Heatmaxx SRPH33A Series Owner's Manual

Outdoor patio heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
Questions, problems, missing / replacement parts? Before returning to your retailer,
call our customer service department at 1-
Monday-Frida
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
A propane cylinder not connected
for use shall not be stored in the
vicinity of this or any other appliance.
WARNING
For Outdoor Use Only.
CAUTION:
Installer: Leave the manual instructions
to the user for future use.
Consumer: Please keep this manual
for future reference.
Model#: SRPH33A-XXXX
Read the instructions before use.
This appliance must be installed in
accordance with such regulations as
are in force.
-
-
,
am -
pm, ST,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRPH33A Series and is the answer not in the manual?

Questions and answers

Related Manuals for Heatmaxx SRPH33A Series

Summary of Contents for Heatmaxx SRPH33A Series

  • Page 1 DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department. WARNING Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: Warnings And Cautions

    WARNINGS AND CAUTIONS DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. WARNING: Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death.
  • Page 3 WARNINGS AND CAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Any guard or other protective device removed for servicing the heater must be replaced prior to operating the heater. Installation and repair should be done by a qualified service person. The heater should be inspected before use and at least annually by a qualified service person.
  • Page 4 WARNINGS AND CAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Within a partial enclosure which includes an The pressure regulator and hose assembly sup- overhead cover and three side walls, as long as plied with the appliance must be used, replace- 30 percent or more of the horizontal periphery of ment pressure regulators and hose assemblies the enclosure is permanently open.
  • Page 5 WARNINGS AND CAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES: PREPARATION TOOLS NEEDED: (NOT INCLUDED)

  • Page 6: Exploded View

    EXPLODED VIEW Please check the contents of the packaging as to whether anything is missing!

  • Page 7: Parts & Hardware

    PARTS & HARDWARE...
  • Page 8 ASSEMBLY INSTRUCTIONS...
  • Page 9 ASSEMBLY INSTRUCTIONS...
  • Page 10 ASSEMBLY INSTRUCTIONS 3 x1 Bx3 6MM Dx3 M6 x 70 1 x1 2 x4 Ax12 M6x10 Bx12 6MM Cx12 M6 Note: Remove protective cover on the reflectors before assembly.
  • Page 11 ASSEMBLY INSTRUCTIONS...
  • Page 12 ASSEMBLY INSTRUCTIONS...

  • Page 13: Safety Check

    SAFETY CHECK WARNING : ONLY AN AUTHORIZED GAS TECHNICIAN SHOULD INSTALL THIS PRODUCT. Check for leaks Note:...
  • Page 14 SAFETY CHECK WARNING: ONLY AN AUTHORIZED GAS TECHNICIAN SHOULD INSTALL THIS PRODUCT. propane e. If no bubbles appear, the connection is safe. f. If bubbles appear, there is a leak. Shut off the propane gas cylinder valve, loosen and then re-tighten this connection. propane line 1-888-909-3888.
  • Page 15 propane Push in gas control knob and turn counter-clockwise to "LOW" position, this will light the burner. If needed, keep depressing and turning control knob counter-clockwise until the burner lights. (You will hear 1 clicking noise). Once the burner is lit, continue to keep the control knob depressed for at least 30 seconds, Then release control knob.
  • Page 17 burner. propane propane...

  • Page 18: Locating Heater For Use

    LOCATING HEATER FOR USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT, ABOVE, BESIDE OR UNDER THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. Minimum clearance from combustible surfaces This heater is primarily used for the heating of outdoor patios, decks, spas, pools and open working areas.

  • Page 19: Maintenance & Storage

    MAINTENANCE/STORAGE CLEANING AND MAINTENANCE : NOTE: At least once a year, the unit should be inspected NOTE:...
  • Page 20 MAINTENANCE/STORAGE Spiders and insects can nest in burner or orifices. This dangerous condition can damage heater and render it NOTE: unsafe for use. Clean burner holes by using a heavy-duty wait until heater is cool before pipe cleaner. Compressed air may help clear away covering.

  • Page 22: One-Year Limited Warranty

    ONE-YEAR LIMITED WARRANTY Need help? call our toll free number at:...
  • Page 23 SRPH33A-XXXX color material & base pole & wheels reflector material & base reflector pole & wheels 1. 1PC pole w/o wheels 1. Steel w/ bigger base 1. 1PC reflector 2. 1PC pole w/ wheels 2. S/S w/ bigger base 2. 2PCS reflector 3.
