- Page 1 OPERATING MANUAL IN074 Electronic Shipping Indicator Model No.: 9995x G-Tek Corporation Pvt. Ltd. 3, mahavir estate, karelibaug vadodara-390 018 tel.: +91-265-2461912 email: info@gtek-india.com English/ 2023/ Rev.1.0 url: www.gtek-india.com...
-
Page 2: Table Of Contents
ONTENTS List of Tables ........................2 List of Figures ........................2 ..................... 3 AFETY AND THE NVIRONMENT 1.1. About this document ......................3 1.2. Ensure Safety ........................3 1.3. Protecting the Environment ....................3 ........................4 PECIFICATIONS 2.1. Use ............................ 4 2.2 Technical Data ........................ -
Page 3: List Of Tables
7.1 Accessories ........................25 7.2 Cleaning of LM IN074 Indicator ..................25 7.3 Battery ..........................25 ......................26 IPS AND SSISTANCE List of Tables Table 1 Technical Specifications ......................4 Table 2 Commonly used Abbreviations ....................11 Table 3 Frequently Asked Questions(FAQs) ..................26 List of Figures Figure 1 LM IN074 Electronic Shipping Indicator models .............. -
Page 4: Safety And The Environment
At the end of its useful life, send the product to the separate collection for electric and electronic data loggers (observe local regulations) or return the product to G-Tek for disposal. (Dispose or recycle the LM IN074 Electronic Shipping Indicator in accordance with the WEEE 2012/19/EU guidelines or your local regulations. -
Page 5: Specifications
PECIFICATIONS 2.1. Use IN074 is an Electronic Shipping Indicator. It shows if a vaccine is exposed to time- temperature limits beyond stipulated by WHO/PQS/E06/TR07.4 There are 4 models to choose from, based on the vaccines being transported – Type C, Type A/B, Type Rotateq and Type Prevenar. - Page 6 Type Rotateq: Alarm1: High Threshold: >= 27 °C; Single event for >1 minute Alarm2: Medium Threshold: >=17 ° C; cumulative exposure for >2 hours Alarm3: Low Threshold: <= -25 °C; Single event for >1 minute Type Prevenar: Alarm1: High Threshold: >= 40 °C; Single event for >1 hour Alarm2: Medium Threshold: >=30 °...
- Page 7 For manual deactivation of the device, press “ Start/Stop ” button again for 10 seconds (To avoid wrong trigger, if the button is pressed for more than 30 seconds, device will not be stopped.). Clearly marked for Type C, Type A/B, Type Rotateq and Type Type Identification Prevenar on devices with different colored casing.
-
Page 8: Unpacking The Product
NPACKING THE RODUCT 3.1 Unpacking and Inspection of LM IN074 ➢ LM IN074 Electronic Shipping Indicator is dispatched in a recyclable, environment friendly package specially designed to give adequate protection during transit. ➢ Figure 1 shows Four models of LM IN074 Electronic Shipping Indicator Viz. -
Page 9: Figure 1 Lm Pro In074 Electronic Shipping Indicator Models
Figure 1 LM IN074 Electronic Shipping Indicator models ➢ As per the LM IN074 Electronic Shipping Indicator models, default alarm settings are as below: Alarm Type Alarm Threshold Period of exposure Type-C Alarm-1 >= 45 °C 1 hour continuous exposure Alarm-2 >= 30 °C 10 hours cumulative exposure... -
Page 10: Mechanical Dimensions Of Lm
3.2 Mechanical Dimensions of LM IN074 Figure 2 Overall dimensions of LM IN074 Overall Dimensions Dimension (L x W x H) mm 128 x 60 x16 mm Mounting Screw Mounted Weight Approx. 100 gms 3.3 Enclosure Mounting of LM IN074 ➢... -
Page 11: Figure 4 Mounting Of Lm Pro In074 On Shipment Information Card
➢ Stick the device on the shipment information card as per the instruction written on it as below figure 4. Figure 4 Mounting of LM IN074 on shipment information card Page 10... -
Page 12: Terms And Definitions
ERMS AND EFINITIONS 4.1 Abbreviations and its Description Table 2 Commonly used Abbreviations Abbreviation Description Starting the LM IN074 Elapsed time in terms of Days and Hours Data logging is ON Data logging is stopped Error message for temperature out of measurement range Minimum temperature Maximum temperature Duration in Hr:Mn... -
Page 13: Product Description
RODUCT ESCRIPTION 5.1 Display (LCD) The multi–Character LCD Display consists of OK/Alarm, Bell, Min/Max, Battery Level indication, USB connection, Alarm high and Low, Rec, day, calendar, clock, duration, delay counter, day/time/duration text and current temperature reading with measurement unit. The position and description of each segment is shown in figure 5. Figure 5 LCD Display overview 1. -
