VHF FM TRANSCEIVER, UHF FM TRANSCEIVER
3 S ERVICE MANUAL
2014
RA008<Rev.001>
B5B-7115-00
TK-7302, TK-7302(V), TK-7302H, TK-7302H(V)
TK-8302, TK-8302(U), TK-8302H, TK-8302H(U)
SUPPLEMENT
This service manual has been revised due to the modification of the Audio IC.
Refer to the TK-7302/7302(V)/7302H/7302H(V) (K,M,M2) service manual (B51-8886-00) or
TK-7302 (E) service manual (B51-8914-00) or TK-7302H (M4) service manual (B51-8981-00) or
TK-8302/8302(U)/8302H/8302H(U) (K,K2,M,M2) service manual (B51-8907-00) or TK-8302 (E)
service manual (B51-8915-00) or TK-8302 (C6) service manual (B51-8927-00) or TK-8302H
(M4) service manual (B51-8982-00) for any information which has not been covered in this
service manual.
This product complies with the RoHS directive for the European market.
B5B-7261-00
SERVICE MANUAL
COPYRIGHT © 2017 JVC KENWOOD Corporation
This product uses Lead Free solder.
No.RQ185<Rev.001>
2017/5
