SR Research EyeLink Portable Duo Quick Start Manual

1 Basic PC Setup
With the Laptop Host PC (included) powered off, connect its power supply. Set up the basic components of the Display PC
as you would any other computer. The Display PC can be any modern Windows (7 or 10), macOS (Intel Mac 10.6.8 or
later), or Linux PC with an Ethernet port, and may have been op琀椀onally acquired from SR Research.
Surge Protector
Laptop Host PC
4
Host PC to Display PC Connec琀椀on
Using the Ethernet cable supplied, connect the Host PC
Ethernet port to an Ethernet port on your Display PC.
Configure that Display PC Ethernet port with the
following sta琀椀c IP address:
IP Address: 100.1.1.2 Subnet Mask: 255.255.255.0
Leave the default gateway and other se琀�ngs blank.
See Chapter 6 of the EyeLink Portable Duo Installa琀椀on Guide for detailed instruc琀椀ons
EyeLink Portable Duo Quick Start Guide R
Laptop Host PC with Tripod Mount
Use the port on the le昀琀
Display PC
EyeLink® Portable Duo
5
Test that the Setup is Working
Turn on the Host PC to verify that the Host
Applica琀椀on starts. Once the Host PC is up and
running you should see the Camera Setup
screen.
Display PC
A琀琀ach the Tripod to the Camera
2 2
Align the tripod screw with the 1/4" moun琀椀ng hole
on the bo琀琀om of the camera. Turn the rota琀椀ng wheel
on the tripod un琀椀l the tripod is firmly a琀琀ached to
3
the camera.
Camera Connec琀椀on
3
Connect both plugs at the end of the eye tracker's cable into the USB 3.0
ports on the Host PC.
To exit to the File Manager from the Host Applica琀椀on, press Ctrl-Alt-Q (or click the "Exit"
bu琀琀on on the Setup screen and then select "Exit"). The File Manager interface is illustrated
below. You can use the bu琀琀ons highlighted below to start the Host PC Applica琀椀on or shut
down the Host PC.
Starts Host Applica琀椀on
Version 1.07T
Moun琀椀ng Hole
Rota琀椀ng Wheel
USB Ports
Shuts down Host PC
Con琀椀nued
on back
