Page 1 Owner’s Manual Thank you for your purchase of the PR-80 Realtime Video Presenter. 201b Before using this unit, carefully read the sections entitled:“USING THE UNIT SAFELY” (DV-7DL PRO Owner’s Manual P.4), and “IMPORTANT NOTES” (DV-7DL PRO Owner’s Manual p.6). These sections provide important information concerning the proper operation of the unit.
Page 2: Before Using The Pr-80
You can play multiple clips in a specified sequence, or have a specified clip play automatically upon startup. Automatic Operations with the Scheduler You can use the Scheduler to have the PR-80 automatically perform a variety of functions, such as playing back data, stopping, synchronizing times over a network, or starting up at a predetermined time.
Page 3: Direct Linear Editing
Before Using the PR-80 Editor Features These are described in the "DV-7DL PRO Owner's Manual." The PR-80 is equipped with the editing features of the DV-7DL PRO, and lets you use them to edit video. Direct Linear Editing This unit has a wide range features that let you perform editing intuitively, and despite being a non- linear editing device, it makes it possible for you to carry out direct linear editing with with the feel of a linear editing system.
Page 4: Table Of Contents
Setting Up and Connecting Equipment ....................10 Instructions for Connecting Digital Video Devices Equipped with DV Connectors..11 Connecting to a Computer Over a Network................12 Examples of Using and Connecting the PR-80..................13 Usage Examples ..........................13 Connection Examples ........................15 Working with the Keyboard and Mouse ....................
Page 5 Using a DV-7DLC ........................100 Using the RS-232C Connector ....................105 Using a Touch Panel Display ....................105 Controlling Other Devices with the PR-80 ..................106 Controlling Another Presenter....................106 Controlling the V-4 ........................107 Controlling AR Series Devices ....................110 Making the System Settings........................
Page 6: Before Using The Pr-80
PR-80, from turning on the power to playing back and loading prepared data, in a manner that allows an easy grasp of how the PR-80 works. • Most of the procedures involve using the mouse or keyboard while viewing the PR-80’s screens.
Page 7: Other Notes
About the Hard Disk The PR-80 uses a hard disk for saving video and storing the system. Hard disks do have a limited lifetime, and thus are considered a consumable item. Depending on how the unit is handled, the hard disk may reach the end of its service life sooner than expected.
Page 8: Names Of Things And What They Do
However, you cannot connect two remote removable hard disk simultaneously on the same project. controllers simultaneously. * Always turn off the power to the PR-80 before inserting f. Headphone Jack [PHONES] and or removing the removable hard disk. Volume Knob [LEVEL] * For a detailed explanation of how the removable hard disk is installed, refer to “About the Removable Hard Disk”...
Page 9: Rear Panel
Connect a networking cable here. For more detailed 80/PC-300) here. information, refer to “Making the Network Settings” Connect devices here only when the PR-80’s power is (p. 113). turned off. You can connect to either of the two c. OUTPUT Jacks [OUTPUT:S-VIDEO, connectors.
Page 10: Setting Up And Connecting Equipment
Connecting equipment with the power turned on may cause malfunctioning and other problems. The PR-80 comes with a DV (digital video) cable for use in connecting video devices equipped with DV connectors to the PR-80’s DV connector. Use the included DV cable when connecting to the DV connector.
Page 11: Instructions For Connecting Digital Video Devices Equipped With Dv Connectors
Connector the included DV cable • Electromagnetic interference produced by using the PR-80 near a television or radio may cause unevenness in the TV screen picture color or produce noise in the radio. • If connecting to a computer's IEEE1394 connector (also called i.LINK or FireWire), be sure to use...
Page 12: Connecting To A Computer Over A Network
Connect using a LAN cable. Connecting to the computer over a network allows you to copy data from the computer to the PR-80 and access a network time server to adjust the PR-80’s timing. Whenever making these connections, always make sure that the power for all devices is turned off.
Page 13: Examples Of Using And Connecting The Pr-80
Before Using the PR-80 Examples of Using and Connecting the PR-80 Usage Examples Presenting Video Performances on Stage You can utilize the PR-80’s high-quality video and superb responsiveness to add the effects of video to concerts and other stage events. fig.stage.eps PR-80 Projector Video camera, etc.
Page 14 Before Using the PR-80 Video at Facilities It’s a breeze to set up a system that allows visitors to museums or individual booths at conventions and the like to see and hear video and audio descriptions when they want. You can also use the Scheduler to have video play automatically.
Page 15: Connection Examples
Before Using the PR-80 Connection Examples Standalone Use The PR-80 is controlled with the keyboard and mouse. For more detailed information, refer to “Playing Back Clips” (p. 48). fig.standalone.eps Display for operation Display PR-80 Power amplifier Speakers Mouse Keyboard Using the PR-80 with the Optional DV-7DLC Using the DV-7DLC provides the kind of operability you can get only with a dedicated controller.
Page 16 Before Using the PR-80 Using the PR-80 with MIDI Using the optional UM-1 or other USB compatible (UM Series) MIDI interface enables you to control MIDI devices with MIDI signals. Additionally, you can connect a V-LINK compatible device and use the V-LINK feature to enjoy a variety of video effects that bring visual element of expression to your performances.
