Sukup Sweepway Owner's Installation & Operations Manual

Bin unloading power sweep

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Sweepway

Owner's Installation & Operation Manual

Website: www.sukup.com

ATES

01/13/2020 – Updated incline dimensions & installation instructions ................................................... 10-11, 32-33

Updated bin sweep, scraper & Cluster Buster installation instructions .................................... 20-27

Updated parts drawings & tables .................... 41-43, 46-47, 49, 53, 57-64, 67-70, 74-75, 83-84, 86

Added sweep auger replacement part numbers ............................................................................ 90

04/24/2019 – Updated warranty ............................................................................................................................. 4

Updated instructions for supporting floor over unload tube ........................................................... 14

Added note on trimming stirring machine down-augers if present ................................................ 22

Updated troubleshooting solutions for increasing sweep auger capacity ..................................... 40

Added drawings & part numbers for square shaft connectors ...................................................... 55

Manual L1435

01/13/2020

Bin Unloading Power Sweep

Sukup Manufacturing Co.

1555 255th Street, Box 677

Sheffield, Iowa, USA 50475-0677

Phone: 641-892-4222

Fax: 641-892-4629

E-mail: info@sukup.com

EVISIONS

AGES

Table of Contents

Summary of Contents for Sukup Sweepway

Page 1 Updated instructions for supporting floor over unload tube ............14 Added note on trimming stirring machine down-augers if present ..........22 Updated troubleshooting solutions for increasing sweep auger capacity ........40 Added drawings & part numbers for square shaft connectors ............55 Manual L1435 © Sukup Manufacturing Co. 01/13/2020...
Page 2: Introduction
DISCLAIMER: Bin sweeps will vary in performance based on grain condition and condition of bin floor. Any capacities provided by Sukup Manufacturing Co. are based on dry, clean corn and ideal conditions. It may take two passes over a given area to remove grain, with a layer of grain remaining on floor...
Page 3: Table Of Contents
Limited Warranty ........................4 Safety ............................5 General Safety Practices ......................5 Safety Decals for Sweepway ....................7 Safety Decals Placement for Sweepway ................. 8 Sweepway Dimensions ......................9 Unload System Dimensions ......................10 Preparation / Unload Installation ....................12 Independent Intermediate Sump Pull Rod Installation ...............17 Assembling Bin Sweep......................20...
Page 4: Limited Warranty
Limited Warranty...
Page 5: Safety
Sukup Manufacturing Co. via mail at PO Box 677, Sheffield, Iowa USA, 50475; by phone at 641-892-4222; or by e-mail at info@sukup.com. It is the responsibility of the owner/operator to know what specific requirements, precautions, and work hazards exist. It is also the responsibility of the...
