Page 1: Table Of Contents
RS232 Protocol Function List .... 49 Remote Control ........10 Ceiling Mount Installation ....52 Installation ........11 Optoma Global Offices .....53 Connecting the Projector ....11 Regulation & Safety Notices .....55 Connect to Computer/Notebook ..11 Connect to Video Sources ....12 Powering On/Off the Projector ..13...
Page 2: Usage Notice
Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. 7. Do not let objects or liquids enter the projector. They may touch dangerous voltage points and short out parts that could result in fire or electric shock.
Page 3: Precautions
Usage Notice Precautions Please follow all warnings, precautions and maintenance as recommended in this user’s guide. ▀■ Warning- Do not look into the projector’s lens when the lamp is on. The bright light may hurt and damage your eyes. ▀■ Warning- To reduce the risk of fire or electric shock, do not expose this projector to rain or moisture.
Page 4 Usage Notice  Turn off and unplug the power plug from the AC outlet before cleaning the product.  Use a soft dry cloth with mild detergent to clean the display housing. Disconnect the power plug from AC outlet if the product is ...
Page 5: Eye Safety Warnings
Usage Notice Eye Safety Warnings ▀■ Avoid staring/facing directly into the projector beam at all times. Keep your back to the beam as much as possible. ▀■ When projector is used in a classroom, adequately supervise students when they are asked to point out something on the screen.
Page 6: Introduction
Introduction Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact your nearest customer service center. VGA Cable 1.8m Projector with lens cap Power Cord 1.8m Overscan HDMI  Due to different...
Page 7: Product Overview
Introduction Product Overview Main Unit 1. Control Panel 6. Security Bar 2. Focus Ring 7. Input / Output 3. Lens Connections 4. IR Receivers 8. Power Socket 5. Tilt-Adjustment Feet English...
Page 8: Control Panel
Introduction Control Panel 1. AV Mute 2. Menu 3. Source 4. Enter 5. Re-Sync 6. Power 7. Keystone Correction 8. Four Directional Select Keys 9. On/Standby LED 10. Lamp LED 11. Temp LED 12. IR Receiver English...
Page 9: Input/Output Connections
Introduction Input/Output Connections VGA-IN / YPbPr / S-VIDEO VIDEO AUDIO-OUT RS-232 RCA-L RCA-R HDMI HDMI Connector (For WXGA only) 2. VGA-In/YPbPr/ Connector (PC Analog Signal/Component Video Input/HDTV/YPbPr/ Wireless Dongle) 3. S-Video Input Connector 4. Composite Video Input Connector 5. Audio Output Connector (3.5mm Mini Jack) 6.
Page 10: Remote Control
Introduction Remote Control 1. LED Indicator 2. Power On/Off 3. Four Directional WXGA Select Keys 4. Re-Sync 5. Volume +/- 6. Overscan 7. AV mute 8. Video 9. VGA 10. Freeze 11. S-Video 12. HDMI (For WXGA only) 13. Brightness 14.
Page 11: Installation
Installation Connecting the Projector Connect to Computer/Notebook  Due to the VGA-IN / YPbPr / S-VIDEO VIDEO AUDIO-OUT difference in applications RS-232 RCA-L RCA-R HDMI for each country, some regions may have different accessories.  (*) Optional accessory 1....................Power Cord 2...................*DVI/HDMI Cable 3.....................VGA Cable 4....................*RS232 Cable 5..................*Audio Input Cable...
Page 12: Connect To Video Sources
Installation Connect to Video Sources DVD Player, Set-top Box, HDTV receiver S-Video Output Composite Video Output Audio Input VGA-IN / YPbPr / S-VIDEO VIDEO AUDIO-OUT RS-232 RCA-L RCA-R HDMI  Due to the difference in applications 1....................Power Cord for each 2....................*HDMI Cable country, some 3..........*15-Pin to 3 RCA Component/HDTV Adaptor regions may...
Page 13: Powering On/Off The Projector
Installation Powering On/Off the Projector Powering On the Projector 1. Remove the lens cap.  2. Securely connect the power cord and signal cable. When connected, the ON/STANDBY LED will turn Amber. 3. Turn on the lamp by pressing “ ” button either on the top of the projector or on the remote.
