Klipsch T5 II TRUE WIRELESS ANC - Earbuds Manual

FEATURES

LEGENDARY SOUND + GREAT FIT
After 60+ years of making legendary loudspeakers, we built upon our bold audio heritage to revolutionize the headphone industry. Since 2007 we have been creating the most innovative headphones on the market. We are the performance and comfort winners. Period.

The same advanced acoustic engineering and industrial design from our legendary home theater speakers provide the performance, voice and design for the T5 II Series earphones. They are engineered for pure performance and designed to be the best sounding most comfortable earphones on Earth and the embodiment of legendary Klipsch sound.

PATENTED OVAL EAR TIPS
Klipsch T5 II earphones include 6 pairs of patented contour ear tips that are designed to accurately sit inside the ear canal. These soft oval silicon tips reduce ear fatigue, provide the ultimate comfort and an excellent seal for noise isolation and superior bass. They fit better, they feel better, and only Klipsch has them.

HIGH CLARITY 5.8MM DYNAMIC DRIVER
Engineered from the ground up to deliver powerful performances from the smallest package, the T5 II True Wireless ANC dynamic driver combines high output, neutral sound and deep bass extension. The second generation T5 driver utilizes an all-new diaphragm with minimal thickness to enhance clarity and improve audio quality across the entire frequency spectrum.

DIRAC HD SOUND
T5 II True Wireless ANC is the world's first True Wireless headphone integrated with Dirac® HD Sound, a state-of-the-art digital audio performance enhancement technology that optimizes the T5's sound signature by correcting impulse and magnitude frequency response. This technology drastically improves music staging, clarity, voice intelligibility, and bass fidelity while still allowing for custom sound equalizers to personalize your earphones.

DUAL MICROPHONE ACTIVE NOISE CANCELLATION
Two-mic hybrid, feedforward and feedback ANC for maximum noise cancellation.

BATTERY LIFE + WIRELESS CHARGING CASE
T5 II True Wireless ANC provides 7 hours of battery life on a single charge (5 hours w/ ANC) and up to 21 additional hours with the charging case (15 hours w/ ANC), giving you the freedom to take calls and listen all day long. The high-polish chrome battery case not only charges your earphones but protects them when not in use. Charge wirelessly using any Qi-compatible charging pad or use the included USB-C cable.

DIGITAL ASSISTANT READY
Instantly trigger your voice assistant with one press.

BRAGI MOVES
A built-in Bragi operating system with embedded AI allows for Bragi Moves hands-free, advanced gesture-controlled experiences. This innovative operating system will enable new functionality over the life of the product.

TRANSPARENCY MODE
This mode is designed to allow sound from the outside world into your ears, so you know what's going on around you.

CLEAR VOICE WITH BEAMFORMING MICROPHONES
Six beamforming microphones integrated with noise suppression automatically enhance voice clarity and actively reduces environmental noise to ensure your calls are loud and clear.

SIGNAL-BOOST EXTERNAL ANTENNA
Delivers a high-quality, seamless connection between earphones and your device while minimizing the footprint in your ear.

BLUETOOTH 5
Easily pair to your device for a quick, wireless connection.

SWEAT RESISTANT
IPX4 rated means these earphones will withstand the elements.

SPECIFICATIONS

Bluetooth 5.0
A2DP Codecs: SBC, AAC
Range: up to 10m (33 ft.)
Charging Case Input Rating: 5V DC, 0.5A

All specifications are subject to change without notice.

INSIDE

POWER

PAIRING

SETUP

Download the Klipsch Connect app and follow the instructions

CHARGING

STATUS INDICATORS

Solid Red → Charging
Slow Blink Blue → Ready to Pair
Fast Blink Blue → Connected

LED 1 → Charging 0-33%
LED 2 → Charging 33-66%
LED 3 → Charging 66-100%

Solid Red - Slow Blink Blue - Fast Blink Blue

LED - Charging - Ready to Pair - Connected

CONTROLS

*Note: Hot button can be configured in the Klipsch Connect App
** Active Noise Cancellation

DURING PLAYBACK

CALL HANDLING

*During Call

Short Press

Double Press

Triple Press

Short Hold

Active Noise Cancelling - Transparency - During Playback

Voice Assistant - Call Handling - During Call

PLACEMENT

FACTORY RESET

LEDs on both Left and Right will alternate RED/BLUE

TRUE WIRELESS RESET

1.

