Sukup Sweepway 8" Owner's Installation & Operations Manual

Bin unloading power sweep
Hide thumbs Also See for Sweepway 8":
Table of Contents

Advertisement

Quick Links

Download this manual
Sweepway
Owner's Installation & Operation Manual
Phone: 641-892-4222
Website: www.sukup.com
D
ATE
08/30/2023 – Updated warranty ........................................................................................... ................................. 4
Updated two-motor bottom drive installation instructions ............................................................... 32
Updated statement on sweeping bins made by other manufacturers ............................................ 38
Added sump drive chain lubrication & tightening instructions ........................................................ 39
Added heading to flinger attachment drawings .............................................................................. 47
Added part numbers for center sump drawings & parts lists ..................................................... 64-67
Added drawing & parts list for heavy duty 10" center sump ...................................................... 68-69
Updated Contact Information page & added QR code for warranty registration ............................ 88
10/26/2022 – Added 8" & 10" description to manual name .................................................. ................................. 1
Added incline powerhead dimensions drawing .............................................................................. 10
Updated drawing showing clutch lock assy. ................................................................................... 20
Minor editing of powerhead installation instructions. ................................................................. 29-33
Updated drawings showing sump opener connectors ............................................................ 36 & 79
Added horizontal powerhead part numbers ................................................................................... 45
Updated part number for 8" top spout ............................................................................................ 53
Updated drawing & parts list for bin collar ...................................................................................... 63
Updated drawing of intermediate sumps ........................................................................................ 71
Updated part number for 3/4" long key for 10" Sweepway top gearbox......................................... 73
Added sump opener part numbers ................................................................................................. 77
Manual L1435
08/30/2023
Bin Unloading Power Sweep
For 8" & 10" Systems
Sukup Manufacturing Co.
1555 255th Street, Box 677
Sheffield, Iowa, USA 50475-0677
R
Fax: 641-892-4629
E-mail: info@sukup.com
EVISION
®
P
© Sukup Manufacturing Co.
AGE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sweepway 8" and is the answer not in the manual?

Questions and answers

Related Manuals for Sukup Sweepway 8"

Summary of Contents for Sukup Sweepway 8"

  • Page 1 Updated drawing & parts list for bin collar ..................63 Updated drawing of intermediate sumps ..................71 Updated part number for 3/4" long key for 10” Sweepway top gearbox......... 73 Added sump opener part numbers ....................77 Manual L1435 © Sukup Manufacturing Co. 08/30/2023...

  • Page 2: Introduction

    DISCLAIMER: Bin sweeps will vary in performance based on grain condition and condition of bin floor. Any capacities provided by Sukup Manufacturing Co. are based on dry, clean corn and ideal conditions. It may take two passes over a given area to remove grain, with a layer of grain remaining on floor...

  • Page 3: Table Of Contents

    Table of Contents TABLE OF CONTENTS Introduction ..........................2 Limited Warranty ........................4 Safety ............................5 General Safety Practices ......................5 Safety Decals for Sweepway ....................7 Safety Decals Placement for Sweepway ................. 8 Sweepway Dimensions ......................9 Unload System Dimensions ......................10 Preparation / Unload Installation ....................13 Independent Intermediate Sump Pull Rod Installation ...............18 Assembling Bin Sweep......................21...

  • Page 4: Limited Warranty

    Limited Warranty...

  • Page 5: Safety

    Safety decals must be kept in good condition. Replace missing or damaged safety decals by contacting Sukup Manufacturing Co. via mail at PO Box 677, Sheffield, Iowa USA, 50475; by phone at 641-892-4222; or by e-mail at info@sukup.com. It is the responsibility of the owner/operator to know what specific requirements, precautions, and work hazards exist.

  • Page 6: Personal Protective Equipment

    Safety To avoid electric shock or electrocution, all WARNING: Metal is slippery when wet. To equipment must be properly wired and grounded avoid falls, never carry items if climbing on according to electrical codes. Have unit wired by bin. Maintain secure hand and foothold if qualified electrician.

