The Source for Pedicure Spas
J&A USA INC.
335 CROOKED HILL RD.
BRENTWOOD, NY. 11717
1.631.243.3336
WWW.JAUSAINC.COM
USER'S MANUAL
Copyright 2010 by J&A USA Inc.
LENOX LX
Please read user's Manual thoroughly
before using pedicure spa
SERVICE & ORDER PARTS
1.631.243.5300
WWW.PEDISPAFIX.COM
Printed in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LENOX LX and is the answer not in the manual?

Questions and answers

Related Manuals for j&a LENOX LX

Summary of Contents for j&a LENOX LX

  • Page 1 Copyright 2010 by J&A USA Inc. Printed in USA The Source for Pedicure Spas USER’S MANUAL LENOX LX Please read user’s Manual thoroughly before using pedicure spa J&A USA INC. SERVICE & ORDER PARTS 335 CROOKED HILL RD. 1.631.243.5300 BRENTWOOD, NY. 11717 WWW.PEDISPAFIX.COM...

  • Page 2: Table Of Contents

    Table of contents Warranty form Service inquiry form Introduction & Safety Important Consideration Identify parts & Description Specification Dimension Drain Connection Rough end (Plumbing) 11--15 Magna-Jet Pipeless System Power Discharge Pump Maintenance (Massage Mechanism) Assembly Instruction (Chair) Disinfecting Pedicure Spa Trouble Shooting User’s Recommendation UL Certification...

  • Page 3: Limited Warranty Registration Form

    Limited Warranty Registration Form IMPORTANT To validate the limited warranty, The Limited Warranty Registration Form MUST be filled out completely and return to J&A USA within 30 days of original purchased date. This Limited Warranty is valid if J&A USA received registration form. Serial No.: Area Code: Phone :...

  • Page 4: Service Inquiry Form

    After Service Inquiry Form Please use inquiry form as all service request (Fill out all blanks and Fax or email us, our A/S Dept. will call you promptly) Distributor Name:____________________________________________ Date_________________________ Phone Number:____________________________________________ Contact Person:____________________________________________ Salon Name:____________________________________________ Address:_______________________________________________________________________________________ _______________________________________________________________________________________ Phone Number:____________________________________ Alternate Phone Number:___________________________ Contact Person:____________________________________ Best time to reach: ________________________________ Serial Number: ____________________________________ Brief Description of Problem:_____________________________________________________________________________...
  • Page 5 Lenox Lenox...

  • Page 6: Important Consideration

    Important Considerations Electrical Service 110V, 60Hz, 15Amp GFCI protected grounded circuit MUST be used to supply power each individual pedicure spa. And the main circuit breaker MUST be at 25Amp. For maximum of two units per each electrical outlet. Water Supply All plumbing connections must conform to local codes.
  • Page 7 IDENTIFICATION Pillow POWER KNEADING TIME Replaceable Backrest SPEED TAPPING RANGE COMBINATION WIDTH VIBRATION WHEEL ADJUST UP/DOWN AUTO MASSAGE Easy access Up & Down INCLINE RECLINE Armrest FORWARD BACKWARD Folding Manicure Tray J & A Combine functional Remote Control Magnetic Pipeless whirlpool Pump Glass Bowl Individual height Adjust Footrest...

  • Page 8: Specification

    Specification Dimension & Weight Lenox Pedicure Spa 67L x 37W x 40H 285lbs (Shipping) Stool 20.25L x 27.25W x 17H 20lbs Capacity of Tub Lenox Switch On/Off Air Activated Switch Power Source Dedicated 15 Amp. GFCI protected Ground outlet Magna-Jet Pipelss 115 Vac.

  • Page 9: Dimension

    Dimension 45 1/4” 28 1/4” 21 1/4” 3 ½” 3/4” 8 1/2” 13 ½” 27” 24” 17 1/4” 26 1/4” 41” 20 3/4” 16 1/4” 54” 13”...

  • Page 10: Drain Connection

    Drain Connection Wall Drain Rear 3 ½” 3/4” 13” 15” 13 ½” 27” Discharge Pump ( An Option at Request) (See Detail in Power Drain Pump)
  • Page 11 15”...
  • Page 12 When using electrical equipment, Basic safety precautions must be followed to reduce the risk of fire, electrical shock, and injury to Persons. 1. Read and follow all instructions before using the equipment. 2. Keep electrical cord out of heavy traffic area. To avoid fire hazard NEVER place electrical cord under the rug, near heat Generating devices.