Page 17 Projector PR-80 V-Synth Mouse Keyboard You can also use an optional PCR-50 or other USB keyboard (PCR Series or PC-300), connecting the keyboard directly to the PR-80 with no MIDI interface necessary. fig.with.pc300.eps Display for operation Projector PR-80 PCR-50 Mouse...
Page 18 Before Using the PR-80 Using the RS-232C Connector Connecting with the RS-232C cable allows you to control the PR-80 with a computer or other external control device. For more detailed information, refer to “Using the RS-232C Connector” (p. 105). fig.with.pc.eps...
Page 19 Before Using the PR-80 Controlling AR Series Devices You can use the PR-80 for MIDI control of the AR-3000 and other models in Roland’s AR (Audio Recorder) Series. This allows you to switch playback of AR Series phrases by switching clips with the PR-80.
Page 20 You can control multiple other Presenters (such as other PR-80s, PR-50s or DV-7PRs) with the PR-50. You can make settings for starting and stopping playback of clips, selecting palettes and clips, and setting switch effect times. For more details about setting the PR-80 to control other Presenters, refer to “Controlling Another Presenter” (p. 106). fig.with.DV-7PR.eps...
Page 21 Before Using the PR-80 Controlling the V-4 Using a V-4, you can handle video input from an external device connected to the V-4 as PR-80 clips. Additionally, you can use an external MIDI device to control the V-4’s effect settings and fade the final video output.
Page 22: Working With The Keyboard And Mouse
• Do not turn on the power to the PR-80 while pressing and holding down any of the keys. • After turning on the power to the PR-80, do not press any of the keys on the keyboard until the Selector screen appears.
Page 23 Before Using the PR-80...
Page 24: Introduction To Use Of The Pr-80
How the PR-80 is Organized The PR-80 consists of the two main sections below. Selector fig.selector.eps This is what first appears when the PR-80 is turned on. Various different functions use this as their starting point. Presenter fig.playmode.eps Play mode Edit mode Included here are functions used in playing back and switching video materials.
Page 25: Basic Workflow
Introduction to Use of the PR-80 Basic Workflow Most of the PR-80’s operations are performed using the mouse and keyboard as you look at the screens. The following guides you through the basic workflow, while making use of samples that were supplied with the PR-80.
Page 26 Introduction to Use of the PR-80 Starting Up Presenter Click [Presenter] in Selector. The Presenter Play mode screen appears, after a few seconds. fig.playmode01.eps • Play Mode Screen → (p. 34)
Page 27 Select a disk Click [Open] Select a project Projects are the most basic unit managed with the PR-80. Clips are played back and materials are saved in project units. • What is a Project? → (p. 45) • Creating Projects → (p. 46)
Page 28 Introduction to Use of the PR-80 Playing Back the Clip The area in the Play Mode screen where the thumbnail video images are shown is called the palette, and each of the video images is called a clip. You select the clip to be played back from the palette.
Page 29 Introduction to Use of the PR-80 Editing the Palette This is done in the Edit Mode screen. You can display the Edit Mode screen by clicking the [Edit Mode] button in the upper right of the Play Mode screen. fig.editmode01.eps...
Page 30 Introduction to Use of the PR-80 Importing Materials This is done in the Edit Mode screen. You can import new materials. When you click the [Import] button at the lower right of the screen, the following dialog appears; you can then import materials from another project, disk, or other source.
Page 31 Capturing Video from a Video Deck or Other Device You can capture video from a video deck or a similar device connected to the PR-80. When you click the [Capture] button at the lower right of the screen, a “Capture” screen for capturing video appears.
Page 32: What Is V-Link
MIDI to connect two or more V-LINK compatible devices, you can easily enjoy performing a wide range of visual effects that are linked to the expressive elements of a music performance. With V-LINK, you can easily control the PR-80 with a V-LINK compatible MIDI device. fig.connection.Vlink01.eps...
Page 33: Names Of Things In Screens/What They Do
This calls up the Utility screen (p. 40). This is used for organizing the projects on the hard disk. d. [System Preferences] Button This calls up the System Preferences screen (p. 41). These settings affect the PR-80’s overall system environment.
Page 34: Play Mode
[EXIT] Button This lets you quit the Presenter and turn off the PR-80 or switch to the "Editor" (p. 24). b. Clock This indicates the current time. You can click the mouse to open the Schedule Editor. This is also lit when the Scheduler is operational.
Page 35 For more details about clip Loop Mode settings, refer to “Making the Palette Settings” (p. 66). o. [Edit Mode] Button This switches the PR-80 to Edit mode (p. 37). p. [Color Correction] Button This displays the status of color correction. For more details about working with this, refer to "Color Correction"...
Page 36 Introduction to Use of the PR-80 r. Audio Settings Panel Volume Level Meter This indicates the volume level. [Audio] Slider This adjusts the volume during audio playback.You can reset to standard values by clicking the triangle at the position corresponding to the standard value.
Page 37: Edit Mode
[EXIT] Button This lets you quit the Presenter and turn off the PR-80 or switch to the "Editor" (p. 24). b. Clock This indicates the current time. You can click the mouse to open the Schedule Editor. This also lights up when the Scheduler is operational.
