 Thank you for choosing these Air Conditioners, please read this owner's manual carefully
before operation and retain it for future reference.
 Fujidenzo reserves the right to interpret this manual which will be subject to any change due to
product improvement without further notice.
Premium DC Inverter U-match Series
Floor Ceiling Type Unit
Indoor Unit
Outdoor Unit
FIS180G IN
FIO180G OD
FIS240G IN
FIO240G OD
FIS360G IN
FIO360G OD
FIS480G IN
FIO480G OD
FIS600G IN
FIO600G OD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U-match FIS180G IN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FUJIDENZO U-match FIS180G IN

Summary of Contents for FUJIDENZO U-match FIS180G IN

  • Page 1  Thank you for choosing these Air Conditioners, please read this owner’s manual carefully before operation and retain it for future reference.  Fujidenzo reserves the right to interpret this manual which will be subject to any change due to product improvement without further notice.

  • Page 2: Table Of Contents

    Contents 1 Safety Precautions ..................1 2 Outline of the Unit and Main Parts ............. 2 3 Preparative for Installation ................. 3 3.1 Standard Accessory Parts................3 3.2 Selection of the Installation Location ............4 3.3 Connection Pipe Requirement ..............6 3.4 Electrical Requirement .................

  • Page 3: Safety Precautions

    Premium DC Inverter Series Floor Ceiling Type Unit 1 Safety Precautions This mark indicates procedures which, if improperly performed, might lead to the death or serious injury of the user. WARNING! This mark indicates procedures which, if improperly performed, might possibly result in personal harm to the user, or damage to property.

  • Page 4: Outline Of The Unit And Main Parts

    Premium DC Inverter Series Floor Ceiling Type Unit 2 Outline of the Unit and Main Parts Air inlet Air outlet Fig. 2.1 Notes: ①. The connection pipe and duct for this unit should be prepared by the user. ②. This unit is standard equipped with the rectangular duct.

  • Page 5: Preparative For Installation

    Premium DC Inverter Series Floor Ceiling Type Unit 3 Preparative for Installation 3.1 Standard Accessory Parts The standard accessory parts listed below are furnished and should be used as required. Table 3.1 Indoor Unit Accessories Name Appearance Q'ty Usage To fix the hook on the Nut with Washer cabinet of the unit.

  • Page 6: Selection Of The Installation Location

    Premium DC Inverter Series Floor Ceiling Type Unit 3.2 Selection of the Installation Location WARNING! The unit must be installed where strong enough to withstand the weight of the unit and fixed securely, otherwise the unit would topple or fall off. CAUTION! Do not install where there is a danger of combustible gas leakage.

  • Page 7: Outdoor Unit

    Premium DC Inverter Series Floor Ceiling Type Unit (4). Install the unit where the drain pipe can be easily installed. (5). The space from the unit to the ceiling should be kept as much as possible so as for more convenient service. 3.2.2 Outdoor Unit WARNING! Install the unit where it will not be tilted by more than 5°.

  • Page 8: Connection Pipe Requirement

    Premium DC Inverter Series Floor Ceiling Type Unit 3.3 Connection Pipe Requirement CAUTION! The maximum length of the connection pipe is listed in the Table below. Do not place the units between which the distance exceeds the maximum length of the connection pipe. Table 3.3 Size of Fitting Max.
  • Page 9 Premium DC Inverter Series Floor Ceiling Type Unit Table 3.5 Power Capability of Air Minimum Sectional Area Model Supply Switch(A) Of Earth Wire (mm FIO180G OD FIO240G OD FIO360G OD 220-240V~ 60Hz FIO480G OD FIO600G OD Notes: ①. The fuse is located on the main board. ②.

  • Page 10: Installation Of The Unit

    Premium DC Inverter Series Floor Ceiling Type Unit 4 Installation of the Unit 4.1 Installation of the Indoor Unit 4.1.1 Indoor unit dimension WARNING ! Install the indoor unit in a location which can withstand a load of at least five times the weight of the ①.

  • Page 11: Indoor Unit Installation

    Premium DC Inverter Series Floor Ceiling Type Unit (3). Release the center hook and remove the front panel. (4). Release the claws in the 2 or 3 places indicated and remove the electric component cover. 4.1.3 Indoor Unit Installation (1). Determine the location of the hanger through the paper template, and then remove the paper template.
  • Page 12 Premium DC Inverter Series Floor Ceiling Type Unit ◆Ceiling type Fig. 4.4 (6). Adjust the height of the unit to make the drain pipe slant slightly downward so that the drainage will become much smoother. 4.1.4 Leveling The water level test must be done after installing the indoor unit to make the unit is horizontal, as shown below.

  • Page 13: Installation Of The Outdoor Unit

    Premium DC Inverter Series Floor Ceiling Type Unit 4.2 Installation of the Outdoor Unit WARNING Install the unit where it will not be tilted by more than 5°. ①. During installation, if the outdoor unit has to be exposed to strong wind, it must be fixed securely. ②.