Page 14: Powering Off The Projector
Installation Powering Off the Projector 1. Press the “ ” button on the remote control or on the control panel to turn off the projector. The following message will be displayed on the screen. Press the “ ” button again to confirm otherwise the message will disappear after 15 seconds.
Page 15: Adjusting The Projected Image
Installation Adjusting the Projected Image Adjusting the Projector’s Height The projector is equipped with elevator feet for adjusting the image height. 1. Locate the adjustable foot you wish to modify on the underside of the projector. 2. Rotate the adjustable rings clockwise/anticlockwise to lower or raise the projector.
Page 16: Adjusting The Projector's Focus
Installation Adjusting the Projector’s Focus To focus the image, rotate the focus ring until the image is clear.  SVGA series: The projector will focus at distances from 1.64 to 18.05 feet (0.5 to 5.5 meters).  WXGA series: The projector will focus at distances from 1.64 to 16.40 feet (0.5 to 5.0 meters).
Page 17 Installation Screen 27.1” 54.1” 135.3” 189.5” 243.6” 297.8” (Diagonal) (68.8cm) (137.5cm) (343.8cm) (481.3cm) (618.8cm) (756.3cm) Screen 21.7” x 16.3” 43.3” x 32.5” 108.2” x 81.2” 151.6” x 113.7” 194.9” x 146.2” 238.2” x 178.7” Size (WxH) 55.0 x 41.3cm 110.0 x 82.5cm 275.0 x 206.3cm 385.0 x 288.8cm 495.0 x 371.3cm...
Page 18: User Controls
User Controls Control Panel & Remote Control Control Panel Using the Control Panel Refer to the “Power On/Off the Projector” section on POWER pages 13-14. Automatically synchronize the projector to the input RE-SYNC source. Enter Confirm your item selection. SOURCE Press “SOURCE”...
Page 19: Remote Control
User Controls Remote Control Using the Remote Control WXGA Refer to the “Power On/Off the Projector” Power section on pages 13-14. Adjust the contrast of the image. (For SVGA Contrast only) L Button No function. R Button No function. Page + No function.
Page 20: Using The Remote Control
User Controls Using the Remote Control Press “HDMI” to choose HDMI source. (For HDMI WXGA only) Press “Freeze” to pause the screen image. Freeze Press this button again to unlock. Momentarily turns off/on the audio and AV mute video. S-Video S-Video Press “...
Page 21: On-Screen Display Menus
User Controls On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. How to operate To open the OSD menu, press “Menu” on the Remote Control or Projector Keypad.
Page 22: Menu Tree
User Controls Menu Tree Settings Main Menu Sub Menu IMAGE Display Mode Cinema / Bright / Presentation / Game / Blackboard / Classroom / User / 3D Contrast Brightness Color Tint Sharpness Advanced BrilliantColor™ 0-10 Gamma Film / Video / Graphics / Standard Color Temp.
Page 23 User Controls Settings Main Menu Sub Menu OPTIONS Source Lock On / Off High Altitude On / Off Information Hide On / Off Keypad Lock On / Off Background Color Black / Red / Blue / Green / White Test Pattern None / Grid / White Pattern Advanced Direct Power On...
Page 24: Image
User Controls IMAGE Display Mode There are many factory presets optimized for various types of images. Presentation: Good color and brightness from PC input.  Bright: Maximum brightness from PC input.  Cinema: For home theater.  Game: For game mode. ...
Page 25 User Controls Color Adjust a video image from black and white to fully saturated color. Press the to decrease the amount of saturation in the image.  Press the to increase the amount of saturation in the image.  Tint Adjust the color balance of red and green.
Page 26: Image | Advanced
User Controls IMAGE | Advanced BrilliantColor™ This adjustable item utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while provid- ing true, more vibrant colors in picture. The range is from “0” to “10”. If you prefer a stronger enhanced image, adjust toward the maximum setting.
Page 27 User Controls Color Setting Press into the next menu as below and then use select item. Use to select Red, Green, or Blue for brightness (Gain) and contrast (Bias). Color Space Select an appropriate color matrix type from AUTO, RGB or YUV. Input Source Use this option to enable / disable input sources.