  • Page 7: Safety Decals For Sweepway

    To order a replacement decal or shield at no charge, contact your dealer or Sukup Manufacturing Co., Box 677, Sheffield, IA USA 50475. If replacement is necessary, make sure location for decal is free from grease, oil and dirt.

  • Page 8: Safety Decals Placement For Sweepway

    Safety Safety Decals Placement for Sweepway HORIZONTAL INCLINE VERTICAL SWEEP BACKBOARD...

  • Page 9: Sweepway Dimensions

    Dimensions SWEEPWAY DIMENSIONS See Fig. 1 and Table 1 for Sweepway dimensions. Fig. 1 & Table 1 – Sweepway dimensions DIMENSION DISTANCE FROM BIN FLOOR 8” 10" 7-1/2” Top of gearbox 8-1/2” 2” Bottom of backboard 2-5/8” 9-7/8” Top of backboard 12-5/8”...

  • Page 10: Unload System Dimensions

    Dimensions UNLOAD SYSTEM DIMENSIONS See Figs. 2-6 and Tables 2-4 for approximate dimensions of unload systems. Fig. 2 – Horizontal unload 8” 10” WIDTH 8” 10” LENGTH 8” 10” Table 2 – Horiz. discharge dims. Fig. 3 – Incline unload Fig.
  • Page 11 31.5 96.5 217.5 system dimensions 26' 3" (8M) 13.5 32.5 97.5 227.5 for 8” Sweepway 236.5 27' 10" 236.5 Sukup bin diameters 29' 6" (9M) 246.5 shown in bold. 255.5 255.5 273.5 273.5 36' (11M) 291.5 37' 1" 12.5 31.5 96.5...
  • Page 12 Dimensions See Fig. 5 for 8” incline dimensions and Fig. 6 for 10” incline dimensions. NOTE: Discharge box for 8” system is 10” x 10”. Discharge box for 10” system is 12” x 12”. Fig. 5 – 8” Incline unload Fig.

  • Page 13: Preparation / Unload Installation

    Preparation / Installation PREPARATION / UNLOAD INSTALLATION Unload tube can either be placed in a bin with a steel aeration floor as shown in Fig. 7 or a concrete trench as shown in Fig. 10. Instructions are provided for both types of floor. In either case, the first step is to determine from which side of bin grain will be unloaded.
  • Page 14 Preparation / Installation Cut hole in bin wall at desired unloading location, with center of hole located as shown in Fig. 8. Fig. 8 – Bin wall cutout If floor has not previously been installed, install half of bin floor on side opposite of unload, plus two planks past center of bin.

  • Page 15: Installation

    Consideration should include, but not be limited to, live loads, dead loads and seismic zone. Sukup Manufacturing Co. will not be responsible for any damage to a product, including, but not limited to, any damage that results from inadequate or improper support methods and materials.
  • Page 16 Installation For installation in concrete trench: Ensure trench meets dimensions shown in Fig. 10 and Table 7. Trench will need to be formed when foundation is poured. Because of moving slide gates and pull rods, concrete CANNOT be poured over sweep tube.

  • Page 17: Stub Shaft

    Installation For installation in both floor types: With tabs on unloading tube closest to center sump, slide unloading tube out slightly through bin wall and then back into sump. Position tube so intermediate sumps are straight up. Bolt tube to sump using attachment tabs welded onto tube, and holes provided in sump.

  • Page 18: Independent Intermediate Sump Pull Rod Installation

    Installation Slide bin collar over tube protruding from bin. Position bin collar so clutch pull rod hole and lock assembly are on lower right side as shown in Fig. 14. Collar clamp tabs will be horizontal as shown. Mark clutch rod hole and drill through bin wall.
  • Page 19 Installation Slide clutch pull rod through bin collar and into rear compartment of center sump. If not already installed on unload tube in bin 31' dia. or larger, bolt clutch rod support clamp midway on unload tube and slide clutch pull rod through support (support not needed in smaller bins). Attach clutch pull rod to clutch shifter arm with 3/8 x 1-1/2”...
  • Page 20 Installation Slide 1" lock collar onto clutch pull rod with clutch disengaged (rod pushed in). Push latch down and slide 1” lock collar against bin collar so that when latch is released, lock collar is sandwiched between latch and bin collar. See Fig. 19. Tighten 1” lock collar setscrew. Latch will keep clutch disengaged. When latch is pushed down, rod can be pulled for engagement of clutch.

