G-Tek 62 Series Operating Manual

Paperless recorder
Hide thumbs

Advertisement

Quick Links

Download this manual
OPERATING
MANUAL
Paperless Recorder
Model No.: 62xx...
G-Tek Corporation Pvt. Ltd.
3, mahavir estate, karelibaug
vadodara-390 018
tel.: +91-265-2461912
email: info@gtek-india.com
url: www.gtek-india.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 62 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for G-Tek 62 Series

Summary of Contents for G-Tek 62 Series

  • Page 1 OPERATING MANUAL Paperless Recorder Model No.: 62xx... G-Tek Corporation Pvt. Ltd. 3, mahavir estate, karelibaug vadodara-390 018 tel.: +91-265-2461912 email: info@gtek-india.com url: www.gtek-india.com...
  • Page 2 Contents LIST OF FIGURES ....................... 2 LIST OF TABLES ......................... 4 INTRODUCTION ........................ 5 MAIN MENU ........................18 BATCH SETUP ......................... 19 4.1.1 Global Configuration ...................... 19 4.1.2 Channel Configuration ....................20 4.1.3 Output Configuration ..................... 22 4.1.4 Relay Configuration ......................23 4.1.5 Group ..........................
  • Page 3 IST OF IGURES Figure 1- Overall Dimensions (Height and Width)........................6 Figure 2- Overall Dimension (Depth) ............................6 Figure 3- Panel Mounting................................7 Figure 4- Back Panel of Paperless Recorder ..........................11 Figure 5-Sensor Wiring - RTD (Pt-100) 3-Wire Input ........................13 Figure 6- Sensor Wiring –...
  • Page 4 Figure 49- Communication Configuration error for invalid field values entered ................ 41 Figure 50- Message - Communication Parameters updated successfully .................. 42 Figure 51- Factory Settings Menu .............................. 42 Figure 52- Connection for 3 wire RTD calibration ........................43 Figure 53- Connection for 4 wire RTD calibration ........................43 Figure 54 RTD Calibration 20 ohm .............................
  • Page 5 IST OF ABLES Table 1 Global Configuration parameters ..........................19 Table 2 Additional Channel Configuration parameters ......................20 Table 3 Modify Group parameters ............................. 26 Table 4 Create Batch parameters .............................. 28 Table 5 Communication Parameters ............................40 Table 6 Chart Speed Selected V/S Graph Update Rate ......................70...
  • Page 6 NTRODUCTION This manual will help user to get acquainted with the installation and operation of the Paperless Recorder. Paperless Recorder has multiple options to view data such as the digital view, horizontal bar graph, vertical bar graph, horizontal line graph, vertical line graph and polar graph. There are several options to group channels, view them separately, change batch setup, system setup and others.
  • Page 7 3.2 I NSTALLATION Figure 1- Overall Dimensions (Height and Width) Figure 2- Overall Dimension (Depth)
  • Page 8 Figure 3- Panel Mounting...
  • Page 9 3.3 E LECTRICAL NSTALLATION General information To comply with Underwriter Laboratories (UL) and Canadian Standards Association (CSA) certification, route signal leads and power cables in earthed (grounded), flexible metal conduit. Connect proper Earth to the earthing terminal of the Paperless Recorder. ▪...
  • Page 10 To achieve the best results, the following notes should be considered: Low level signal wiring such as that associated with thermocouples, RTDs and current loops should always be kept separate from power and control output wiring. Signal input wiring should be twisted pairs/triplets etc. The conductors should be stranded rather than solid in construction.
  • Page 11 3.3.1 Wiring diagram for Paperless Recorder Check for proper Earthing: Proper Earthing is necessary for best performance of the Paperless Recorder. Follow the steps mentioned below to check whether the earthing given is proper or not: ▪ Find out the Phase line of connection with the help of “Tester with Neon Lamp”. When Neon Lamp glows, it is an indication of the phase line.