Page 38 “Copying Projects” (p. 84) and “Changing Project Names” (p. 84). h. [Play Mode] Button This switches the PR-80 to Play mode (p. 34). i. [Project] Area Here is where you can set up the automatic playback that is to take place when Presenter starts up.
Page 39 • Material Name • “Time” This is the material length. • “Date Created” This indicates the date the material was imported into the PR-80. • “Date Modified” This indicates the date the material was last edited. • “Date Shot” For materials shot with digital video cameras, this shows the date recorded by the camera.
Page 40: Utility
Introduction to Use of the PR-80 Utility This is displayed when “Utility” is selected in the Selector screen (p. 24). This function is used for organizing the projects (p. 45) on the hard disk. For more details, refer to “Organizing Projects” (p. 84).
Page 41: System Preferences
[Time Zone]. For more details about time servers, refer to "Adjusting the PR-80's Time and Date by Connecting to a Time Server" (p. 113). [Time Zone] refers to the regional standard time zones around the world. It indicates the standard time for the region as the difference (plus or minus up to 12 hours) from the time at the Royal Greenwich Observatory in England (Greenwich Mean Time, or GMT).
Page 42 Power On and Off” (p. 112). g. “Network” This setting is used when the PR-80 is connected to a computer network. Included here are settings for time servers used in adjusting the PR-80’s time and for copying material materials from computers to the PR-80 when the PR-80 is connected to a network.
Page 43: Turning The Power On And Off
The selector appears. Select [Presenter] or [Editor]. fig.selector.eps The PR-80 can also be turned on by means of an external power switch. To turn on the PR-80 without pressing the PR-80’s [POWER] button, refer to “Using an External Power Switch to Turn the Power...
Page 44: Turning Off The Power
• If a project has not been saved, the message “Would you like to save the current project?” appears. If you want to save the project, click the [Save] button. • Do not hold down the [POWER] button for four seconds or longer. Turn off the power to all of the peripheral devices connected to the PR-80.
Page 45: Creating And Opening Projects
The PR-80 manages materials in what are called “projects.” What is a Project? Projects are the most basic unit managed with the PR-80. Materials are imported into projects, and the projects are played back in real time in Presenter using the imported materials. Furthermore, settings for realtime playback and the data for editing operations are also saved in projects.
Page 46: Creating Projects
Introduction to Use of the PR-80 Creating Projects This procedure creates a new project. Click the “Open” button in the upper part of the Play Mode screen (p. 34) or Edit Mode screen (p. 37). The “Open” dialog appears. fig.open01.eps...
Page 47: Opening Projects
Introduction to Use of the PR-80 Opening Projects This opens projects already saved to the PR-80. Click the “Open” button in the upper part of the Play Mode screen (p. 34) or Edit Mode screen (p. 37). The “Open” dialog appears.
Page 48: Playing Back Clips
Introduction to Use of the PR-80 Playing Back Clips When you turn on the power to the PR-80 and click the [Presenter] button in the Selector screen, Presenter's Play Mode screen appears, and the most recently opened project opens. Using the Mouse to Play Back Clips Click on a clip thumbnail in the palette area to start playback of the clip.
Page 49: About The Video Output Monitor Display
Introduction to Use of the PR-80 Shifting a Clip’s In Point and Out Point The point at which a clip starts playback is called the In point, and the point where it stops playing is called the Out point. Click...
Page 50 Introduction to Use of the PR-80 Turning Displays On and Off You can turn the video output monitor display on and off. The settings menu is displayed when you right-click on the video output monitor. fig.monitor.menu02.eps Checked options are displayed in the video output monitor display. Unchecking an item removes it from the display.
Page 51: Switching The Palette
Introduction to Use of the PR-80 Switching the Palette Clicking on a palette in the palette list switches the palette. fig.playmode07.eps Palettes list You can change the sequence of palettes, change palette names, and perform various other editing functions in Edit mode (p. 37). For more on palette editing procedures, refer to “Editing Palettes” (p.
Page 52: Transition Effects
Introduction to Use of the PR-80 Transition Effects This setting determines the time used to switch from a currently playing clip to playback of the next clip. You can also select the type of transition effect to be used. fig.playmode08.eps...
Page 53: Dual Stream
Introduction to Use of the PR-80 Dual Stream You can play back two pieces of video material simultaneously, and switch between them. [Dual Stream] Button INSERT Preview Window T-bar Slider These are displayed MAIN Preview Window when the [Dual Stream] button is lit.
Page 54: Effects
Introduction to Use of the PR-80 Effects You can apply a wide range of effects to the video output from the PR-80. [Main] button (When in the Dual Stream mode, this becomes the [M] and [I] buttons.) Defaults button Effect buttons Effect 1 Effect 2 Effect 3 Effect 4 Click the [Main] button to apply effects to the video playback.
Page 55: Color Correction55
Introduction to Use of the PR-80 Color Correction You can adjust the hue (H), saturation (S), and bvightness (V) of the video picture. Color Correction button Click the Color Correction button to display the Color Correction Palette. Click the Color Palette and adjust the hue and saturation.
