- Page 1 OPERATING MANUAL CR-2010 CR-2010 Pro Series 6" Circular Chart Recorder Model No.: 20xx..., 25xx... G-Tek Corporation Pvt. Ltd. 3, mahavir estate, karelibaug vadodara-390 018 tel.: +91-265-2461912 email: info@gtek-india.com url: www.gtek-india.com...
-
Page 2: Table Of Contents
ONTENTS Contents ................................ 0 List of Figures ............................1 List of Tables ............................1 Safety and The Environment ......................... 2 About This Document ......................2 Ensure Safety .......................... 2 Protecting The Environment ....................2 Specifications ............................3 Use of The Recorder ........................ 3 Technical Specifications ...................... -
Page 3: List Of Figures
IST OF IGURES Figure 1 – Front and Back View of The Chart Recorder ................7 Figure 2 - Environmental Conditions ......................8 Figure 3 - Overall Mechanical Dimensions ....................9 Figure 4 - Panel Mounting ........................... 10 Figure 5 – Back panel view .......................... 11 Figure 6 - Fitting / Replacing the Pen ...................... -
Page 4: Safety And The Environment
AFETY AND NVIRONMENT 3.1 A BOUT OCUMENT ➢ This instruction manual is an essential component of the product. ➢ Please read this documentation carefully and pay attention to the safety instructions and warning notices to prevent injuries and damage to the product. ➢... -
Page 5: Specifications
SE OF ECORDER The CR-2010 Pro Series of the recorder comes as either 1 or 2 pen continuous marking circular chart recorder. The Recorder with no display can have single channel only. This manual is written specifically for single pen recorder without display. -
Page 6: Table 2 Chart Type Of Chart Recorder
Mounting Panel Mount Chart speed 4 hour/ 24 hour/ 7 day per revolution Chart Calibrated Radius 2.3" (approx. 59mm) Chart Size (diameter) Circular, 6" (calibrated radius 75mm) approx.. Chart Ranges Refer Table 1 (Operation) 5˚C to 45˚C Temperature (Limiting) 0˚C to 50˚C (Storage)-20˚C to 60˚C (Operation) 10 to 80 % RH Non-Condensing Humidity... - Page 7 +20 to -10 7 Day 6” 308009 W620-10PS +50 to -100 7 Day 6” 308004 W650-100PS +40 to -10 7 Day 6” 308003 W640-10PS -50 to +50 7 Day 6” 210042 W6-5050PS Other Please Specify ** The center of the chart is designated as range low value of recording. Page No.: 5...
-
Page 8: Unpacking The Product
NSPECTION OF ECORDER G-Tek recorders are dispatched in a recyclable, environment friendly package, specially designed to give adequate protection to the recorder against transit damage. If the outer box shows any sign of damage, it should be opened immediately for inspection of the contents. If there is evidence of damage, please do not operate the equipment. -
Page 9: Figure 1 - Front And Back View Of The Chart Recorder
Figure 1(B) Back view of recorder Figure 1 – Front and Back View of The Chart Recorder Page No.: 7... -
Page 10: Installation Of The Recorder
5.2 I NSTALLATION OF ECORDER Figure-2 B Figure-2 A Figure 2 - Environmental Conditions Environmental Conditions: Recorder should be used with proper environmental conditions for better operation. The environmental conditions are shown in Figure 2. Attention Select a location away from strong electrical and magnetic field. If this is not possible, particularly in application where mobile communication device is expected to be used, screened cables within earthed (grounded) metal contact must be used as shown in above figure 2B. -
Page 11: Overall Mechanical Dimensions
5.3 O VERALL ECHANICAL IMENSIONS Figure 3 - Overall Mechanical Dimensions Overall Dimensions( approx.) Dimensions L x W x D (mm) 232 x 205 x 117 Panel Cutout L x W (mm) 200 x 170 Bezel (mm) 232 x 205 Page No.: 9... -
Page 12: Figure 4 - Panel Mounting
The panel mounting of recorder is shown in figure 4 . Figure 4 - Panel Mounting Page No.: 10... -
Page 13: Electrical Installation
LECTRICAL NSTALLATION 6.1 W IRING IAGRAM FOR ECORDER The connection of the mains supply, battery backup and sensor are shown in figure 5. Refer the following table 3 for supply and sensor connection of the recorder. Figure 5 – Back panel view Table 3 Connection Notations Code Connector Name... -
Page 14: Fitting The Pen
➢ The connections for Mains supply, battery terminals and sensor input are shown in Figure 5. As per the figure the live, neutral & earth from the mains cord are connected to L, N & E respectively. ➢ Ensure that the bared ends of the mains cord are fully inserted into the mains connector and no loose/poor connection. -
Page 15: Fitting The Chart
6.3 F ITTING THE HART Figure 7 - Chart Fitting To replace the chart, follow the steps: 1. Open the door of the recorder. 2. Unscrew the chart knob as shown in figure 7. 3. Remove the chart. 4. Insert the new chart. 5. -
Page 16: Operation
PERATION After ensuring that the wiring is proper and the pen and chart are fitted correctly, power on the recorder. The pen will move towards the center of the chart. After reaching the center of the chart, it will stop. After a while pen will move to the position on the chart as per the parameter value. -
Page 17: Mechanical Calibration
7.2 M ECHANICAL ALIBRATION It involves setting of pens zero and pen full scale on chart, through the front panel keyboard. User can calibrate the Recorder by following the sequence as shown in figure 9. Figure 9 – Mechanical Calibration Menu Page No.: 15... -
Page 18: Electrical Calibration
7.3 E LECTRICAL ALIBRATION This setting involves aligning the pen to the known parameter value on chart, through the front panel keyboard. User can calibrate the Recorder by following the sequence in figure 10. Figure 10 – Electrical Calibration Menu Page No.: 16... -
Page 19: Frequently Asked Questions(Faqs)
(FAQ REQUENTLY SKED UESTIONS Table 4 Frequently Asked Questions (FAQs) PROBLEM CORRECTIVE ACTION ➢ Check device switch whether it is ON or OFF Power is ON but status ➢ Check AC Mains or Battery Voltage . LED is off. ➢ Check whether sensor is connected properly or not. Chart reading is ➢... -
Page 20: Standard Accessories
TANDARD CCESSORIES Charts Pack of 30 Pens Pack of 5: - 1 number Panel Mounting Clamps: - 2 numbers Optional Accessories Figure 11 – Accessories Page No.: 18... -
Page 21: Order Code
RDER The Order code for the chart recorder is as below: Table 5 Order code P= Pen, C=Chart PS = Power Width Thermal- Supply CT - PI = PC Pen, D= TS - RE = Relay Chart R=Range CS=Chart Speed S=Sensor Type Interface Recorder...