Page 6 Safety WARNING: Metal is slippery when wet. To To avoid electric shock or electrocution, all equipment must be properly wired and grounded avoid falls, never carry items if climbing on according to electrical codes. Have unit wired by bin. Maintain secure hand and foothold if qualified electrician.
Page 7: Safety Decals For Sweepway
To order a replacement decal or shield at no charge, contact your dealer or Sukup Manufacturing Co., Box 677, Sheffield, IA USA 50475. If replacement is necessary, make sure location for decal is free from grease, oil and dirt.
Page 8: Safety Decals Placement For Sweepway
Safety Safety Decals Placement for Sweepway HORIZONTAL VERTICAL BOOT SWEEP BACKBOARD...
Page 9: Sweepway Dimensions
8-1/2” 3” 2” Bottom of backboard 2-5/8” 11-1/4” 9-7/8” Top of backboard 12-5/8” 11-3/4” 10-3/8” Top of huckbolt sleeve 13-1/8” 10” 10” * Top of reduction wheel *Dimension E will be 17” if 17” wheel is used on 8” Sweepway...
Page 10: Unload System Dimensions
8” 10” WIDTH 8-3/8” 10” 12” LENGTH 9-1/8” 10” 12” Table 3 – Incline discharge dims. 6” SWEEPWAY DIMENSIONS BIN DIA. Table 4 – Unload 184.5 system dimensions 15' 6" 184.5 for 6” Sweepway 16" 5" (5M) 128.5 192.5 166.5 17.5...
Page 11 Dimensions 8” SWEEPWAY DIMENSIONS BIN DIA. 99.5 189.5 162.5 15' 6" 99.5 189.5 162.5 16" 5" (5M) 14.5 32.5 195.5 168.5 17.5 35.5 143.5 202.5 18' 7" 143.5 96.5 202.5 19' 8" (6M) 96.5 214.5 187.5 100.5 226.5 199.5 21' 8"...
Page 12: Preparation / Unload Installation
Preparation / Installation PREPARATION / UNLOAD INSTALLATION Unload tube can either be placed in a bin with a steel aeration floor as shown in Fig. 3 or a concrete trench as shown in Fig. 7. Instructions are provided for both types of floor. In either case, the first step is to determine from which side of bin grain will be unloaded.
Page 13 Preparation / Installation Cut hole in bin wall at desired unloading location, with center of hole located as shown in Fig. 4, depending on size of unload tube. 6” Sweep, cut 6-1/4” U-shaped opening 8” Sweep, cut 8-1/4” U-shaped opening 10”...
Page 14 Consideration should include, but not be limited to, live loads, dead loads and seismic zone. Sukup Manufacturing Co. will not be responsible for any damage to a product, including, but not limited to, any damage that results from inadequate or improper support methods and materials.
Page 15 Installation For installation in concrete trench: Ensure trench meets dimensions shown in Fig. 7 and Table 9. Trench will need to be formed when foundation is poured. Because of moving slide gates and pull rods, concrete CANNOT be poured over sweep tube.
Page 16 Installation For installation in both floor types: With tabs on unloading tube closest to center sump, slide unloading tube out slightly through bin wall and then back into sump. Position tube so intermediate sumps are straight up. Bolt tube to sump using attachment tabs welded onto tube, and holes provided in sump.
Page 17: Independent Intermediate Sump Pull Rod Installation
Installation Slide bin collar over tube protruding from bin. Position bin collar so clutch pull rod hole and lock assembly are on lower right side as shown in Fig. 11. Collar clamp tabs will be horizontal as shown. Mark clutch rod hole and drill through bin wall.
