Xiaomi G9 Plus / G10 Plus Manual

Replacement Instructions

1. Pull the dust compartment release switch in the direction illustrated in image , then remove the dust compartment from the vacuum cleaner as illustrated in image .

2. Remove the filter from the vacuum cleaner by pulling it down in the direction shown in the figure. Insert the new filter into the vacuum cleaner and gently press down.

3. Remove the pre-filter, then place the new pre-filter with its front side facing up into the cyclone assembly.

4. Slightly tilt the dust compartment so its slot aligns with the clip on the vacuum cleaner. Then gently push the dust compartment until it clicks into place.


Note:
Illustrations of product, accessories, and user interface in the user manual are for reference purposes only. Actual product and functions may vary due to product enhancements.

Specifications

For more information about the consumer warranty benefits, please refer to Xiaomi's official website https://www.mi.com/en/service/warranty/.
