Samsung LN26A330 User Manual

Samsung LN26A330 User Manual

330 series lcd tv
Hide thumbs Also See for LN26A330:

Advertisement

Available languages

Available languages

Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG
customer care center.
Comment contacter Samsung dans le monde
Si vous avez des suggestions ou des questions concernant les produits Samsung, veuillez contacter le Service
Consommateurs Samsung.
Country
Customer Care Center
Web Site
CANADA
1-800-SAMSUNG(726-7864)
www.samsung.com/ca
U.S.A
1-800-SAMSUNG(726-7864)
www.samsung.com
Address
Samsung Electronics Canada Inc., Customer
Service 55 Standish Court Mississauga,
Ontario L5R 4B2 Canada
Samsung Electronique Canada Inc.,
Service à la Clientèle 55 Standish Court
Mississauga, Ontario L5R 4B2 Canada
Samsung Electronics America, Inc.
105 Challenger Road
Ridgefield Park, NJ 07660-0511
BN68-01514B-00
LCD TV

user manual

imagine the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service, please
register your product at
www.samsung.com/global/register
Model
Serial No.

Advertisement

loading

Summary of Contents for Samsung LN26A330

  • Page 1: User Manual

    If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Comment contacter Samsung dans le monde Si vous avez des suggestions ou des questions concernant les produits Samsung, veuillez contacter le Service Consommateurs Samsung. Country...
  • Page 2: Important Warranty Information Regarding Television Format Viewing

    (SAMSUNG) products, and the requirements, conditions, exclusions and limitations contained herein, SAMSUNG will additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on SAMSUNG products purchased in the United States, for the warranty period originally specified, and to the Original Purchaser only.
  • Page 3: Table Of Contents

    Contents GENERAL INFORMATION PC DISPLAY ■ List of Features ................2 ■ Using Your TV as a Computer (PC) Display ....... 34 ■ Accessories .................. 2 ■ Display Modes ................34 ■ Viewing the Control Panel ............3 ■ Setting up the TV with your PC ..........35 ■...
  • Page 4: General Information

    General Information List of Features  Adjustable picture settings that can be stored in the TV’s memory.  Automatic timer to turn the TV on and off.  A special sleep timer.  Excellent Digital Interface & Networking : With a built-in HD digital tuner, non-subscription HD broadcasts can be viewed with no Cable Box/Satellite receiver (Set-Top Box) needed.
  • Page 5: Viewing The Control Panel

    Viewing the Control Panel Buttons on the Lower-Right Part of the Panel The buttons on the lower-right panel control your TV’s basic features, including the on-screen menu. To use the more advanced features, you must use the remote control. Side Panel buttons The product color and shape may vary depending on the model.
  • Page 6: Viewing The Connection Panel

    Viewing the Connection Panel Use the connection panel jacks to connect A/V components that will be connected continuously, such as DVD players or a VCR. For more information on connecting equipment, see pages 6~12. The product color and shape may vary depending on the model. 1 AUDIO OUT 7 SERVICE Connects to the audio input jacks on your Amplifier/...
  • Page 7: Remote Control

    Remote Control You can use the remote control up to a distance of about 23 feet from the TV. @ MTS 1 POWER Turns the TV on and off. Press to choose stereo, mono or Separate Audio Program 2 TV (SAP broadcast). Selects the TV mode directly.
  • Page 8: Installing Batteries In The Remote Control

    Installing Batteries in the Remote Control 1. Lift the cover at the back of the remote control upward as shown in the figure. 2. Install two AAA size batteries. Make sure to match the "+" and "–" ends of the batteries with the diagram inside the compartment. 3. Replace the cover.
  • Page 9: Connecting Cable Tv

    Connecting Cable TV To connect to a cable TV system, follow the instructions below. Cable without a Cable Box 1. Plug the incoming cable into the ANT IN terminal on the back of the TV. ANT IN Because this TV is cable-ready, you do not need a cable box to view unscrambled cable channels. Connecting to a Cable Box that Descrambles All Channels 1. Find the cable that is connected to the ANT OUT terminal on your cable box.
  • Page 10: Connecting A Dvd Player Or Cable Box/Satellite Receiver (Set-Top Box) Via Hdmi

    Connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box) via HDMI This connection can only be made if there is an HDMI Output connector on the external device. 1. C onnect an HDMI Cable DVD Player or Cable Box/Satellite receiver between the HDMI IN (1 or 2) TV Rear Panel (Set-Top Box) Rear Panel...
  • Page 11: Connecting A Dvd Player Or Cable Box/Satellite Receiver (Set-Top Box) Via Component Cables

    Connecting a DVD Player or Cable Box/Satellite receiver (Set-Top Box) via Component cables The rear panel jacks on your TV make it easy to connect a DVD Player or Cable Box/Satellite receiver (Set-Top Box) to your TV. 1. C onnect a Component Cable TV Rear Panel between the COMPONENT IN (1 or 2) [Y, P...
  • Page 12: Connecting A Vcr

    Connecting a VCR Video Connection These instructions assume that you have already connected your TV to an antenna or a cable TV system (according to the instructions on pages 6~7). Skip step 1 if you have not yet connected to an antenna or a cable system. 1. U nplug the cable or antenna from the back of the TV.
  • Page 13: Connecting A Digital Audio System

    Connecting a Digital Audio System The rear panel jacks on your TV make it easy to connect a Digital Audio System (Home theater/Receiver) to your TV. 1. C onnect an Optical Cable Digital Audio System between the “DIGITAL AUDIO TV Rear Panel OUT (OPTICAL)”...
  • Page 14: Connecting A Pc

    Connecting a PC Using the D-Sub Cable 1. C onnect a D-Sub Cable TV Rear Panel between PC IN [PC] connector on the TV and the PC output connector on your computer. 2. C onnect a PC Audio Cable between the PC IN [AUDIO] jack on the TV and the Audio Out jack of the sound card on...
  • Page 15: Operation

    Operation Turning the TV On and Off Press the POWER button on the remote control. You can also use the POWER button on the TV. Plug & Play Feature Plug & Play When the TV is initially powered on, basic settings proceed automatically and subsequently.
  • Page 16: Changing Channels

    Auto Program Plug & Play Auto Program is completed. 7 Channels are memorized. DTV Air : 24 Air : 1 DTV Cable : 17 Cable :  Enter Skip 6. Press the ENTER button. Plug & Play Press the ▲ or ▼ button to select “Auto”, then Press the ENTER button.
  • Page 17: Adjusting The Volume

    Using the Button button is used to select stations that broadcast a digital signal. 1. F or example, for Channel 7-1, press 7, then , then 1. HD indicates the TV is receiving a Digital High Definition signal. SD indicates the TV is receiving a Standard Definition signal.
  • Page 18: Using The Tools Button

    Using the TOOLS Button You can use the Tools button to select your frequently used functions quickly and easily. The “Tools” menu changes depending on which external input mode you are viewing. 1. P ress the TOOLS button. The “Tools” menu will appear. 2. Press the ▲...
  • Page 19 Storing Channels in Memory (Automatic Method) 1. Press the MENU button to display the menu. Channel Press the ▲ or ▼ button to select “Channel”, then press the ENTER button. Antenna : Air ► 2. Press the ▲ or ▼ button to select "Auto Program", then press the ENTER Auto Program ►...
  • Page 20: To Select The Source

    To Select the Source Use to select TV or other external input sources such as DVD players or Cable Box/ Input Satellite receivers (Set-Top Box) connected to the TV. Use to select the input source Source List : TV ► of your choice.
  • Page 21: Picture Control

    Picture Control Changing the Picture Standard You can activate either Dynamic, Standard, Movie by making a selection from the menu. 1. Press the MENU button to display the menu. Picture Press the ENTER button, to select “Picture”. Mode : Standard ►...
  • Page 22: Configuring Picture Options