  • Page 21: Assembling Bin Sweep

    Installation ASSEMBLING BIN SWEEP For 8” and 10” systems, start by attaching sweep input shaft to top gearbox. Insert 1/4" key into shaft and insert shaft 1” into sprocket. See Fig. 21. Tighten two (2) setscrews. 8” & 10” Fig. 21 For 8”...
  • Page 22 Installation On 8” Sweepway, attach backboard to top gearbox as shown in Fig. 23 using previously installed backboard mount bracket. Slide a flat washer over each stud protruding from gearbox, then slide studs through backboard mount bracket and attach using flat washer, 15/16” spacer then a flat washer and lock washer.
  • Page 23 Installation Size of drive wheel used on sweep depends on size of bin and unload system. A 10” wheel with 4:1 reducer comes standard for 8” systems in bins up to 34’ dia. A 17” wheel with 16:1 reducer comes standard for 8”...

  • Page 24: Attaching Sweep Stop

    Installation Attach rear carrier wheel(s) to backboard as shown on Page 63. In bins smaller than 24’, attach one carrier wheel near center of backboard. In bins 24’ dia. and larger, attach one wheel as close to drive wheel as allowed (within 4’ of outer end of backboard) and one as close to center as allowed (within 4’...

  • Page 25: Backboard Scraper Installation

    Installation BACKBOARD SCRAPER INSTALLATION Fig. 31 1. Attach scrapers to backboard using 3/8 x 1” carriage bolts, with heads of bolts on auger side of backboard. See Fig. 31. Place scraper’s short side flat against backboard as shown and align scraper holes with slots.
  • Page 26 Installation 2. Continue attaching scraper sections on backboard until all are installed or until all visible slots in backboard have been filled. Scraper closest to center sump may only be 18" long depending on bin diameter. NOTE: If an 18” section of scraper is needed, it will be factory-attached to back of backboard.

  • Page 27: Cluster Buster Installation

    Installation CLUSTER BUSTER INSTALLATION Determine location for hole in side of bin. Position sweep auger just behind outermost intermediate sump (to left of sump when looking toward bin wall). Note location of backboard torsion bar and drill 1” dia. hole in bin wall that will line up with torsion bar.
  • Page 28 Installation Image 5 – Alignment rod in torsion bar Remove cable from bin and insert rod through bin wall hole and into torsion bar. See Image 5. Press down on handle as shown in Image 6 to seal rubber grommet in hole. If seal is not tight, remove rod and turn rubber grommet counterclockwise while holding Image 6 –...

  • Page 29: Powerhead Options

    Installation SWEEPWAY POWERHEADS There are three main powerhead options for Sweepway and two sub-options for Vertical. See below. Horizontal • Vertical • o Two-Motor Bottom Drive o Top Drive Incline • See applicable installation instructions on this and following pages. Horizontal Powerhead To aid in part identification during assembly, see Pages 45-46.

  • Page 30: Vertical

    Installation Vertical Powerhead To aid in part identification during assembly, see Pages 48-49. 1. Flinger is factory-attached to vertical auger used with vertical powerhead. Flinger for horizontal auger feeding vertical auger must be field-attached. Prepare horizontal auger for use with vertical powerhead by using a cutoff wheel to trim flighting from end of unload auger to make room for flinger.
  • Page 31 Installation 6. Slide vertical auger (double flighting at bottom) through boot so that bottom shaft extends through bearing on bottom of boot. Vertical auger should have a factory installed flinger on upper end. 7. Slide tube over flighting into second connector sleeve so that tube contacts boot. Tighten connector sleeve.

  • Page 32: Two-Motor Bottom Drive

    Installation Two-Motor Bottom Drive To aid in part identification during assembly, see Pages 50-51. 1. Follow Steps 1-18 in Vertical Powerhead assembly instructions. 2. Mount motor (motor and motor pulley not included) to horizontal motor mount using four 3/8 x 1-1/2" bolts, lock washers, flat washers and nuts.