Page 56: Masking
[Mask] Button * To stop display of the mask, click [Mask] a second time. The PR-80 lets you use eights types of masks. To switch the type of mask, right-click the [Mask] button and select the mask type from the menu.
Page 57: Color Bar
* To stop display of the color bar, click [Color Bar] a second time. The PR-80 comes with eight types of color bars. To change the type of color bar, right-click the [Color Bar] button and select the type of color bar you want from the menu.
Page 58: Turning Loop Playback On And Off
Introduction to Use of the PR-80 Turning Loop Playback On and Off You can turn the Loop Mode settings on and off to have the same clip play repeatedly, play clips in sequence, or play back another specified clip. Click the [Loop] button to switch the setting.
Page 59: Assigning Materials To Palettes
Introduction to Use of the PR-80 Assigning Materials to Palettes Clips in the palette can be arranged in any order you like. You can assign materials to the clips. Select materials from the Materials list. This procedure is carried out in the Edit Mode screen (p. 37).
Page 60 Introduction to Use of the PR-80 Importing Materials from Another Project Not only can you capture material from the same project, you can import material from other projects.For more details about working with this, refer to “Importing Materials from Another Project”...
Page 61: Saving Projects
Introduction to Use of the PR-80 Saving Projects Click the [Save] button in the upper part of the screen. The project is updated and saved. You carry out this operation in the Edit Mode window (p. 37). fig.editmode05.eps [Save] button You cannot change a project’s name and then save the project under the different name.
Page 62: Using V-Link
SMPU-64, UM-1, UM-1S, UM-1X, UM-1SX, UM-2, UM-2E, UM-2C, UM-4, UM-550, UM-880, PCR-30, PCR-50, PCR-80, PC-300 The driver software included with these units is not used by the PR-80. In addition, when connecting multiple interfaces and using interfaces with multiple ports, set all inputs to merge (mix) and all outputs to parallel (whereby the same signals are output).
Page 63 Introduction to Use of the PR-80 The functions that can be controlled may vary with the V-LINK compatible MIDI device. Refer to the owner’s manual for each MIDI device for more information on the device’s compatibility. In addition, for details on controlling with MIDI without using the V-LINK function, refer to “Controlling Presenter with MIDI.”...
Page 64: Practical Use Of The Pr-80
Practical Use of the PR-80 Making the Settings for the Project You can make more detailed settings for projects in Presenter’s Edit mode. In this case, you can make the following settings. → Editing Palettes “Editing Palettes” (p. 65) You can alter names, rearrange palette sequences, delete clips in palettes, and perform other editing functions.
Page 65: Editing Palettes
Practical Use of the PR-80 Editing Palettes Here you can change palette names, rearrange palette sequences, delete clips in palettes, and perform other editing functions. To edit a palette, right-click on the palette and work from the context menu that is displayed.
Page 66: Making The Palette Settings
Practical Use of the PR-80 Making the Palette Settings You can make the Loop mode settings for all of the clips in a palette simultaneously. You can have the same clip play repeatedly, play the subsequent clip after the current clip is finished, or specify another clip to play back.
Page 67: Editing Clips
Practical Use of the PR-80 Editing Clips You can change clip names, rearrange clip sequences, copy and delete clips, and perform other editing functions.To edit a clip, right-click on the clip and work from the context menu that is displayed.
Page 68 Practical Use of the PR-80 Cutting and Moving Clips to Other Locations and Palettes Right-click on the name of the clip you want to cut in the “Clips” list. A context menu appears. Select [Cut]. Right-click on the location (even in another palette) where you want to paste the cut clip in the “Clips”...
Page 69 Practical Use of the PR-80 Editing Clips in the Palette Window You can edit clips in the Palette window. Right-click on the “Palettes” list. A context menu appears. Select [Open palette window]. The Palette window opens. fig.palette.window01.eps Context menu You can also open the Palette window by double-clicking in the “Palettes” list.
Page 70: Making The Clip Settings
Practical Use of the PR-80 Making the Clip Settings Here you can set each clip’s Loop Mode settings, In point and Out point, volume levels, and more. Clip settings are made in the Parameter Area. fig.editmode06.eps Parameters area Setting the Clip Playback Segment This sets the clip’s In point and Out point.
Page 71 Practical Use of the PR-80 Using the Transport Control • : Return to first frame • : Advance to last frame • : Go back 1 frame • : Advance 1 frame • : Go back 10 frames • : Advance 10 frames •...
Page 72 Practical Use of the PR-80 Using the In Point and Out Point Settings Icons Out point • Sets the In point • : Sets the Out point • : Plays back from the In point to the Out point In point Using the Optional DV-7DLC •...
Page 73 Practical Use of the PR-80 Setting the In Point and Out Point While Playing the Audio You can set the In point and Out point as the audio is being played. Select a clip in Edit mode. Press in the upper left of the clip parameter Preview Area to switch on scrub playback with audio.
Page 74 Practical Use of the PR-80 Setting Loop Mode for Each Clip You can make separate Loop mode settings for each clip.When this is turned on, each clip plays in accordance with its own Loop Mode setting. You can have the same clip play continuously or play the next clip when the current one is finished.
Page 75 Practical Use of the PR-80 Setting the Volume for Each Clip You can adjust the volume level of each clip independently of the others. Adjust clip volume levels individually when, for example, there are discrepancies in the levels from one clip to another.
