Thank you for purchasing the Panasonic KX-T7737 Proprietary Telephone.
Please read this manual before using and save for future reference.
This product can be used with a Panasonic KX-TA624/KX-TA824/KX-
TAW848/KX-TDA series PBX.
Included Accessories: (for extra orders, call toll free 1-800-332-5368)
Handset . . . . . . . . . . . . . . . 1
Overlay . . . . . . . . . . . . . . . . 1
Quick Reference Guide

Table of Contents

Operation for KX-TA624/TA824......................... 2
Location of Controls..........................................14
Before Operating the Telephone...................... 16
Tilt Angle............................................................ 17
Connection......................................................... 18
Wall Mounting.................................................... 18
Important Information....................................... 19
Important Safety Instructions.......................... 20
FCC Information................................................ 21
Other Information.............................................. 23
Proprietary Telephone
KX-T7737
Model No.
Handset Cord . . . . . . . . . 1
Stand . . . . . . . . . . . . . . . . 1

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-T7737

Summary of Contents for Panasonic KX-T7737

  • Page 1: Table Of Contents

    Important Safety Instructions......20 FCC Information..........21 Other Information..........23 Thank you for purchasing the Panasonic KX-T7737 Proprietary Telephone. Please read this manual before using and save for future reference. This product can be used with a Panasonic KX-TA624/KX-TA824/KX- TAW848/KX-TDA series PBX.

  • Page 2: Operation For Kx-Ta624/Ta824

    Operation for KX-TA624/TA824 Outside (CO) Line button Programmable Feature button Feature number * "Location of Controls" is shown on pages 14-15. Off-hook On-hook Talk Operation Desired Feature Making Calls To an extension To an external party Calling extension no. phone no. Redial To program desired no.
  • Page 3 Operation for KX-TA624/TA824 Operation Desired Feature When the Dialed Extension is Busy/No Answer To set To call Automatic While hearing a busy tone If you hear callback ringing Callback Busy To leave a notification Sender To cancel a notification receiver's extension no. Message Waiting To call back...
  • Page 4 Operation for KX-TA624/TA824 Operation Desired Feature During a Conversation Holding To retrieve a call at the holding extension Holding a call To retrieve an outside call from another extension Holding Holding a call exclusively To retrieve a call on exclusive hold Screened To an extension extension no.
  • Page 5 Operation for KX-TA624/TA824 Operation Desired Feature Useful Features Three-party third party's no. conference To set parameter message no. (if required) Setting Absent Message To cancel For Log-in Log-in/Log-out For Log-out All calls extension no. Busy/No answer extension no. To an outside line line access phone no.
  • Page 6 Operation for KX-TA624/TA824 Operation Desired Feature Useful Features Do Not Disturb (DND) Cancel (Lock code is 4 digits.) Locking your Lock lock code lock code extension Unlock lock code Clearing the setting...
  • Page 7 Operation for KX-TA624/TA824 Operation Desired Feature To Make Use of Voice Mail Service KX-TVA series Listen to Message Extension No. of the VPS From your Deliver Message Password Mailbox Management Extension If you have no password, you can Automated Attendant skip the last step.

  • Page 8: Operation For Kx-Taw848/Tda Series

    Operation for KX-TAW848/TDA Series Outside (CO) Line button Programmable Feature button Feature number * "Location of Controls" is shown on pages 14-15. Off-hook On-hook Talk Operation Desired Feature Making Calls To an extension To an external party Calling phone no. extension no.
  • Page 9 Operation for KX-TAW848/TDA Series Operation Desired Feature When the Dialed Extension is Busy/No Answer To set To call Automatic While hearing a busy tone If you hear callback ringing Callback Busy To leave a notification Sender To cancel a notification receiver's extension no.
  • Page 10 Operation for KX-TAW848/TDA Series Operation Desired Feature During a Conversation Holding To retrieve a call at the holding extension Holding a call To retrieve an outside call from another extension Holding Holding a call exclusively To retrieve a call on exclusive hold Screened To an extension extension no.
  • Page 11 Operation for KX-TAW848/TDA Series Operation Desired Feature Useful Features Three-party third party's no. conference To set parameter message no. (if required) Setting Absent Message To cancel ICD Group* Specified For Log-in extension no. Log-in/Log-out For Log-out *ICD Group: Incoming Call Distribution Group Both calls Outside calls Intercom calls...
  • Page 12 Operation for KX-TAW848/TDA Series Operation Desired Feature Useful Features Both calls Do Not Disturb Outside calls (DND) Cancel Intercom calls Setting your extension PIN To set (Personal same extension PIN Identification extension PIN Number) To cancel stored extension PIN Locking your Lock extension Unlock...
  • Page 13 Operation for KX-TAW848/TDA Series Operation Desired Feature To Make Use of Voice Mail Service KX-TVA series Listen to Message Extension No. of the VPS From your Deliver Message Password Mailbox Management Extension If you have no password, you can Automated Attendant skip the last step.