  • Page 12 See the back panel of the Paperless Recorder, you will find all the connectors for wiring. As shown in the following figure. Figure 4- Back Panel of Paperless Recorder The Paperless Recorder can be connected and configured to operate with a variety of signal sources as thermocouple, RTD, DC current, DC voltage etc.
  • Page 13 3.3.1.1 Sensor wiring To ensure maximum performance of Paperless Recorder, proper wiring installation practices must be followed. Failure to do so can result in a range of problems, from loss of configuration to component failure, caused by transmitted or radiated electrical noise. Proper consideration must be given to local noise sources and appropriate suppression steps taken to minimize any potential problems.
  • Page 14 3.3.1.1.1 Sensor wiring - RTD (Pt-100) 3-wire input Figure 5-Sensor Wiring - RTD (Pt-100) 3-Wire Input The connection for 3-wire RTD (Pt-100) sensor is shown in figure 5. Normally RTD (Pt-100) sensor with 3-wires has two similar color wires and other one distinct color. Connect two similar color wires at ‘-’...
  • Page 15 3.3.1.1.2 Sensor wiring – Thermocouple/mV Input Figure 6- Sensor Wiring – Thermocouple/mV Input Connect the 2-wires of sensor at ‘+’ &’-’ of sensor connector as shown in Figure 7. 3.3.1.1.2 Sensor wiring - 4-20mA / 0-20mA Input Connect the ‘+’ wire at pin-1 and ‘-‘ wire at pin-2 , connect 50 Ω in between ‘+’ and ‘-‘ wires. Figure A...
  • Page 16 3 2 1 Figure 7- Sensor Wiring - 4-20mA / 0-20mA Input The connection for 4-20mA / 0-20mA input is shown in the figure 8(A). For Paperless Recorder, the shunt of 50Ω 0.1% is externally supplied. If you want to connect more than one instrument in series, than recorder should be placed in such a way that not more than 250Ω...
  • Page 17 3.3.1.1.3 Connecting Paperless Recorder with Transmitter and External Power Supply 3 2 1 Figure 8- Connecting Paperless with Transmitter and External Power Supply Connection of Paperless Recorder with Transmitter and External Power Supply is as shown in Figure 9. The shunt of 50Ω is externally supplied. 3.3.1.1.4 Sensor wiring –...
  • Page 18 The Paperless Recorder can relate to PC using TCPIP Interface through GtekNet software developed by G-Tek. For this, RJ-45 connector is given on the back panel of the Paperless Recorder. A Crossover TCPIP Cable is required to connect Paperless Recorder to LAN. The cable...
  • Page 19 MAIN MENU The main menu can be accessed by pressing the three dots on the upper right corner of the screen. By pressing, the following options will be available. Press any one of these options to view or set them. Main menu page header displays path of the current selection.
  • Page 20 4.1 BATCH SETUP 4.1.1 Global Configuration By modifying the global configuration, parameters of all the channels are changed accordingly. Path: Main Menu -> Batch Setup -> Global Config Table 1 Global Configuration parameters Channel Thickness Thickness of channel line in graph - max 10 Type of sensor Choose sensor...
  • Page 21 4.1.2 Channel Configuration Path: Main Menu -> Batch Setup -> Channel Config -> Channel List From channel list, select any channel to modify its channel configuration. Fill the appropriate information in the relevant field to modify channel configuration. Table 2 Additional Channel Configuration parameters Channel Number Auto generated fixed number of channels Channel Tag...
  • Page 22 On clicking button “Update And Next” which will update channel configuration to device and opens next channel Configuration page. On clicking button “Update And Previous” which will update channel configuration to device and opens previous channel Configuration page. Error messages: If mandatory fields are left blank, error will be generated as below.
  • Page 23 Once all the fields are set properly then an alert message appears that ask to confirm the change in the channel settings. Figure 17 Confirmation message for channel configuration Following message is displayed when channel configuration is updated successfully. Figure 18- Channel Configuration Updated message 4.1.3 Output Configuration Note: Current software version does not contain this feature.
  • Page 24 4.1.4 Relay Configuration A relay configuration provides 4 relays. Figure 19 Relay Configuration Each single relay can be configured for multiple channels. There are three type of relay configuration is available Figure 20 Relay Type...
