MAJORITY DVD120 - DVD Player Manual

Table of Contents

Contents

1 BOX CONTENTS
2 USEFUL TIPS
3 CONTROL BUTTONS
4 REMOTE CONTROL
5 RANGE OF USE
6 SPECIFICATIONS
7 TROUBLESHOOTING
8 SUPPORT
9 WARRANTY
10 Documents / Resources
- 10.1 References
- 10.2 Download manual

BOX CONTENTS

Portable Video Player
Remote Controller
AC Adapter
Car Charger
3-in-1 AV Cable

USEFUL TIPS

Battery: DVD120 has a high-capacity built-in lithium rechargeable battery of 2500mAH which will last for 5 hours when the Battery is fully charged.
Please note: Battery should be fully charged for at least 6 hours before first time use on battery.
Before charging make sure DVD120 is switched off. The charging indicator LED will change from RED to OFF indicating that the battery has been fully charged. When the unit is ON, the LED turns GREEN.
DVD120 can also be powered with its Car Charger or AC Power adapter. If you choose to use DVD120 plugged on, you can simply plug and play with either of these 2 power cables included in the box.
Screen Protector: Device is supplied with a screen protector, which can be removed from screen for clearer picture
Laser Protection: There is a yellow card inside the player. Before you insert a disc, please remove the card. Please DO NOT touch the laser pick up or other parts with your hand.

Disc Format

Disc Format Supported	CD, DVD, DVD + R/-R, DVD + RW/-RW, VCD, SVCD, CD-R/RW
Disc Format NOT Supported	Blu-ray, HD DVD, Discs recorded in the AVCHD format, DVD-Audio, Version 1.0 of DVD-RW, DVD-ROM, CD-ROM, CDV, CD-G, SACD, Photo CD, DVD-RAM that cannot be removed from their cartridges, 2.6-GB and 5.2-CB DVD-RAM, PAL discs.

Language Settings. Press key [SETUP] → [OSD language] → Change the display language. It is the same procedure for Audio, Subtitles and Menu.

CONTROL BUTTONS

TFT ON/OFF	Turn the unit screen on and off.
VOL -/VOL +	Controls the volume up or down.
PLAY/PAUSE	Press to pause current video. Press again to restart video.
MENU	Press to return to the root menu for DVD.
MODE	Press repeatedly to switch the mode for AV IN or DVD.
SETUP	Press to enter the setup menu, then use the direction keys and OK to set the system menu.
Direction Keys	Use direction keys for: previous/next, fast forward/ fast rewind.
OK	In DVD play mode, press to pause/restart playback. In menu mode, press to enter the selected item.
DVD/USB/SD	Press repeatedly to switch input source: Disc/USB mode/SD card.
MUTE	Press to mute audio.
AUDIO	Press to access audio settings.

REMOTE CONTROL

MUTE: Mute audio, press again to resume audio.

USB CARD: Switch between DVD, SD Card and USB modes.

SLOW: Slow down the playback.

A-B: Repeat DVD between two points. Press once for start point, press again for end point, and playback will repeat between these points.

REPEAT: Repeat the loaded disc.

VOL-: Reduce the volume.

VOL+: Increase the volume.

DISPLAY: Adjust the ratio and size of display.

RETURN: Return to previous page on menu.

SETUP:Access setup menu.

MENU: When DVD loaded, access main menu of the DVD.

DIRECTION ARROWS: In DVD playback, press once to skip forwards or backwards chapters, hold button to fast forward or rewind playback. In menu, press to scrol left, right, up, down.

ENTER: In menu, press to select menu option.

PLAY/PAUSE: Pause and resume DVD playback.

STOP: Stop DVD playback.

0-9 NUMBER KEYS: Press number to input a DVD chapter or CD track.

TFT: Press to turn off the DVD screen, press again to turn back on.

SUBTITLE:Change subtitle mode.

Range of use
Remote control Range of use
The distance and angles are approximate.
Within 8m (26ft.) in front
Within 30 degrees angle either left or right

RANGE OF USE

CONNECTIONS
Connect to TV

Power Supply & Charge

Connect to mains power supply with AC Adaptor, to play using mains power supply or to charge internal battery. Battery charge will show as red light on front panel. When fully charged, the red light will dim
Note - When plugged on to the mains the DVD player will also charge the battery while playing.
Connect to car power supply with Car Adaptor, to power device using car power supply or to charge internal battery. Battery charge will show as red light on front panel. When fully charged, the red light will dim.
Note - When plugged on to the mains the DVD player will also charge the battery while playing.
Internal Battery Power — If the DVD player battery is fully charged, do not connect the device with AC Adaptor or Car Adaptor. The DVD player will play using its internal charged battery. When battery level is running low, an icon indicating the battery level will flash on the DVD player screen.
To maintain power supply when the battery icon is flashing, connect the DVD player with AC Adaptor or Car Adaptor for charging. supply, and to charge battery.

SYSTEM SETUP
Menu Operation

Press [SETUP] on the remote control or on the unit to access the setup menu.
Press [LEFT] / [RIGHT] to select an item. The submenu of the selected item will be instantly shown.
Press [UP] / [DOWN] to select an item in the submenu, then press [OK]/ [ENTER] to enter. Use [UP] / [DOWN] to select an option, then press [OK] / [ENTER] to confirm it or press [LEFT] to cancel.
Press [UP] / [DOWN] to continue to set other items in the to access the setup menu.
Press [LEFT] to go back to the superior menu of the current one.
Press [SETUP] again and press [ENTER] / [OK] to exit the setup menu.

