Si no es así, póngase en contacto con el fabricante del ordenador o con un concesionario Samsung.) . Primero, haga clic en “Panel de control” en el menú Inicio de Windows.
Ajuste del televisor con el ordenador Cómo realizar el Ajuste automático Utilice la función de Ajuste automático para que el aparato de TV ajuste automáticamente las señales de vídeo que el monitor recibe. La función también ajusta automáticamente con más configuración y ajusta los valores y las posiciones de la frecuencia. Esta función no está...
Page 88
Cambio de la posición de la pantalla Ajuste la posición de la pantalla del PC si no se acopla a la pantalla del TV. Pantalla Grueso Preselección: Pulse el botón SOURCE para seleccionar el modo PC. Fino Posición ► Reiniciar Imagen ►...
Ajuste de la Hora Configuración del Reloj Establecer el reloj es necesario para usar las distintas características de temporizador del TV. Además, puede comprobar la hora mientras está viendo el TV. (Simplemente pulse INFO.) . Pulse el botón MENU para ver el menú en pantalla. Configuración Pulse los botones ▲...
Configuración del Temporizador de sueño El temporizador de desconexión apaga automáticamente el televisor después de un período prefijado (entre 30, 60, 90, 120, 150, 180 minutos). . Pulse el botón MENU para ver el menú en pantalla. Configuración Plug & Play ►...
Activación y desactivación del temporizador Pulse el botón MENU para ver el menú. Tiempo Pulse los botones ▲ o ▼ para seleccionar “Configuración” y, a continuación, pulse Config. Reloj : : 00 am ► Temporizador : Apagado ► el botón ENTER Temporizador : Apagado ►...
Visualización de subtítulos (mensajes de texto en pantalla) La función Subtítulo está activa cuando se ven canales analógicos normales o cuando se ha conectado un componente análogico externo, por ejemplo, un aparato de vídeo. . Pulse el botón MENU para ver el menú en pantalla. Configuración Plug &...
Ajuste de la melodía de encendido y apagado del televisor Puede oír la melodía cuando la televisión se enciende o se apaga. . Pulse el botón MENU para ver el menú en pantalla. Configuración Pulse los botones o para seleccionar “Configuración” y, después, pulse el Plug &...
Uso de la función de ahorro de energía Esta función ajusta el brillo del televisor, lo cual reduce el consumo de energía. Si desea ver la televisión por la noche, ajuste la opción del modo “Ahorro energía” en “Alto” sus ojos se lo agradecerán y, además, reducirá el consumo de energía. .
Apéndice Identificación de problemas Si parece que el TV no funciona correctamente, en primer lugar compruebe esta lista de posibles problemas y soluciones. Si no funciona ninguno de estos consejos, llame al centro de servicio más cercano. Problema Posible Solución Imagen deficiente Intente sintonizar otro canal.
Page 96
Problema Posible Solución Unas barras horizontales Ajuste la función Grueso y después ajuste la función Fino. parpadean, tiemblan u oscilan en la imagen. Unas barras verticales parpadean, Ajuste la función Grueso y después ajuste la función Fino. tiemblan u oscilan en la imagen. Unas barras verticales parpadean, Compruebe lo siguiente en el equipo: Alimentación, Cable de señal.
Instalación del soporte . Acople el TV LCD al soporte. El televisor lo deben transportar dos o más personas. Cuando monte el soporte debe distinguir entre la parte frontal y la posterior del soporte. Para asegurarse de que instala el televisor en el soporte al nivel adecuado, no aplique una presión excesiva en la parte superior izquierda y derecha del televisor.
Samsung no se hace responsable de este tipo de accidentes. Samsung no se hace responsable de daños o lesiones personales cuando se usa un montaje mural que no cumple las especificaciones VESA o si el cliente no sigue las instrucciones de instalación del producto.
Uso del cierre antirrobo kensington (dependiendo del modelo) El bloqueo Kensington es un dispositivo que se usa para fijar físicamente el sistema cuando se usa en un lugar público. La apariencia y el método de bloqueo pueden diferir de la ilustración según los fabricantes. Consulte el manual que acompaña al bloqueo Kensington para utilizarlo correctamente.
Especificaciones Nombre del Modelo LN6A0J LNA0J LN0A0J Tamaño de pantalla (Diagonal) 26 pulg. 32 pulg. 40 pulg. PC Resolución 1360 x 768 @ 60 Hz 1360 x 768 @ 60 Hz 1360 x 768 @ 60 Hz Sonido 5W x 2 10W x 2 10W x 2 Salida...