Page 28: Display
User Controls DISPLAY Format Use this function to choose your desired aspect ratio. SVGA 4:3: This format is for 4×3 input sources.  16:9-I: This format is for 16×9 input sources, like HDTV and  DVD enhanced for Wide screen TV. (576i/p) 16:9-II: This format is for 16×9 input sources, like HDTV and ...
Page 29 User Controls WXGA 4:3: This format is for 4×3 input sources.  16:9: This format is for 16×9 input sources, like HDTV and DVD  enhanced for Wide screen TV. 16:10: This format is for 16×10 input sources, like widescreen ...
Page 30: Display | 3D
User Controls DISPLAY | 3D 3D Mode Off: Select “Off” to turn 3D settings off for 3D images.  DLP Link: Select “DLP Link” to use optimized settings for DLP  Link 3D images. “ ” options may  vary according to IR: Select “IR”...
Page 31: Setup
User Controls SETUP Language Choose the multilingual OSD menu. Press into the sub menu and then use the key to select your preferred language. Press “Enter” to finalize the selection. Rear-Desktop and  Rear-Ceiling are to be used with a translucent screen.
Page 32: Menu Location
User Controls Rear-Ceiling  When selected, the image will appear reversed in upside down position. Menu Location “Wireless” is only  Choose the menu location on the display screen. functional with VGA connector Projector ID Warning: Wired ID definition can be set up by menu (range 0~99), and allow user VGA will not func- control an individual projector by RS232.
Page 33: Setup | Security
User Controls SETUP | Security Security On: Choose “On” to use security verification when the turning  on the projector. Off: Choose “Off” to be able to switch on the projector without  password verification. Security Timer Can be select the time (Month/Day/Hour) function to set the number of hours the projector can be used.
Page 34 User Controls If the incorrect password is entered 3 times, the projector will  automatically shut down. If you have forgotten your password, please contact your local  office for support. English...
Page 35: Setup | Signal
User Controls SETUP | Signal “Signal” is only  supported in Analog VGA (RGB) signal. Automatic Automatically selects the singal. If you use this function, the Phase, frequency items are grayed out, and if Signal is not auto- matic, the phase, frequency items will appear for user to manually tune and saved in settings after that for next time projector turns off and on again.
Page 36: Options
User Controls OPTIONS Source Lock On: The projector will only search current input connection.  Off: The projector will search for other signals if the current  input signal is lost. High Altitude When “On” is selected, the fans will spin faster. This feature is useful in high altitude areas where the air is thin.
Page 37: Options | Advanced
User Controls OPTIONS | Advanced Direct Power On Choose “On” to activate Direct Power mode. The projector will automatically power on when AC power is supplied, without pressing the “ ” key on the projector control panel or on the remote control.
Page 38: Options | Lamp Settings
User Controls OPTIONS | Lamp Settings Lamp Hours Display the projection time. Lamp Reminder Choose this function to show or to hide the warning message when the changing lamp message is displayed. The message will appear 30 hours before suggested replacement of lamp.
Page 39: Appendices
Appendices Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. No image appears on-screen Ensure all the cables and power connections are correctly and ...
Page 40 Appendices 7. Click on “Show all devices”. Next, select “Standard monitor types” under the SP box; choose the resolution mode you need under the “Models” box. 8. Verify that the resolution setting of the monitor display is lower than or equal to UXGA (1600 × 1200). If you are using a Notebook: ...
Page 41 Appendices Image is out of focus Make sure the lens cap is removed.  Adjust the Focus Ring on the projector lens.  Make sure the projection screen is between the required distance.  See page 16. The image is stretched when displaying 16:9 DVD title When you play anamorphic DVD or 16:9 DVD, the projector will ...
Page 42 Appendices The projector stops responding to all controls If possible, turn off the projector, then unplug the power cord and  wait at least 60 seconds before reconnecting power. Check that “Keypad Lock” is not activated by trying to control the ...
Page 43 Appendices On Screen Messages Temperature warning:  Fan failed:  Lamp warming:  Out of display range:  If the remote control does not work Check the operating angle of the remote control is within ±15°  both horizontally and vertically of one of the IR receivers on the projector.
