Instruction

Put in Mobile Phone or Tablet
Tighten the Knob
Long Press for 3 Seconds (Power on/off)
Gesture Control

Show gestures to the Al vision sensor from 0.5ne1.5m(1.64ft-4.92ft) away to enable Al tracking.

Al Tracking

The most effective distance for A1tracking is 0.5m-3m (1.64ft-9.84ft)

Smart Tracking Works without Bluetooth and App.
Remote Control (*available for purchase separately): To take photo and record video remotely.
Pano Mode: Press the power button twice and the tracking holder will rotate 3600. Infinite Spinning Mode: Pressthe power button three times and the tracking holder will enter into this mode while rotating 3600infinitely. (Pressthe power button once to exit.)

* Fully Charged in 2 Hours
Low Battery Caution (<10%): Red Light Flashes Continuously

Charging: The Indicator Slow Flashes Continuously
Fully Charged: The Indicator Light Stays On The Status Indicator Light

Blue	Standby (Tracking Not Started)
Green	Start Tracking
Yellow	Flash, Auto Rotate
Red	Light On; Fully Charged Flash Continuously; Low Battery Caution (<10%)
Slow Flash Continuously (Any color):	Charging

Model	GO
Product Name	2-Axis Al Auto-tracking Holder
Material	PC+ABS
Weight	300 g
Max. Payload	480 g/ 1.06 lbs (Approx. weight of 11 inches tablet)
Size	90 mm*93 mm
Compatible Phones	Phone Thickness: ≤ 13 mm Tablet Size <11 inch (Without case)
Battery	3.7 v / 2000 mAh
Operating Time	10 hours 7 hours (Tracking)
Controllable Range	Pan: 3600 Tilt: -150+150
