INSTRUCTION MANUAL
E.P.P FOAM SPORT TRAINER
Specifications
Wingspan ___________________________ 52 inches, 132cm
Wing area _____________________________ 520 sq. inches
Wing section ________________________ PN1 (symmetrical)
Approximate flying weight ______________ 64 ounces, 1800g
Recommended R/C __________________ 4 channel minimum
Flying skill level ________________________ Beginner/expert
Channels _________________ Aileron/elevator/rudder/throttle
Kit features
Composite construction aileron trainer for beginner/expert
�
E.P.P foam and glass-reinforced covering (included) is almost indestructible
�
Survives punishment like no other plane
�
Modern composite wing with special PN1
�
Ideal for first time flyers and practising new manoeuvres
�
Wing section developed specially to produce soft and predictable stall characteristics
�
E.P.P Foam Sport Trainer
BASH IT ,
SMACK IT ,
BUMP IT &
CRASH IT ............
section gives outstanding low speed flyability
UNBUST BLE!
A
Additional items required
4 Channel or greater Radio Control system (with 5 standard
size servos & 1 Y-lead)
.20 - .40 cu. ins. size engine (up to .53 cu. ins. can be used by
expert flyers)
Quick-setting epoxy
Standard modelling tools
Made in England