  • Page 14: Location Of Controls

    Location of Controls TALK CID RINGER BACKLIGHT RINGER Volume/BACKLIGHT LCD (Liquid Crystal Display) with Backlight Illumination/Talking Caller ID Selector Microphone Headset Jack The use of a headset is optional. Recommended headsets are KX-TCA91 and KX-TCA92.
  • Page 15 Location of Controls PROGRAM: Used to enter and exit the SP-PHONE: Used for the hands-free operation. programming mode. CONF (Conference): Used to establish a NAVIGATOR KEY: Used to adjust the multiple party conversation. volume and the display contrast, or select desired items.

  • Page 16: Before Operating The Telephone

    Before Operating the Telephone Speaker/Handset/Headset volume * Speaker volume While in hands-free conversation Handset/Headset volume Press Up or Down. While using the handset or headset Ringer volume/Backlight illumination BACKLIGHT RINGER Slide the lever of the RINGER Volume Selector and BACKLIGHT Illumination Selector to the desired setting. BACKLIGHT SW POSITION LCD backlight HIGH...

  • Page 17: Tilt Angle

    Before Operating the Telephone Talking Caller ID You can hear Caller ID information vocally sent from your PBX through the built-in speaker. The voice volume of Talking Caller ID depends on the setting of the Ringer volume. For the Ringer volume, refer to "Ringer volume" on page 16. TALK CID Slide the TALK CID Selector to ON to enable the Talking Caller ID feature.

  • Page 18: Connection

    Connection TO MAIN UNIT To the main unit ( The telephone line cord /PABX (included) Headset < Back view > Disable the parallel setting for the single line CAUTION telephone (SLT) in PBX programming. If it is enabled, Ensure the cord is the Talking Caller ID feature may not operate properly.

  • Page 19: Important Information

    DO NOT send the product to the Executive or Regional Sales offices. They are NOT equipped to make repairs. Product service: Panasonic Servicenters for this product are listed in the servicenter directory. Consult your certified Panasonic dealer for detailed instructions. For your future reference DATE OF PURCHASE SERIAL NO.

  • Page 20: Important Safety Instructions

    Important Safety Instructions When using this unit, basic safety 11. Unplug this unit from the main unit precautions, including those below, should and have the unit serviced by always be followed to reduce the risk of qualified service personnel in the fire, electric shock and injury to persons.

  • Page 21: Fcc Information

    FCC Part 68 Approved Device: This equipment is approved under FCC Part 68 as a component device for use with a Panasonic KX-TA624/KX-TA824/KX-TAW848/KX-TDA series PBX. In order for approval of this product to be valid, all other products used in conjunction with this product must also be FCC Part 68 approved as a component device for use with the PBXs listed above.
  • Page 22 FCC Information If the telephone service provider requests the approval number and REN of the device you are connecting, supply the FCC registration or "US" numbers for all components and host devices that have a direct PSTN connection and the highest REN. If at any time the ownership of this component device is transferred to someone else (whether independently or as part of a system), supply this manual to the new owner.

  • Page 23: Other Information

    • If you are having problems making calls, unplug the extension and connect a known working telephone. If the known working telephone operates properly, have the defective telephone repaired by an authorized Panasonic Factory Servicenter. If the known working telephone does not operate properly, check the PBX System and the internal extension wiring.
  • Page 24 Puerto Rico 00985 http://www.panasonic.com/csd Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd.