  • Page 33: Top Drive

    Installation Top Drive To aid in part identification during assembly, see Pages 52-56. 1. Prepare unload auger as shown on Page 30. 2. Slide first of three connector sleeves halfway onto horizontal unloading tube. Loosely attach using 3/8 x 3" screws and whiz nuts. 3.

  • Page 34: Incline

    Installation Incline To aid in part identification during assembly, see Pages 58-62. Remove U-joint cover from incline. See Fig. 36. Remove two bolts attaching auger shaft to unload auger. Remove shaft. Save bolts for reuse. Pull auger out of unload tube slightly. Attach sleeve mount adapter to incline.

  • Page 35: Adjusting Belt Tension

    16.8 Table 12 – Belt deflection settings for Bestorq belts Sukup products use belts made by Bestorq. Sukup recommends using a Bestorq tension meter to measure belt deflection. Go to www.bestorq.com or call (402) 423-3077 for more information. After adjusting tension to desired level by adjusting motor mount, remove any foreign material from inside of belt guard.

  • Page 36: Sump Opener

    Installation SUMP OPENER FOR 8” & 10”SWEEPWAY 1. Prepare center sump connector (8” or 10”) by installing three spacers using two 3/8” clamping bolts as shown in Fig. 40. Note orientations of spacers. Do not tighten yet. 2. Pull center sump pull rod out about 5”, then slide center sump connector over center sump pull rod with 1/2”...
  • Page 37 Installation 6. Insert quick-connect pins to connect rack & pinion opener and intermediate sump connector. See Fig. 42. 7. Tighten shaft collar. 8. Make sure center sump connector is positioned with equal space between tabs on rack & pinion opener and intermediate sump connector. 9.

  • Page 38: Operation

    Sukup grain bins are designed with anchors that allow sweeping of entire diameter of bin with Sukup power sweeps. However, older Sukup bins (sold before 2015) that are 72’ dia. or larger and do not have two anchors per stiffener are not. Additional anchor brackets can be purchased from Sukup Manufacturing Co.

  • Page 39: Troubleshooting

    Troubleshooting TROUBLESHOOTING GUIDE PROBLEM REASON SOLUTION 1. Sweep is not moving around bin. Scraper too close to floor. Raise scrapers up. Bent edge is down by floor. Turn scraper around so sharp edge is at bottom. Obstacles may be hindering Check for any obstacles that forward movement.

