- Page 1 Friteuse à zone froide TF3 Manuel d’utilisation Kaltzonenfriteuse TF3 Bedienungsanleitung Cold-zone fryer TF3 User manual Freidoras TF3 Instrucciones Ed. 03/2022 Manuel original/Originalbetriebsanleitung /Original manual ©Valentine Fabrique SA,2022...
- Page 2 Description de l’appareil Gerätebeschreibung Description of the appliance Descripción del aparato 1 Interrupteur-thermostat Thermostatschalter Switch and Thermostat Interruptor-termostato 2 Témoin de marche (blanc) Kontrolleuchte Betrieb Control lamp power Piloto blanco (weiss) (white) 3 Témoin de chauffe (jaune) Kontrolleuchte Heizen Control lamp for heating Piloto naranja (gelb) (yellow)
- Page 3 Welcome - Safety Congratulations on your purchase of a Valentine fryer, a product of the best quality well known in Europe for over 60 years. This product will work optimally for many years if you respect a few basic rules outlined in this manual.
- Page 4 Commissioning Remove all remaining protective · plastic sheets. Clean the tank and heater [8] · with warm, soapy water then dry well. è see section "maintenance" Safety switch: Once the heating element is raised more than 5 mm, the safety switch is activat- ed and interrupts the current.
- Page 5 Cooking Starting è The white control lamp [2] lights up Turn the knob of the switch thermostat [1] to è The yellow lamp [3] lights up the required temperature, for example 180 As soon as the yellow lamp [3] goes off, im- è...
- Page 6 Changing the oil and maintenance It is highly recommended that you thoroughly clean the fryer when you change the oil. Oil must be changed as soon as it turns brown or when you notice an accumula- tion of water and/or residues on the bottom of the tank. Never change the oil when it is still hot.
-
Page 7: Troubleshooting
Troubleshooting Valentine TF3 fryers are fitted with a safety thermostat. These safety thermostats are placed in the heater housing at the back of the fryer. The red reset button [6] is apparent underneath the housing. It is triggered when the oil temperature exceeds 230°C or in case there is no oil in the fryer To reset the thermostat: ·... -
Page 8: Spare Parts
Orange control lamp B0060-02 230V Working thermostat A0040-14 1P 16A 230V Safety thermostat A0040-51 1P 16A 230V Button A0090-10 Corps de chauffe Heating element TF3 230V A0330-01 230V 2300W Heating element TF3 230V A0330-02 230V 3000W Paniers Basket TF3 A5580-02 155/235/108... - Page 9 Caractéristiques techniques et pièces détachées Technische Daten und Ersatzteile Technical specifications and spare parts Características técnicas 230V 50/60Hz Raccordement Anschluss Mains connection Conexión Puissance / cou- Leistung / Strom Power Current Potencia Cor- rant max riente max Modèle CH CH Modell CH model Modelo CH 2.3kW / 10A...
-
Page 10: Declaration Of Conformity
Declaration of conformity We, the manufacturer Valentine Fabrique SA Z.I. Moulin du Choc E CH - 1122 Romanel-sur-Morges Phone: +41 21 637 37 40 E-mail : info@valentine.ch Website : www.valentine.ch confirms that the above-mentioned products comply with the following standards:... - Page 11 Valentine Fabrique SA Z.I. Moulin du Choc E CH - 1122 Romanel-sur-Morges T +41 21 637 37 40 info@valentine.ch www.valentine.ch Ed. 03/2022 Manuel original/Originalbetriebsanleitung /Original manual ©Valentine Fabrique SA,2022...