  • Page 25 4.1.4.1 High/Low Relay User can set High and Low value as per requirement. On pressing “Accept” button, the changed values can be saved individually for High/Low value in “List of Channels and setpoint value” Table. Click on “Update and Next” for next relay configuration or click on “Update and previous” for previous relay configuration or click on “Update and Exit”...
  • Page 26 4.1.5 Group A group is a set of device channels which is useful when user wants to see the data in certain order or wants to compare different channels which are in different scanning order. Maximum 6 groups are available. These can neither be added or deleted but can only be modified while batch is not running.
  • Page 27 Modify Group: Select a group from “Group List” page. The above image shows list of groups. User can modify following group information. Table 3 Modify Group parameters Group name Enter group name (maximum length is 10 characters) Channels Select channels (Orange color shows selected channel) On clicking button “Update and Exit”, group information is updated and exit from the group menu Figure 23- Modifying Group...
  • Page 28 If mandatory fields are left blank, an error message will be displayed. Figure 24- Mandatory fields blank error If incorrect values are entered, error messages for invalid fields are displayed. Figure 25- Invalid field value entered error Following message is displayed when group information is updated successfully. Figure 26- Group Information Updated Successfully...
  • Page 29 4.1.6 Create Batch From “Create Batch” page, either manual batch or preconfigured batch can be started. Table 4 Create Batch parameters Column Name Description Batch Name Name of the Batch (allows maximum 50 characters) Time interval at which Batch readings are stored -minimum 5 Store Interval (Seconds) seconds and maximum 18 hours Trend interval of Batch.
  • Page 30 To setup preconfigured batch, fill batch information and click on button setup batch. It will start batch on the set Start time and store data at every store interval. If preconfigured batch is set for Recurring mode than the batch will start and stop every interval mentioned in Start and Stop time.
  • Page 31 Error messages: If mandatory fields are left blank, an error message will be generated. Figure 29- Create Batch Error message for blank fields If incorrect values are entered, error messages for invalid fields are displayed. Figure 30- Create Batch Error for invalid fields entered...
  • Page 32 4.2 SYSTEM SETUP System Setup allows to modify system level setting of paperless device. It allows to 1. Change system language, 2. Take system backup, 3. Restore device to factory calibration 4. Perform channel calibration, 5. Modify communication parameters, 6. Set display brightness, 7.
  • Page 33 On pressing button “French”, system language is changed to French and the following message is displayed. Figure 32- System language successfully changed to French On clicking button “Select RTC”, RTC (Real Time Clock) i.e., time, date and time zone of the device can be changed.
  • Page 34 4.2.2 Back / Restore User can take archive file backup of historical data of batch to USB with file extension “.arc” Path: Menu->System Setup->Backup/ Restore Figure 34 -Backup / Restore menu options...
  • Page 35 4.2.3.1 Bach Backup On batch Backup/Restore page, it displays all historical batches with batch name, batch start and batch stop time. Figure 35- Batch details displayed on Backup / Restore page On pressing button “Export”, user can export historical batch data in archive format to USB device.
  • Page 36 4.2.3.2 Download Logs To download the logs, attach USB pen drive with the device. All the logs regarding paperless activities will export to USB pen drive. Once all the logs will be exported to pen drive, the message will appear as follows: Figure 37 Log downloaded successfully If Pen drive is not attached, then error message will appear as follow: Figure 38 Download log error message...
  • Page 37 4.2.3.3 Configuration Backup User can take backup of the set configuration by this menu. Once USB Pen drive is attached to the Paperless device and then press “Configuration Backup”, the set configuration will be exported to the USB pen drive in the form of folder named as “Configuration File”. Once the backup is exported successfully, then below message will appear: Figure 39 Configuration Backup If the USB pen drive is not attached, then following message will appear:...