  • Page 40: Parts/Assemblies

    Parts/Assemblies PARTS/ASSEMBLIES 8” & 10" SWEEPWAY...
  • Page 41 Parts/Assemblies 8” &10” SWEEPWAY REF. # DESCRIPTION QTY. 8” PART # 10” PART # Backboard pivot rod E0107 E0107 Auger/backboard assy. Clutch rod support clamp E5364 E53162 Sump & gearbox assy. E53878 E53341 Independent intermediate sump top E53989 E53964 Independent intermediate sump pull rod handle E5404 E5404 Intermediate sump top...
  • Page 42 Parts/Assemblies UNLOAD TUBE REF. # DESCRIPTION QTY. 8” PART # 10” PART # Intermediate sump, w/ rollers E5398 E5395 Independent int. sump E53981 E53951 Independent int. sump slide gate assy. E53987 E53963 Intermediate sump slide gate assy. E5409 E5409 Shaft collar, 7/8", no set screw E5448 E5448 Shaft collar, 7/8", w/ bolt...
  • Page 43 Parts/Assemblies 8” BACKBOARD REF. # DESCRIPTION QTY. PART # Backboard Auger Inner auger Bearing support spacer E60632 Auger support bushing assy. E60901 Auger connector shaft, 1" OD, 8-1/2" long E6704-03 Torsion bar bracket E6791 Torsion bar bracket, split E6792 Torsion bar pivot bracket E69771 Screw, 5/16 –...
  • Page 44 Parts/Assemblies 10” BACKBOARD REF. # DESCRIPTION QTY. PART # Torsion bar pivot bracket E0104 Backboard Auger support bushing assy. E60917 Torsion bar bracket, split E6789 Backboard pivot mount EU8200 Auger Auger Auger connector shaft, 1-1/4” OD, 13" long EU9044 Screw, 3/8 – 16 x 1” J0606 Bolt, 3/8 - 16 x 1-1/4”...
  • Page 45 Parts/Assemblies HORIZONTAL POWERHEAD 8” 2-BLT 8” 3-BLT 10” 2-BLT 10” 3-BLT REF.# DESCRIPTION QTY. E5591 E55911 E5592 E55921 Connector sleeve, 18” E5424 E5424 E5425 E5425 E56011 E5602 E56021 Powerhead w/ shield, bearing & motor mount E5601 E5720 E5720 E5720 Key, 1/4" sq. x 2-1/2” E5720 Locking collar, 1-1/4”...
  • Page 46 L0281 Decal, Warning, Keep Away … L0284 L0284 L0284 L0284 Sukup logo L03161 L03161 L03161 L03161 *Also needs a 2.438" spacer (E5740, not shown) for 8” & 10” 3-belt **QTY. 2 for 8” 3-belt & 10” 2-belt. QTY. 4 for 10” 3-belt.
  • Page 47 Parts/Assemblies UNDER-BIN UNLOAD AUGER REF. # DESCRIPTION QTY. 8” 10” Shaft, 1-1/4 x 15-3/4”, w/ key E54151 Shaft, 2 x 18”, w/ key E54142 Connecting shaft, 1-1/4 x 10-1/4” G91421 Connecting shaft, 2 x 14-1/4” F48412 Screw, 7/16 - 14 x 2-1/2” J0720 Screw, 1/2 - 13 x 3”...
  • Page 48 Parts/Assemblies BOTTOM DRIVE VERTICAL POWERHEAD...
  • Page 49 Parts/Assemblies BOTTOM DRIVE VERTICAL POWERHEAD REF. # DESCRIPTION QTY. 8” PART # 10” PART # Connector sleeve, 18" E5424 E5425 Key, 1/4" sq. x 2-3/4" E5721 E5721 Half band E57941 E57961 Top spout E5813 E5785 Truck spout, 30" E5815 E5787 Vertical boot, 2 belt E5817 E5782...
  • Page 50 Parts/Assemblies BOTTOM-DRIVE BOOT E5817 – 8” (2-Belt) E58174 – 8” (3-Belt) E5782 – 10” (2-Belt or 3-Belt)
  • Page 51 Decal, Danger, Replace Missing Shield L0271 L0271 Decal, Caution, safety instructions L0281 L0281 Decal, Warning, Keep Away… L0284 L0284 Sukup logo L03161 L03161 *QTY. 1 for 8” 2-belt; QTY. 2 for 8” 3-belt; QTY. 4 for 10” **QTY. 2 for 8” 3-belt...
  • Page 52 Parts/Assemblies TOP DRIVE VERTICAL POWERHEAD...
  • Page 53 Parts/Assemblies TOP DRIVE VERTICAL POWERHEAD REF. # DESCRIPTION QTY. 8” PART # 10” PART # Connector sleeve, 18" E5424 E5425 Key, 1/4" sq. x 2-3/4" E5721 E5721 Spacer, 1-1/4” E57415 E57415 Half band E57941 E57961 Truck spout, 30" E5815 E5787 Vertical boot, 2-motor drive, 2 or 3 belt E58172 E57821...
  • Page 54 Parts/Assemblies TOP DRIVE BOOT E58172 – 8” E57821 – 10”...