Page 76: Changing Material Settings
Practical Use of the PR-80 Changing Material Settings You can change material names, copy and delete materials, and perform other tasks. To change a material’s settings, right-click on the material whose setting you want to change and work from the context menu that is displayed.
Page 77: Setting Automatic Playback
Practical Use of the PR-80 Changing Material Thumbnail Images Click on the material whose thumbnail image you want to change in the “Materials” list. Move the thumbnail slider in the “Information” Area. fig.editmode07.eps Preview Thumbnail slider The thumbnail switches to the frame shown at the current slider position.
Page 78: Importing Materials
Practical Use of the PR-80 Importing Materials Importing Materials from Another Project You can import materials from other projects. Click the [Import] button at the lower right of the Edit Mode screen. The “Import material” dialog is displayed. fig.import01.eps Select disk...
Page 79: Capturing Video From A Video Deck Or Other Device
Start playback of the external device. You can see the playback in the monitor. When you connect a deck to the PR-80 with a DV cable and select “DV” input, you can operate the deck with transport buttons in the screen.
Page 80: Importing Video From An Editor Library
Practical Use of the PR-80 Importing Video from an Editor Library You can import video from a Library registered with the "Editor" (p. 24) into your project. Go to the bottom right of the Edit mode window and click the [Import] button. The "Import Material"...
Page 81: Importing Materials Created With A Computer
You can import materials using video editing software on a computer with the capture function (p. 79). You can also use the network function (p. 113) to copy materials to the PR-80 from a computer. Press the Eject button on the PR-80’s front panel to open the CD-ROM drive’s disk tray.
Page 82 Practical Use of the PR-80 Select the disk you want to import from the “Disks” list. Select the material you want to import in the “Materials” list, then click the [Import] button. To select multiple materials, hold down the [Shift] key as you select.
Page 83: Importing Masks Created On A Computer
Using a network, you can import still pictures created on a computer into the PR-80 as masks (p. 56). You can make the setting for a mask for a single PR-80 unit. It isn't possible to make the setting on a project-by-project basis.
Page 84: Organizing Projects
Practical Use of the PR-80 Organizing Projects You can create copies of projects on the hard disk and change their names. These operations are carried out in the Utility screen (p. 40). fig.utility02.eps Disks list Project information Projects list Done...
Page 85: Deleting Projects
Practical Use of the PR-80 Deleting Projects Moving Projects to the Trash Click Selector’s [Utility] button. The Utility screen appears. Select the disk you want to work with from the “Disks” List. Right-click on the project you want to delete in the “Projects” List.
Page 86: Using Scheduler To Control Presenter
Use of Scheduler requires that the PR-80’s time be set. You can set the time in the “System Preferences” (p. 41). You can also synchronize the PR-80 with the time data from a network time server and have the time adjusted automatically (p. 115).
Page 87: Deleting A Schedule
The unit has a built-in clock for Scheduler operations. This clock is intended for use with a time server (see p. 115 of the PR-80 Owner's Manual). The internal clock cannot be expected to keep accurate time if the PR-80 is used alone.
Page 88: Controlling Presenter With Midi
Switch Presenter to Play mode (p. 34) when controlling it with an external device. Using MIDI Devices Using an optional USB MIDI interface, you can control the PR-80 in a variety of ways from a MIDI device. Connect the USB interface to the [USB] connector on the PR-80 with a USB cable.
Page 89 Practical Use of the PR-80 If you're in the Play mode, click the [Preferences] button and then the [MIDI Preferences] button. If you're in the Edit mode, click the [Preferences] button. If you're in the Play mode, click the [Preferences] button, and when the panel appears, click the [MIDI Preferences] button.
Page 90 Practical Use of the PR-80 If the transition effect time is controlled via MIDI, set the MIDI message to be used in “Transition Time Control” (controls are not accepted via MIDI when this is set to [OFF]). The transition effect time setting is controlled with the selected MIDI message.
Page 91 Practical Use of the PR-80 If you're switching the Mix mode for the Dual Stream mode via MIDI, go to "Mix Mode" and set the MIDI message to be used. (Controls are not accepted via MIDI when this is set to [OFF].) The Mix mode is changed using the selected MIDI message.
Page 92 Practical Use of the PR-80 If you're switching the Stream mode for masking via MIDI, go to "Mask Control" and set the MIDI message to be used. (Controls are not accepted via MIDI when this is set to [OFF].) Masking is switched on and off using the selected MIDI message.
Page 93 Practical Use of the PR-80 Controlling Color Correction You can control color correction (p. 55) via MIDI. Color correction lets you perform independent control for the picture's hue (H), saturation (S), and brightness (V). Set the MIDI preferences. These settings are saved without regard to the project.
Page 94 Practical Use of the PR-80 Controlling Fades You can control, via MIDI, the fade (output fade) applied to the final video output. Set the MIDI preferences. These settings are saved without regard to the project. Making these settings lets you use a MIDI device for the following operations.
Page 95 Practical Use of the PR-80 Controlling Effects You can control effects (p. 54) via MIDI. You can independently control the effects corresponding to the Effect buttons 1 through 4. Set the MIDI preferences. These settings are saved without regard to the project.
