Smart Response Swing
™
Product features and decorations may vary from picture above.
Accessories sold separately.
Model Number: B0637, B1636, B2108
Please keep this instruction sheet, as it contains important information.
Adult assembly is required.
Tool needed for assembly: Phillips Screwdriver (not included).
Requires four "D" (LR20) alkaline batteries for operation.
Maximum Weight Limit: 24 lbs. (10.9 kg).
IMPORTANT! The maximum weight limit for this product is 24 lbs. If your child weighs
less than 24 lbs., but is really active and appears to be able to climb
out of the swing, immediately discontinue its use.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fisher-Price Smart Response Swing B0637
Summary of Contents for Fisher-Price Smart Response Swing B0637
- Page 1 Smart Response Swing ™ Product features and decorations may vary from picture above. Accessories sold separately. Model Number: B0637, B1636, B2108 Please keep this instruction sheet, as it contains important information. Adult assembly is required. Tool needed for assembly: Phillips Screwdriver (not included). Requires four “D”...
-
Page 2: Warnings And Caution
• To prevent falls, never use with an replacement parts. Please call Fisher-Price® Consumer Relations, toll-free at 1-800-432-KIDS, 8 AM - 6 PM EST active child who may be able to Monday through Friday. - Page 3 Parts 2 Accessory Bins Housing 2 Rear Legs (Shorter) 2 Front Legs (Longer) Motor Housing Toybar (Toys may be different) Front Base Bracket Rear Base Seat with Restraint 2 Seat Tubes 2 Seat Wire Caps Seat Wire Tray M4 Screw - 4 #8 x 1 "...
- Page 4 Assembly IMPORTANT! Before assembly, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price® for replacement parts and instructions if needed. Never substitute parts. Housing...
- Page 5 Assembly Pull Up Pull Up Pull Rear Pull Rear Rear Legs Rear Base • Pull both rear legs out until they “snap” into place. • While standing on the rear base, pull the rear legs up. They should remain secured to the rear base. If you can remove the rear legs, you have not assembled them cor- rectly to the rear base.
- Page 6 Assembly M4 Lock Nut Rounded Side Bracket Grooves Shown Actual Size Tall Lock Nut Seat Tubes Bottom Edge of Seat Hexagonal Opening • Position the bracket so that the tall end is toward the bottom edge of the seat. Seat Hint: The M4 lock nuts have been assembled to the bracket at Tubes the factory.
- Page 7 Assembly Accessory Bin Accessory Bin Seat Wire Grooves Slots #8 x 1 ” Screw - 4 Seat Shown Actual Size • Lift the seat tubes slightly. • With the seat wire hanging down, insert the ends of the seat • Turn the seat face down. wire through the slots in the seat, as shown.
- Page 8 Assembly Elastic Loops Frame Hubs Crotch Belt Holes #8 x 1 ” Screw - 2 Shown Actual Size Seat Bottom • Insert a #8 x 1 " screw through each frame hub and into • Lift the bottom of the pad. the swing tubes.
- Page 9 Assembly Battery Installation and Tips Hint: We recommend using alkaline batteries for longer battery life. ” Screw - 4 #8 x Shown Actual Size Plug Toybar Battery Compartment Door Plug Plug Installation • Locate the battery compartment door on the swing frame. •...
-
Page 10: Securing Your Child
IMPORTANT! Before each use, inspect this product for dam- aged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price® for replacement parts and instructions if needed. Never substitute parts. WARNING... -
Page 11: Adjusting The Seat
Adjusting the Seat Using the Toybar Toybar Semi-Recline Upright Recline Adjust the seat angle in any of three positions: Upright, Semi-Recline or Recline. To adjust the seat angle: • Push down on the seat back to position the seat wire in the desired groove in the bracket for Upright, Semi-Recline or Recline. - Page 12 Swing Modes The Smart Response Swing has two modes: Baby Sounds Activated and Parent Activated Baby Sounds Activated Parent Activated IMPORTANT! The maximum weight limit for this product is 24 lbs. If your child weighs less than 24 lbs., but is really active and appears to be able to climb out of the swing, immediately discontinue its use.
- Page 13 Baby Sounds Activated Speed Dial Sound Sensitivity Dial Power L.E.D. Swing Mode Switch Music/Volume Switch Sound Sensitivity Dial Swing Mode Switch • Slide the switch to high sensitivity for incoming • Slide the switch to baby sounds activated. The sounds (listens for shallow sounds). power L.E.D.
- Page 14 Parent Activated Power L.E.D. Swing Mode Switch Speed Dial Music/Volume Switch Swing Mode Switch Music/Volume Switch • Slide the switch to parent activated. The power L.E.D. • Select for music highest volume. lights and the swing begins swinging. • Select for music high volume.
- Page 15 Storage Care The pad is machine washable. Wash the pad separately in cold water on the gentle cycle. Do not use bleach. Tumble dry separately on low heat and remove promptly. The frame, tray, and toybar may be wiped clean using a mild cleaning solution and a damp cloth.
-
Page 16: One (1) Year Limited Warranty
Richmond, Victoria 3121 Australia. Consumer Advisory Service 1300 135 312. New Zealand: 16-18 William Pickering Drive, Albany 1331, Auckland. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. Printed in China ©2002 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