Page 18 Installation Slide clutch pull rod through bin collar and into rear compartment of center sump. If not already installed on unload tube in bin 31' dia. or larger, bolt clutch rod support clamp midway on unload tube and slide clutch pull rod through support (support not needed in smaller bins). Attach clutch pull rod to clutch shifter arm with 3/8 x 1-1/2”...
Page 19 Installation Slide 1" lock collar onto clutch pull rod with clutch disengaged (rod pushed in). Push latch down and slide 1” lock collar against bin collar so that when latch is released, lock collar is sandwiched between latch and bin collar. See Fig. 15. Tighten 1” lock collar setscrew. Latch will keep clutch disengaged. When latch is pushed down, rod can be pulled for engagement of clutch.
Page 20: Assembling Bin Sweep
(4) 3/8” bolts. See Fig. 18. Fig. 18 For 8” or 10” Sweepway, line up 1” diameter holes in backboard with holes in backboard mount. See Fig. 19. Insert pin and secure it with two (2) 5/16” bolts, one on each end.
Page 21 Installation On 6” Sweepway, attach backboard to top gearbox as shown in Fig. 20 using previously installed backboard extension bracket. Slide a 1” spacer over each 7/16” stud, then a flat washer and lock washer. Secure with 7/16” nut on each stud.
Page 22 Installation Size of drive wheel used on sweep depends on size of bin and unload system. A 10” wheel with 4:1 reducer comes standard for all 6” systems and for 8” systems in bins up to 34’ dia. A 17” wheel with 16:1 reducer comes standard for 8”...
Page 23: Attaching Sweep Stop
Bolt sweep stop to bin wall near door so it can be positioned without entering bin. Bottom of stop must be 1-1/2” from floor. For Sweepway with 17” drive wheel, add sweep stop extension (E5515) as shown in Image 1 using two (2) 5/16” bolts and 5/16” flange nuts.
Page 24: Backboard Scraper Installation
Installation BACKBOARD SCRAPER INSTALLATION Fig. 27 1. Attach scrapers to backboard using 3/8 x 1” carriage bolts, with heads of bolts on auger side of backboard. See Fig. 27. Place scraper’s short side flat against backboard as shown and align scraper holes with slots.
Page 25 Installation 2. Continue attaching scraper sections on backboard until all are installed or until all visible slots in backboard have been filled. Scraper closest to center sump may only be 18" long depending on bin diameter. If an 18” section is used, it must be field-attached to inside end of backboard. All scraper sections provided may not be used.
Page 26: Cluster Buster Installation
Insert end of 1” OD bent conduit (E7968 or E79681) into torsion bar and attach other end to backboard using U-bolt (1/4” for 6” unit, 3/8” for 8” or 10”). See Fig. 29. On 8” or 10” Sweepway, end of conduit should be about 3-1/2”...
Page 27 Installation Image 5 – Alignment rod in torsion bar Remove cable from bin and insert rod through bin wall hole and into torsion bar. See Image 5. Press down on handle as shown in Image 6 to seal rubber grommet in hole. If seal is not tight, remove rod and turn rubber grommet counterclockwise while holding Image 6 –...
Page 28: Powerhead Options
