Page 1 OWNER’S MANUAL Thank you for purchasing the Photo Presenter P-1. Before using this unit, carefully read the sections entitled: “USING THE UNIT SAFELY” and “IMPORTANT NOTES” (OWNER’S MANUAL p. 2–4). These sections provide important information concerning the proper operation of the unit. Additionally, in order to feel assured that you have gained a good grasp of every feature provided by your new unit, Owner’s manual should be read in its...
Page 2 USING THE UNIT SAFELY symbol alerts the user to important instructions Used for instructions intended to alert or warnings.The specific meaning of the symbol is the user to the risk of death or severe determined by the design contained within the injury should unit...
Page 3 012b 101b • Immediately turn the power off, remove the • The unit and the AC adaptor should be AC adaptor from the outlet, and request located so their location or position does not servicing by your retailer, the nearest Roland interfere with their proper ventilation.
Page 4: Important Notes
IMPORTANT NOTES 291a In addition to the items listed under “USING THE UNIT SAFELY” on page 2-3, please read and observe the following: Power Supply Maintenance 401a • Do not connect this unit to same electrical outlet that • For everyday cleaning wipe the unit with a soft, dry is being used by an electrical appliance that is cloth or one that has been slightly dampened with controlled by an inverter (such as a refrigerator,...
Page 5 About the stand • Do not transport the P-1 by grasping its stand. • Do not apply weight to the P-1 from above when the stand is set up. • Please note that the rubber feet of the stand may...
Page 6 For details on these fonts, contact DigitalDreamDesign http://www.digitaldreamdesign.net mailto:into@digitaldreamdesign.net • The computer graphics used in the demo and contained in the PHOTO/VJMASARU folder of the included CD-ROM are original graphics created for the P-1 by VJ Masaru. TUN Entertainment VJ MASARU http://www.vjmasaru.com...
Page 7: Table Of Contents
Contents IMPORTANT NOTES ..............4 Main features of the P-1 ............11 Main applications..............12 In a concert..........................12 Using the P-1 with the V-1....................13 In a presentation ........................14 When performing live......................15 Panel Descriptions..............16 Top panel ..........................16 Rear panel ..........................
Page 8 Contents Playing background music ........... 36 Selecting background music ....................36 Playing background music..................... 38 Stopping the background music.................... 38 Returning to the beginning of the song................38 Moving the playback location of the background music........... 39 Specifying the playback method of the background music ..........39 Adjusting the pitch of the background music ..............
Page 9 Connections and driver installation..................82 Supported operating systems................... 82 Making connections and installing the driver ............... 82 Connecting your computer to the P-1 and transferring albums, photos, or music ..85 Connect the P-1 to your computer................... 86 Transferring files ........................ 87 Shutting-down the USB connection ................
Page 10 Contents System settings (SYSTEM) ..........101 SYSTEM SETTING ........................ 102 Switching between NTSC and PAL (NTSC/PAL)............102 MIDI Thru on/off (MIDI SOFT THRU)................ 102 Album Auto Save on/off (AUTO ALBUM SAVE) ............. 103 Setting the range of the Tempo Adjustment Knob ............. 103 AUTO SETTING ........................
Page 11: Main Features Of The P-1
You can use Mix or Wipe effects to transition between photos, and superimpose titles on a photo. * You can create titles using the P-1’s Title Maker function (p. 75), or create titles on your computer and load them via USB.
Page 12: Main Applications
Photos of the performers, still images appropriate for the song, or titles you create can be projected on the screen. You can use the touch panel to switch the photos or titles. The P-1 also provides convenient functions for a concert performance, such as playing background music or narrations.
Page 13: Using The P-1 With The V-1
SYMPHONY CONCERT VIDEO INPUT SYMPHONY CONCERT By using the P-1 in conjunction with the V-1 four-channel video mixer, you can superimpose titles on scenes of the performance. • For more about connections with the V-1, refer to p. 91.
Page 14: In A Presentation
You can preview a photo before outputting it for the audience, or freely select a photo from a list of “thumbnails.” • For more about the P-1’s display screen and how to output a photo from the P-1, refer to p. 29.
Page 15: When Performing Live
Photos can be switched in synchronization with a performance on keyboard or V-Drums, in synchronization with MP3/SMF playback on the P-1 itself, or in synchronization with the input from an external audio device. • For more about switching photos in synchronization with MIDI or audio, refer to p. 49.
