Mod.
1054
DS1054-218
LBT21405
WIFI ACTUATOR RELAY
Ref.1054/102
Interactive Links
LINKLINKLINKLINK
INSTALLATION, CONFIGURATION AND USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1054 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for urmet domus 1054

Summary of Contents for urmet domus 1054

  • Page 1 Mod. 1054 DS1054-218 LBT21405 WIFI ACTUATOR RELAY Ref.1054/102 Interactive Links LINKLINKLINKLINK INSTALLATION, CONFIGURATION AND USER MANUAL...

  • Page 2: Table Of Contents

    ENGLISH CONTENTS 1. GENERAL DESCRIPTION ......................... 3 2. DESCRIPTION OF COMPONENTS ......................3 3. INSTALLATION ............................4 3.1 WARNINGS FOR THE INSTALLER ....................4 3.2 INSTALLATION MODE ........................4 3.3 DESCRIPTION OF THE TERMINALS ....................6 4. CONFIGURATION ............................ 6 4.1 RELAY WIFI PAIRING AND CONFIGURATION ................

  • Page 3: General Description

    GENERAL DESCRIPTION The device Ref. 1054/102 is a WiFi actuator relay that can be associated with the WiFi thermostat Ref. 1054/101. The WiFi relay allows activation/deactivation of any air purifiers, ventilation and/or extraction systems and heating/cooling systems. The device has two operating modes: Manual and Automatic.

  • Page 4: Installation

    INSTALLATION Warnings for the installer ATTENTION! Urmet S.p.a. denies all liability for damage or malfunctions of any kind arising from or in any way connected with installations carried out in ways different from or contrary to these instructions or by unskilled personnel. This exclusion of liability extends beyond the warranty period of the product. The following instructions must be observed when installing the device: •...
  • Page 5 Hook the closure lid onto the fixing base by making a rotary movement from top to bottom, first coupling the small teeth on the upper side. Power the system from the mains; the device switches on in Configuration mode. The WiFi led (3) turns on with a white flashing light.

  • Page 6: Description Of The Terminals

    IEC 60332-2-2 if they have a cross-section of less than 0.5 mm². CONFIGURATION To configure and use the device, it is necessary to first pair the thermostat Ref. 1054/101 with a smartphone or tablet using the UrmetON app. The smartphone or tablet must be connected to the Internet, via its own data connection or WiFi.
  • Page 7 The Home page is displayed in which the thermostats associated with the account with which you are logged in are displayed. Select the thermostat to which you want to associate the relay. In the following example, the thermostat present in the place named “Office“ was selected. DS1054-218...
  • Page 8 The user interface of the selected thermostat is displayed. Enter the setup menu by pressing the key The screen with the configuration menu appears, and by scrolling down the page you can view all parameters. Relay relay DS1054-218...
  • Page 9 Press the “Relay” button to associate and configure the relay to the selected time thermostat. Relay The following association and configuration screen appears. Relay Air quality relay relay Relay not associated Temperature relay relay Relay not associated Humidity relay relay Relay not associated Press the “Associate”...
  • Page 10 Relay not associated ATTENTION! It is possible to associate up to a maximum of 3 relays Ref. 1054/102 to a thermostat Ref. 1054/101, one for each use mode. In the event of multiple association with a single thermostat, it is necessary to carry out the association procedure individually for each relay.
  • Page 11 12. Once pairing with the thermostat is complete, the WiFi led (3) switches on with a fixed white light. 13. After pairing, you can define how to use the relay by pressing the relevant buttons : “AUTO” or “Manual”. Relay Air quality relay Relay not associated Temperature relay...

  • Page 12: 4.1.1 Humidity

    4.1.1 Humidity By setting the relay to “Humidity relay” mode, it is necessary to set the maximum humidity that the time thermostat must detect to activate the relay. Scroll down the following screen until the “Humidity” section is displayed. Relay Air quality relay Relay not associated Temperature relay...

  • Page 13: Relay Unpairing

    RELAY UNPAIRING It is possible to unpair the relays associated with the thermostat Ref. 1054/101. On the “Relay“ page, press the “Deassociate“ button, the following screen appears. Relay Air quality relay Relay not associated Temperature relay Relay not associated Humidity relay Relay associated ATTENTION! Unpairing involves the removal of all the relays associated with the thermostat.

  • Page 14: Technical Specifications

    TECHNICAL SPECIFICATIONS Power voltage: ........................110 ÷ 260V~ - 50/60 Hz Maximum power consumption :........................3VA WiFi frequency bands: ......................2400 ÷ 2483,5 MHz WiFi standard: ..........................IEEE 802.11 b/g/n Output power (Max) WiFi: ........................20 dBm Contact capacity (N.O.): ...................250 V~ - 7A (resistive load) Weight:................................63,5 g Dimensions (WxHxD): .......................67 x 47 x 32 mm Operating temperature........................-9.9°...
  • Page 15 DS1054-218...
  • Page 16 DS1054-218 LBT21405 URMET S.p.A. Area tecnica 10154 TORINO (ITALY) servizio clienti +39 011.1962.0029 VIA BOLOGNA 188/C http://www.urmet.com Telef. +39 011.24.00.000 (RIC. AUT.) e-mail: info@urmet.com +39 011.24.00.300 - 323...