Installation SWEEPWAY POWERHEAD OPTIONS Horizontal with Single Motor Drive To aid in part identification during assembly, see Pages 48-49. 1. Slide connector sleeve onto unloading tube and loosely attach with 3/8 x 3" bolts, lock washers and nuts. See Pages 35-37 for instructions on installation of sump openers.
Page 29: Basic Vertical Auger
Installation Basic Vertical Auger To aid in part identification during assembly, see Pages 50-51. 1. Slide connector sleeve (13) halfway onto unloading tube. Loosely bolt with 3/8 x 3” bolts, lock washers and nuts. See Pages 35-37 for instructions on installation of sump openers. 2.
Page 30: Two Motor Drive
Installation Two Motor Drive (Standard Equipment) To aid in part identification during assembly, see Pages 52-53. 1. Follow Steps 1-17 in Basic Vertical Auger Assembly Instructions. 2. Mount motor (motor and motor pulley not included) onto horizontal motor mount using four 3/8 x 1-1/2" bolts, lock washers, flat washers and nuts.
Page 31: Top Drive
Installation Top Drive To aid in part identification during assembly, see Pages 56-57. 1. Slide first of three connector sleeves (40) halfway onto horizontal unloading tube. Loosely bolt connector sleeve with 3/8 x 3" bolts, nuts and lock washers. 2. Remove safety shields (48, 47) and shield brackets (46) from vertical auger boot. 3.
Page 32: Incline
Installation Incline To aid in part identification during assembly of incline for 6” Sweepway, see Pages 58-59. Installation of incline will depend on size of Sweepway system. Instructions for 6” system start below. Instructions for 8” or 10” systems are on next page.
Page 33 Installation To aid in part identification during assembly of incline for 8” or 10” Sweepway, see Pages 60-64. Remove flinger and auger shaft from unload auger. Save fasteners. Remove U-joint cover from incline. See Fig. 35. Weld 1’ section of flighting to auger. See Fig. 32.
Page 34: Adjusting Belt Tension
16.8 Table 12 – Belt deflection settings for Bestorq belts Sukup products use belts made by Bestorq. Sukup recommends using a Bestorq tension meter to measure belt deflection. Go to www.bestorq.com or call (402) 423-3077 for more information. After adjusting tension to desired level by adjusting motor mount, remove any foreign material from inside of belt guard.
Page 35: Sump Opener For 6" Sweepway
Installation SUMP OPENER FOR 6” SWEEPWAY ROTATED VIEW SHOWS ATTACHMENT OF STATIONARY BAR TO SLEEVE CONNECTOR Fig. 39 & Table 13 REF. # DESCRIPTION QTY. 6" PART # Complete pull rod opener assembly E5432 Stationary bar E5884 Center sump opener handle...
Page 36: Sump Opener For 8" Sweepway
Installation SUMP OPENER FOR 8” SWEEPWAY Fig. 40 & Table 14 REF. # DESCRIPTION QTY. 8" PART # Complete rack & pinion opener assembly E5443 Center sump connector E5914 Rack & pinion opener assy., 8" E5919 Opener handle E5967 Intermediate sump connector E5998 Quick-release pin, 3/8 x 1"...
Page 37: Sump Opener For 10" Sweepway
Installation SUMP OPENER FOR 10” SWEEPWAY Fig. 41 & Table 15 REF. # DESCRIPTION QTY. 10" PART # Complete rack & pinion opener assembly E5444 Opener handle E5967 Rack & pinion opener assembly, 10" E5969 Center sump connector E5997 Intermediate sump connector E5998 Bolt, 3/8 - 16 x 3”...