  • Page 38 4.2.3.3 Configuration Restore User can restore the previously set configuration, if backup is taken. To restore the configuration, attach USB Pen drive where the “Configuration File” is available and press the “Configuration Restore” on the paperless device. First the message appears, asking for the confirmation as follow: Figure 41 Configuration Restore If the USB pen drive is not attached, then following message will appear: Figure 42 Configuration Restore error message...
  • Page 39 4.2.3.4 Database Backup User can take backup for the whole database of the device from this menu. Attach the USB pen drive to the device, press “Database Backup”. Whole database will be exported to the USB pen drive in the form of folder named as “Database Backup”. Once database is exported to the USB pen drive successfully, then message appears as follow: Figure 43 Database Backup If the USB pen drive is not attached, then following message will appear:...
  • Page 40 4.2.3.5 Database Restore User can restore older database if database backup is taken. To restore the database, attach the USB pen drive where “Database Backup” folder is available. Press “Database Restore” on the paperless device; the following message will appear: Figure 45 Database Restore If the USB pen drive is not attached, then following message will appear: Figure 46 Database restore error message...
  • Page 41 4.2.3 Communication Press on the text block to modify the following network and communication parameters: Table 5 Communication Parameters Host Name Name of Host - Maximum 15 characters (Required) MAC Address MAC Address of Device (Required) DHCP Enable Yes – to enable and No – to disable IP Address Enter valid IP Address of Device (e.g.
  • Page 42 If mandatory fields are left blank, the following error will be generated. Figure 48- Communication configuration error for blank fields If incorrect values are entered, error messages for invalid fields are displayed. Figure 49- Communication Configuration error for invalid field values entered Following message is displayed when Communication configuration is updated successfully.
  • Page 43 Figure 50- Message - Communication Parameters updated successfully 4.2.4 Factory Setting From this menu, user can calibrate channel, touch, restore device, restore configuration and update software. Path: Menu->System Setup-> Factory Setting Figure 51- Factory Settings Menu...
  • Page 44 4.2.4.1 User Calibration If unable to get satisfactory readings, User can perform calibration through “User Calibration” menu: 4.2.4.1.1 RTD Calibration For 3 wire RTD, Connect the red wire of RTD in pin 1 of the connector. Similarly connect the first white wire of RTD in pin 2.
  • Page 45 To perform the calibration for RTD for respected card select 1 channel of that card as calibrate channel, click on “RTD” and apply input as per shown in the message below and click on “next” button: Figure 54 RTD Calibration 20 ohm Figure 55 RTD Calibration 360 ohm...
  • Page 46 If an invalid value is applied, then the error message will appear as follow: Figure 56 Calibration error message for RTD Figure 57 Calibration successful for RTD...
  • Page 47 4.2.4.1.2 mVolt Calibration Connect the 2-wires of sensor at ‘+’ (pin-1 of the connector) & ‘-’ (pin-2 of the connector) of sensor connector as shown in below figure. Figure 58 -Connection for mVolt Calibration To perform the calibration for thermocouple for respected card select 1 channel of that card as calibrate channel, click on “mVolt”...
  • Page 48 Figure 60 Thermocouple 80 mV If invalid input value is applied, then following error message will appear: Figure 61 Calibration error message for mVolt...
  • Page 49 On successful calibration following message will appear: Figure 62 Calibration Successful for mVolt 4.2.4.1.3 Volt Calibration Connect positive (+ve) terminal in 1 pin of the connector and negative (-ve) terminal in 2 of the connector. Figure 63 -Connection for Volt calibration...
  • Page 50 To perform the calibration for Voltage for respected card select 1 channel of that card as calibrate channel, click on “Volt” and apply input as per shown in the message below and click on “next” button: Figure 64 Volt +5 V Figure 65 Volt -5 V...
  • Page 51 If invalid input value is applied, then following error message will appear: Figure 66 Error message for volt calibration On successful calibration following message will appear: Figure 67 Calibration successful for Volt 4.2.4.1.4 mA Calibration Connect positive (+ve) terminal in 1 pin of the connector and negative (-ve) terminal in 2 pin of the connector.