Page 16: Panel Descriptions
Panel Descriptions Top panel fig.p-front1 Display (touch panel) This displays various information according to the operation you’re performing. This is a touch panel; you can perform operations simply by lightly touching the panel with your finger. A light touch is sufficient when operating the touch panel. Pressing the touch panel forcefully or with a hard object will damage it.
Page 17 Turn this on when you want to output video from the P-1 to your television or other output device. If you don’t want to output video (i.e., if you only want to view a photo on the P-1’s own display), turn this off.
Page 18 Photo Assign button (PHOTO ASSIGN) From the photos saved in the P-1 or on a PC card, use this button to select the photo you want to display on your television or other output device.
Page 19 91 Specify the channel on which MIDI messages are to be transmitted and re- V-LINK ceived, and make settings for using V-LINK to control the P-1 from an ex- p. 94 ternal MIDI device. Make system-related settings, such as those for the NTSC/PAL format se- SYSTEM p.
Page 20: Rear Panel
Audio input jacks (INPUT AUDIO): RCA phono type These are input jacks for analog audio signals. Mic input jack (INPUT MIC): phone type Connect a mic to this jack. LCD contrast adjustment knob (LCD CONTRAST) This knob adjusts the contrast of the P-1’s display screen.
Page 21 (p. 94). USB connector (USB) You can connect your computer here to transfer photos or background music into the P-1 (p. 82). Grounding terminal Depending on the circumstances of a particular setup, you may experience a discomforting sensation, or perceive that the surface feels gritty to the touch when you touch this device, microphones connected to it, or the metal portions of other objects, such as guitars.
Page 22 MEMO...
Page 23: Operation
Operation...
Page 24: An Overview Of The P-1
Let’s start by explaining what these terms mean. fig.o-album1-e Photo Page Page The screen that appears when you power up the P-1 is called a Page. You can assign up to twelve photos (still images) to each page. Photo Photo Photo •...
Page 25: Saving And Loading Albums
Computer If you use a USB cable to connect your computer to the P-1, you’ll be able to save (back up) albums or individual photos or music from internal memory or a PC card to the hard disk of your computer.
Page 26: Connecting Peripheral Equipment
Connecting the P-1 to your television The P-1 does not have a built-in amp or speakers. In order to hear the sound, you must connect the P- 1 to an audio playback system such as monitor speakers, a stereo set, or television. Alternatively, you can listen through headphones.
Page 27 When using speakers (connect to Audio input of speakers) headphones To connect the P-1 to your television, you’ll need audio cables and a video cable. If your television has an S-video jack, we recommend that you use the S-video connector to make connections, since this provides better image quality than the conventional (composite) video jack.
Page 28: Turning The Power On/Off
Turning the power off Turn off the power to your television or other connected equipment. Press the power switch located on the P-1’s rear panel to turn off the power. All buttons and indicators on the top panel will go out.
Page 29: Displaying A Photo On The Television Screen
When you power-on the P-1, an album will be loaded, and after a short time a list of photos will appear in the P-1’s display. This screen is called Photo Play mode. When you select (touch) a photo in Photo Play mode, that photo will appear on the television screen.
Page 30: Selecting A Photo Directly
Viewing the selected photo in the full screen fig.b-p-play When in Photo Play mode (i.e., when the [PHOTO PLAY] button is lit and the P-1’s display shows a list of photos), press the [PHOTO PLAY] button once again. The P-1 switches to a full-screen display.
Page 31: Selecting A Photo Directly From The Full Screen Display
If you touch , an arrow cursor will appear. You can touch and drag the arrow to move it. The arrow will be visible both on the P-1’s display and on the television screen. To un-displaying an arrow cursor, touch once again.
Page 32: Assigning Photos
Assigning photos You can assign up to twelve photos to each of the P-1’s “Pages” (p. 24). This section explains how to assign photos to pages, and how to adjust the location at which the photo is assigned. Selecting a photo fig.b-p-assign...
Page 33 19 / 75 to assign. A red frame appears around the selected photo. displays a preview of the selected photo. Switching between the P-1’s internal memory and a PC card fig.fs-p-assign-p1cf 19 / 75 When you touch , a list of the photos in the P- 1’s internal memory will appear.