2. LED will alternate RED/BLUE

3. LED will alternate RED/BLUE

4. Glow solid purple


TROUBLESHOOTING

There is sound coming from one side only.

SOLUTION: Insert both earphones into the case and remove them again.

How do I get the best Bluetooth connection?

SOLUTION: Ensure your device isn't being blocked by your body or any objects (move it from your pocket). Next, place the earphones back in the case and take out the earphone that corresponds with the side your device is on first (Right earphone if right pocket, left earphone if left pocket). Try to reduce the distance between your earbuds and your audio device to further improve performance.

What if I have poor wireless connectivity?

SOLUTION: If possible, move away from cell phone towers, dense WiFi networks, other Bluetooth devices and household appliances like microwave ovens.

I want more bass

SOLUTION: Try a larger ear tip, further boost bass using the Klipsch Connect App.

I can't connect to my phone

SOLUTION: Press and hold the right earphone button for three (3) seconds to engage pairing mode.

My audio and video won't sync up

SOLUTION: Some apps do not always use the correct audio codec for lowest latency. If the audio is delayed in an App, try streaming the same video using your device's web browser.

Are my earphones water and dust resistant?

SOLUTION: Your earphones are IPX4 sweat resistant which means they can handle humid environments and sweat but CANNOT be submerged in water. Please note the charging case is not water or dust proof and should be kept away from the elements.

One earphone is unresponsive or stuck

SOLUTION: Hold the power button on that earphone for 20 seconds, place it back into the charging case, then remove it.

ADDITIONAL SUPPORT

Be sure to check klipsch.com/support and download Klipsch Connect to install the latest firmware available.

IMPORTANT SAFETY INFORMATION

1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all these instructions.
5. DO NOT use this apparatus near water or moisture.
6. If you hear ringing or experience pain or discomfort in your ears during or after using any in-ear audio product, that is a sign you are listening too loud. When your ears are exposed to high volumes (In excess of 85dB) for over an hour, you may be permanently damaging your hearing.
7. TURN DOWN your listening device's volume to zero before you insert the Klipsch headphones and turn on the device. Once you have the headphones on, gradually increase the volume to a comfortable, moderate volume.
8. DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. ONLY USE attachments/accessories specified by the manufacturer.
10. REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged In any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally or has been dropped.
11. NEVER operate a motor vehicle while listening to or wearing your headphones.
    Not only dangerous. It is illegal in many places.
12. NEVER operate heavy machinery while listening to or wearing your headphones.
13. We don't recommend you use the headphones while riding a bicycle, running, or walking In heavy traffic areas.

Except in case of emergency, Kllpsch recommends you do not use these headphones or headsets (headphones plus microphone) as aviation communication equipment as they are not engineered tor many environmental conditions common in commercial or noncommercial aircraft (including, but not limited to: altitude, temperature, noise conditions. unpressurized aircraft. etc.) resulting in possible interference lo critical communications. The Occupational Safety Health Administration (OSHA) has issued headphone usage recommendations for maximum dally exposure and sound pressure levels (measured In decibels (dB)). A decibel is a unit of measure of sound, and decibels increase exponentially as sound gets louder. For example, conversational speech is typically around 60dB, and a rock concert in a stadium is often about 110d8.

PRODUCT REGISTRATION

• Register your product on line at www.klipsch.com/register
• Klipsch will keep you up-to-date on new products and promotions.
• Your personal information will never be resold.
• This registration information is not used for warranty purposes.
  Please retain your receipt for warranty claims.

KLIPSCH.COM