  • Page 52 To perform the calibration for mAmp for respected card select 1 channel of that card as calibrate channel, click on “mA” and apply input as per shown in the message below and click on “next” button: Figure 69 mA 0 Volt Figure 70 mA 1 Volt...
  • Page 53 If invalid input value is applied, then following error message will appear: Figure 71 Error message for mAmp calibration On successful calibration following message will appear: Figure 72 Calibration successful for mAmp...
  • Page 54 4.2.4.2 Factory Calibration Device calibration parameters set by factory. User can restore the device to these factory settings. 4.2.4.3 Configuration Reset Configuration reset execution will reset all the channel configuration to its default value. 4.2.4.4 Factory Reset Factory configurations are wiped off. 4.2.4.5 Software Upgrade Note: Current software version does not contain this feature.
  • Page 55 Figure 74 Wrong password error message On entering proper password, following message will appear for confirmation: Figure 75 Confirmation message for clear memory On pressing “Yes”, again another message will appear for final confirmation as follow: Figure 76 Final confirmation for clear memory On pressing “Yes”, device will restart, and all the databases will be cleared.
  • Page 56 4.3 VIEW DATA It contains information about Audit Trail, Event Summary and Historical Data. Audit trail and event summary module will be available in future versions. In Historical data module, the user can view list of historical batches and view group wise batch data for selected history batch. 4.3.1 Event Summary Note: Current software version does not contain this feature.
  • Page 57 Figure 78 Historical data page On pressing button “Export”, historical batch data can be exported to a USB device in CSV format. The CSV File will be stored in the “Logcontainer” folder. On pressing button “View”, horizontal line graph of selected historical batch can be viewed. On pressing button historical data from “View”...
  • Page 58 The following image shows list of historical batches between start time “23-06-2020 17:58:50” and “23-06-2020 18:39:31”. Figure 79- Historical Data between a time interval On pressing “View”, batch data can be viewed as a Horizontal trend graph, a vertical trend graph or a polar graph.
  • Page 59 Figure 81 Historical Vertical Graph Figure 82 Historical Polar Graph...
  • Page 60 User can see the graph on single page as per selected chart speed. Here chart speed is set to 5 minutes. Each page will show the data of cycle of 5 minutes. To see the data of next cycle or previous cycle, user should have to press the buttons as shown in the below figure.
  • Page 61 Figure 85 Group wise Historical graph User can see the graph for specific channels by skipping the unwanted channel on the legend shown on left side. User should only click on the channels shown on the left side in the legend. to remove from display.
  • Page 62 Figure 86 Skip channel in the historical graph User can insert the mark on the graph for specific time on the graph by clicking on “Marker On” button. Figure 87 Graph marker...
  • Page 63 User can insert a note at specific time for any important event by clicking on the channel when marker is on. Figure 88 Insert operator note...
  • Page 64 5 CURRENT DATA 5.1 H EADER Figure 89 Header All Current data pages have following header. In middle of the header, it shows name of the selected page, name of the selected group and current device RTC. The “Menu” button redirects to the main menu of paperless application. The “Start”/ “Stop” buttons allow to start or stop the current batch.
  • Page 65 Figure 90 -Group menu on current data page On clicking “Channels”, a sliding window which contains all channels within a group is opened. User can enable/disable any of the channels from this sliding window.
  • Page 66 Figure 91- Channel selection menu on current data page By default, all current data pages show last selected group and channels.
  • Page 67 5.2 D IGITAL Digital View page is the default page of paperless application. It shows current data of each channel with channel unit and tag within selected group. Also shows channel color indication as a background color of header of each channel data. Digital View page updates after every 5 second.
  • Page 68 5.3 H ORIZONTAL RAPH Horizontal Bar Graph page shows horizontal bar graph for current channel data. Horizontal Bar Graph page updates after every 5 second. User can select group from bottom panel and select channels. Horizontal Bar Graph page shows only those channels which are selected. Figure 93- Horizontal Bar Graph for current data Horizontal Bar Graph shows current Data vs.