Page 38: Operating Instructions
For single-stage sweeping of Sukup bins 54’ to 105’ in diameter, bin must have 1” Grade 5 anchor bolts (17” deep for “Inverted T” foundation, or deep into stemwall ring rebar zone for “T-Cap”), with a minimum of 7-1/2”...
Page 39 5. Close sumps and place sweep just behind intermediate sumps. NOTE: If a slower flow of grain is desired, (e.g., grinding) a larger driven pulley (12” comes standard) should be used on unload auger. (14” pulley available from Sukup Manufacturing Co.)
Page 40: Troubleshooting
30%. 3. Drive chain breaking. Grain piling in center of bin. Make sure center sump gate is (8" & 10” Sweepway) fully open. 4. When using an incline auger, Moving very small grains or hard Weld a piece of flighting, (6-8"...
Page 41: Parts/Assemblies
Parts/Assemblies PARTS/ASSEMBLIES 6” SWEEPWAY REF. # DESCRIPTION QTY. PART # REF. # DESCRIPTION QTY. PART # Auger/backboard assy. Screw, 5/16 – 18 x 1-3/4” J0570 Clutch rod support clamp E5314 Screw, 5/16 – 18 x 2”, self-drill J0584 Sump & gearbox assy.
Page 42 Parts/Assemblies 8” & 10" SWEEPWAY...
Page 43 Parts/Assemblies 8” &10” SWEEPWAY REF. # DESCRIPTION QTY. 8” PART # 10” PART # Backboard pivot rod E0107 E0107 Auger/backboard assy. Clutch rod support clamp E5364 E53162 Sump & gearbox assy. E53878 E53341 Independent intermediate sump top E53989 E53964 Independent intermediate sump pull rod handle...
Page 44 Parts/Assemblies UNLOAD TUBE REF. # DESCRIPTION QTY. 6” PART # 8” PART # 10” PART # Intermediate sump, w/ rollers E5390 E5398 E5395 Independent int. sump, 10", 2018 E53981 E53951 Independent int. sump slide gate assy., 10" E53987 E53963 Intermediate sump slide gate assy., 6" & 8" E5409 E5409 E5409...
Page 45 Parts/Assemblies 6” BACKBOARD REF. # DESCRIPTION QTY. PART # Auger support bushing assy. E6089 Auger connector shaft, 1" OD, 8-1/2" long E6704-03 Torsion bar bracket E6791 Torsion bar bracket, split E6792 Auger Auger extension Backboard Screw, 5/16 – 18 x 1-3/4” J0570 Square U-bolt, 3/8"...
Page 46 Parts/Assemblies 8” BACKBOARD REF. # DESCRIPTION QTY. PART # Backboard Auger, 70-1/2” E11880 Inner auger Bearing support spacer E60632 Auger support bushing assy. E60901 Auger connector shaft, 1" OD, 8-1/2" long E6704-03 Torsion bar bracket E6791 Torsion bar bracket, split E6792 Torsion bar pivot bracket E69771...
Page 47 Parts/Assemblies 10” BACKBOARD REF. # DESCRIPTION QTY. PART # Torsion bar pivot bracket E0104 Backboard Auger support bushing assy. E60911 Bearing support spacer E60914 Torsion bar bracket, split E6789 Backboard pivot mount EU8200 Auger, 49.5’ EU8205 Auger, 69.5’ EU8222 Auger connector shaft, 1-1/4” OD, 13" long EU9044 Screw, 3/8 –...
Page 48 Parts/Assemblies HORIZONTAL POWERHEAD MOTOR DRIVE...
Page 49 Parts/Assemblies HORIZONTAL POWERHEAD MOTOR DRIVE REF.# DESCRIPTION QTY. 6” PART # 8” PART # 10” PART # Powerhead w/ shield & bearing E5600 E5601 E5602 HPH w/ bearing, shield, lg. motor mount. ----- E56011 E56021 STD powerhead housing E5567 E5568 E5569 6”...
Page 50 Parts/Assemblies BASIC VERTICAL AUGER SWSW0052 10/17/2012 MKB Stiffened Bin Installation Non-Stiffened Bin Installation...