Page 96 Not only can you connect a MIDI keyboard to the UM-1 or other USB MIDI interface using a MIDI cable, you can also connect an optional PC-300, PCR-30, PCR-50, or PCR-80 USB keyboard directly to the PR-80. Connect the PC-300, PCR-30, PCR-50, or PCR-80 with a USB cable to the [USB] connector on the PR-80.
Page 97 Practical Use of the PR-80 In 49-Key MIDI Keyboard mode, the clips are assigned to the white keys of the 49-key keyboard. The 4 x 8 display in the Play mode Palette Area and the Edit mode Palette window changes to 4 x 7, thus showing one octave per row.
Page 98 Range of notes Click “Set from MIDI” to highlight it. Specify the range of notes with the MIDI keyboard connected to the PR-80. Hold down the key for the lowest pitch and press the key for the highest pitch. The specified range is displayed.
Page 99 PR-80 to control another Presenter (such as another PR-80 or the DV-7PR), or when setting the PR-80 as the controlled device, make sure that the “Presenter Control” Device ID set in the MIDI preferences for the controlling device matches the PR-80’s Device ID.
Page 100: Using Other Devices To Control Presenter
Using Other Devices to Control Presenter When controlling the PR-80 from an external device, set the PR-80 to Play mode (p. 34). In Edit mode, only the DV-7DLC transport control, In and Out point settings, and mouse and keyboard functions are enabled.
Page 101 Practical Use of the PR-80 Using the DV-7DLC Like a Deck Controller You can change the control assignments to make the unit function like a video-deck controller in the Play mode. Click [Show Preferences]. A dialog box appears, asking you which preferences panel you want to display.
Page 102 Practical Use of the PR-80 Controlling the Transition Effects and Volume You can transition effects, other effects, the volume level, and other settings in the Play mode. fig.dv7c.play.eps a b c d e h i j k l The factory defaults are the setting values indicated below.
Page 103 Practical Use of the PR-80 Changing the Functions Assigned to Sliders and Button You can use the procedure described below to assign different features to sliders 1 through 4 and buttons 1 through 5 on the DV-7DLC. Click [Show Preferences].
Page 104 Practical Use of the PR-80 Displaying the Color Bar, Switching the Play Mode and Edit Mode, and Turning Off the Power The following operations are common to each of the Presenter's modes. fig.dv7c.play.eps COLOR BAR MODE SHIFT Displaying the Color Bar Go to the lower right, hold down the [SHIFT] button, and press the [COLOR BAR] button.
Page 105: Using The Rs-232C Connector
ASCII Flow Control: XON/XOFF fig.232c.connecter.j.eps Pin number Signal name Pin connections * The PR-80’s connector is male. To connect to a computer, use a female to female cross cable. Cable Connections: fig.232c.cable.eps PR-80 Computer 1 : DCD 1 : DCD...
Page 106: Controlling Other Devices With The Pr-80
Set the PR-80 as the master, and the other Presenter as the slave. Connect the PR-80 and the Presenter functioning as the slave to a UM-1 or other USB MIDI interface, and use a MIDI cable to connect the MIDI OUT of the MIDI interface for the master PR-80 to the MIDI IN of the slave Presenter.
Page 107: Controlling The V-4
IN with a MIDI cable, and connect the PR-80’s OUTPUT connector to [INPUT 4] on the V-4. First turn on the power to the V-4, then turn on the PR-80. Assign Mix01 to the V-4 MEMORY 8 MIX button. When controlling the setup from the PR-80, bring the V-4’s video fader to the Channel A side.
Page 108 Practical Use of the PR-80 Set the MIDI message setting the V-4’s effects with “VFX1 Control” in “V-4 Control” (commands are not received via MIDI when this is set to [OFF]). The effects are controlled with the selected MIDI message.
Page 109 Practical Use of the PR-80 You can assign the V-4's INPUT 1–3 as clips. fig.dditV4.eps...
Page 110: Controlling Ar Series Devices
You can have playback of the AR Series phrases switch by switching clips with the PR-80. Connect a USB MIDI interface to the PR-80, and connect the MIDI interface’s MIDI OUT to the MIDI IN of the AR Series device with a MIDI cable.
Page 111: Making The System Settings
About the Operational Display Refresh Rate You can change the refresh rate for the PR-80’s operational display. If you are using a CRT as your operational display and the refresh rate is higher than 60 Hz, the display can induce a certain amount of noise in the video monitor.
Page 112: Automatically Starting Up Presenter
Select “Turn On/Off using External power-line switch.” Click the [Done] button You can then use the power switch of the device to which the PR-80’s power cord is connected to turn the PR-80’s power on and off. When turning off the power, click the [Power off] button in the screen. Then, once the dialog “It’s now safe to turn off the computer.”...
Page 113: Making The Network Settings
Copying Material to the PR-80 from Networked Computers Cautions to Note When Using the File-sharing Features • Before you turn off the PR-80's power or stop file sharing, quit the connection to the computer. • No password is set for file sharing. This means you must never use the file-sharing feature while connected to the Internet or in other network environments in which someone may gain unauthorized access to your files.