Page 34 Checking that the selected photo is correctly assigned fig.b-p-play Press the [PHOTO PLAY] button. fig.fs-p-play-8 The Photo Play mode screen appears in the P-1’s display. Verify that the selected photo appears in the specified page and photo number. If you want your photo assignment settings to be saved automatically when you leave Photo...
Page 35: Cutting A Frame
Assigning photos Cutting a frame fig.fs-p-assign-cut Touch the number of the photo you want to remove 19 / 75 from the page. As an example here, try pressing [2]. fig.fs-p-assign-cut1 Touch 19 / 75 The photo assignments following the frame you cut are moved toward the left by one frame.
Page 36: Playing Background Music
Playing background music The P-1 lets you assign background music to each album (p. 24). This section explains how to assign background music, how to play/stop/rewind it, how to set various options for playback, and how to adjust the pitch/volume/tempo.
Page 37 Playing background music fig.fs-smf-f From the list, select (touch) the background music you want to use. The selected music is enclosed by a red frame. You can use only one song for background music. If you want to use a different song, simply change your selection.
Page 38: Playing Background Music
MIDI OUT (p. 21). The P-1 does not contain a MIDI sound generator. In order to play back SMF data (*.mid file), you must use a MIDI cable to connect the P-1’s MIDI OUT to the MIDI IN of your MIDI sound module.
Page 39: Moving The Playback Location Of The Background Music
Playing background music Moving the playback location of the background music fig.b-tri While playback is stopped (i.e., while the [PLAY] is dark), touch and drag it to left or right. Dragging toward the left moves the playback location toward the beginning of the song (“rewind”). Dragging toward the right moves the playback location toward the end of the song (“fast-forward”).
Page 40: Adjusting The Pitch Of The Background Music
Playing background music Adjusting the pitch of the background music You can adjust the playback pitch of the background music over a range of three semitones upward or downward. Raising the pitch fig.fs-smf-pitchup Touch once. indication changes to +1, and the pitch is raised by a semitone.
Page 41: Adjusting The Volume Of The Background Music
Playing background music Adjusting the volume of the background music You can adjust the volume of the background music. This lets you adjust the volume balance between the narration and the music. Raising the volume fig.fs-smf-volup Touch indication changes to +1, and the volume of the background music increases.
Page 42: Adjusting The Tempo Of The Background Music
Playing background music Adjusting the tempo of the background music The tempo at which the background music plays can be adjusted over a range of +/-20% relative to the original tempo. Raising the tempo fig.k-tempo-r Turn the tempo adjustment knob (p. 19) toward the right. The playback tempo speeds up.
Page 43: Applying Effects To The Image (Transition)
Applying effects to the image (TRANSITION) When displaying photos (still images) from the P-1 on a television screen, you can specify the time over which the photo is to appear. You can also apply visual effects such as Mix or Wipe, or superimpose a Title.
Page 44: Specifying The Time For The Mix Effect
(lit), and you’re returned to the Photo Play mode screen. In the Photo Play mode screen, select (touch) a photo. The photo appears on the P-1 and on the connected television. Then select (touch) a different photo. The mix effect you selected is used to transition from the first photo to the second.
Page 45: Wipe
Applying effects to the image (TRANSITION) Wipe Wipe This effect is named after its similarity to the windshield wipers of a car. It transitions to the next image by “wiping away” the current image. Selecting the Wipe type fig.b-wipe Press the [WIPE] button. Six different Wipe types appear.
Page 46: Specifying The Time For The Wipe Effect
In the Photo Play mode screen, select (touch) a photo. The photo appears on the P-1 and on the connected television. Then select (touch) a different photo. The wipe effect you selected is used to transition from the first photo to the second.
Page 47: Title
Applying effects to the image (TRANSITION) Title The P-1 lets you assign up to four titles to each page of an album (Assigning a title to an album page (TITLE ASSIGN) (p. 80)).When you press the [TITLE] button, a screen in which you can choose one of these four titles to be displayed will appear.
Page 48: Specifying The Time For The Title Display
Turn the photo transition time knob (p. 17) to specify the length of time over which the title is to appear in (or disappear from) the P-1’s display. Turning the knob toward the right lengthens the time over which the title appears (disappears) (i.e., it will appear or disappear more slowly).