    Configuring Picture Options Activating Picture Options 1. Press the MENU button to display the menu. Press the ENTER button, to select “Picture”. Picture 2. P ress the ▲ or ▼ button to select "Picture Options", then press the ENTER ▲...
  • Page 23 Temporary image retention may occur when viewing a static image on the set ➣ Size for more than two hours. 16 :  Zoom1 After selecting “Zoom1”, “Zoom2” or “Wide Fit”: Position Reset ➣ Zoom2 Press the ◄ or ► button to select “Position”, then press the ENTER button.
  • Page 24 Setting the Digital Noise Reduction If the broadcast signal received by your TV is weak, you can activate the Digital Noise Picture Options Reduction feature to help reduce any static and ghosting that may appear on the screen. Color Tone : Normal ►...
  • Page 25: Resetting The Picture Settings To The Factory Defaults

    Resetting the Picture Settings to the Factory Defaults 1. Press the MENU button to display the menu. Picture Press the ENTER button, to select “Picture”. ▲ More Picture Options 2. Press the ▲ or ▼ button to select "Reset", then press the ENTER button.
  • Page 26: Sound Control

    Sound Control Changing the Sound Standard You can select the sound mode to best suit the programming you’re watching. 1. Press the MENU button to display the menu. Sound Press the ▲ or ▼ button to select "Sound", then press the ENTER button.
  • Page 27: Setting The Trusurround Xt

    Setting the TruSurround xT TruSurround XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers. TruSurround delivers a compelling, virtual surround sound experience through any two-speaker playback system, including internal television speakers. It is fully compatible with all multichannel formats. 1. Press the MENU button to display the menu.
  • Page 28: Choosing A Multi-Channel Sound (Mts) Track - Analog

    Choosing a Multi-Channel Sound (MTS) track - Analog Multi-Track Sound Multi-Track Options 1. Press the MENU button to display the menu. Preferred Language : English ► Press the ▲ or ▼ button to select "Sound", then press the ENTER button. Multi-Track Sound : Stereo ►...
  • Page 29: Setting The Tv Speakers On/Off

    Setting the TV Speakers On/Off Sound output from the TV speakers is muted. Sound 1. Press the MENU button to display the menu. Mode : Custom ► Press the ▲ or ▼ button to select "Sound", then press the ENTER button.
  • Page 30: Channel Control

    Channel Control Clearing Scrambled Channels - Digital The Clear Scrambled Channel function is used to filter out scrambled channels after Auto Program is completed. This process may take up to 20~30 minutes. 1. Press the MENU button to display the menu. Channel Press the ▲...
  • Page 31: Adding And Erasing Channels

    Adding and Erasing Channels Using this menu, you can Add/Delete or set Favorite channels and use the program guide for digital broadcasts. To use the Channel List function, first run “Auto Program” (see page 17). 1. Press the MENU button to display the menu. Channel Press the ▲...
  • Page 32: To Set-Up Your Favorite Channels

    To Set-Up Your Favorite Channels You can set channels you watch frequently as favorites. 1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select "Channel", then press the ENTER button. Channel Antenna : Cable ►...
  • Page 33: Viewing The Channel Lists

    Viewing the Channel Lists You can display a list of all channels, added channels or your favorite channels. Channel 1. Press the MENU button to display the menu. Antenna : Cable ► Press the ▲ or ▼ button to select "Channel", then press the ENTER button.
  • Page 34: Labeling Channels

    Labeling Channels Channels can be labeled so that their call letters appear whenever the channel is selected. Channel 1. Press the MENU button to display the menu. Antenna : Air ► Press the ▲ or ▼ button to select “Channel”, then press the ENTER button.
  • Page 35: Fine Tuning Analog Channels

    Fine Tuning Analog Channels Use fine tuning to manually adjust a particular channel for optimal reception. 1. Press the MENU button to display the menu. Channel Press the ▲ or ▼ button to select "Channel", then press the ENTER button. Antenna : Air ►...
  • Page 36: Pc Display

    Windows and your particular video card. However, even if your actual screens look different, the same basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) 1. First, click on "Control Panel"...
  • Page 37: Setting Up The Tv With Your Pc

    Setting up the TV with your PC How to Auto Adjust Use the Auto Adjust function to have the TV set automatically adjust the video signals it receives. The function also automatically fine-tunes the settings and adjusts the frequency values and positions. This function does not work in DVI-Digital mode.
  • Page 38 Changing the Screen Position Adjust the PC’s screen positioning if it does not fit the TV screen. Preset: Press the SOURCE button to select PC mode. Screen Image Lock ► 1. Press the MENU button to display the menu. Position ►...
  • Page 39: Time Setting