  • Page 13: How To Use Magnetic Jet

    How to USE Magnetic jet ! WARNING: DO NOT RUN DRY, BASIN MUST FILLED WITH WATER TO LEVEL INDICATOR. CAUTION: MAGNETIC JET COVER ASSEMBLY MUST ALIGN WITH DISCHARGE PORT POSITIONED AT 3/9 O’CLOCK. WHEN READY TO USE, MAKE SURE JET COVER IS POSITIONED AT 3 /9 OCLOCK FOR PROPER WHIRLPOOL ACTION IN THE BASIN.

  • Page 14: Safety Instructions

    Ultra jet Whirlpool Motor Safety Instructions When using electrical equipment, basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons, including the following: 1. Read and follow all instructions before using the equipment. 2.
  • Page 15 L E N O X Discharge Pump ( Optional): Up to 3ft @ +/- 39 sec. with 1/2” Connection to main drain DRAIN OUTLET MUST BE 3/4” FOR EFFICIENT DRAINAGE. 3/4” Brass Swing Check Valve PLUMBER MUST BE UTILIZED TO INSTALL CHECK VALVE (SMALL Rubber Coupling) Air Check Valve...
  • Page 16 L E N O X Remote Controller Functions POWER On / Off INCLINE BACKWARD Press down to move chair Press to hold to move To desirable angle. chair to desirable position FORWARD RECLINE Press to hold to move Press down to move chair chair to desirable position To desirable angle.
  • Page 17 2nd Remote ControlConnection to Main PCB Board Holders Travel Sensor Remote Control D/C Motors 2nd Remote to PCB Red (Recliner) White (Slider) Power Vibration(Grn/Yel) PCB Fuse Female Receptacle (From PCB) (Male Receptacle) Connection 2nd Remote Control * Installed in front of Pedicure spa * Independent Operation from Primary (hand held) Remote AUTO * Press button for desire chair position...
  • Page 18 Massage Mechanism (Lenox LX) Massage Mechanism Exposed View Chair Main Frame Massage Mechanism Frame Mechanism Limited frame Bar Phillip Screws Kneading Belt Belt Pulley DC Motor (Kneading) Massage Arm extension Mechanism Track Guide Roller Tapping Belt Massage Mechanism Up and Down Gear Box...
  • Page 19 Placing Backrest in Correct position Detachment of Backrest * Pull latch lever upward to release from recliner piston. * As Arrow indicates, bring backrest to fold onto the seat. * Disconnect all cables ( recliner, slider) Pull latch upward to release Attachment of Backrest * On the lower portion of both side of the backrest, there are pivots (Fig.1) * Align both pivots correctly so they rest perfectly onto the “U”pivot frame (Fig.2)

  • Page 20: Power Discharge Pump

    Troubleshooting Guide If there is still a problem after trying the solutions given in the troubleshooting guide, stop using the product immediately so as to prevent accident or injury and unplug the product from the wall outlet. For technical service, please contact J&A technical support at 631-243-5300 with any issue that cannot be resolved using troubleshooting guide.
  • Page 22 Reset the main power switch located at the rear of the chair to OFF and back ON after about Massage stops in the middle of 5 second. the program 1- if the chair return to normal, No further action is required. 2- if the chair does not return to normal, stop using the chair and unplug it from the wall outlet.
  • Page 25 Back Flow Protection Device (Dual Check Valve) May.1.2014 In accordance with applicable Local or State regulations, J&A USA Inc., The manufacturer of the pedicure whirlpool spa certifies that the following models are equipped with factory installed Dual Check Valve back flow preventer: ** Lenox Series ** Cleo Series ** Episode Series...

  • Page 26: Warranty

    Glass bowl Care and Cleaning CARE AND CLEANING Clean the surface of your JSG Oceana glass product with mild soap and warm water. Wipe the entire surface completely dry with a clean, soft cloth. MANUFACTURER’S RECOMMENDED DRAIN INSTALLATION Drain installation requirements will vary by supplier basin and unit. Manufacturer’s drain installation instructions suggest to apply plumber’s putty under rim of drain and hand-tighten drain only.
  • Page 27 Limited Warranty Pedicure Spa IMPORTANT To validate the limited warranty, The Limited Warranty Registration Form MUST be filled out completely and return to J&A USA within 30 days of original purchased date. This Limited Warranty is valid if J&A USA received registration form. J&A USA Inc.
  • Page 28 The Source for Pedicure Spas Copyright 2010 by J&A USA Inc. Printed in USA J&A USA, INC 335 CROOKED HILL RD., BRENTWOOD, NY 11717 631.243.3336 - WWW.JAUSAINC.COM SCAN ME www.jausainc.com SERVICE & ORDER PARTS 631.243.5300 - WWW.PEDISPAFIX.COM SCAN ME www.pedispafix.com...
