GT SONIC-S SERIES ULTRASONIC CLEANER
USER MANUAL
Thank you for purchasing GT SONIC ultrasonic cleaner. Please take
the time to read these operating instructions before use and retain
them for future reference. Failure to follow these instructions may
lead to serious personal injury and damage to property.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S2 and is the answer not in the manual?

Questions and answers

Related Manuals for GT SONIC S2

Summary of Contents for GT SONIC S2

  • Page 1 GT SONIC-S SERIES ULTRASONIC CLEANER USER MANUAL Thank you for purchasing GT SONIC ultrasonic cleaner. Please take the time to read these operating instructions before use and retain them for future reference. Failure to follow these instructions may lead to serious personal injury and damage to property.
  • Page 2 Content 01.Overview /Scope of Delivery 02.Safety Instructions 03.Applications 04.Introduction 9 -11 05.Operation 11 -13 06.Care and maintenance 13-14 07.Specifications 01. OVERVIEW/SCOPE OF operation Note:Check that all accessories are included and undamaged. C:Warning marking D: Housing A : Lid B:Handles E: Drain tap F: Controlpanel G:Rubber feet H: Louver...
  • Page 3 Contents: a: Main machine c: Power cord b: Soundproof lid d: Outlet filter e: Mesh basket f: User manual available for 6L-9L...

  • Page 4: Safety Instructions

    02. SAFETY INSTRUCTIONS Intended use The cleaner can be used for commercial purposes & indoors only. Possible misuse The cleaner must only be used according to the purposes described in these instructions. DANGER for children This cleaner is not intended to use by individuals with restricted physical sensory or metal capacities or those with lack of experience or knowledge including children, unless they are supervised by an Individual who is responsible for their safety or has received training in...
  • Page 5 DANGER of electric shock Do not operate the cleaner if it or the cable shows visible signs of damage or if the cleaner has been dropped. Only connect the mains plug to a properly installed socket which is easily accessible and supplies voltage matching the rating plate. The socket must still be easily accessible after connection.
  • Page 6 DANGER of electric shock as a result of moisture Do not use this cleaner if it is in the vicinity of bathtubs, showers, washbasins or other vessels containing water. Never put the cleaner down in such a way that it could fall into water. Protect the cleaner from moisture, dripping water or splashing water.
  • Page 7 Do not ever use alcohol ,gasoline or flammable solutions. Doing so can cause a fire or explosion and will avoid your warranty. Only use non-flammable and water-based solutions.
  • Page 8 WARNING - To prevent damage to the cleaner Do not operate the cleaner when the tank is empty. Dry running will damage the cleaner. When filling the tank always ensure that the water is past ½ way of tank and do not exceeded the max fill line at the top of the tank. Do not place parts or containers directly on the bottom of the tank.
  • Page 9 03. Application Examples below are of items that are suitable for ultrasonic cleaning Jewellery especially gold, silver & platinum Laboratory Glassware Hospital, Medical & Dental Instruments Beauty & Nail Tools Automotive and motor parts Metal parts Industrial parts and tools Laser Components Electronic Boards The list is almost endless as to possible uses provided the product is non-...
  • Page 10 Examples of items not suitable for ultrasonic cleaning: Soft Jewellery: Pearls, emerald, ivory, coral. Agate, sea turtle shells, etc. Welded, Plated and Glued Items: Welded or plated metal items, glued items. Watches: Except diver’s watches with depth rating over 50m(150ft). Others: Ceramic, camera filters with preexisting cracks.
  • Page 11 A: Display for temperature. B: Display for cleaning time C: Heating button: Touch this button to start/stop heating. (Note: A new machine will display the ambient temperature on first time use.) D: Increase Temperature: Touch this button to set the temperature. Touch one time to increase 1 , holding the button will increase by 10 E: Reduce Temperature: Touch this button to set the temperature.

  • Page 12: Operation

    05. OPERATION Step Action Fill the tank at least half way. Follow manufacturers instruction for dilution if using a detergent solution. Do not exceed the max fill line at the top. Note: Do not ever use alcohol, gasoline or flammable solutions.
  • Page 13 Touch heating button to start/stop heating. Touch to set the required temperature. Note: 1. To get the best cleaning result, the temperature we suggest is 40-60℃. Heating 2. When setting the temperature if the set temperature exceeds the ambient temperature, touch the key.

  • Page 14: Care And Maintenance

    After timer and temperature are set and the degas cycle run, Touch “ultrasonic” key, Ultrasonic Mode the corresponding indicator will light up and the device will work continuously with full ultrasonic power until the timer countdown reaches 00:00. When the cleaning is completed, unplug the power cord, open the lid and take out the basket and items.

  • Page 15: Specifications

    Tank Size Ultrasonic Power Heating Power Heating Temperature Unit Size Volume Timer Model (L*W*H)mm (kHz) (Min) (L*W*H)mm GT SONIC-S2 150x140x100 175x165x230 1-99 30-80 1-99 30-80 GT SONIC-S3 240x140x100 330x165x230 GT SONIC-S6 300x150x150 400x175x305 1-99 30-80 GT SONIC-S9300x235x150 400x265x305 1-99 30-80...

This manual is also suitable for:

S3S6S9