  • Page 55 J1260 J1260 Hairpin clip, .120 x 2-1/2” J5412 J5412 Decal, Danger, Do Not Enter Bin L0258A L0258A Decal, Danger, Replace Missing Shield L0271 L0271 Decal, Caution, safety instructions L0281 L0281 Decal, Warning, Keep Away… L0284 L0284 Sukup logo L03161 L03161...
  • Page 56 J1260 J1260 Hairpin clip, .120 x 2-1/2” J5412 J5412 Decal, Danger, Do Not Enter Bin L0258A L0258A Decal, Danger, Replace Shield L0271 L0271 Decal, Caution, safety instructions L0281 L0281 Decal, Warning, Keep Away … L0284 L0284 Sukup logo L03161 L03161...
  • Page 57 Parts/Assemblies VERTICAL AUGER PART # DESCRIPTION E5847 8” bottom drive, 16’ E58541 8” bottom drive, 20’ E58471 8” top drive, 16’ E58542 8” top drive, 20’ E57833 10” bottom drive, 16’ E57837 10” bottom drive, 20’ E57836 10” top drive, 16’ E57834 10”...
  • Page 58 Parts/Assemblies INCLINE AUGER FOR 8” & 10” UNLOAD 8” Unload uses 25°, 8-10” Incline (E5030 – 2-belt; E5031 – 3-belt) 10” Unload uses 20°, 10-12” incline (E5020 – 3-belt) REF. # DESCRIPTION QTY. 8-10” PART # 10-12” PART # Incline, 25°, 2-belt E5042 ---- Incline, 25°, 3-belt...
  • Page 59 Parts/Assemblies 25° INCLINE AUGER FOR 8” UNLOAD (E5032 – 3-belt)
  • Page 60 Bushing, rubber, 1/2" ID J5021 Hairpin clip, .120 x 2.5 J5412 Decal, Do Not Enter Bin L0258A Decal, Danger, Replace Missing Shield L0271 Decal, Safe Operation L0281 Decal, Keep Away From Moving Parts L0284 Sukup logo L03161 Hinge spacer, 2.438" E5740...
  • Page 61 Parts/Assemblies 20° INCLINE AUGER FOR 10” UNLOAD (E5010 – 3-belt)
  • Page 62 Machine bushing, 3/4 x 1-1/4”, 14ga J1260 Bushing, rubber, 1/2" ID J5021 Hairpin clip, .120 x 2.5 J5412 Decal, Do Not Enter Bin L0258A Decal, Danger, Replace Missing Shield L0271 Decal, Safe Operation L0281 Decal, Keep Away From Moving Parts L0284 Sukup logo L03161...
  • Page 63 Parts/Assemblies REAR CARRIER WHEEL REF. # DESCRIPTION QTY. PART # Rear carrier wheel kit E6099 Rear carrier wheel bracket, left E7741 Rear carrier wheel bracket, right E7740 Rubber wheel, 6”, w/ bushing J7271 U-bolt, 3/8" - 16 J0644 Bolt, 3/8 - 16 x 3" J0661 Flat washer, 3/8"...
  • Page 64 Parts/Assemblies 8" SWEEPWAY CENTER SUMP, E53878...
  • Page 65 Parts/Assemblies 8" SWEEPWAY CENTER SUMP, E53878 REF. # DESCRIPTION QTY. PART # Clutch shifter arm assembly E53132 Chain, #50, 73 links E5319-01 Spacer washer, 3/8” ID, 2-1/4” OD E5324 Weld support plate w/ snap ring, 10" E5339 Side gate rail E5350-14 Sump cover E5354...
  • Page 66 Parts/Assemblies 10" SWEEPWAY CENTER SUMP, E53341...
  • Page 67 Parts/Assemblies 10" SWEEPWAY CENTER SUMP, E53341 REF. # DESCRIPTION QTY. PART # Clutch shifter arm assembly E53132 Spacer washer, 3/8” ID, 2-1/4” OD E5324 Weld support plate w/ snap ring, 10" E5339 Side gate rail E5350-14 Sump cover E5354 Gearbox support cover E5357 Chain cover E5358...
  • Page 68 Parts/Assemblies HEAVY DUTY 10" SWEEPWAY CENTER SUMP, E5334H (Used in bins 15-24 rings tall)
  • Page 69 Parts/Assemblies HEAVY DUTY 10" SWEEPWAY CENTER SUMP, E5334H REF. # DESCRIPTION QTY. PART # Clutch shifter arm assembly E53132 Spacer washer, 3/8” ID, 2-1/4” OD E5324 Top gearbox support E53362 Side gate rail, 2-piece E53364 Side gate rail E5350-14 Sump cover, HD E53541 Lower gearbox E5360...
  • Page 70 Parts/Assemblies INDEPENDENT INTERMEDIATE SUMP 8” & 10” 10” 8” REF. # DESCRIPTION QTY. PART # Sump bottom, 10” E53951 Slide gate, 10” E53963 Sump top, 10” E53964 Sump bottom, 8” E53981 Slide gate, 8” E53987 Sump top, 8” E53989 Bearing, 1/4" ID, 5/8” OD J0016 Screw, 1/4 –...
  • Page 71 Parts/Assemblies 8” & 10" SWEEPWAY INTERMEDIATE SUMPS REF. # DESCRIPTION QTY. PART # Bearing, 1/4" ID, 5/8” OD J0016 Screw, 1/4 – 20 x 1”, slotted J05081 Hex nut, 1/4" – 20 J0990 Lock washer, 1/4" J1195 * QTY. varies with sump size...