Page 51 Parts/Assemblies BASIC VERTICAL AUGER REF. # DESCRIPTION QTY. 6" PART # 8" PART # 10" PART # Rollpin, 5/16" x 1-3/4" J1495 J1495 J1495 Top shaft E58091 E97711 E58243 Hex nut, 7/16" -14 J1035 ----- ----- Hex nut, 1/2" – 13 ----- J1040 J1040...
Page 52 Parts/Assemblies...
Page 53 Parts/Assemblies Table applies to two-motor drive and one-motor drive units...
Page 54 Parts/Assemblies...
Page 55 Parts/Assemblies CONNECTOR SLEEVE & UNLOAD AUGER SQUARE CONNECTORS FOR (LEFT TO RIGHT) 6”, 8” & 10” UNLOAD AUGERS REF. # DESCRIPTION QTY. 6” PART # 8” PART # 10” PART # Connector sleeve, 6 x 18” E5423 Connector sleeve, 8 x 18” E5424 Connector sleeve, 10 x 18”...
Page 56 Parts/Assemblies TOP DRIVE...
Page 57 Decal, Danger, Replace Missing Shield L0271 L0271 L0271 Decal, Safe Operation L0281 L0281 L0281 Decal, Keep Away From Moving Parts L0284 L0284 L0284 Decal, Sukup logo (Not shown) L0317 L0317 L0317 Top drive spacer M3239 E57415 E57415 Rack & pinion opener ----- E5919 E5969...
Page 58 Parts/Assemblies 25° INCLINE AUGER FOR 6" UNLOAD...
Page 59 Parts/Assemblies 25° INCLINE AUGER FOR 6” UNLOAD REF. # DESCRIPTION QTY. 6” PART # 5’ basic incline E5950 Flighting & auger tube E5622 Incline shaft E56421 Shaft E54151 Shaft, auger to knuckle E56411 Hinged motor mount E5746 Small pivot rod E5744 10”...
Page 60 Parts/Assemblies INCLINE AUGER FOR 8” & 10” UNLOAD 8” Unload uses 25°, 8-10” Incline (E5030 – 2-belt; E5031 – 3-belt) 10” Unload uses 20°, 10-12” incline (E5020 – 3-belt) REF. # DESCRIPTION QTY. 8-10” PART # 10-12” PART # Incline, 25°, 2-belt E5042 Incline, 25°, 3-belt E5032...
Page 61 Parts/Assemblies 25° INCLINE AUGER FOR 8” UNLOAD (E5032 – 3-belt)
Page 62 Hairpin clip, .120 x 2.5 J5412 Decal, Do Not Enter Bin, Keep Clear of Augers L0258A Decal, Danger, Replace Missing Shield L0271 Decal, Safe Operation L0281 Decal, Keep Away From Moving Parts L0284 Sukup logo L03161 Hinge spacer, 2.438" E5740...
Page 63 Parts/Assemblies 20° INCLINE AUGER FOR 10” UNLOAD (E5010 – 3-belt)
Page 64 Bushing, rubber, 1/2" ID J5021 Hairpin clip, .120 x 2.5 J5412 Decal, Do Not Enter Bin, Keep Clear of Augers L0258A Decal, Danger, Replace Missing Shield L0271 Decal, Safe Operation L0281 Decal, Keep Away From Moving Parts L0284 Sukup logo L03161...
Page 65 Parts/Assemblies 6" SWEEPWAY CENTER SUMP...
Page 66 Parts/Assemblies 6” SWEEPWAY CENTER SUMP REF. # DESCRIPTION QTY. 6” PART # Center sump shell E5300 Center sump cover E5306 Center sump brace E5308 Chain cover E5309 Gearbox support cover E5312 Clutch shifter arm assembly E5313 Top gearbox bearing support slide plate w/ bearings E5317 #50 chain, 73 links &...
Page 67 Parts/Assemblies 8" SWEEPWAY CENTER SUMP...
Page 68 Parts/Assemblies 8" SWEEPWAY CENTER SUMP REF. # DESCRIPTION QTY. PART # Clutch shifter arm assembly E53132 Chain, #50, 73 links E5319-01 Spacer washer, 3/8” ID, 2-1/4” OD E5324 Weld support plate w/ snap ring, 10" E5339 Side gate rail E5350-14...
Page 69 Parts/Assemblies 10" SWEEPWAY CENTER SUMP...
Page 70 Parts/Assemblies 10" SWEEPWAY CENTER SUMP REF. # DESCRIPTION QTY. PART # Clutch shifter arm assembly E53132 Spacer washer, 3/8” ID, 2-1/4” OD E5324 Weld support plate w/ snap ring, 10" E5339 Side gate rail E5350-14 Sump cover E5354 Gearbox support cover...