Page 49: Playing Photos Automatically (Auto)
Playing photos automatically (AUTO) You can switch photos either by touching a photo in the P-1’s display, or by using time or audio/ MIDI signals to switch photos automatically. When you press the [AUTO] button (so it is lighted), a screen will appear in which you can make settings for switching photos automatically.
Page 50: Switching Photos At A Specified Interval (Auto Timer)
Playing photos automatically (AUTO) Switching photos at a specified interval (AUTO TIMER) Here’s how you can consecutively switch photos in numerical order at a fixed interval of time. Using AUTO TIMER fig.fs-auto-timer Touch turns blue, and the “PUSH PLAY BUTTON” prompt appears.
Page 51: Switching Photos According To Playback Volume Or Midi Messages (Mp3/Smf Sync)
Playing photos automatically (AUTO) Switching photos according to playback volume or MIDI messages (MP3/SMF SYNC) Here’s how you can consecutively switch photos in synchronization with background music. If you’ve selected an MP3 file as the background music, the photos will switch in synchronization with the volume.
Page 52: Switching Photos According To External Audio Volume (Input Sync)
Playing photos automatically (AUTO) Switching photos according to external audio volume (INPUT SYNC) Here’s how you can switch photos in synchronization with the volume of an external audio device connected to the audio input jacks (p. 20). Using INPUT SYNC fig.fs-auto-input Touch turns blue, and the “PUSH PLAY BUTTON”...
Page 53: Using The Demo Play Function
Playing photos automatically (AUTO) Using the Demo Play function Let’s use the Demo Play function to hear how AUTO mode works. fig.fs-auto-demo1 Touch DEMO PLAY 1/2/3. fig.b-play Press the [PLAY] button. A demonstration album is loaded automatically, and demo play will begin. It may take a short time for the album to load.
Page 54: Turning Automatic Playback On/Off
Playing photos automatically (AUTO) Turning automatic playback on/off Turning on automatic playback In the Auto Mode Select screen, select (touch) either AUTO TIMER, MP3/SMF SYNC, or INPUT SYNC. Press the [PLAY] button to begin automatic playback. If the [AUTO] button is not lit, automatic playback is off. Photos will not switch automatically even if you press the [PLAY] button.
Page 55: Assigning Narrations To Photos (Narration)
A narration is sound that is automatically played when you display a photo. A narration can be an explanation of the photo, or it might be music or sound that goes with the photo. On the P-1, you can assign each photo its own narration.
Page 56 The Narration screen shows information about the currently selected narration, and a list of the narrations (WAV files) stored in the P-1’s internal memory (or on a PC card)..Preview of the photo selected as the narration ..Assign the narration to the photo assignment destination ....Cancel the assignment...
Page 57 From the list, select (touch) the narration you want to assign. The selected narration is enclosed by a red frame. Switching between the P-1’s internal memory and the PC card fig.fs-n-p1cf Touch to view the list of narrations (WAV files) in the P-1’s internal memory.
Page 58 Assigning narrations to photos (NARRATION) Verifying that the selected narration was assigned correctly fig.b-p-play Press the [PHOTO PLAY] button. The Photo Play mode screen appears. fig.o-n-mark If a narration is assigned to a photo, a small symbol is displayed on the photo. fig.o-n-mark1 Touch a photo to which a narration is assigned.
Page 59: Recording A Narration
Here’s how to record a narration using your own voice. Connect a microphone to the mic input jack (p. 20). fig.c-mic-jack P-1 Rear Panel Howling could be produced depending on the location of microphones relative to speakers. This can be remedied by: 1.
Page 60 Assigning narrations to photos (NARRATION) fig.t-n-r ..Preview of the photo selected as the ....Audition the narration assignment destination ..Assign the narration to the photo ..Information about the narration assigned to the photo ....Cancel the assignment ..Volume adjustment ....Stop ..
Page 61: Saving A Recorded Narration
Assigning narrations to photos (NARRATION) Saving a recorded narration fig.fs-n-r-assign When you’ve finished recording, touch Your recorded voice will be saved as a narration, and assigned to the selected photo. The narration is saved using a name that consists of “the name of the selected photo” followed by a filename extension of “.wav.”...
Page 62: Menu Mode
Control a V-1 (if connected; sold separately) from the P-1. p. 91 Specify the channel on which MIDI messages are to be transmitted and re- ceived, and make settings for using V-LINK to control the P-1 from an ex- p. 94 V-LINK ternal MIDI device.