  • Page 72 Parts/Assemblies 8" SWEEPWAY TOP GEARBOX (E53741) REF. # DESCRIPTION QTY. PART # Plate, open end E5902-01 Shaft, 6” E5905 Shaft, 8.601”, w/ keyway E5908 Gearbox case F9004 Hub, standard F9007-01 Bearing cup J0105 Tapered bearing, 1” J0111 Bearing cup, 2-23/32” OD J0115 Tapered bearing,1-3/8”...
  • Page 73 Parts/Assemblies 10" SWEEPWAY TOP GEARBOX (E53751) REF. # DESCRIPTION QTY. PART # Sprocket shaft E5379 Plate, open end E5902-01 Key,1/4" x 1" E5915 Shaft, 8" EU0839 Output hub, 1-1/4" shaft EU0840 Gearbox case F9004 Key, 1/4" sq. x 3/4" G75081 Bearing cup, 2-23/32 OD J0115 Tapered bearing, 1-3/8”...
  • Page 74 Parts/Assemblies 8" SWEEPWAY LOWER GEARBOX REF. # DESCRIPTION QTY. PART # Shaft, 9-3/4" x 1-3/8", w/ keyway E5900 Plate, open end E5902-01 Shaft, 1” x 6-1/2”, w/ keyway F4738 Gearbox case, two hole F9004 Hub, standard F9007-01 Bearing cup J0105 Bearing, 1", tapered J0111 Cup, 2-23/32”...
  • Page 75 Parts/Assemblies 10" SWEEPWAY LOWER GEARBOX REF. # DESCRIPTION QTY. PART # Hub casting, HD, 1-3/8”, 10”, 1998 E5365 Gearbox shaft, 10” E5366 Shaft, 8-5/16” E5367 Key, 1/4” sq. x 1” E5915 Lower gearbox casting, HD, 3 hole F9051 Bevel gear, 18 tooth, 1-1/4” bore F9052 Gear, 27-tooth, 1-3/8”...
  • Page 76 Parts/Assemblies TOP GEARBOX BEARING SUPPORT SLIDE PLATE E5339 (8” & 10”) REF. # DESCRIPTION QTY. 8” & 10” PART # Bearing, 1.1811 ID, 2.8346 OD J00599 Snap ring, 2.047” J35991 CLUTCH SHIFTER ARM E53132 (8” & 10”) REF. # DESCRIPTION QTY.
  • Page 77 Parts/Assemblies SUMP OPENERS E5443 FOR 8” & E5444 FOR 10” SWEEPWAYS 8” REF. # DESCRIPTION QTY. PART # Center sump pull rod connector E59141 Rack & pinion opener assy. E5919 Handle E5967 Intermediate sump pull rod connector E5998 Screw, 3/8 - 16 x 3” J0660 Nut, 3/8”...
  • Page 78 Parts/Assemblies 8” & 10” SWEEPWAY RACK & PINION OPENERS 8” (E5919) 10” (E5969) REF. # DESCRIPTION QTY. PART # REF. # DESCRIPTION QTY. PART # Slide guide E5962 Slide guide E5962 Opener crank shaft E5964 Opener crank shaft E5964 Slide plate rack weldment E5916 Slide plate rack weldment E5963...
  • Page 79 Parts/Assemblies PULL ROD CONNECTOR PARTS 8” 10” REF. # DESCRIPTION QTY. E59141 E59971 Pull rod connector bracket E59142 E59972 Spacer E59143 E59973 Screw, 3/8 – 16 x 1-1/2” J0627 J0627 Whiz nut, 3/8” - 16 J1017 J1017 Shaft collar, 1/2" J1320 J1320 KIT E59141 IS FOR 8”;...
  • Page 80 Parts/Assemblies 4:1 REDUCTION DRIVE WHEEL Standard on 8” sweeps in bins up to 33’ dia. REF. # DESCRIPTION QTY. PART # Complete wheel E6092 4:1 Reduction drive wheel mount assy., w/ brng. E6096 Back plate w/ roller E6087 10" rubber ring J0271 Back plate, 9-1/4”...
  • Page 81 Parts/Assemblies 16:1 DRIVE WHEEL & RECLAIM SHIELD ITEM # DESCRIPTION 8” PART # 10” PART # QTY. Drive wheel, w/ green tread* E73491 E73491 Shield bracket E7381 E7381 Reclaim shield extension plate E7397 E7397 Gearbox, w/ mount E7408 EU8246 Brace E7412 E7412 Reclaim shield...
  • Page 82 Parts/Assemblies 16:1 DRIVE WHEEL SPEED REDUCER (E7408 for 8”, EU8246 for 10”) REF. # DESCRIPTION QTY. 8” PART # 10” PART # Flat washer, 11/16” E7322 E7322 Chain, # 40, 37 links E7327 E7327 Grain deflector E7407 E7413 Input shaft E7419 EU8249 Mounting bracket...
  • Page 83 Parts/Assemblies SWEEP AUGER SUPPORT BUSHING 8” REF. # DESCRIPTION QTY. 8” PART # Complete assembly E60901 Mounting bracket E60631 Sweep auger bushing E6065 Screw, 3/8 - 16 x 1” J0606 Hex nut, 3/8” – 16 J1020 Lock washer, 3/8” J1205 REF.

