- Page 1 MIO /ARTE /RING/ TREND Wall Fan Ventilator Axial de Perete Wand Axialventilator Ventilador Axial Muro Aspiratore Elicoidale da Parete Ventilateur Hélicoïde Murale Instruction manual EN RO GE SP IT FR...
-
Page 2: Table Of Contents
PRECAUTIONS MODELS INSTALLATION INSTRUCTIONS ELECTRIC CONNECTION MAINTENANCE & SERVICE... -
Page 3: Precautions
Declaration of conformity Manufacturer: , Ilfov, Intax Trading SRL - 14B Ion Creanga Str., 075100, Otopeni Romania. This product complies with the following European directives: 2014/30/EU (EMV) 2014/35/EU (LVD) 2011/65/EU (RoHS) Please read this manual carefully to operate this fan PRECAUTIONS 1. - Page 4 necessary, contact only technical service center approved by the manufactured and ask for original spares. No observance of the above could put the safety of thr appliance at risk. 6. When the appliance is out of use, remove the power lead. Moreover, make potentially dangerous parts harmless,especially with regard to Children who might play with appliance when it is not in use.
- Page 5 * Store the appliance out of the reach of children and infirm persons if you decide to disconnect it from the power supply and no longer use it. *Do not operate the appliance in the presence of inflammable vapors (alcohol, insecticides, petrol, etc.). this symbol indicates precautions that must be taken to avoid damaging the appliance .
- Page 6 The gap between the switch contacts must be no less than 3 mm. * Switch off the appliance at the installations main switch: a) if the appliance does not function correctly; b) before cleaning the outside of the appliance ; c) if the appliance is not to be used for any length of time.
-
Page 7: Models
3. The shutter will be opened after 40 second when the Fan on. 4. The shutter will be closed after 40 second when the Fan off. MODELS A. (S) Standard Model This model is operated by switching it on by means of the power switch. B. -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS Caution: make sure power is switched off at service panel before starting installation. note :the location of installation must be near a socket outlet. a licensed electrician will be required to install the socket outlet. WALL INSTALLATION 1. Ensure to choose right voltage shown in the label before connecting with power source. 2. - Page 10 GLASS-WINDOW INSTALLATION 1. Before commencing any cutting, check in the windows that there is no obstruction such as windows frames, or joints and that there is sufficient tight clearance for the housing. 2. Position the fan against the window glass and mark then to cut to suit. 3.
-
Page 11: Ceiling Installation
CEILING INSTALLATION 1. Position a suitable location for the fan and cut a flush hole in ceiling to size. 2. Remove the front cover of fan, bring the cable to the unit via a double pole switch with a minimum 3mm separate on all poles. -
Page 12: Electric Connection
WIRING 1. The fans are double insulated and do not need earth wire. 2. For partition fans, precautions must be taken to avoid any back-flow of gases into the room from open flue gas fire or other appliances. 3. L – connecting to thr Live. N –... -
Page 13: Wiring Diagram
WIRING DIAGRAM... - Page 14 C). WITH LED LIGHT WIRING CONNECTION Exhaust fan Internal wiring Blue Black Brown Transformer Blue Black White INFO for C). WITH LED LIGHT WIRING CONNECTION - When power cable is connected to an L1, the fan turn on . - When power cable is connected to an L2, the LED turn on...
-
Page 15: Maintenance & Service
MAINTENANCE & SERVICE Before carrying out any maintenance, ensure the power is switched OFF from the mains power supply. 1. Wipe down the fascia and grilles with a wet soapy cloth only. Do not allow water to contact electrical part, such as motor.