Page 71 Parts/Assemblies INDEPENDENT INTERMEDIATE SUMP 8” & 10” REF. # DESCRIPTION QTY. PART # Sump bottom E53951 Slide gate E53963 Sump top E53964 Sump bottom E53981 Slide gate E53987 Sump top E53989 Bearing, 1/4" ID, 5/8” OD J0016 Screw, 1/4 – 20 x 1” J05081 Screw, 5/16 –...
Page 72 Parts/Assemblies 6”, 8” & 10" SWEEPWAY INTERMEDIATE SUMPS REF. # DESCRIPTION QTY. PART # Bearing, 1/4" ID, 5/8” OD J0016 Screw, 1/4 – 20 x 1” J05081 Hex nut, 1/4" – 20 J0990 Lock washer, 1/4" J1195 * QTY. varies with sump size...
Page 73 Parts/Assemblies 6" SWEEPWAY TOP GEARBOX REF. # DESCRIPTION QTY. PART # Complete gearbox, sump, top 6”, 8” (prior to 2011) E5325 Complete gearbox, sump, top 8”, 2011 E5374 Gearbox case, two hole F9004 Snap ring, 1.37, 5160-137 J3589 1/2" center sunk hex head plug J2615 Cup, 2-23/32”...
Page 74 Parts/Assemblies 8" SWEEPWAY TOP GEARBOX REF. # DESCRIPTION QTY. PART # Plate, open end E5902-01 Shaft, 6” E5905 Shaft, 8.601”, w/ keyway E5908 Gearbox case F9004 Hub, standard F9007-01 Bearing cup J0105 Tapered bearing, 1” J0111 Bearing cup, 2-23/32” OD J0115 Tapered bearing,1-3/8”...
Page 75 Parts/Assemblies 10" SWEEPWAY TOP GEARBOX REF. # DESCRIPTION QTY. PART # Sprocket shaft E5379 Plate, open end E5902-01 Key,1/4" x 1" E5915 Shaft, 8" EU0839 Output hub, 1-1/4" shaft EU0840 Gearbox case F9004 Key, 1/4" sq. x 3/4" G7508 Bearing cup, 2-23/32 OD J0115 Tapered bearing, 1-3/8”...
Page 76 Parts/Assemblies 6" & 8" SWEEPWAY LOWER GEARBOX REF. # DESCRIPTION QTY. PART # Complete gearbox, lower sump E5320 Complete gearbox, lower sump E5378 Shaft, 1-3/8” main, lower sump E5900 Shaft, 10-7/16", 13/8" w/ keyway E5927 Open end plate w/ grease zerk & cup E59021 Lower hub, 6”...
Page 77 Parts/Assemblies 10" SWEEPWAY LOWER GEARBOX REF. # DESCRIPTION QTY. PART # Hub casting, HD, 1-3/8”, 10”, 1998 E5365 Gearbox shaft, 10” E5366 Shaft, 8-5/16” E5367 Key, 1/4” sq. x 1” E5915 Lower gearbox casting, HD, 3 hole F9051 Bevel gear, 18 tooth, 1-1/4” bore F9052 Gear, 27-tooth, 1-3/8”...
Page 78 Parts/Assemblies TOP GEARBOX BEARING SUPPORT SLIDE PLATE E5317 (6”)* E5339 (8” & 10”) REF. # DESCRIPTION QTY. 6” PART # 8” & 10” PART # Bearing, 1-1/4” ID, 2-1/2” OD J0060 Bearing, 1.1811 ID, 2.8346 OD J00599 Snap ring, 2.047” J35991 *Also 8”...
Page 79 Parts/Assemblies CLUTCH SHIFTER ARM E5313 (6”) E53132 (8” & 10”) REF. # DESCRIPTION QTY. 6” PART # 8” & 10” PART # E53131 Clutch arm weldment E5351 E5311 Clutch shifter support bracket E5352 Bearing, 3/4",cam follower J0035 J0035 Screw, 3/8 -16 x 1” J0606 J0606 Lock nut, 3/8”...
Page 80 Parts/Assemblies 8" SWEEPWAY RACK & PINION OPENER (E5919) REF. # DESCRIPTION QTY. PART # Slide guide E5962 Opener crank shaft E5964 Slide plate rack weldment E5916 Spacer E5966 Pinion gear E5961 Key, 1/4 x 1-1/2" E9007 Screw, 5/16 – 18 x 1-3/4”...
Page 81 Parts/Assemblies 10" SWEEPWAY RACK & PINION OPENER (E5969) REF. # DESCRIPTION QTY. PART # Slide guide E5962 Opener crank shaft E5964 Slide plate rack weldment E5963 Spacer E5966 Pinion gear E5961 Key, 1/4 x 1-1/2" E9007 Screw, 5/16 – 18 x 1-3/4”...