  • Page 69 5.4 V ERTICAL RAPH Vertical Bar Graph page shows vertical bar graph for current channel data. Vertical Bar Graph page updates after every 5 second. User can select group from bottom panel, also selects channels. Vertical Bar Graph page shows only those channels which are selected. Figure 94- Vertical Bar Graph view for current data Vertical Bar Graph shows channels Vs.
  • Page 70 5.5 H ORIZONTAL RAPH This page shows horizontal line graph for current channel data. On the left side, it shows current data of each channel within the selected group. Also, channel color is indicated as a background color of each channel data. Horizontal line graph page updates after every trend interval selected for current batch.
  • Page 71 Horizontal Line Graph shows Time Vs. channel current data. Channel series contains color same as channel color in channel configuration. Y-Axis has auto scaling facility as per minimum and maximum current data for all series. Table 6 Chart Speed Selected V/S Graph Update Rate Chart Speed Selected Graph Update Rate 5 minutes...
  • Page 72 5.6 V ERTICAL RAPH This page shows vertical line graph for current channel data. On the left side, it shows current data of each channel within selected group. Also, channel color is indicated as a background color of each channel data. Vertical line graph page updates after every trend interval selected for current batch.
  • Page 73 5.7 P OLAR RAPH Polar graph is the circular representation (Data vs. Time) of the data with the radial axis indicating data value while the angular axis representing time. Chart Speed set in channel configuration, is the maximum time interval represented in the graph. Figure 97-Online Polar Graph...
  • Page 74 6 DEVICE TOUR This menu is not available in current version.
  • Page 75 7 ABOUT This menu shows the information regarding the company. Figure 98 About Menu...
  • Page 76 8 DEVICE INFORMATION User can see the device information such as, Version no., Product code, Serial No., Display size, Analog input type, No. of analog input channels, Power supply/Transmitter power, Relay, Analog O/P and PC interface. Figure 99 Device Information...
  • Page 77 9 HELP Help regarding the operation of the device, is availble in this menu. Figure 100 Help Menu...
  • Page 78 10 TROUBLESHOOTING GUIDE 1. Problem: At power on, display screen appears blank Solution: a. Check if a working supply cable is connected correctly b. Check Mains supply c. Check if internal LEDs are ON or OFF. Try turning the device OFF and then turn it ON again. 2.
  • Page 79 6.Problem: How to change the System Language? Solution: b. Press on the top-right corner of the screen c. Press d. Select the second option from the main menu e. Then select the first option and system language options will be seen 7.
  • Page 80 11 TECHNICAL SPECIFICATIONS Model No PL700 Series; 7" recorder Product Code* 6xxxxxx-x Display: Display Type: TFT Color LCD Display Size: 7” Viewable Screen: 155mm x 86mm Display Resolution: 800 x 480 pixels Color Resolution: 24 bits Touch Screen: 10 fingers Capacitive Display Screen: Digital View, Bar Chart, Horizontal trend, Vertical trend, Circular Chart, Menus and other user...
  • Page 81 Safety / EMI-EMC: EMI-EMC: IEC 61326-1 Class B Safety: IEC 61010-1 Pollution Degree: Installation Category: Vibration Category: 2g Peak (10Hz – 150Hz) Shock: IEC 61010- 1 IP Rating: IP 65 (Only front Bezel) Power Requirement: Supply Voltage (Mains Operated 85-264 V AC through adapter): 47-63 Hz Power:...
  • Page 82 Analog Output Board: No of Inputs per Board: No of Slots consumed per board: Output type User Settable: mA / Volt Accuracy: ±0.1 % FSR Temperature Drift: ±0.01 % FSR/°C @ 25°C Resolution: 16 bits Step Response: 250 ms (10 – 90%) Output Refresh Rate: 500 ms Self-Diagnostics:...
  • Page 83 Transmitter Output Power: Maximum no of Output: Output Voltage: 24 V DC Max Current: 30 mA Short Circuit: Protected Isolation Output – Earth: 1.5 KVrms 1 minute (IEC 61010-1) Suggested Sensor Input: Suggested Sensor Accuracy At 25°C Sensor Standard Range Error Error% Input Error% Error...