Page 114 [Share Disk] button Connect the PR-80 to the network through the computer. Connect using the host name you set on the PR-80. For more-detailed instructions about making these connections, refer to the documentation for your computer. If you're using Mac OS X, you can use "smb://unit's_host_name/IMPORT/" to access the unit.
Page 115 This is convenient when you're using the Scheduler feature (p. 86). You can have the PR-80's time adjusted automatically at startup or at the time set in the Scheduler. We recommend never connecting the PR-80 directly to the Internet. Make sure you have a separate NTP server ready.
Page 116: Making The Touch Panel Display Settings
Before turning on the power to the PR-80, confirm that the touch panel display is connected, then turn on the display first. After turning on the PR-80, do not touch the touch panel display until an active operational screen appears.
Page 117: Specifications
Specifications Keyboard shortcut keys The shortcut key can be set to the [Ctrl] or [Alt] key at the “Shortcut key” setting of the System Preferences dialog box. (Click the [System Preferences] button of Selector to bring up the System Preferences dialog box. For more information, see page 19.) When using the Play Mode of Presenter Shortcut Function...
Page 118: Midi Implementation (Presenter)
SPECIFICATIONS MIDI implementation (Presenter) ●Control Change Model: PR-80 (Realtime Video Presenter) Date: Nov. 12, 2004 * You can make the settings for a variety of controls at the MIDI Preferences window. Version: 4.0.0 * Assignable functions for Control Change are as follows: •...
Page 119 SPECIFICATIONS ❍Main volume (Controller Number 7) ●Channel After Touch Status Second Third Status Second ❍Balance (Controller Number 8) Status Second Third * You can set various controls at the MIDI preferences window. * For the details of the function that you can set, see the item of the Control Change. ●Pitch Bend Change ❍Panpot (Controller Number 10) Status...
Page 120 Status Second Third identification of the manufacture). The ID number of Roland is 41H. 7EH and 7FH are used as the universal non-realtime message (7EH) and universal realtime message (7FH). ❍Portamento (Controller Number 65) dd,...,ee = Data: 00H - 7FH (0 - 127)
Page 121: Transmitting Data
A0065 - A0096 Palette4/Clip1-4 60H - 63H A0097 - A0100 Palette4/Clip5-32 00H - 1BH A0101 - A0128 A-4 (PR-80) Palette5/Clip1-32 1AH - 3BH A0129 - A0160 Palette6/Clip1-32 3AH - 5BH A0161 - A0192 * When the Presenter control is on, the message is transmitted as follows:...
Page 122 = ID number: Manufacturer number (ID number for the System Exclusive message identifying the manufacturer). Roland's manufacturer ID number is 41H. The ID numbers 7EH and 7FH are used as extensions to the MIDI standard as the universal non-realtime message (7EH) and the universal realtime message (7FH).
Page 123 SPECIFICATIONS 3. Parameter address map 3-1. PR-80 (Model ID = 00H 00H 05H) Start Address Description 00H 00H 00H System Common Preference Area (Reserved Area) 01H 00H 00H Clip Control Preference Area (See 3-1-1) 02H 00H 00H Color Control Preference Area (See 3-1-2)
Page 124 SPECIFICATIONS 3-1-2. Color Control Preference Area Address Parameter Name Sys.Ex.Value Meaning of Value 02H 00H 00H Color Control Rx MIDI Ch. 00H - 10H 1 - 16 Ch., OFF #02H 10H 00H Color Hue Control Assignment 01H-05H, 07H-1FH, 40H-5FH, D0H, E0H, FFH Control Change, Channel Press, Pitch Bend, OFF #02H 10H 02H Color Saturation Control Assignment...
Page 125 Ex. When the unit transmit “BCH”, “0BH” is transmitted for first transmitting, and next, “0CH” is transmitted. The data that is not transmitted 2 byte simultaneously is ignored. * The value “–” is the non-corresponding parameter of the PR-80. When receiving, it is ignored.
Page 126 SPECIFICATIONS 3-2-2. Clip Control Assignment Area Address Parameter Name Sys.Ex.Value Meaning of Value #10H 10H 00H V-LINK Rx Setting (Playback Speed) 01H-05H, 07H-1FH, 40H-5FH, D0H, E0H, FFH Playback Speed : Control Change, Channel Press, Pitch Bend, OFF #10H 10H 02H V-LINK Rx Setting (Dissolve Time) 01H-05H, 07H-1FH, 40H-5FH, D0H, E0H, FFH Transition Time : Control Change, Channel Press, Pitch Bend, OFF...
Page 127 ■Table of the corresponding a decimal number calculation of checksum In the case of the exclusive message of Roland (RQ1, DT1), the message is transmitted with and hexadecimal number checksum after the data to check if the message is received correctly. The checksum value Hexadecimal numbers are described with “H”.
Page 128 SPECIFICATIONS Realtime Video Presenter Date: April 7, 2004 MIDI Implementation Chart Model PR-50 Version : 1.00 Presenter/Clip Control Section Transmitted Recognized Function... Remarks Basic Default ************** Stored after power down Channel Changed 1–16 ************** Default Mode Messages Altered ************** ************** Note ************** 0 –...