Page 63: Creating A New Album (New Album)
Menu mode Creating a new album (NEW ALBUM) Here’s how to create a new album in the P-1’s internal memory or on a PC card. Creating an album fig.b-menu Press the [MENU] button. The Menu screen appears in the P-1’s display.
Page 64: Loading An Album (Album Load)
Menu mode Loading an album (ALBUM LOAD) Here’s how to load an album from the P-1’s internal memory or on a PC card. Loading an existing album fig.b-menu Press the [MENU] button. The Menu screen appears in the P-1’s display.
Page 65 The selected album will be loaded, and the Photo Play mode (p. 29) screen will appear. You can’t load an album directly from your computer. You must first save the album in the P-1’s internal memory, and then load it.
Page 66: Saving An Album (Album Save)
Press the [MENU] button. The menu screen appears in the P-1’s display. fig.m-a-save Touch ALBUM SAVE. The contents of the P-1’s internal memory or the PC card is displayed. fig.t-a-save Album saving destination ..Name of the album to save ....When you select an album in...
Page 67 PC card. fig.fs-a-save-album Touch The album will be saved in the P-1’s internal memory or on the PC card, and the Photo Play mode (p. 29) screen will appear. You can’t load an album directly from your computer.
Page 68: Editing The Name Of An Album (Album Name)
Press the [MENU] button. The Menu screen appears in the P-1’s display. fig.m-a-name Touch ALBUM NAME. The P-1’s display will show a screen where you can input the album name. fig.t-a-name ..Input the album name ..Save the album name Arrow key (left) Moves the cursor left.
Page 69: Saving The Album Name
Menu mode fig.fs-a-name-key Touch the on-screen keyboard in the P-1’s display to input characters. Saving the album name Touch The text you input will be saved as the name of the album, and the Photo Play mode (p. 29) screen will...
Page 70: Viewing Information On Photos, Music, And Narrations, And Deleting Them (File Utility)
The FILE UTILITY screen lets you view information (size, modification date, etc.) on photos, music, and narrations in the P-1’s internal memory or on an inserted PC card. Here you can also select and delete photos, music, or narrations you no longer need.
Page 71 Menu mode The contents of the P-1’s internal memory or PC card will appear. fig.t-utility ..Preview of the photo (if you selected a photo) ..Copy ..Information about the selected photo, music, ..Paste or narration File Size: Size of the selected file ....Delete...
Page 72 The P-1 does not contain a built-in MIDI sound generator. In order to play SMF datas (*.mid), you’ll need to use a MIDI cable to connect the P-1’s MIDI OUT to the MIDI IN of your MIDI sound module. If you choose narrations (WAV files) fig.fs-utility-narration...
Page 73: Deleting Photos, Music, Or Narrations
The menu screen appears on the P-1’s display. fig.m-utility Touch FILE UTILITY. fig.fs-utility-file In the list in the P-1’s display, select (touch) the photo, music, or narration that you want to delete. fig.fs-utility-trash Touch A message will ask “ARE YOU SURE?”...
Page 74: Copying Photos, Music, Or Narrations
Press the [MENU] button. The menu screen appears on the P-1’s display. fig.m-utility Touch FILE UTILITY. fig.fs-utility-file In the list in the P-1’s display, select (touch) the photo, music, or narration that you want to copy. fig.fs-utility-copy Touch Select (touch) the copy-destination folder.
Page 75: Using The Keyboard To Input A Title (Title Maker)
Press the [MENU] button. The menu screen appears in the P-1’s display. fig.m-t-maker Touch TITLE MAKER. A keyboard appears in the P-1’s display, allowing you to input characters. fig.t-t-maker ... Input a name for your title ... Input alphabetic characters with accent symbols ...
Page 76 Menu mode fig.fs-t-maker-key Touch the on-screen keyboard in the P-1’s display to input characters. These boxes correspond to the position in the P-1's display, divided vertically into nine parts.
Page 77: Saving Your Title
Menu mode Saving your title fig.fs-t-maker-save Touch The text you input will be saved in the Title folder (p. 90) under the name Title_***.jpg (*** will be a number). To assign a saved title to an album page, use TITLE ASSIGN (p.