  • Page 14: Installation Of The Connection Pipe

    Premium DC Inverter Series Floor Ceiling Type Unit (3). Installation Method: Insert the pipe joint into the hole φ25 located at the base plate of the unit and then connect the drain pipe to the pipe joint. Fig. 4.7 4.3 Installation of the Connection Pipe 4.3.1 Flare Processing (1).
  • Page 15 Premium DC Inverter Series Floor Ceiling Type Unit (3). When pipes are repeatedly bent or stretched, the material will harden, making it difficult to bend or stretch them any more. Do not bend or stretch the pipes more than three times. (4).
  • Page 16 Premium DC Inverter Series Floor Ceiling Type Unit Fig. 4.11 Fig. 4.12 Table 4.3 Flare nut tightening torque Pipe Diameter Tightening Torque 1/4 Inch） 15-30 (N·m) 3/8 Inch） 35-40 (N·m) 5/8 Inch） 60-65 (N·m) 1/2 Inch） 45-50 (N·m) 3/4 Inch） 70-75 (N·m) 7/8 Inch）...
  • Page 17 Premium DC Inverter Series Floor Ceiling Type Unit 4.3.5 Checking the Pipe Connections for Gas Leaking For both indoor and outdoor unit side, check the joints for gas leaking by the use of a gas leakage detector without fail when the pipes are connected. 4.3.6 Heat Insulation on the Pipe Joints (Indoor Side Only) Stick coupler heat insulation (large and small) to the place where connecting pipes.

  • Page 18: Vacuum And Gas Leakage Inspection

    Premium DC Inverter Series Floor Ceiling Type Unit (2). If the outdoor unit is installed higher than the indoor unit 1). Taping should be done from lower to the upper part. 2). All pipes are bound and taped together and also should be trapped to prevent water from returning to the room (See Fig.

  • Page 19: Additional Charge

    Premium DC Inverter Series Floor Ceiling Type Unit pipe to balance the pressure inside and outside of the connection pipe, so that air will not come into the connection pipe when removing the hose. Note that the gas and liquid valve can be opened fully only after the manifold valve assembly is removed.

  • Page 20: Installation Of The Drain Pipe

    Premium DC Inverter Series Floor Ceiling Type Unit When the height difference between the indoor unit and outdoor unit is larger than 10 meters, an oil bend should be employed for every 6 meters. Fig. 4.18 4.5 Installation of the Drain Pipe 4.5.1 Precautions When Doing the Piping Work (1).

  • Page 21: Installing The Drain Pipes

    Premium DC Inverter Series Floor Ceiling Type Unit 4.5.2 Installing the Drain Pipes (1). For determining the position of the drain hose, perform the following procedures. (2). Insert the drain pipe to the drain outlet of the unit and then tighten the clamp securely with tape.

  • Page 22: Electrical Wiring

    Premium DC Inverter Series Floor Ceiling Type Unit 4.5.4 Testing of Drain Piping (1). After piping work is finished, check if drainage flows smoothly. (2). As shown in the Figure, pour water into the drain pan from the right side to check that water flows smoothly from the drain hose.
  • Page 23 Premium DC Inverter Series Floor Ceiling Type Unit 4.6.2 Electrical Wiring (1). For solid core wiring (Fig. 4.26) 1). Cut the wire end with a wire cutter or wire-cutting pliers, then strip the insulation about 25 mm (15/16") . 2). Using a screwdriver, remove the terminal screw(s) on the terminal board. 3).
  • Page 24 Premium DC Inverter Series Floor Ceiling Type Unit WARNING! Before starting work, check that power is not being supplied to the indoor unit and outdoor unit. ①. Match the terminal block numbers and connection cord colors with those of the indoor unit side. ②.
  • Page 25 Premium DC Inverter Series Floor Ceiling Type Unit communication cord and the power cable into the terminal board. Fig. 4.30 CAUTION! The power cord and the wire of the fresh air valve are high-voltage, while the communication cord ①. and connection wire of the wired controller are low-voltage. They should run separately against electromagnetic interference.

  • Page 26: Installation Of Controllers

    Premium DC Inverter Series Floor Ceiling Type Unit Remove the big handle (18~36K) /front board(48~60K) of the outdoor unit and insert the end of the communication cord and the power cable into the terminal board. Single phase: Fig. 4.31 5 Installation of Controllers Refer to the Installation Manual of the controller for more details.
  • Page 27 Premium DC Inverter Series Floor Ceiling Type Unit Outdoor ambient temperature sensor error Discharge temperature sensor error Temperature sensor error of wired controller Outdoor memory chip error Electric box sensor error Compressor overload protection Overloading IPM protection DC fan motor error Drive desynchronizing protection Pfc protection Activation failure...

  • Page 28: Working Temperature Range

    Premium DC Inverter Series Floor Ceiling Type Unit Type Unit. Fig. 6.1 States of the Indicating Lamps: 1). Indicating Lamp of “POWER”: The indicating lamp will shine when power on, while it will go out when power off. 2). Indicating Lamp of “COOL” : The indicating lamp will shine when “COOL”...

  • Page 29: Troubleshooting And Maintenance

    Fujidenzo. Only ask professional serviceman to check and repair the unit.

  • Page 30: Routine Maintenance

    Premium DC Inverter Series Floor Ceiling Type Unit 7.2 Routine Maintenance WARNING! Do turn off the unit and cut off the main power supply when cleaning the air conditioner, ①. otherwise electric shock may happen. Do not make the air conditioner wet or electric shock may be lead; Ensure that the air ②.
  • Page 31 Premium DC Inverter Series Floor Ceiling Type Unit 3.Disassemble the left and right side board After the grille is removed, use a screwdriver ①. to remove the screws shown on the picture. Push the side plate as per the arrowed ②.
