  • Page 1 Operator's 2008-01 Manual O0802007 Tiller 650 RTT 96093000202 Operator's Manual...

  • Page 2: Safety Rules

    SAFETY RULES Safe Operation Practices for Walk-Behind Powered Ro ta ry Tillers TRAINING • Keep children and pets away. • Do not overload the machine capacity by attempting • Read the Owner’s Manual care ful ly. Be thor ough ly to till too deep at too fast a rate.

  • Page 3: Table Of Contents

    PRODUCT SPECIFICATIONS CUSTOMER RESPONSIBILITIES • Read and observe the safety rules. Gasoline Capacity: 3 Quarts • Follow a regular schedule in maintaining, caring for Unleaded Reg u lar and using your tiller. OIL (API-SG-SL): SAE 30 (Above 40°F) • Follow instructions under “Maintenance” and “Stor age” (Capacity 20 oz./0.6L) SAE 5W-30/10W30 sections of this Owner’s Manual.

  • Page 4: Assembly

    ASSEMBLY Your new tiller has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tiller all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness.
  • Page 5 ASSEMBLY UNPACKING CARTON (See Fig. 2) • Grasp handle assembly. Hold in “up” position. Be sure handle lock remains in gearcase notch. Slide handle assembly into position. CAUTION: Be careful of exposed sta ples when handling or disposing of cartoning material. HANDLE ASSEMBLY "UP"...
  • Page 6 ASSEMBLY CONNECT SHIFT ROD (See Fig. 7) ATTACH CLUTCH CABLE (See Fig. 6) • Insert end of shift rod into hole of shift lever indicator. • Hook end of clutch cable through hole in control bar bracket. • Insert hairpin clip through hole of shift rod to secure. CONTROL BAR SHIFT HAIRPIN...

  • Page 7: Know Your Tiller

    OPERATION KNOW YOUR TILLER READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TILLER. Compare the illustrations with your tiller to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your Tiller or in literature supplied with the product. Learn and understand their meaning.
  • Page 8 OPERATION The operation of any tiller can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields before starting your tiller and while tilling. We recommend a wide vision safety mask for over spectacles or standard safety glasses.

  • Page 9: Before Starting Engine

    OPERATION • When you have completed your turn-around, release the drive control bar and lower handle. Place shift lever in till position and move throttle control to de sired LEVEL speed. To begin tilling, hold drive control bar against the handle. OUTER SIDE SHIELDS (See Fig.

  • Page 10: Tine Shear Pins

    OPERATION • Turn fuel shut-off valve 1/4 turn to open position. • Move choke control to choke position. • Grasp recoil starter handle with one hand and grasp tiller handle with other hand. Pull rope out slowly until engine reaches start of com pres sion cycle (rope will pull slightly harder at this point).

  • Page 11: Maintenance Schedule

    MAINTENANCE MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE SERVICE DATES REGULAR SERVICE Check Engine Oil Level Change Engine Oil Oil Pivot Points Inspect Spark Arrester / Muffler Inspect Air Screen Clean or Replace Air Cleaner Cartridge Clean Engine Cylinder Fins Replace Spark Plug RH Gear Case Grease Fitting (1oz.) 1 - Change more often when operating under a heavy load or in high ambient temperatures.

  • Page 12: Engine Lubrication

    MAINTENANCE Disconnect spark plug wire before performing any maintenance (except car bu re tor adjustment) to prevent accidental start ing of engine. Prevent fires! Keep the engine free of grass, leaves, spilled oil, or fuel. Re move fuel from tank before tipping unit for maintenance.
  • Page 13 MAINTENANCE MUFFLER Do not operate tiller without muffler. Do not tamper with COVER exhaust system. Damaged mufflers or spark arresters could create a fire hazard. Inspect pe ri odi cally and re place if nec es sary. If your engine is equipped with a spark arrester screen assembly, re move every 50 hours for cleaning and inspection.

  • Page 14: Service & Adjustments

    SERVICE AND ADJUSTMENTS CAUTION: Disconnect spark plug wire from spark plug and place wire where it cannot come into contact with plug. TILLER CLEVIS TO ADJUST HANDLE HEIGHT (See Fig. 20) Select handle height best suited for your tilling conditions. Handle height will be different when tiller digs into soil.
  • Page 15 SERVICE AND ADJUSTMENTS TO REPLACE GROUND DRIVE BELT GROUND DRIVE BELT ADJUSTMENT (See Fig. 23) (See Fig. 23) • Remove belt guard (See “TO REMOVE BELT GUARD” For proper belt tension, the extension spring should in this section of this manual). have about 5/8 inch stretch when drive control bar is in •...

  • Page 16: Tine Replacement

    SERVICE AND ADJUSTMENTS TINE REPLACEMENT • To maintain the superb tilling performance of this ma chine the tines should be checked for sharpness, (See Figs. 24, 25, and 26) wear, and bending, particularly the tines which are next to the transmission. If the gap between the tines CAUTION: Tines are sharp.
  • Page 17 SERVICE AND ADJUSTMENTS ENGINE TO AD JUST CARBURETOR The carburetor has been preset at the factory and ad just ment TO ADJUST THROTTLE CONTROL CABLE should not be necessary. However, engine per for mance (See Fig. 27) can be affected by dif fer enc es in fuel, tem per a ture, al ti tude or load.