Page 78: Creating A Title By Freehand Drawing (Free Canvas)
Here’s how you can use freehand drawing to create pictures or text you can superimpose on a photo. Drawing the picture or text for the title fig.b-menu Press the [MENU] button. The menu screen appears in the P-1’s display. fig.m-free Touch FREE CANVAS. The drawing area appears in the P-1’s display. fig.t-free ...
Page 79: Saving Your Title
Menu mode Saving your title fig.fs-free-save Touch The freehand drawing or text you created will be saved in the Title folder (p. 90) under the name Canvas_***.jpg (*** will be a number). To assign a saved title to an album page, use TITLE ASSIGN (p.
Page 80: Assigning A Title To An Album Page (Title Assign)
Selecting a title fig.b-menu Press the [MENU] button. The menu screen appears on the P-1’s display. fig.m-t-assign Touch TITLE ASSIGN. A screen where you can select titles appears in the P-1’s display. fig.t-t-assign 24 / 75 Title assignment destination Title...
Page 81 Touch to select the page to which you want to assign a title. 23 / 75 fig.fs-t-assign-f From the list shown in the P-1’s display, select (touch) the title you want to use. 23 / 70 19 / 75 fig.fs-t-assign-assign...
Page 82: Connecting Your Computer Via Usb (Usb Mode)
A “driver” is software that allows the P-1 and your computer to communicate when connected via a USB cable. The driver passes data between the P-1 and your computer. If the driver is installed, you will be able to send files from the P-1’s internal memory to your computer, or from your computer to the P-1.
Page 83 USB cable P-1 Rear Panel Turn on the power of the P-1. After a short time the Photo Play mode screen appears in the P-1’s display. fig.b-menu Touch the [MENU] button to access the menu screen. fig.m-usb Touch USB.
Page 84 USB cable P-1 Rear Panel Turn on the power of the P-1. After a short time the Photo Assign mode screen appears in the P-1’s display. fig.b-menu Touch the [MENU] button to access the menu screen. fig.m-usb Touch USB.
Page 85: Connecting Your Computer To The P-1 And Transferring Albums, Photos, Or Music
Connecting your computer to the P-1 and transferring albums, photos, or music You can use a USB cable to connect the P-1 to your computer, and transfer files from the P-1’s internal memory or PC card to your computer. You can also transfer files from your computer to the P-1.
Page 86: Connect The P-1 To Your Computer
Connect the P-1 to your computer Turn on your computer and start up Windows. With the P-1 turned off, use a USB cable to connect the P-1 to your computer. Turn on the power of the P-1. If you want to use a PC card, insert it into the PC CARD slot.
Page 87: Transferring Files
P-1, the volume label will be “PC CARD.” Double-click the “EDIROL” icon in the drive icon. The folders and photos, music, narrations, and albums in the P-1’s internal memory or PC card will be displayed.
Page 88: Shutting-Down The Usb Connection
Connecting your computer via USB (USB mode) Shutting-down the USB connection If you’ve connected the P-1 to your computer via a USB cable, you must shut down the USB connection before you perform the following actions. Avoid doing any of the following if you have not yet shut down the USB connection.
Page 89 The USB connection has been shut down. Macintosh users On your computer desktop, drag the P-1 drive icon into the trash. Alternatively, if you’re on Mac OS 9 you can choose the Special menu command Remove, or if you’re on Mac OS X you can choose the File menu command Remove.
Page 90: How The P-1'S Internal Memory Is Organized
Connecting your computer via USB (USB mode) How the P-1’s internal memory is organized fig.o-usb-directry-e The files and folders you create in the P-1's internal memory or in a PC card are organized as follows. EDIROL Album Albums are stored in this folder...
Page 91: V-1 Control
Using the P-1 to control a V-1 (V-1 CONTROL) Here’s how to connect a V-1 (sold separately) and control it from the P-1. This setup makes it easy to combine photos or text from the P-1 with video from the V-1.
Page 92: Using A P-1 Photo With The V-1'S Superimpose Function
V-1 CONTROL Using a P-1 photo with the V-1’s Superimpose function Here’s how a photo or other still image (e.g., containing text) created on the P-1 or on your computer can be assigned the Superimpose attribute on the P-1. fig.fs-v1 Select (touch) the photo (or other image) that you want to use as a title.
