Summary of Contents for j&a Lenox GX
- Page 1 L E N O X WHIRLPOOL PEDICURE SPA Owner’s Manual Please read user’s Manual thoroughly before using pedicure spa Pedicure Spa Copyright 2010 by J&A USA Inc. Printed in USA...
- Page 2 Table of Contents Table of Contents Introduction & Safety Identify Parts & Description Consideration Specification Dimension Drainage Connection Installation Summary L E N O X Maintenance ( Dura-Jet) Maintenance (Magna-Jet (OPTIONAL) Discharge Pump Chair / Backrest attachment Remote Control Function Disinfecting Pedicure spa User Recomendation UL Certificate...
-
Page 3: Important Requirements
Thank you for choosing GX series , This finest Whirlpool Pedicure Spa has been develop and Manufactured by LEONX J&A USA Inc., to bring quality and exquisitely balanced design yet afford-ability and dependability when properly use. Please read this entire manual thoroughly before installation and use PLEASE TAKE TIME TO READ THIS MANUAL THOROUGHLY BEFORE USE. - Page 4 L E N O X Identification Comfort Pillow Back Rest Cover BackRest Padding Manicure Tray W/Cup Holder Easy Access Up & down Armrest Dual Functional Shower Sprayer Remote Control Three Stage Adjustable Footrest Drain Handle Tampered Glass Bowl Non Slip Bumpon Basin Seven Sequential Light Standard Pipless Motor...
-
Page 5: Important Considerations
Important Considerations Electrical Service 110V, 60Hz, 15Amp GFCI protected grounded circuit MUST be used to supply power each individual pedicure spa. And the main circuit breaker MUST be at 25Amp. For maximum of two units per each electrical outlet. Water Supply All plumbing connections must conform to local codes. -
Page 6: Specification
L E N O X Specification Specification Dimension & Weight (Sipping) Pedicure Spa & Massage Chair 67L x 37W x 40H 285 lbs Stool 20.25L x 8.5H x 20W 19 lbs Dimension & Weight (Net) Pedicure Spa & Massage Chair 4L x 27W x 53H 230 lbs Capacity of Tub... - Page 7 Front View L E N O X 7 3/4” 29 3/4” Dimension 21” Rear View 16 ½” 3” 5 ½” 3 ½” 14 ½” 10” 24 ½ ” Wall 27 ½” 39 3/4” 6 3/4” 4 ½” 31 3/4” 14 3/4” 16 1/4”...
- Page 8 L E N O X DRAIN Basement Connection (NOT recommended on floor drain) Rear View 6” 16 ½” 15 ½” 3” 5 ½” 3 ½” 14 ½” 10” 24 ½ ” Hot and Cold Water Inlet : 1/2” Drain: 1 1/2” PVC Pipe Outlet Wall drain Power Drain (See detailed power drain pump)
-
Page 9: Installation Specifications Summary
Installation Specifications Summary Warning: Failure to comply with federal, state or local codes and ordinances will result in warranty being null and void. As stated, the pedicure spa installation must comply with all plumbing and electrical codes. A licensed plumber and licensed electrician must complete the applicable connections of the pedicure spa. -
Page 10: Safety Instructions
Dura-Jet III Safety Instructions When using electrical equipment, basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons, including the following: 1. Read and follow all instructions before using the equipment. 2. - Page 11 When using electrical equipment, Basic safety precautions must be followed to reduce the risk of fire, electrical shock, and injury to Persons. 1. Read and follow all instructions before using the equipment. 2. Keep electrical cord out of heavy traffic area. To avoid fire hazard NEVER place electrical cord under the rug, near heat Generating devices.
- Page 12 How to USE Magnetic jet ! WARNING: DO NOT RUN DRY, BASIN MUST FILLED WITH WATER TO LEVEL INDICATOR. CAUTION: MAGNETIC JET COVER ASSEMBLY MUST ALIGN WITH DISCHARGE PORT POSITIONED AT 3/9 O’CLOCK. WHEN READY TO USE, MAKE SURE JET COVER IS POSITIONED AT 3 /9 OCLOCK FOR PROPER WHIRLPOOL ACTION IN THE BASIN.