Page 129 SPECIFICATIONS Realtime Video Presenter Date: April 7, 2004 MIDI Implementation Chart Model PR-50 Version : 1.00 Presenter/Color Control Section Transmitted Recognized Function... Remarks Basic Default ************** Stored after power down Channel Changed 1–16 ************** Default Mode Messages Altered ************** ************** Note ************** **************...
Page 130 SPECIFICATIONS Realtime Video Presenter Date: April 7, 2004 MIDI Implementation Chart Model PR-50 Version : 1.00 Presenter/System Control Section Transmitted Recognized Function... Remarks Basic Default Stored after power down ************** ************** Channel Changed 1 – 16 Default Mode Messages Altered ************** ************** Note...
Page 131: Rs-232C Command Reference (Presenter)
RS-232C Command Reference (Presenter) For information on using the RS-232C communication settings, refer to "Using the RS- 232C Connector" (p. 105). Command Overview A command consists of an ASCII code sequence containing "stx," to uppercase letters of the alphabet, and a semicolon (";"). The two letters of the alphabet indicate the command type.
Page 132: Commands Sent From An External Device To The Presenter
Commands Sent from an External Device to the Presenter * The commands stx (02H), ACK (06H), and Xon (11H)/Xoff (13H) are control codes. Select video clip stxPA:a,b; • a: Palette Number(0 - 19) • b: Clip Number(0 - 31) This sends the palette number and clip number for the video clip that you want to play back.
Page 133 Transition type stxTR:a; • a: Transition Type • 0: Fade Out (Black) Fade In • 1: Fade Out (White) Fade In • 2: Fade Out (Black) Cut In • 3: Fade Out (White) Cut In • 4: Cross Dissolve When the Presenter receives the command correctly, it returns ACK. Transition time stxTM:a;...
Page 134 Output fade stxOF:a; • a: Fade (-256 - 0 - 256) • 256: White 100% • 0: Normal • -256: Black 100% When the Presenter receives the command correctly, it returns ACK. Hue control stxHU:a; • a: Hue (0 - 360) When the Presenter receives the command correctly, it returns ACK.
Page 135 Active sense request stxAC; You send this when you want to request the Presenter's status. If the Presenter is not performing any action, it returns ACK. If it is playing back a video clip, it returns AC. Acknowledge correct receipt This is sent when a command sent from the Presenter was received correctly.
Page 136: Commands Sent From The Presenter To An External Device
Commands Sent from the Presenter to an External Device * The commands stx (02H), ACK (06H), and Xon (11H)/Xoff (13H) are control codes. Video-clip playback-start information stxPL:a,b; • a: Palette Number(0 - 19) • b: Clip Number(0 - 31) This is information regarding the video clip being played back. It is sent when clip playback starts.
Page 137 XON/XOFF Flow control Xoff...
Page 138: About The Removable Hard Disk
About the Removable Hard Disk You can use the PR-80 with an optional removable hard disk (DV-HD Series) in the hard disk bay. Precautions to Note When Using Disks Please observe the following cautions in regard to handling removable hard disks.
Page 139: Instructions For Installing The Hard Disk
Lock the hard disk. After inserting the hard disk in the PR-80, lock the hard disk so that it doesn't come out. Insert a coin or other thin object in the key slot and turn it clockwise until it makes a click sound; the hard disk is then locked.
Page 140: Index
Index Deleting Material ..............76 Assigning Palette ................ 65 Clip ................98 Project ..............35, 85 File ................59 Schedule .............. 86–87 Automatic Disk Checking ..........42 Disk .................. 30 Disks List ................ 40 Display ................9 Black and White ............. 54 Done ................
Page 141 Index Interlace ................49 Parameter Area .............. 38 Pausing ................48 Play Back ................. 28 Keyboard .............. 9, 22, 42 Keyboard ..............50 Play back scrubs ............70 Play Mode ............28, 34, 38 LAN Connector ............... 9 Playback Speed .............. 36 Language ................
Page 142 Index Automatic Playback ..........77 Video at Facilities ............14 Clip ................70 Video Deck ............... 31, 39 Clip Playback Segment ........... 70 Video Output Monitor ........28, 35, 49 Materials ..............76 V-LINK ............ 16, 32, 34, 37, 62 Network ..............
Page 143: Main Specifications
Main specifications PR-80: Realtime Video Presente 962a * In the interest of product improvement, the specifications and/or appearance of this unit are subject to change without prior notice. Supported TV Systems Control Interfaces NTSC or PAL • PS/2: 6-pin mini DIN type x 2 (for mouse and...
Page 144 Information When you need repair service, call your nearest EDIROL/Roland Service Center or authorized EDIROL/Roland distributor in your country as shown below. DENMARK CZECH REP. CENTRAL/LATIN OCEANIA ASIA Roland Scandinavia A/S K-AUDIO AMERICA Nordhavnsvej 7, Postbox 880, Kardasovska 626. Roland Corporation...

Edirol PR-80 Owner's Manual

Before Using the PR-80

Contents

Before Using the PR-80

Introduction to Use of the PR-80

Practical Use of the PR-80

Specifications

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Edirol PR-80

Summary of Contents for Edirol PR-80

Table of Contents