Page 93: Switching V-1 Input Channels From The P-1
V-1 CONTROL Switching V-1 input channels from the P-1 You can assign P-1 photos (numbers) so that they will switch V-1 input channels (CH1–CH4). fig.fs-v1-3 Select (touch) a photo that you want to use to switch input channels. fig.fs-v1-4 Touch a channel number. As an example here, let’s select The indication “CH1”...
Page 94: V-Link
MIDI messages are not received except PHOTO PLAY mode. Using a MIDI device to switch photos on the P-1 Use a MIDI cable to connect the MIDI OUT connector of your MIDI device to the P-1’s MIDI IN connector. fig.c-v-link-e...
Page 95: Using Note Messages To Switch Photos
Photos located in the shaded areas of the table cannot be selected via note messages from a MIDI device. In order to control the P-1 from a MIDI device, the P-1’s MIDI receive channel must match the MIDI device’s MIDI transmit channel (p. 99).
Page 96 You can limit to only forward the page, not backword. (➔DETAILS (p. 103) In order to control the P-1 from a MIDI device, the P-1’s MIDI receive channel must match the MIDI device’s MIDI transmit channel (p. 99).
Page 97: Using Program Change Messages To Switch Photos
MSB 19 MSB 19 MSB 19 MSB 19 MSB 19 MSB 19 MSB 19 MSB 19 In order to control the P-1 from a MIDI device, the P-1’s MIDI receive channel must match the MIDI device’s MIDI transmit channel (p. 99).
Page 98: Using Control Change Messages To Switch Photos
1 message with a value of 13, it will display the first photo on page “B.” In order to control the P-1 from a MIDI device, the P-1’s MIDI receive channel must match the MIDI device’s MIDI transmit channel...
Page 99: Setting The Midi Receive Channel
V-LINK Setting the MIDI Receive Channel In order to control the P-1 from a MIDI device, the P-1’s MIDI receive channel must match the MIDI device’s MIDI transmit channel. For details on how to set the transmit channel of your MIDI device, refer to its owner’s manual.
Page 100: Setting The Midi Device Id
V-LINK Setting the MIDI Device ID If you’re using two or more P-1 units connected together, you’ll need to specify a different MIDI Device ID for each unit. fig.fs-vlinkdvid Touch to select the MIDI Device ID. With the factory settings this is set to 17.
Page 101: System Settings (System)
Press the [MENU] button. The menu screen appears in the P-1’s display. fig.m-system Touch SYSTEM. The system setting screen appears in the P-1’s display. fig.t-system ..Switch between NTSC and PAL ..Specify the order in which photos will be switched when synchronized to background ..
Page 102: System Setting
This is a function by which MIDI messages received at MIDI IN are re-transmitted from MIDI OUT. If MIDI Thru is on, MIDI messages received at the P-1’s MIDI IN will be re-transmitted from the P- 1’s MIDI OUT to a connected MIDI sound module or other device.
Page 103: Album Auto Save On/Off (Auto Album Save)
The playback may be interrupted if you play back an MP3 at a high speed. DETAILS When you touch in the SYSTEM screen, the DETAILS screen will appear in the P-1’s display.In the DETAILS screen, you can make settings for the NOTE RND of V-LINK(p. 96). fig.fs-details ..
Page 104: Auto Setting
System settings (SYSTEM) AUTO SETTING Specifying the interval at which Auto Timer will switch photos fig.fs-sphoto The PHOTO CHANGE TIME setting specifies this interval. With the factory settings this is set to 2.0 (two seconds). You can touch to select the switching interval in a range of 0.5–4.0 seconds.
Page 105: Appendices
Appendices...
Page 106: Troubleshooting
The P-1 does not contain a built-in MIDI sound generator. In order to play back SMF (*.mid file) data, you must use a MIDI cable to connect the P-1’s MIDI OUT to the MIDI IN of your MIDI sound module.
Page 107 Troubleshooting Photos do not switch even though the AUTO button is on If MP3/SMF SYNC is selected • Have you specified background music? If you’ve selected MP3/SMF SYNC, the photos will switch in synchronization with the playback of the background music. This means that if you haven’t specified any background music, the photos will not switch.
Page 108: Message List
Error Where the error Message Response Page message appears NARRATION PHOTO ASSIGN The P-1 internal memory is full. Delete unneeded files from the P-1 Internal Full! p. 73 P-1 internal memory. MP3/SMF ASSIGN NEW ALBUM ALBUM SAVE FILE UTILITY PC Card Full! The PC card is full.