  • Page 84: Quick Reference Parts List (Motors, Pulleys, Bushings)

    Parts/Assemblies QUICK REFERENCE PARTS LISTS OPTIONAL - FARM-DUTY MOTORS (1750) FRAME SHAFT PART # E182T 1-1/8" H2175 F145T 7/8" H2475 J184T 1-1/8" H2845 E182T 1-1/8" H3345 L184T 1-1/8" H3675 F184T 1-1/8" H4190 K215T 1-3/8" H4900 213T 1-3/8" H4910 215T 1-3/8" H5300 215T 1-3/8"...

  • Page 85: Unload Auger Flighting Assembly

    Parts/Assemblies UNLOAD AUGER FLIGHTING 10" SWEEPWAY 8" SWEEPWAY BIN DIA. PART # PART # BIN DIA. PART # PART # *15'-15' 6" ---- E6450 *21'-21' 8" ---- E6482 16' 5" (5M) ---- E6449 22' 11" (7M) ---- E64821 *24'-24' 9" ---- E6483 *18'-18' 7"...

  • Page 86: Sweep Auger Replacement Kits

    Parts/Assemblies SWEEP AUGER REPLACEMENT PARTS Tables below show replacement auger part numbers & lengths. Backboard Assy. includes backboard, auger, torsion tube & hardware. Sections are numbered from middle of bin to sidewall. Backboard Length Length Length Length Length Assy. Auger Auger Auger Auger...
  • Page 87 Notes NOTES ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________...

  • Page 88: Contact Information

    Contact Information CONTACT INFORMATION Sukup Dealer Information Dealer name: Address: Cell phone: Office phone: Fax: In Case of Emergency Have emergency numbers and written directions to your location near a phone. Arrange and practice a safety plan. Ambulance • Fire • Police: 9-1-1...
