Weego N70 Manual

GETTING TO KNOW YOUR PRODUCT

CHARGE UP YOUR DEVICE

When you unpack your new Weego 70 for the first time, charge it up to 100% with either the wall or car charger and included USB-C charging cord. Remember to recharge your Weego 70 every 6 months, even when you're not using it - it will help extend its lifespan.

It takes 3.5 hrs. to fully charge. The indicator lights will flash one by one while the unit is charging. A solid light indicates a completed level of charge.

POWERING ON/OFF

There's a Power ON/OFF Button on the back of your Weego 70. While powered "ON", the blue power button will remain illuminated. Make sure you turn OFFyour Weego 70 after every use; leaving it on slowly drains the battery.

JUMP STARTING

BEFORE YOU JUMP

• Read all instructions and safety information prior to using this product. Improper use of this product will void your warranty and may result in product damage, excess heat, toxic fumes, fire, and other unsafe conditions for which Weego is not responsible.
• Read vehicle owner's manual first: it may have specific cautions and instructions about jumping your engine.
• This product is for use on 12V Lead-Acid batteries only! DO NOT use this product on any other voltage battery, such as 6V, 24V, etc. DO NOT use this product on lithium-ion batteries.
• Never jump an engine in an enclosed area.
• Put your vehicle in PARK and engage the emergency brake (boats and powersports' vehicles should be put in NEUTRAL).
• TURN OFF ALL ELECTRONICS! - air conditioner, radio, lights, etc.
• Remove any devices attached to your Weego 70 Never leave your Weego 70 connected to your engine's battery unless actively jumping.
• Always disconnect the Smarty Clamps from your Weego 70 when not in use.

JUMP STARTING YOUR ENGINE

1. Ensure your engine is completely OFE
2. Securely connect the Smarty Clamps to your Weego 70, then power ON.

3. Attach BLACK clamp to your battery's negative (-) terminal, then the RED clamp to your battery's positive (+) terminal Adjust your Smarty Clamps to achieve MAXIMUM contact with the terminals. Poor connections will prevent you from starting your engine! Clear off any dirt or build-up with a wire brush or a dry towel before connecting your clamps.

4. Place your Weego 70 in a secure location or suspend using the provided hook& lanyard so it won't fall. Check your Smarty Clamps lights.
5. When you have a SOLID GREEN READY light, start your engine. If the engine doesn't start, turn off your vehicle and check your Smarty Clamps lights.

6. After a successful start, quickly disconnect the Smarty Clamps from your Weego 70.

7. Detach the Smarty Clamps from the battery.

8. You're now good to go - be sure to run your engine for at least 15 minutes before shutting it off again so it has time to recharge your battery.

If you are having issues getting your engine started, see the Troubleshooting section in your quick start guide, owners manual or on myweego.com for further details and assistance.

Exposed Metal Jaws May Be HOT After Use!

UNDERSTANDING YOUR Smarty Clamps

Your Smarty Clamps have a "smart" box that will help guide you through a jump with both sight and sound. It will let you know when it is safe to jump or if there is an error.

TROUBLESHOOTING

Visit www.myweego.com/support for FAQs and additional troubleshooting inquiries and details.

My unit won't power on/charge/charge past a few lights
If you're unit won't power on, won't take a charge OR won't charge past a few lights then been overdischarged. This can happen if the unit is left ON,or if an engine pulled the Weego battery past a certain limit during a jump start.

Please reach out to support@myweego.com to let them know about this issue - we'll receive and test the overdischarged Weego, then determine if we can repair it or if it needs to be fully replaced.

The unit won't jump start my vehicle

We have listed below a few things that can cause a failed jump start:

• Poor connection between the Weego clamps and vehicle battery: the better the connection, the more likely you are to have a successful jump
• Dirty battery terminals: build up prevents all the available power from reaching your battery
• Vehicle-specific compatibility issues: occasionally we come across a vehicle that has unique power demands that a smaller model cannot fulfill, even though its within our recommended engine range. In addition, vehicles with heavier electronics can sometimes create issues when jumping with a Weego; we mostly see this in push-to-start vehicles.
• Cold temperatures: Freezing temperatures create a lot of resistance in an engine which means it can require up to 3.5X the usual amount of power to get started; for example, an engine that usually needs 200A could need up to 700A in the extreme cold. In addition, if your Weego was stored in the cold temps it will make it harder for the Weego to deliver its full power.
• Low-Charged Weego: its always best to work with full power on your Weego if you can. Our jump starters perform better at 100% charge than they do at 20% charge, especially when jumping larger engines.

USB-A & USB-C CHARGING

Charge your phone, tablet and other portable devices with your Weego 70. Weego 70 comes equipped with Detect-o-Matic USB Fast Charging.

You can charge your USB-A devices by plugging in your own USB-A cord into your Weego 70 USB-A port OR by plugging the your own USB-C to USB-C cord into your Weego 70 USB-C input/output port. Connect to your device, power on Weego 70 and start charging!

LIGHTING

Your Weego 70 comes with a 600 lumen LED flashlight. Power on your Weego 70, then briefly press and release the flashlight button to initiate the following sequences:

• 1^st click: Normal
• 2^nd click: Strobe
• 3^rd click: SOS
• 4^th click: OFF

Your Weego 70 will give you up to 15 hours of flashlight time and up to 30 hours of strobe & SOS light on a full charge.

WEEGO CUSTOMER SUPPORT
We are dedicated to providing the best possible service. To reach Weego Customer Support, visit myweego.com/support or email support@myweego.com.

myweego.com