    Time Setting Setting the Clock Setting the clock is necessary in order to use the various timer features of the TV. Also, you can check the time while watching the TV. (Just press the INFO button.) Option 1: Setting the Clock Manually 1. Press the MENU button to display the menu.
  • Page 40 Option 2: Setting the Clock Automatically The Clock can be set automatically if you are receiving a digital signal. Setup Plug & Play ► 1. Press the MENU button to display the menu. Language : English ► Press the ▲ or ▼ button to select "Setup", then press the ENTER button.
  • Page 41: Setting The Sleep Timer

    Setting the Sleep Timer The sleep timer automatically shuts off the TV after a preset time (30, 60, 90, 120, 150 and 180 minutes). 1. Press the MENU button to display the menu. Time Press the ▲ or ▼ button to select "Setup", then press the ENTER button.
  • Page 42: Function Description

    Setting the On/Off Timer 1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select "Setup", then press the ENTER button. Time Press the ▲ or ▼ button to select "Time", then press the ENTER button.
  • Page 43: Using The V-Chip

    Using the V-Chip The V-Chip feature automatically locks out programs that are deemed inappropriate for children. The user must enter a PIN (personal ID number) before any of the V-Chip restrictions are set up or changed. “V-Chip” function is not available in HDMI, component or PC mode. The Screen Saver is activated if there is no remote control key input for longer than 1 minute while setting up the “V-Chip”.
  • Page 44 How to Enable/Disable the V-Chip 1. Press the MENU button to display the menu. Setup Press the ▲ or ▼ button to select "Setup", then press the ENTER button. Plug & Play ► Language : English ► 2. Press the ▲ or ▼ button to select “V-Chip”, then press the ENTER button.
  • Page 45 3. The “V-Chip” screen will appear. Press the ▲ or ▼ button to select “TV Parental V-Chip Guidelines”, then press the ENTER button. V-Chip Lock : On ► TV Parental Guidelines ► MPAA Rating ► Canadian English ► Canadian French ►...
  • Page 46 How to Set up Restrictions Using the MPAA Ratings: G, PG, PG-1, R, NC-17, x, NR The MPAA rating system uses the Motion Picture Association of America (MPAA) system and its main application is for movies. When the V-Chip lock is on, the TV will automatically block any programs that are coded with objectionable ratings (either MPAA or TV-Ratings).
  • Page 47 How to Set up Restrictions Using the ‘Canadian English’ 1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select “Setup”, then press the ENTER button. Setup Plug & Play ► 2. Press the ▲ or ▼ button to select “V-Chip”, then press the ENTER button.
  • Page 48 How to Set up Restrictions Using the ‘Canadian French’ 1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select “Setup”, then press the ENTER button. Setup Plug & Play ► 2. Press the ▲ or ▼ button to select “V-Chip”, then press the ENTER button.
  • Page 49 Using the V-Chip for Digital channels Parental restriction information can be used while watching DTV channels. 1. Press the MENU button to display the menu. Setup Plug & Play ► Press the ▲ or ▼ button to select “Setup”, then press the ENTER button.
  • Page 50: Viewing Closed Captions (On-Screen Text Messages) - Analog

    Viewing Closed Captions (On-Screen Text Messages) - Analog The Analog Caption function operates in either analog TV channel mode or when a signal is supplied from an external device to TV. (Depending on the broadcasting signal, the Analog Caption function may operate on digital channels.) 1. Press the MENU button to display the menu.
  • Page 51: Viewing Closed Captions (On-Screen Text Messages) - Digital

    Viewing Closed Captions (On-Screen Text Messages) - Digital The Digital Captions function operates on digital channels. 1. Press the MENU button to display the menu. Press the ▲ or ▼ button to select “Setup”, then press the ENTER button. Caption 2. Press the ▲...
  • Page 52: Adjusting The Tv On/Off Melody Sound