Page 109 FILE UTILITY p. 73 All Data On The P-1 Internal All files in the P-1’s internal memory will be deleted; are you Will Be Lost. Are You Sure? sure you want to do this? All Data On The PC Card All files in the PC card will be deleted;...
Page 110 USB is being connected. Disconnecting... USB is being disconnected. p. 85 USB Offline! USB has been disconnected. Please Reboot P-1 To Effect In order for the NTSC/PAL selection to take effect, turn the SYSTEM p. 102 NTSC/PAL Setting. power off, then on again.
Page 111: Midi Implementation
* Received if PHOTO CHANGE TRIGGER is set to PC. The model ID of the exclusive messages used by this instrument is 00H 7BH (P-1) and 00H51H (V-LINK). ❍Control Change (Controller number 1 - 31, 33 - 95)
Page 112 ❍Bank Select (Controller number 0, 32) ID number (Roland) Status 2nd byte 3rd byte Device ID (dev: 00H - 1FH, 7FH) Model ID #1 (P-1) Model ID #2 (P-1) Command ID (DT1) n = MIDI channel number: 0H - FH (ch.1 - 16) Address MSB...
Page 113 MIDI Implementation ■System Exclusive Messages 3-1-1. System P-1 Control Data Set 1 (DT1) is the only System Exclusive messages transmitted by the P-1. Address Parameter Name Value Meaning of Value ●Data Transmission 01 00 00 Video Out CC Assign 00H - 5FH...
Page 114 Superimpose(*1) #10 20 08 VFX2 Ctrl Assign * If the value is shown as..., this is a parameter not supported by the P-1. It will be #10 20 0A VFX3 Ctrl Assign ignored if received. #10 20 0C VFX4 Ctrl Assign...
Page 115 4-4 Controlling the P-1 via V-LINK 4-1-4. Switching photos on the P-1 If you want to control the P-1 via V-LINK, you must transmit system (PHOTO CHANGE TRIGGER; CC) exclusive messages to the P-1 as shown in the example that follows.
Page 116 MIDI Implementation ■Calculating a Checksum ❍Keyboard Range Lower F0 41 10 00 51 12 10 30 02 00 3E F7 Roland Exclusive messages (RQ1, DT1) are transmitted with a checksum at the end F0 41 10 00 51 12 10 30 02 05 39 F7 (before F7) to make sure that the message was correctly received.
Page 117 MIDI Implementation Date : Jan. 28, 2004 PHOTO PRESENTER MIDI Implementation Chart Version : 1.00 Model P-1 Transmitted Recognized Function... Remarks Basic Default 1–16 1–16 Channel Changed 1–16 1–16 Default Mode 3 Mode 3 Mode Messages Altered ************** ************** Note...
Page 118: Specifications
Specifications ●Audio signal processing PHOTO PRESENTER Audio A/D, D/A Conversion:44 kHz / 16 bits ●Audio Input Impedance ●Video Format LINE20 k ohms NTSC or PAL MIC2 k ohms ●Display ●Audio Nominal Input Level 320 x 240 dots, 5.7-inch Color Graphic LCD with LINE -16–...
Page 119: Index
Specifying the playback method of the background ..............39 music ......38 Grounding terminal ..........21 Stopping the background music ......85 Transferring background music .. 70 Viewing information on the background music Headphone jack ............. 20 How the P-1’s internal memory is organized ..90...
Page 120 Index INPUT AUDIO ............20 NARRATION ..........17, 55, 59 ........57 Auditioning the narration INPUT MIC ............20 ..........74 Copying narrations Input symbols ..........68, 75 ........73 Deleting the narrations INPUT SYNC ............52 .......... 59 Recording a narration Input uppercase characters ......
Page 121 Index Page ................. 24 Sample ..............25 PAL ............. 24, 33, 81 SAVE ..............61, 66 PC CARD ............... 19 SD ................25 PC card ............. 25, 86 Security Slot ............21 PC card adaptors ........... 25 SEQULOTY LOCK ..........21 PC card slot ............
Page 122 Index Video (composite) output jack ......20 Video cable ............. 27 VIDEO OUT ............17 Video output button ..........17 V-LINK ............. 21, 51 VOLUME ............... 17 WIPE ..............17, 45 Wipe button ............. 17, 45...
