Fisher-Price B8869 Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
B8869
www.fisher-price.com/uk
Product features and decorations may vary from photo above.
WARNING
IMPORTANT! KEEP INSTRUCTIONS FOR
FUTURE REFERENCE.
Please read these instructions before assembly and use of this product.
Adult assembly is required.
Tool needed for battery installation: Phillips Screwdriver (not included).
Requires four LR14 ("C") alkaline batteries for operation (not included).
Weight Limit: 9 kg (20 lbs).
IMPORTANT! The maximum weight limit for this product is 9 kg (20 lbs).
If your child weighs less than 9 kg (20 lbs), but is really active and appears
to be able to climb out of the swing, immediately discontinue its use.

Advertisement

loading

Related Manuals for Fisher-Price B8869

Summary of Contents for Fisher-Price B8869

  • Page 1 B8869 www.fisher-price.com/uk Product features and decorations may vary from photo above. WARNING IMPORTANT! KEEP INSTRUCTIONS FOR FUTURE REFERENCE. Please read these instructions before assembly and use of this product. Adult assembly is required. Tool needed for battery installation: Phillips Screwdriver (not included).
  • Page 2 Warnings WARNING To prevent serious injury or death from falls and being strangled in the restraint system: • Always use the restraint system. • Not recommended for children who can sit up by themselves (6 months approximately, until 9 kg/20 lbs). •...
  • Page 3 Parts Frame with Liner Pad with Restraint Front Tube 2 Frame Tubes...
  • Page 4 Assembly IMPORTANT! Before assembly, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing, damaged or broken. Contact Mattel for replacement parts and instructions if needed. Never substitute parts. Upper Frame Tube...
  • Page 5 Assembly Frame with Liner Press Button on Upper Frame Tube • Position the frame with liner so that the seat is over the front tube. • While pressing the buttons on the upper frame tubes, insert them into the holes in the underside of the frame with liner. •...
  • Page 6 Assembly Upper Frame Upper Tube Frame Tube...
  • Page 7 Assembly Waist Belts Slot Slot...

  • Page 8: Battery Installation

    Battery Installation Battery Battery Compartment Holder Door • Locate the battery compartment door on the frame. • Loosen the screw in the battery compartment door with a Phillips screwdriver. • Remove the battery compartment door and the battery holder from the battery compartment.
  • Page 9 Battery Installation Battery Battery Holder Compartment Door • Align the ridge on the battery holder with the groove in the battery compartment. • Slide the battery holder back into the battery compartment. • Replace the battery compartment door and tighten the screw with a Phillips screwdriver.

  • Page 10: Battery Safety Information

    Battery Safety Information 1.5V x 4 LR14 ("C") SHOWN ACTUAL SIZE In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: • Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).

  • Page 11: Securing Your Child

    Securing Your Child Restraint Waist Waist Belt Belt...
  • Page 12 Securing Your Child Free End Free End Anchored Anchored End Tighten Loosen To tighten the restraint: • Feed the anchored end of the restraint belt up through the buckle to form a loop • Pull the free end of the restraint belt •...
  • Page 13 Starting the Swing IMPORTANT! Before each use, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing, damaged or broken. Contact Mattel for replacement parts and instructions if needed. Never substitute parts. Power Dial Power Dial •...
  • Page 14 Lights and Music! Hint: Your baby can enjoy lights and music with or without swinging. Baby Activated Parent Activated Lights and Volume Dial Lights and Music Switch Music Switch • Slide the lights and music switch to: baby activated lights and one song ;...
  • Page 15 Take-Along Seat Bottom...
  • Page 16 Take-Along Strap Seat Back Press Tab Press Tab • Tip the swing backwards the seat back down. • Unfasten the straps on the seat bottom. • Pull the straps from the loops on the seat bottom. • Press both tabs on the frame at the same time to release the frame base.
  • Page 17 Take-Along Lower Frame Tube...
  • Page 18 Take-Along Upper Frame Tube Strap Lower Frame Tube • Fit the straps on the seat bottom between the upper and lower frame tubes, as shown. • Wrap the straps around the lower frame tubes and fasten the straps. To set the swing back up for use: •...
  • Page 19 Care • The pad, frame, liner and toys may be wiped clean using a mild cleaning solution and a damp cloth. Do not immerse the frame. • This product has no consumer serviceable parts. Do not take this product apart. Pad Seat Back Pocket...

  • Page 20: Consumer Information

    Floor, Menara Lien Hoe, Persiaran Tropicana Golf Country Resort, 47410 PJ. Tel: 03-78803817, Fax: 03-78803867. B8869a-0726 Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. ©2005 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. PRINTED IN CHINA...
