Heatmaxx SRPT03 Owner's Manual

Bronze tabletop patio heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Bronze Tabletop
Patio Heater
Owner's Manual
Questions, problems, missing / replacement parts? Before returning to your retailer,
please call service department at 1-888-909-3888, 7:30am to 4:
Friday, or send an e-mail to customerservice@shinerich.us.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
WARNING
For Outdoor Use Only.
CAUTION:
Installer: Leave the manual instructions
to the user for future use.
Consumer: Please keep this manual
for future reference.
Model#: SRPT03
Read the instructions before use.
This appliance must be installed in
accordance with such regulations as
are in force.
30pm PST, Monday-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRPT03 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heatmaxx SRPT03

Summary of Contents for Heatmaxx SRPT03

  • Page 1 CAUTION: Installer: Leave the manual instructions to the user for future use. Consumer: Please keep this manual for future reference. Model#: SRPT03 Read the instructions before use. This appliance must be installed in accordance with such regulations as Owner’s Manual are in force.