Page 44: Replacing The Lamp
Appendices Replacing the lamp The projector automatically detects the lamp life. When the lamp life is nearing the end of use, you will receive a warning message. When you see this message, please contact your local reseller or service center to change the lamp as soon as possible. Make sure the projector has been cooled down for at least 30 minutes before changing the lamp.
Page 45: Lamp Replacement Procedure
Appendices The screws on the  lamp cover and the lamp cannot be removed. The projector  cannot be turned on if the lamp cover has not been placed back on the projector. Do not touch the  glass area of the lamp.
Page 46: Compatibility Modes
Appendices Compatibility Modes Computer Compatibility  V-Sync (Hz) H-Sync (KHz) Mode Resolution Anglog Digital Anglog Digital 640 × 350 31.50 31.50 640 × 350 37.90 37.90 640 × 400 37.90 37.90 640 × 480 31.50 31.50 640 × 480 640 × 480 37.90 37.90 640 ×...
Page 47: Video Compatibility
Appendices Computer Compatibility  Mode Resolution V-Sync (Hz) H-Sync (KHz) MAC LC 13” 640 × 480 66.66 34.98 MAC II 13” 640 × 480 66.68 35.00 MAC 16” 832 × 624 74.55 49.73 MAC 19” 1024 × 768 60.24 1152 × 870 75.06 68.68 MAC G4...
Page 48: Rs232 Commands And Protocol Function List
Appendices RS232 Commands and Protocol Function List RS232 Pin Assignments Spec. Pin no. (from projector side) English...
Page 49: Rs232 Protocol Function List
Data Bits: 8 Parity: None Stop Bits: 1 1. There is a <CR> after Flow Control : None Optoma ES523ST/EW533ST RS232 Command Table all ASCII commands. --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- UART16550 FIFO: Disable Baud Rate : 9600 Note : There is a <CR> after all ASCII commands 2.
Page 50 Appendices ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ---------------------------------- ~XX60 1 7E 30 30 36 30 20 31 0D Format ~XX60 2 7E 30 30 36 30 20 32 0D 16:9-l (for ES523ST) / 16:9 (for EW533ST) ~XX60 3 7E 30 30 36 30 20 33 0D 16:9-ll (for ES523ST) / 16:10 (for EW533ST) ~XX60 6 7E 30 30 36 30 20 36 0D...
Page 51 Appendices --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- ~XX105 1 7E 30 30 31 30 35 20 31 0D Advanced Direct Power On ~XX105 0 7E 30 30 31 30 35 20 30 0D Off (0/2 for backward compatible) ~XX106 n 7E 30 30 31 30 36 20 a 0D Auto Power Off (min) n = 0 (a=30) ~ 180 (a=31 38 30) step:5 ~XX107 n...
Page 52: Ceiling Mount Installation
Ceiling Mount Installation 1. To prevent damage to your projector, please use the Optoma ceiling mount. 2. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector...
Page 53: Optoma Global Offices
Appendices Optoma Global Offices For service or support please contact your local office. 715 Sycamore Drive 408-383-3700 Milpitas, CA 95035, USA 408-383-3702 www.optomausa.com services@optoma.com Canada 5630 Kennedy Road, Mississauga, 905-361-2582 ON, L4Z 2A9, Canada 905-361-2581 www.optoma.ca canadacsragent@optoma.com Europe 42 Caxton Way, The Watford Business Park...
Page 54 Appendices Latin America 715 Sycamore Drive 408-383-3700 Milpitas, CA 95035, USA 408-383-3702 www.optoma.com.br www.optoma.com.mx Korea WOOMI TECH.CO.,LTD. 4F,Minu Bldg.33-14, Kangnam-Ku, +82+2+34430004 seoul,135-815, KOREA +82+2+34430005 Japan 東京都足立区綾瀬3-25-18 info@osscreen.com 株式会社オーエスエム 0120-46-5040 www.os-worldwide.com サポートセンター: Taiwan 5F., No. 108, Minchiuan Rd. +886-2-2218-2360 Shindian City, +886-2-2218-2313 Taipei Taiwan 231, R.O.C.
Page 55: Fcc Notice
Appendices Regulation & Safety Notices This appendix lists the general notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules.
Page 56: Operation Conditions
Appendices Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation.