Page 82 Parts/Assemblies 4-TO-1 REDUCTION DRIVE WHEEL Standard on all 6” sweeps and on 8” sweeps in bins up to 33’ dia. REF. # DESCRIPTION QTY. 6" COMP # 8" PART # Complete wheel E6094 E6092 6” assembly mount, E6095 2010 8” assembly mount, split, w/ brng., E6096 2010 10”...
Page 83 Parts/Assemblies 16:1 DRIVE WHEEL & RECLAIM SHIELD ITEM # DESCRIPTION 8” PART # 10” PART # QTY. Drive wheel, w/ green tread* E73491 E73491 Shield bracket E7381 E7381 Reclaim shield extension plate E7397 E7397 Gearbox, w/ mount E7408 EU8246 Brace E7412 E7412 Reclaim shield...
Page 84 Parts/Assemblies 16-TO-1 REDUCTION DRIVE WHEEL REF. # DESCRIPTION QTY. 8” PART # 10” PART # Flat washer, 11/16” E7322 E7322 Chain, # 40, 37 links E7327 E7327 Grain deflector E7407 E7413 Input shaft E7419 EU8249 Mounting bracket E7428 E7411 Input side of gearbox EU8247 EU8247 Output side of gearbox...
Page 85 Parts/Assemblies REAR CARRIER WHEEL REF. # DESCRIPTION QTY. PART # Rear carrier wheel kit E6099 Rear carrier wheel bracket, left E7741 Rear carrier wheel bracket, right E7740 Rubber wheel, 6”, w/ bushing J7271 U-bolt, 3/8" - 16 J0644 Bolt, 3/8 - 16 x 3-1/4" J0663 Flat washer, 3/8"...
Page 86 Parts/Assemblies SWEEP AUGER SUPPORT BUSHING REF. # DESCRIPTION QTY. 6” PART # 8” PART # Complete assembly E6089 E60901 Mounting bracket E6061 E60631 Sweep auger bushing E6065 E6065 Screw, 3/8 - 16 x 1” J0606 J0606 Hex nut, 3/8” – 16 J1020 J1020 Lock washer, 3/8”...
Page 87: Quick Reference Parts List (Motors, Pulleys, Bushings)
Parts/Assemblies QUICK REFERENCE PARTS LISTS OPTIONAL - FARM-DUTY MOTORS (1750) FRAME SHAFT LBS. PART # E182T 1-1/8" H2175 F145T 7/8" H2475 J184T 1-1/8" H2845 E182T 1-1/8" H3345 L184T 1-1/8" H3675 F184T 1-1/8" H4190 K215T 1-3/8" H4900 213T 1-3/8" H4910 215T 1-3/8"...
Page 88: Replacement Vertical Flighting, Shafts & Tubes
Parts/Assemblies REPLACEMENT VERTICAL FLIGHTING, SHAFTS & TUBES -- STANDARD BOTTOM DRIVE NOTE: Vertical flight numbers include flinger and top and bottom shafts. FLIGHTING FOR VERTICAL AUGER DESCRIPTION 6" PART # 8" PART # 10" PART # 14' w/ dbl flight, 1" E5806 - - - - - - - - - -...
Page 89: Unload Auger Flighting Assembly
Parts/Assemblies UNLOAD AUGER FLIGHTING 6” SWEEPWAY BIN DIAMETER PART # *15'-15' 6" E6430 16' 5" (5M) E64301 *18'-18' 7" E6431 19' 8" (6M) E64310 *21'-21' 8" E6432 22' 11" (7M) E64320 *24'-24' 9" E6433 26' 3" (8M) E64331 *27'-27' 10"...
Page 90: Sweep Auger Replacement Kits
Parts/Assemblies SWEEP AUGER REPLACEMENT PARTS Tables below show replacement auger part numbers & lengths. Backboard Assy. includes backboard, auger, torsion tube & hardware. Sections are numbered from middle of bin to sidewall. Backboard Length Length Length Length Length Assy. Auger Auger Auger Auger...
Page 91 Notes NOTES ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________ ____________________________________________________________________________________________...
Page 92: Contact Information
Contact Information CONTACT INFORMATION Owner’s manuals are available from Sukup and additional copies can be requested at the address, phone number or e-mail address shown below. Please indicate manual number L1435 when requesting Sweepway Owner’s Installation & Operation Manual. Sukup Dealer Information...