Page 14: Keys And Their Function
9. Digits used to display various parameters like Day, time and duration 10. Delayed start indicator: when the device is activated, it will wait for 60 minutes to start logging the data. During this time, the sand clock symbol will be on. 11. -
Page 15: Activation Of Lm Pro In074 Electronic Shipping Indicator
SING THE PRODUCT 6.1 Activation of LM IN074 Electronic Shipping Indicator IN074 Electronic Shipping Indicator is dispatched in deep sleep mode. To activate the IN074, press “Start/Stop” key for about 10 seconds. Once it is activated, all segments of display will turn ON for 5 seconds followed by “Srt” – start message on the display as shown in figure 6. -
Page 16: Stopping The Data Logging Of Lm
Data recording mode is ON which is indicated by “REC” message on display. 1. Temperature reading is within the Alarm threshold value. • The Elapsed time from the starting of the LM IN074 is 2 days 03 hours which is indicated by “Et 02 03”... -
Page 17: Stopped Condition Display
Note: If the “Start/Stop” key is kept pressed for more than 30 seconds, LM IN074 will not be stopped and continue to be in recording state. 6.4.1 Stopped condition Display In Stopped mode of the LM IN074, Elapsed counter is stopped, display shows “Stp” message instead of the temperature reading and “REC”... - Page 18 -DAY Temperature conditions and alarm status Display Press Review key for 1 second. Day1 Alarm-1 limit was crossed for 26 minutes on day 1 with max temperature 43.1 °C, the duration not enough to trigger the alarm. Press Review key for 1 second. Alarm-2 limit was crossed for 40 minutes on day 1, duration not enough to trigger the alarm.
- Page 19 Press Review key for 1 second. Day5 No alarm excursions were occurred on day 5. Press Review key for 1 second. Day6 On day 6, alarm-3 was triggered at 8 hr 50 min with min temperature -2.8 °C indicated by bell-3 symbol. Press Review key for 1 second.
-
Page 20: Starting Measurement
6.6 Measurement Starting Measurement With Default Configuration of the LM IN074 indicator, the measurement program will be started automatically after 60 minutes of start up. The Configuration parameters are prefixed as per WHO Specification reference WHO/PQS/E006/TR07.4 Issue date 16 October 2014 and user cannot change them from device menu. -
Page 21: Generating Pdf Report
Figure 7 Micro-USB Attachment 6.7.2 Generating PDF report ➢ Open LMViewIN-074 software Application to carry out analysis for process readings. The pop-up window will appear as shown in figure 8. Select the appropriate file path and batch file name for saving the data file and press button. -
Page 22: Figure 9 Downloaded Data Summary
Figure 9 Downloaded data summary ➢ Generate the PDF report of data summary by clicking on icon. A pop-up window will appear for selecting the file path and filename of report to be generated as shown in figure 10. Figure 10 Selecting file location for saving PDF report Page 21... -
Page 23: Pdf Report Explanation
6.7.3 PDF Report Explanation ➢ Sample PDF file generated from LM IN074 indicator for 22 days recorded data is shown in figure 11, figure 12 and figure 13. This report consists of following data: 1. Title of the report generated – Prefixed title 2. -
Page 24: Figure 12 Sample Pdf Report Part -2
Figure 12 Sample PDF report part -2 Page 23... -
Page 25: Definition Of Important Terms In Pdf Report
Figure 13 Sample PDF report part -3 ➢ Solid red lines in the graph shows Alarm 1 (40 °C) , Alarm 2 (30 °C) and Alarm 3 (-0.5 °C ) limits. Tag event indications for alarm trigger, alarm restore, are specified in graph labels as shown in figure 13. -
Page 26: Maintaining The Product
AINTAINING THE RODUCT 7.1 Accessories ➢ USB cable ➢ LM IN074 calibration certificate 7.2 Cleaning of LM IN074 Indicator Ensure that no liquids enter the housing. ➢ If the housing of LM IN074 Indicator gets dirty, clean it with damp cloth. ➢... -
Page 27: Tips And Assistance
IPS AND SSISTANCE Table 3 Frequently Asked Questions(FAQs) Questions Cause/Solution How to activate LM IN074? ▪ Press Start/Stop key for 10 seconds. All segments on the device display will be ON for 5 sec, after that “Srt” message will be displayed for 10 Sec, if Review key is not pressed, LM IN074 will go into deep sleep mode. - Page 28 Page 27...