-
Page 13: Installation Instruction
L E N O X Discharge Pump ( Optional): Up to 4ft @ +/- 39 sec. with 1/2” Connection to main drain Fastner On/Off Switch ½”Drain Outlet Plumber MUST install Check Valve (SMALL Rubber Coupling) from backflow Air Check Valve 3/4”... - Page 14 NE 560 Massage System D/C Motor (Kneading) FRONT VIEW REAR VIEW Cover Massage Roller Kneading (Gear) Massage Arm extension D/C Motor (Tapping) Belt Main Shaft Serial Number Tapping Limited Switch Kneading Power Transformer Fuse Up & Down Gear Black White Sensor Rotation Counter Sensor Vibration...
- Page 15 Placing Backrest in Correct position L E N O X Detachment of Backrest * Pull latch lever upward to release from recliner piston. * As Arrow indicates, bring backrest to fold onto the seat. * Disconnect all cables ( recliner, slider) Pull latch upward to release Attachment of Backrest * On the lower portion of both side of the backrest, there are pivots (Fig.1)
- Page 16 LENOX REMOTE CONTROL INSTRUCTION KNEADING POWER It has Strong/medium/weak ON/OFF 3 intensity adjustments and the setting intensity is at medium.(5,10,15 Minutes) TIME Manual time setting for TAPPING 5/10/15 minutes It has Strong/medium/weak 3 intensity adjustments and the setting intensity is at medium.(5,10,15.
- Page 17 DISINFECTING YOUR PEDICURE SPA Note: Please be advised that it is responsibility of purchaser/user to adhere strictly to the following procedure. Any non-compliance will be considered negligence of the purchaser/user. The Bureau of barbering and cosmetology requires that salons using whirlpool pedicure spas use the following disinfecting Procedures to ensure proper cleaning and maintenance of the equipment, and to prevent bacterial infection.
- Page 18 USER RECOMMENDATION PLEASE READ THE MANUAL THROUGHLY BEFORE USE TO ENSURE CORRECT OPERATION. THOSE UNDER A DOCTORS CARE OR WHO ARE EXPERIENCING ONE OR MORE OF THE FOLLOWING DONDITIONS SHOULD CONSULT THEIR DOCTOR BEFORE USE. - You are receiving medical treatment or are feeling ill. - Your body shows any cute symptoms.
-
Page 20: Care And Cleaning
Glass bowl Care and Cleaning CARE AND CLEANING Clean the surface of your JSG Oceana glass product with mild soap and warm water. Wipe the entire surface completely dry with a clean, soft cloth. MANUFACTURER’S RECOMMENDED DRAIN INSTALLATION Drain installation requirements will vary by supplier basin and unit. Manufacturer’s drain installation instructions suggest to apply plumber’s putty under rim of drain and hand-tighten drain only. - Page 21 Back Flow Protection Device (Dual Check Valve) May.1.2014 In accordance with applicable Local or State regulations, J&A USA Inc., The manufacturer of the pedicure whirlpool spa certifies that the following models are equipped with factory installed Dual Check Valve back flow preventer: ** Lenox Series ** Cleo Series ** Episode Series...
-
Page 22: Limited Warranty
Limited Warranty Pedicure Spa IMPORTANT To validate the limited warranty, The Limited Warranty Registration Form MUST be filled out completely and return to J&A USA within 30 days of original purchased date. This Limited Warranty is valid if J&A USA received registration form. J&A USA Inc. -
Page 23: Limited Warranty Registration Form
Limited Warranty Registration Form IMPORTANT To validate the limited warranty, The Limited Warranty Registration Form MUST be filled out completely and return to J&A USA within 30 days of original purchased date. This Limited Warranty is valid if J&A USA received registration form. Serial No.: Area Code: Phone :...