General Setup Page

[TV Display]

4:3 Normal / PS PANSCAN
If the unit is connected to a conventional TV set, the wide-screen image will be displayed on the screen in its native aspect ratio with some part on the left and right cut off.
4:3 Normal / LB LETTERBOX
If the unit is connected to a conventional TV set, the wide-screen image will be displayed in its native aspect ratio with black borders on the top and the bottom side.
16:9 wide
Select this option if the unit is connected to a wide-screen TV set. The wide-screen image will be displayed in full screen in its native aspect ratio while the 4:3 image will be stretched out horizontally to fit in the screen.

[ANGLE MARK]

Set this item to ON. When a disc encoded with multiple camera angles is playing, the angle mark will display on the screen. Then you can view the video of different camera angles by pressing [ANGLE] on the remote control.
Set this item to OFF to disable this function.
NOTE: This function only works with those discs encoded with multiple camera angles.

[OSD LANGUAGE] (on-screen display language)
Set this on-screen display language in this item.

[SCREEN SAVER]

ON: If the image remains motionless on the screen, for several minutes, a screen saver will appear on the screen. You can press any key or button to wake it up.
OFF: Turn off the screen saver function.

[LAST MEMORY]

ON: Each time you turn off the unit or stop the disc, it will memorize the last play duration. Next time you turn on the unit and play the same disc, the unit will play from that memorized point.
OFF: Disable the last memory function.

[MP3 LYRIC]
If you want to show the lyrics of a song, please load lyrics and music as the same name in a USB or Memory card before performing this function.

Choose MP3 file.
Download the corresponding lyrics with the extension ".lrc" from the Internet or create it with lyric file editor (not included).
Rename the lyrics file. Make sure that the lyrics filename is the same as the music file name.

Audio Setup Page

The Audio menu allows you to change the audio setup of the DVD.
[Down mix] Set down mix to LT/RT,Stereo, V SURR.
[Dual Mono] Set down Stereo, L-Mono, R-Mono or Mix-Mono.
[Dynamic] Full 3/4, 1/2, 1/4, OFF

Panel Quality Setup

The video menu allows you to change the display properties of the DVD.
[Sharpness] Adjusts the screen sharpness.
[Brightness] Adjusts the screen brightness.
[Contrast] Adjusts the screen contrast.
[Saturation] Adjusts the screen saturation.
[Hue] Adjusts the screen hue.
[Aspect Ratio] Setup panel display to 16:9 or 4:3.

Preference Page

The preference menu option allows you to adjust the default DVD disc setting. (The setting is only available when no media is inside the unit.)
[TV Type] Set TV Type to PAL, AUTO, or NTSC.
[Audio] Set the default audio language.
[Subtitle] Set the subtitle language.
[Disc Menu] Set the disc menu language.
[Parental] When setting a rating level, a password screen is shown. Follow the on-screen instructions. Do not forget your password.
[Password] Enter the default password "8888" then set your password.
[Default] Return the portable DVD to factory default beyond the maximum output of the speaker in sound effects processing.

SPECIFICATIONS

Supported format for different files

File	Supported Format
Compatible Disc	CD-R, CD-RW, VCD, SVCD, CVD, DVD±R, DVD±RW
Audio	MP3, WMA, OGG
Video	AVI, YOB, FLY, RMVB (Resolution must be within 720*576)
Picture	JPG
E-book	TXT(Code: ANSI)

Specification

Compatible DISC	CD, DVD, CD-R(RW), DVD±R, DVD±RW, VCD, SVCD(RW)
Frequency response	20HZ to 2OKHZ
Video output	1 Vp-p75 Ohm unbalanced
Audio outpu	1.4 Vrms/10 kohm
Dynamic range	Better than 85dB
Laser	Semiconductor laser, Waver length: 650
Power source	DC9-12V lA
Battery Type	Li polymer

TROUBLESHOOTING

Before contacting the customer service, please kindly check by yourself with the following chart.

Troubleshooting	Solution
The player can't read discs	Please clean the laser and DVDs with the alcohol first. Ensure the disc is in the right format for our DVD player. Our player doesn't support Dolby, pirate, burnt and blu rays DVDs.
The player doesn't work	Make sure the power switch has been set to the "ON" position. Check connections to the AC adaptor or battery pack. Check the status of the indicator light. Under the premise of power connection, if it's on, there is a problem with the motherboard; if it's off, there is a problem with the motherboard or power adapter.
Picture is distorted	The disc might be damaged. Try another disc. It is normal for some distortion to appear during forward or reverse scaning.
Remote controller doesn't work	Replace the battery (AAA battery) All buttons fail: A problem with remote controller or receiver. Note: The remote controller needs to be aimed directly at the front of the Video Player, within 8 m and 30 degrees.
The player sound is too low	Check that the two speakers of the player that the two speakers of the player are working properly, cover one speaker with your hand, and check if the other speaker is sounding. Check whether the disc you put in meets whether the disc you put in meets the specifications. Our player does not support DTS, which is the audio track of Dolby Disc. Please try another disc(not pirate, burnt, Dolby and Blu-ray discs) to hear whether it will play louder.
No sound or distorted sound	The speaker is off if headphones connected. Make sure your DVD is placed properly and all cables are securely connected into the appropriate jack. Audio may not be output due to how files were created.
Can't advance through a movie	You can't advance through the opening credits and warning information that appears at the beginning of moviesbecause the disc is programmed to prohibit that action.
Other problem	Static discharges or other external interferences can cause the DVD player to malfunction. When this happens, disconnect the power plug and plug it back in. If the problem happened again, disconnect the device from main power and contact Customer Service or a repair shop.

SUPPORT

Thank you for purchase of Oakcastle portable DVD120 Please follow the guidance of the manual to set up your device and enjoy its fantastic features. If you require further assistance with your new device, please contact our support team on the Oakcastle website: https://www.oakcastle.co.uk/support