    Adjusting the TV On/Off Melody Sound A melody sound can be set to come on when the TV is powered On or Off. Setup 1. Press the MENU button to display the menu. Plug & Play ► Press the ▲ or ▼ button to select "Setup", then press the ENTER button.
  • Page 53: Upgrading The Software

    Upgrading the Software Samsung may offer upgrades for TV's firmware in the future. Please contact the Samsung call center at 1-800-SAMSUNG (726-7864) to receive information about downloading upgrades and using a USB drive. Upgrades will be possible by connecting a USB drive to the USB port located on your TV.
  • Page 54: Appendix

    Appendix Troubleshooting If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, call Samsung customer service at 1-800-SAMSUNG. Problem Possible Solution Poor picture Try another channel.
  • Page 55 Problem Possible Solution Horizontal bars appear to flicker, Adjust the Coarse tuning and then adjust the Fine tuning. jitter or shimmer on the image. Vertical bars appear to flicker, Adjust the Coarse tuning and then adjust the Fine tuning. jitter or shimmer on the image. Screen is black and power On your computer check: Power, Signal Cable.
  • Page 56: Installing The Stand

    Installing the Stand 1. Attach your LCD TV to the stand. Two or more people should carry the TV. ➣ Make sure to distinguish between the front and back of the stand when attaching it. ➣ To make sure the TV is installed on the stand at a proper level, do not apply excess downward pressure to the upper left ➣...
  • Page 57: Auto Wall-Mount Adjustment (Sold Separately)

    Auto Wall-Mount Adjustment (Sold separately) (LN2A0J1D, LN7A0J1D, LN40A0J1D) Once the auto wall mount is installed, your TV’s position can be easily adjusted. Auto Wall-Mount TV Rear Panel Ex-LINK Cable (Not supplied) Entering the menu 1. Press the ▲, ▼, ◄ or ► button on your remote control. External Settings Melody : Medium...
  • Page 58: Wall Mount Kit Specifications (Vesa)

    Do not use fasten the screws too strongly, this may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
  • Page 59: Using The Anti-Theft Kensington Lock

    Using the Anti-Theft Kensington Lock The Kensington Lock is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for proper use.
  • Page 60: Specifications

    Specifications Model Name LN26A0J1D LN2A0J1D Screen Size (Diagonal) 26 inches 32 inches PC Resolution 1360 x 768 @ 60 Hz 1360 x 768 @ 60 Hz Sound Output 5W x 2 10W x 2 Dimensions (WxDxH) Body 29.3 X 3.1 X 17.6 inches 34.4 X 3.2 X 20.9 inches (743.8 X 79.8 X 447.4 mm) (874 X 81 X 531 mm)
  • Page 61: Dimensions

    NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors. © 2008 Samsung Electronics America, Inc. English - ...
  • Page 62 NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors. © 2008 Samsung Electronics America, Inc. English - 60...
  • Page 63 NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors. © 2008 Samsung Electronics America, Inc. English - 61...
  • Page 64 NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors. © 2008 Samsung Electronics America, Inc. English - 62...
  • Page 65 TÉLÉVISEUR ACL Guide de l’utilisateur Imaginez les possibilités Merci d’avoir acheté un produit Samsung. Pour obtenir un service complet, veuillez enregistrer votre produit à : www.samsung.com/global/register Modèle N° de série...
  • Page 66 Assujettie aux exigences, conditions, exclusions et limitations de la garantie limitée originale fournie avec les produits de Samsung Electronics (SAMSUNG) et les exigences, conditions, exclusions et limitations de la présente garantie, SAMSUNG offrira en plus un service de réparation sous garantie aux États-Unis pour les produits achetés au Canada et un service de réparation sous garantie au Canada pour les produits achetés aux États-Unis pendant la période de garantie précisée à...
  • Page 67 Table des matières InFormaTIons générales ConTrôle des Chaînes ■ Liste des fonctions ................2 ■ Suppression des canaux brouillés – canaux numériques ..... 28 ■ Accessoires ..................2 ■ Ajout et suppression de chaînes ........... 29 ■ Présentation du panneau de commande ........3 ■...