  • Page 18: Engine Fuel System

    STORAGE Immediately prepare your tiller for storage at the end of the ENGINE OIL season or if the unit will not be used for 30 days or more. Drain oil (with engine warm) and replace with clean oil. (See “ENGINE” in the Maintenance section of this man ual). WARNING: Never store the tiller with gasoline in the tank inside a build ing CYLINDER(S)

  • Page 19: Troubleshooting

    TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION Will not start 1. Out of fuel. 1. Fill fuel tank. 2. Engine not “CHOKED” properly. 2. See “TO START ENGINE” in Operation section. 3. Engine flooded. 3. Wait several minutes before attempting to start. 4.

  • Page 20: Repair Parts-Tiller

    REPAIR PARTS TILLER - - MODEL NUMBER 650RTT (96093000202), PRODUCT NUMBER 960 93 00-02 HANDLE ASSEMBLY 12 13 Handle_assy_99_19 PART PART DESCRIPTION DESCRIPTION 532 18 11-27 Handle 532 18 94-82 Control, Throttle 532 08 67-77 Screw, Hex Washer SLT#10-24 x .50 532 16 57-87 Grip, Handle 532 15 92-28 Bar Assembly, Control 532 00 94-84 Clip...
  • Page 21 REPAIR PARTS TILLER - - MODEL NUMBER 650RTT (96093000202), PRODUCT NUMBER 960 93 00-02 MAINFRAME, LEFT SIDE PART PART DESCRIPTION DESCRIPTION 873 22 06-00 Nut, Hex 3/8-16 532 16 67-92 Guard, Belt 532 17 01-27 Shield, Inner Belt Guard RT 532 13 28-01 Belt, V 532 16 43-29 Pin Spirol Flared 532 10 46-79 Pulley, Idler...
  • Page 22 REPAIR PARTS TILLER - - MODEL NUMBER 650RTT (96093000202), PRODUCT NUMBER 960 93 00-02 MAINFRAME, RIGHT SIDE PART PART DESCRIPTION DESCRIPTION 873 97 05-00 Locknut, Hex, Flange 5/16-18 - - - - - - - - Engine, Briggs & Stratton 532 10 23-32 Bracket, Reinforcement RH Model No.
  • Page 23 REPAIR PARTS TILLER - - MODEL NUMBER 650RTT (96093000202), PRODUCT NUMBER 960 93 00-02 TRANSMISSION 13 15 18 32 transmission_19.5b PART PART DESCRIPTION DESCRIPTION 532 18 85-54 Transmission Assembly 532 10 21-34 Chain #35-50 Pitch (In cludes Key Nos. 2-53) 532 15 07-37 Ground Shaft Assembly 532 18 84-82 Gearcase, L.H.
  • Page 24 REPAIR PARTS TILLER - - MODEL NUMBER 650RTT (96093000202), PRODUCT NUMBER 960 93 00-02 TINE SHIELD PART PART DESCRIPTION DESCRIPTION 873 90 05-00 Nut, Lock Hex Flange 5/16-18 874 93 06-32 Bolt, Hex 3/8-16 x 2 532 16 29-52 Shield, Side, Outer L. H. 532 00 44-40 Hinge 532 00 83-93 Pin, Stake, Depth 872 14 04-04 Bolt, Carriage 1/4-20 x 1/2 Gr.
  • Page 25 REPAIR PARTS TILLER - - MODEL NUMBER 650RTT (96093000202), PRODUCT NUMBER 960 93 00-02 TINE ASSEMBLY tine_ipb_1 PART PART DESCRIPTION DESCRIPTION 532 00 44-59 Tine, Outer, L.H. 532 13 27-28 Assembly, Hub and Plate, R.H. 532 13 26-73 Clevis Pin 532 00 65-55 Tine, Inner, R.H.
  • Page 26 DECALS PART DESCRIPTION 532 41 83-94 Decal, Belt Guard 532 41 83-98 Decal, Husqvarna, Control Panel 532 18 08-13 Decal, Control Tine 532 41 84-73 Decal, Tine Shield 532 11 06-14 Decal, Hand Placement 532 10 21-80 Decal, Shift Indicator 532 16 23-84 Decal, Warning 532 40 91-40 Decal, Engine, 8.5...
  • Page 27 Rental Warranty: 90 days on all applicable professional equipment reference warranty time period charts mailed to Husqvarna Forest & Garden Company. This card should be mailed within ten (10) days from the date of purchase located in the back of the Retailer Warranty Policy & Procedure Manual.

  • Page 28: Service Notes

    SERVICE NOTES...
  • Page 29 532 41 81-65 11.29.07 CL Printed in U.S.A.
